Digibell Vandal Resistant System
Entrance Panel Controls
After entering the flat number press this button to call the flat.
If a mistake is made entering the flat number, use this button to clear the
display.
This button rings reception with a single press (optional)
Used for residents to gain access or deliveries during set times, a 4 digit
code maybe required (optional)
A> Each press causes the displayed letter to increment by 1 in the range A
down to Z
<Z Each press causes the displayed letter to decrement by 1 in the range Z
down to A
PD-190 Issue 1
Digibell Vandal Resistant System
Residential entry
Call sequence
The caller firstly approaches the entrance panel and enters the required flat number
followed by the button. This causes the phone to ring in the selected flat. The
phone will continue to ring for typically 30 seconds if not answered or until the
resident responds by picking up the handset. The call may be terminated by
replacing the handset or more usually by pressing the
visitor access through the entrance.
Ringer Mute (optional, BS-LX phone only)
The phone ringer can be muted when you do not wish to be disturbed. Caller mute is
activated by pressing the button on the phone, which then illuminates in red as a
reminder. Pressing the button a second time will disengage the mute function.
The Mute button can be used to turn the ring on or off, or off for a timed period
depending on installation settings.
Door Status Indication (optional, BS-LX phone only)
The green lamp on the phone will illuminate to warn that a door has been left
open.
Coded Entry (optional)
Press the button, the word 'CODE' will be displayed, enter the assigned 4 digit
code, the display will change to 'OPEN' and the door is now unlocked.
PD-190 Issue 1
key button to allow the
