[MAIN UNIT]
REF ORDER
NO. NO.
C231 4030011600 S.CERAMIC
C232 4030011600 S.CERAMIC
C233 4030006860 S.CERAMIC
C234 4030006860 S.CERAMIC
C236 4030009530 S.CERAMIC
C243 4030006860 S.CERAMIC
C245 4030006860 S.CERAMIC
C246 4030011600 S.CERAMIC
C247 4030006860 S.CERAMIC
C248 4030006900 S.CERAMIC
C249 4030006900 S.CERAMIC
C250 4030006900 S.CERAMIC
C251 4030006900 S.CERAMIC
C252 4030006860 S.CERAMIC
C256 4030006860 S.CERAMIC
C258 4030011600 S.CERAMIC
C260 4030006860 S.CERAMIC
C264 4030011600 S.CERAMIC
C272 4030006900 S.CERAMIC
C278 4550006680 S.TANTALUM
C279 4030007120 S.CERAMIC
C281 4030007030 S.CERAMIC
C285 4030006860 S.CERAMIC
C290 4030009000 S.CERAMIC
C291 4550006150 S.TANTALUM
C295 4030006860 S.CERAMIC
C296 4030011600 S.CERAMIC
C298 4030007070 S.CERAMIC
C299 4030007090 S.CERAMIC
C300 4550006650 S.TANTALUM
J2 6450001680 CONNECTOR
J3 6450001690 CONNECTOR
J4 6450000870 CONNECTOR
J5 6510007080 CONNECTOR
J6 6910010850 CONNECTOR
DS1 5030001460 LCD
DS2 5010000160 S.LED
DS3 5010000160 S.LED
DS4 5040002190 S.LED
MC1 7700002160 MICROPHON
S1 2230000900 S.SWITCH
W1 7030003860 S.JUMPER
W10 7030003860 S.JUMPER
EP1 910050712 PCB
EP2 8930042590 LCD CONTACT SRCN-1922-SP-N-W
DESCRIPTION
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 030B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N [ANI] only
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
ECST0JY156R
C1608 CH 1H 820J-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 102K-T-A
C2012 JB 1C 224K-T-A
ECST1CY105R
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 330J-T-A
C1608 CH 1H 470J-T-A
ECST1CY685R
HSJ1122-010010
HSJ1456-01-220
HEC2711-01-020
PI28A-02M
IMSA-9230B-1-05Z080-T
LM-1462B
LNJ310M6URA
LNJ310M6URA
LNJ808R8ERA
KUC3523-040245
JPM1990-2013R
ERJ3GE JPW V
ERJ3GE JPW V
B 5193B

[VCO BOARD]

REF ORDER
NO. NO.
Q6 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q7 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q8 1530002920 S.TRANSISTOR 2SC4226-T2 R25
D5 1720000370 S.VARICAP
D6 1790000620 S.DIODE
L10 6200006670 S.COIL
L11 6130002760 S.COIL
L12 6200004480 S.COIL
R22 7030003610 S.RESISTOR
R23 7030003340 S.RESISTOR
R24 7030003360 S.RESISTOR
R25 7030003540 S.RESISTOR
R26 7030003540 S.RESISTOR
R27 7030003360 S.RESISTOR
R28 7030003320 S.RESISTOR
R29 7030003460 S.RESISTOR
C33 4030006860 S.CERAMIC
C34 4030009500 S.CERAMIC
C35 4030006860 S.CERAMIC
C36 4030006860 S.CERAMIC
C37 4030009510 S.CERAMIC
C38 4030009510 S.CERAMIC
C39 4030006860 S.CERAMIC
C40 4030009510 S.CERAMIC
C41 4030007060 S.CERAMIC
C44 4030006860 S.CERAMIC
C45 4030006860 S.CERAMIC
C259 4030007160 S.CERAMIC
J1 6910010840 CONNECTOR
EP1 910050691 PCB
[VR BOARD]
REF ORDER
NO. NO.
R1 7210002950 VARIABLE
C1 4030006860 S.CERAMIC
EP1 910050701 PCB
6 - 4
DESCRIPTION
HVU350TRF
MA77 (TX)
ELJRE 68NG-F
LB-312
MLF1608D R82K-T
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
C1608 JB 1H 102K-T-A
C1608 CH 1H 0R5B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 010B-T-A
C1608 CH 1H 010B-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 010B-T-A
C1608 CH 1H 270J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 181J-T-A
IMSA-9230B-1-05Z057-T
B 5195A
DESCRIPTION
RV-312 (RK0971110)
C1608 JB 1H 102K-T-A
B 5196A
S.=Surface mount
