Page 1: User Manual
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual VP200HDi Vidéo/audio player USER MANUAL ® Waves System V 1.0 - 2014... -
Page 2: Table Of Contents
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual SOMMAIRE A - Safety instructions ................P1 B - Product information ................P3 1 - Product presentation ................. P4 2 - Functionnalities ................. P4 3 - Installation ..................P5 4 - Operating mode ................ -
Page 3: A - Safety Instructions
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual ACAUTION! DO NOT EXPOSE TO HUMIDITY & DUST! Unplug the power supply cable before any servicing FOR YOUR SAFETY, PLEASE READ THE USER’S GUIDE CAREFULLY BEFORE OPERATING YOUR PLAYER. - Page 4 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual to draw your attention to the following instructions: • When using the device, comply with all local rules and regulations in force. Any modification or conversion of the device automatically entails loss of the homologation. The operation of a modified device is liable to a penalty.
-
Page 5: B - Product Information
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual A.6 - Terms of use: • This product has been designed for indoors use only. • If this device has been exposed to very high temperature fluctuations (e.g.: after transportation), do not connect it immediately. -
Page 6: Product Presentation
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 1 - Product presentation The VP200HDi is an interactive full HD video player. The files are stored on a USB device. This standalone player can read files automatically when switch on: Autplay function. -
Page 7: Installation
14 - Contacts ouputs 15 - Leds for status First use: VP200HDi is factory setting configured with parameters by default and the player must operate on inserting a prepared media dedicated to ( chapter 4 ). 1 - Insert a prepared USB flash memory. - Page 8 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 2 - Connect a display, speakers or a sound system to the audio output and switch on the player thanks to the PSU Speakers 12v power supply HDMI or composite...
- Page 9 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 3.1 - Connections Connection is directly from the sensor/push button to the player trigger inputs. Status Leds : 1 à 8 - Output state 1 to 8 V - Activity, show the receipt of the commands E - Player status.
-
Page 10: Input Connections
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 3.2 - 8 input connections Using up to 8 triggers you can connect the electricals contacts directly to the 8 inputs. Over 8 push button, you need to combine the input with some diodes or other electronic system. Input are a binary mapping of the number of folders. - Page 11 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 3.3 - Output contacts The VP200HDi can enable output contacts to operate various devices. You can switch on lamps, relays, motors … The output contacts are activated through folders.
-
Page 12: Operating Mode
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 4 - Operating mode See in annex at the end of this manual, the compatible files. The name of the files and folders define the playback mode. The files and folders must be stored and copied according to a specific organisation described below. - Page 13 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual [Jxxx] – Assign the folder No. to be read after the reading the current folder. ● ● ● ● ● By adding this parameter within the name of the folder, you define the conduct of the player after reading the current folder so that it starts reading another folder for example.
- Page 14 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual [Vxx] - Volume setting ● ● ● ● ● The name of the folder have an effect on the output volume. This function is used to broadcast messages loud more or less than others files.
- Page 15 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual [RSSxxx] ou [RSExxx] – These tags allows to send bytes onto the RS232 output. ● ● ● ● ● When the folder is called, a list of bytes is transferred by the serial link in order to control other devices (another player, switching grid, projector, ..) The bytes to send are included in a text file that will be...
- Page 16 The trigger inputs offer the possibility to play the folder of your choice. The number of the inputs show the folder number to be played. The VP200HDi offer 1 separate input and 8 extended inputs. The separat input start only the folder N°001.
- Page 17 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Example to start the first 9 folders : Folder / Input Input N°1 -> Folder 001 Input N°2 -> Folder 002 Input N°1 + N°2 -> Folder 003 Input N°3 -> Folder 004 Input N°1 + N°3 ->...
-
Page 18: Rs232 Serial Link Protocol
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 5 - RS232 serial link protocol The VP200HDi can communicate with other devices by receiving instructions onto the Rx input or transferring data through its Tx output. The player complies with the RS232 norm (see annex for features). - Page 19 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual List of commands: 00h: not used 01h: command of a jump into a folder 02h: transport bar command 03h: volume control command 04h : Request informations 05h/06h : Reserved 07h à...
- Page 20 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Example of the full frame : 81 03 0E Byte1 : 81h - 10000001b : status byte, plater number 001 Byte2 : 03h - 00000011b : volume command Byte3 : 0Eh - 00001110b : volume setting at 14 04h - 00000100b : Request informations ●...
-
Page 21: Setup Menu
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual 6 - Setup Menu You can configure the player to change some parameters. Press «Setup» key from the remote control to enter into the setup menu. Navigate and change the menus you want by using the remote control. -
Page 22: Annexe A : Characteristics
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Annexe A - Characteristics • Power supply : Nominal voltage : 12V DC • 12V supply consumption: - Playing mode (line output - amplifier is not used): 400 mA - Playing mode with amplifier at mximum level: 3A •... -
Page 23: Annexe B : Functionalities
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Annexe B - Functionnalities Video decoder : - MPEG-2 TS/TP, MPEG-4, MOV et H.264 Video format : - SD 720x576 25i/25p (576p/576i) (4:3/16:9) - SD 720x480 30i/30p (480p/480i) (4:3/16:9) -
Page 24: Annexe C : Infrared Remote Control
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Annexe C - Infra red remote control You can send command to player using an infra red remote control. Function Power ON/OFF Title Not used INFO Show file informations... -
Page 25: Annexe D - Input Vs Folders
I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual Annexe D - Input vs folders Binary table : The 8 input contacts can be combined to obtain up to 255 combinations according to the table hereafter: X indicates the contact to be made on inputs or made on the outputs N °... - Page 26 I.D. AL - VideoPlayer VP200HDi - Video/Audio player - User manual http://www http://www http://www .id-al.com .id-al.com .id-al.com .id-al.com http://www http://www .id-al.com ® Waves System V 1.0 - 2014...
