KitchenAid that, if your Food Processor should fail within the first year of ownership, KitchenAid will arrange to deliver an identical or comparable replacement to your door free of charge and arrange to have your original Food Processor returned to us.
INTRODUCTION Hassle-Free Replacement Warranty...Inside Front Cover Product Registration Card ...Inside Front Cover Food Processor Safety ...3 Important Safeguards...4 Electrical Requirements ...5 FEATURES AND OPERATION Food Processor Features ...6 Preparing the Food Processor for Use Before First Use ...8 Work Bowl Assembly ...8 Multipurpose Blade &...
Page 4
Table of Contents FOOD PROCESSING TIPS Using the Multipurpose Blade...18 Using a Slicing or Shredding Disc ...19 Using the Dough Blade...20 Using the Egg Whip ...20 Helpful Hints ...21 RECIPES Appetizers ...23 Salads and Dressings ...28 Soups and Sandwiches ...32 Vegetables and Side Dishes ...37 Main Dishes...41 Breads ...46...
Food Processor Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others.
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions. 2. To protect against risk of electrical shock do not put Food Processor in water or other liquid. 3. Close supervision is necessary when any appliance is used by or near children.
Failure to follow these instructions can result in death, fire or electrical shock. NOTE: Model KFPM770 has a 3 prong grounded plug. To reduce the risk of electrical shock, this plug will fit in an outlet only one way. If the plug does not fit in the outlet, contact a qualified electrician.
Food Processor Features Medium (4 mm) Shredding Disc Medium (4 mm) Slicing Disc Disc Stem Fine (2 mm) Slicing Disc Work Bowl Cover with Ultra Wide Mouth™ Feed Tube Stainless Steel Multipurpose Blade Dough Blade Work Bowl Heavy Duty Base 2-Piece Food Pusher 10-Cup Chef’s Bowl...
Page 9
Food Processor Features Work Bowl Cover with Ultra Wide Mouth™ Feed Tube One of the industry’s largest, the Ultra Wide Mouth™ feed tube accommodates large items – like tomatoes, cucumbers, and potatoes – with a minimum of sectioning or slicing. 2-Piece Food Pusher For smaller items, remove the small pusher from the central tube in the...
Preparing the Food Processor for Use WARNING Cut Hazard Handle blades carefully. Failure to do so can result in cuts. Before First Use Before using your Food Processor for the first time, wash the work bowl, work bowl cover, chef’s bowl, mini bowl, feed tube pusher, discs, and blades either by hand or in the dishwasher (see “Cleaning the Food...
Preparing the Food Processor for Use WARNING Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire or electrical shock.
Preparing the Food Processor for Use WARNING Cut Hazard Handle blades carefully. Failure to do so can result in cuts. 2. Fit the disc over the metal pin on the disc stem, then rotate the disc until it falls fully onto the stem. Mini Bowl Assembly 1.
Preparing the Food Processor for Use Egg Whip Assembly and Use The egg whip is designed to whip egg whites or heavy cream to create toppings or soft meringues. For the best results, at least 1 cup of heavy cream or 3 egg whites should be whipped at a time.
Page 14
Preparing the Food Processor for Use 4. The 2-piece cone offers two sizes; choose the right size for the fruit you are juicing. Use the outer cone for grapefruit, oranges and other large fruits. Remove the outer cone to reveal a smaller inner cone that’s perfect for lemons and limes.
Using the Food Processor WARNING Rotating Blade Hazard Always use food pusher. Keep fingers out of openings. Keep away from children. Failure to do so can result in amputation or cuts. Before Use Before operating the Food Processor, be sure the work bowl, blades, and work bowl cover are properly assembled on the Food Processor base (see “Preparing the Food...
Using the Food Processor WARNING Rotating Blade Hazard Always use food pusher. Keep fingers out of openings. Keep away from children. Failure to do so can result in amputation or cuts. Using the Pulse Control The pulse control allows precise control of the duration and frequency of processing.
Page 17
Disassembling the Food Processor 2. If using a disc, remove it before removing the bowl. Place two fingers under each side of the disc and lift it straight up. Remove the disc stem. 3. If using the mini bowl or chef’s bowl, grasp and remove the bowl using the finger grips located along the top edge of the bowl.
Cleaning the Food Processor WARNING Cut Hazard Handle blades carefully. Failure to do so can result in cuts. 1. Press the Off Button and unplug the Food Processor before cleaning. 2. Wipe the base and cord with a warm, sudsy cloth, and wipe clean with a damp cloth.
If the problem cannot be corrected with the steps in this section, see the KitchenAid Warranty and Service section on pages 57-58. Do not return the Food Processor to the retailer – they do not provide service.
Food Processing Tips USING THE MULTIPURPOSE BLADE To chop fresh fruits or vegetables: Peel, core, and/or remove seeds. Cut food in 1 to 1 ⁄ -inch pieces. Process food to desired size, using short pulses, 1 to 2 seconds each time. Scrape sides of bowl, if necessary.
Food Processing Tips To grate hard cheeses, such as Parmesan and Romano: Never attempt to process cheese that cannot be pierced with the tip of a sharp knife. You can use the multi- purpose blade to grate hard cheeses. Cut cheese in 1-inch pieces. Place in work bowl.
Food Processing Tips To slice uncooked meat or poultry, such as stir-fry meats: Cut or roll food to fit feed tube. Wrap and freeze food until hard to the touch, 30 minutes to 2 hours, depending on thickness of food. Check to be sure you can still pierce food with the tip of a sharp knife.
1. When cutting and packing food items in the Ultra Wide Mouth™ feed tube, do not exceed the maximum fill line. This will permit the pusher to engage the interlock and the unit to operate. 2. Never process any food that is so hard or firmly frozen that it cannot be pierced with the tip of a sharp knife.
Page 24
15. After removing the work bowl cover, place it upside down on the counter. This will help keep the counter clean. 16. To remove the contents of the work bowl without removing the multipurpose blade, grasp the work bowl from the bottom and place one finger through the center opening to hold the blade in place.
Hot Artichoke Dip 4 ounces Asiago or Parmesan cheese, room temperature 2 green onions, cut into 1-inch pieces ⁄ red or green jalapeno pepper, seeded and cut into quarters 1 small clove garlic 1 can (14 oz.) artichoke hearts, well drained and cut into halves ⁄...
Dilled Sour Cream Cucumbers and Onions 2 medium cucumbers 1 teaspoon salt ⁄ small onion ⁄ cup sour cream ⁄ cup mayonnaise ⁄ cup loosely packed fresh dill 1 tablespoon white wine vinegar 2 teaspoons sugar ⁄ ⁄ teaspoon black pepper White Balsamic Vinaigrette 1 tablespoon fresh...
Chicken Wild Rice Salad 2 green onions, cut into 1-inch pieces 1 pound boneless, skinless chicken breast halves, grilled or broiled and cooled ⁄ large red bell pepper, seeded and cut into quarters lengthwise 1 medium rib celery 2 cups cooked wild rice, cooled Dressing ⁄...
Page 33
Broccoli Kohlrabi Salad 1 stalk (about ⁄ lb.) broccoli 2 bulbs kohlrabi, peeled and cut into eighths lengthwise 1 large carrot, peeled Dressing ⁄ cup vegetable oil 3 tablespoons red wine vinegar 1 tablespoon fresh lemon juice 2 green onions, cut into 1-inch pieces 1 teaspoon prepared mustard...
Pan-Fried Veggie Burgers 8 ounces Monterey Jack cheese, chilled 3 firm Roma tomatoes, cored 2 large cloves garlic ⁄ small red onion, cut into 1-inch pieces ⁄ medium green bell pepper, cut into 1-inch pieces 1 can (15 oz.) pinto or kidney beans, well drained 1 can (8...
Muffaletta Sandwiches 1 medium plum tomato 2 large fresh basil leaves 2 tablespoons fresh parsley leaves 2 large cloves garlic ⁄ small red onion, peeled and cut into 1-inch pieces ⁄ cup pimiento-stuffed green olives ⁄ cup pitted ripe olives ⁄...
Spring Mix Basmati Rice 1 clove garlic 1 medium shallot, cut into quarters 1 tablespoon olive oil ⁄ pound (about 1 cup) fresh green beans, trimmed 1 small carrot, peeled and cut into halves crosswise ⁄ cups chicken broth 1 cup water 1 teaspoon salt ⁄...
Country White Bread ⁄ cup water ⁄ cup milk 2 tablespoons butter or margarine 1 package active dry yeast 3 cups all-purpose flour 1 tablespoon sugar 1 teaspoon salt 1 teaspoon melted butter or margarine, if desired Combine water, milk, and 2 tablespoons butter in small saucepan.
Page 50
Country White Bread Variations Cinnamon Bread After first rising, roll out dough into a 15 x 9-inch rectangle. Spread with 1 tablespoon soft butter or margarine. Sprinkle with 3 tablespoons sugar and 1 teaspoon cinnamon. Starting at short end, roll firmly to form loaf.
Crust 1 cup all-purpose flour 2 teaspoons sugar ⁄ teaspoon salt ⁄ cup cold butter, cut into 1-inch pieces 1 tablespoon cold shortening 1 egg yolk 2 tablespoons ice water 1 teaspoon lemon juice 1 egg, blended with 1 tablespoon water Filling ⁄...
Page 55
Pear Hazelnut Crunch Pie 1 9-inch pastry crust (see page 54) Topping ⁄ cups hazelnuts ⁄ cup all-purpose flour ⁄ cup packed brown sugar ⁄ cup rolled oats ⁄ teaspoon cinnamon ⁄ teaspoon nutmeg ⁄ cup butter or margarine, cut into pieces and softened Filling 4 large firm pears,...
One Crust 1 cup all-purpose flour ⁄ teaspoon salt ⁄ cup cold shortening 1 tablespoon cold butter or margarine, cut up 2-4 tablespoons ice water Two Crusts 2 cups all-purpose flour ⁄ teaspoon salt ⁄ cup cold shortening 3 tablespoons cold butter or margarine, cut up 5-7 tablespoons ice...
Page 58
Vanilla Chocolate Chunk Cookies ⁄ cup butter or margarine, softened ⁄ cup shortening ⁄ cup granulated sugar ⁄ cup packed brown sugar 2 eggs* 2 teaspoons vanilla 1 teaspoon baking soda ⁄ teaspoon salt 2 cups all-purpose flour ⁄ cups white chocolate chunks ⁄...
Warranty: One Year Full Warranty from date of purchase. KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Failure to do so can result in death or electrical shock. Arranging for Service Outside the 50 United States and Puerto Rico Consult your local KitchenAid dealer or the store where you purchased the ® Food Processor Warranty for Puerto Rico insured, to the nearest Authorized Service Center.
KitchenAid.com or call toll-free 1-800-541-6390, 8 a.m. to 8 p.m., Monday through Friday, 10 a.m. to 5 p.m., Saturday, Eastern Time. Accessories for Models KFPM770 and KFPW760: Blades and Discs 12-cup Multipurpose Blade Dough Blade Mini Blade (for Mini Bowl)
