I.D. AL VP100HDi User Manual

Interactive full hd 1080p video player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual
VIDEO HD
PLAYER
VP100HDi
MANUAL
® Waves System
V 1.03 - 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP100HDi and is the answer not in the manual?

Questions and answers

Related Manuals for I.D. AL VP100HDi

Summary of Contents for I.D. AL VP100HDi

  • Page 1 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual VIDEO HD PLAYER VP100HDi MANUAL ® Waves System V 1.03 - 2012...

  • Page 2: Table Of Contents

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Table of contents A - Safety instructions B - Product information 1 - Product presentation 2 - Functionnalities 3 - Installation 4 - Operating mode 4.1 - First use 4.2 - Play manually the audio/video files...

  • Page 3: A - Safety Instructions

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual CAUTION! DO NOT EXPOSE TO HUMIDITY & DUST! Unplug the power supply cable before any servicing FOR YOUR SAFETY, PLEASE READ THE USER’S GUIDE CAREFULLY BEFORE OPERATING YOUR PLAYER.
  • Page 4 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual conversion of the device automatically entails loss of the homologation. The operation of a modified device is liable to a penalty. In the interest of occupational safety, the operator and the user are held responsible for complying with the regulations.

  • Page 5: B - Product Information

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual A.6 - Terms of use: • This product has been designed for indoors use only. • If this device has been exposed to very high temperature fluctuations (e.g.: after transportation), do not connect it immediately.

  • Page 6: Product Presentation

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 1 - Product presentation The VP100HDi is an Audio/Vidéo full HD player. The files are stored on a SD/SDHC Card or USB device, stick or hard disk. This standalone player can read files automatically when switch on.

  • Page 7: Installation

    Ethernet link, time and date ... 1 -Connect the VP100HDi to a display using HDMI or VGA out. Connect the power supply but don’t insert a media (SD or USB). Status LED change from red to orange and green for about 1 minute. Main menu is now displayed.

  • Page 8: Play Manually The Audio/Video Files

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 4.2 - Play manually the audio/video files 1 - Use a SD card or USB flash memory already formated in FAT32* and copy one or more video, audio or images files (see annex B for compatibility).

  • Page 9: Configuration

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 5 - Configuration You can change some parameters to adapt the uses to your requirement. All the parameters are included in the Setup menu. From the main menu, select «Setup» with the remote control and press OK.

  • Page 10: Network - Setup Ethernet Parameters

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 5.2 - Network - Setup Ethernet parameters In this menu, you can set the Ethernet parameters. - NetMon Info* : Display DNS, IP and PORT information of the NetMon server.

  • Page 11: Slideshow Time

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 5.4 - Slideshow Time In this menu, you can set the time between image from 1 up to 255 seconds, using the slide show mode. 5.5 - Baudrate - Setup RS232 internal link With the VP100HDi model, don’t change the baudrate fixed at 115200 Bauds...

  • Page 12: Ftp User

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 5.7 - FTP User - Réglage des paramètres FTP In this menu, you can set the FTP parameters. - User : Name of the user. Default is "admin".

  • Page 13: Automatic Power On/Off

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 6 - Automatic power on/off You can wake up or put on sleep the player automatically using the power on/off function. In the Setup menu, select RTC tab.

  • Page 14: Ethernet Link

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 7 - Ethernet link Via the Ethernet link, the VP100HDi communicates to update content via FTP. You can use the player in a local network. An adequately configured Modem/Router will allow access of the player via the Internet.
  • Page 15 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual The principle is as follows: When the IP address changes, the Modem sends this information to the DynDNS server. The service immediately carries out the modification in its database to point out the new address on the host name.

  • Page 16: Operating Mode And Naming Of Files

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 8 - Operating mode and naming of files. Folder names define the playing mode. 8.1 Organisation of the folders: Only one folder level is allowed at the root. The folder names are made of 3 digits (000 to 999) followed by optional parameters and a name of your choice.
  • Page 17 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Optional parameters To modify the behaviour of the player, you can add optional parameters to the folder name. These parameters are boxed with the "[" "]"symbols. You can add several parameters to the folder name.
  • Page 18 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual while a new change is not executed. Example: 001 [R1000] - Enables output 1 while reading folder 001 001 [R1111] - Enables all 4 outputs while reading folder 001...
  • Page 19 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 8.2 Organisation of files inside folders. Like for folders, file names define their playback pattern. Note: You may not have to use this notation if the files are read randomly ("RND" option or no option in the folder name).

  • Page 20: Rs232 Serial Link Protocol

    / 1 stop bit / no parity). 9.1 - Reception Protocole VP100HDi can receive commands to start reading a file or change volume. If the same link is used to control several players, each player will only execute commands addressed to its own number.
  • Page 21 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual List of commands: ● ● ● ● ● 00000000b(00h) : not used ● ● ● ● ● 0xxx0001b (01h) : Jump and play a folder The folder is refered to by the range number and the byte of data which follows.
  • Page 22 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual ● ● ● ● ● 01111111b (7F) : Setting the ID of the player The ID is defined by the byte of data as follows: Values of data for byte 3 included between 1 and 127...

  • Page 23: Connections

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 10 - Connections 10.1 - How to connect VP100HDi 8 (up to 255) trigger input RS232 link 4 open collector output Audio PSU 12V Computer display TV display 10.2 - Input connections...
  • Page 24 10.3 - Output contacts The VP100HDi can enable output contacts to operate various devices. You can switch on lamps, relays, motors … The output contacts are activated through folders. The output contacts of the VP100HDi are opto-couplers (see diagram below). The power output is limited (switching up to 60V/50mA max) and only low power devices can be controlled, LED or small relays.
  • Page 25 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual 10.4 - Input vs folders Binary table : The 8 input contacts can be combined to obtain up to 255 combinations according to the table hereafter: X indicates the contact to be made on inputs or made on the outputs N°...

  • Page 26: Annexe A - Specifications

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Annex A - Specifications • Power supply : DC input : 12V DC • Consumption : - Sleep mode : 50 mA - Play mode : 600 mA Taille : Width : 142mm (1/3 19’’...

  • Page 27: Annexe B - Functions

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Annex B - Functions Resolutions : • XGA - 1024 x 768 • WXGA - 1280 x 768 • SXGA - 1280 x 1024 • WXGA+ - 1440 x 900 •...

  • Page 28: Annexe C : Type Of Memory Storage

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Supported CODEC : MPEG layer 1 et 2 MP3 (MPEG layer 3), 44.1KHz / 48KHz - 32kbit/s up to 320kbit/s CBR/VBR AC3 (48kHz / 5 channels) WMA* 44.1KHz / 48KHz de 32kbit/s à...

  • Page 29: Annexe D : Infra Red Remote Control

    I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual Annexe D - Infra red remote control You can send command to player using an infra red remote control. Arrow Valid - OK Escape Volume +...
  • Page 30 I.D. AL - VP100HDi - Interactive Full HD 1080p video player - User manual http://www http://www http://www .id-al.com .id-al.com .id-al.com .id-al.com http://www http://www .id-al.com ® Waves System V 1.03 - 2012...
