I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual
GeoPlayer
Audio Player
MP3 & WAV
with GPS function
MANUAL
® Waves System
V 1.0 - 2008

Advertisement

loading
Need help?

Need help?

Do you have a question about the GeoPlayer and is the answer not in the manual?

Questions and answers

Related Manuals for I.D. AL GeoPlayer

Summary of Contents for I.D. AL GeoPlayer

  • Page 1 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual GeoPlayer Audio Player MP3 & WAV with GPS function MANUAL ® Waves System V 1.0 - 2008...

  • Page 2: Table Of Contents

    I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual Table of content A - Safety instructions ................P1 B - Product information ................P3 1 - Product presentation ................. P4 2 - Functionnalities ................. P4 3 - Installation ..................

  • Page 3: A - Safety Instructions

    I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual WARNING: DO NOT EXPOSE TO MOISTURE AND DUST ! Unplug the power cord before any intervention ! FOR YOUR SAFETY, PLEASE READ CAREFULLY THIS OPERATION MANUAL BEFORE USING YOUR PLAYER A.
  • Page 4 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual • When operating this appliance, observe all local rules and enforced regulations! The homologation shall be invalid if any modification or alteration is made on the appliance. Operating modified appliances may lead to a penal suit.
  • Page 5 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual A.6 - Conditions of use : • This product has been designed for indoor use only. • If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately.

  • Page 6: Product Presentation

    I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual 1 - Product presentation The GeoPlayer is an audio player which reads MP3 and WAV files stored on a SD memory card. Playback of audio files is triggered by global positioning coordinates recorded by the integrated GPS sensor.

  • Page 7: Installation

    «FAT». You can also use FAT32 format for SD card above 512Mo. Push the card without forcing. To remove, push on the card to release it. Caution, the GeoPlayer does not have any on-off switch. The player is powered on as soon as it is plugged in.
  • Page 8 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual 1 - Speaker Output: The GeoPlayer includes a built-in amplifier. The board can therefore be connected directly onto speakers. Connect the speaker wires onto the output of each of the 2 channels.
  • Page 9 6 + 10 - Input on dry contact: Connect a push button to be able to select/force the next GPS position when the GeoPlayer is in track mode. See the GPS mode description chapter in the manual. Create a brief contact between «SW»...
  • Page 10 4 - Operating the player and naming of files The GeoPlayer reads files and playback instructions stored on the SD memory card. No extra software is required to configure the player. Playback options are provided by the way files are named and organized in the directories.
  • Page 11 The «GPS» directory contains files to be broadcast in relation to the geographical positions of the GeoPlayer. File names are compulsory and composed of 3 or 4 figures followed by an optional file name. Example : 001.mp3 or 0011 my file.mp3 or 0011.wav ..
  • Page 12 The sub-number is between 0 and 9. Example : when the GeoPlayer reaches a given location, you could broadcast an introduction jingle, an information message, an advert and an end jingle.

  • Page 13: Gps Configuration File

    I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual 5 - GPS configuration file The GeoPlayer broadcasts audio files in relation to geographical locations. The integrated GPS sensor, permanently compares the player’s position with a pre-established table listing the points to be scrutenized.
  • Page 14 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual Main file number for the triggered file One or several audio files are associated to each location. The files to be broadcast are stored on the SD card in the «GPS»...
  • Page 15 5.1 Creation of the configuration file «gps.csv» For the GeoPlayer to broadcast audio files associated to GPS positions, it is necessary to create a configuration file which is a cross reference table between the audio files and the GPS data.
  • Page 16 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual 5.1 Finding GPS coordinates using GoogleMaps GPS coordinates of locations can be found for free from the GoogleMaps web site. There are indicated in degree decimal format.

  • Page 17: Infrared Remote Control

    Transport bar : Play / Stop / Next - Previous Volume control : Increase or decrease volume Trigger key : Play the next GPS position when the GeoPlayer is in track mode. (same as Input contact function) ® Waves System V 1.0 - 2008...

  • Page 18: Appendix A : Characteristics

    I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual Appendix A - Characteristics Power supply: • Nominal voltage: 12V DC • Power supply range: 10V to 15V DC Consumption on 12V power supply: • Stand-by: 100mA •...
  • Page 19 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual Notes : ® Waves System V 1.0 - 2008...
  • Page 20 I.D. AL - GeoPlayer - MP3 and WAV Player with GPS function - Manual http://www.id-al.com http://www.wsystem.com ® Waves System V 1.0 - 2008...
