1/12th scale 2wd electric caged buggy

Advertisement

EN-ENGLISH
1/12th SCALE 2WD ELECTRIC CAGED BUGGY
Scan this QR
code with your
smart phone to
view the getting
started video for
this product.
LENGTH
344mm (13.54in)
WIDTH
213mm (8.39in)
HEIGHT
109mm (4.29in)
WHEELBASE
250mm (9.84in)
WHEEL SIZE
F-O: 53mm (2.1in) x W: 23mm (0.9in)
R-O: 53mm (2.1in) x W: 28mm (1.1in)
TIRE DIAMETER
F-O: 76mm (2.99in) x W: 29mm (1.14in)
R-O: 77mm (3.0in) x W: 36mm (1.42in)
WEIGHT*
770g (1lb-11.2oz)
BATTERY
1,500mAh 2S LIPO, 7.4V
MOTOR
380 SIZE, REVERSE ROTATION
RADIO
2.4GHz 2-CHANNEL
CHARGER
AC 0.5A BALANCING
*APPROXIMATE OUT-OF-THE-BOX WEIGHT
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 1
OWNER'S MANUAL AND EXPLODED VIEW
Entire contents ©2014 Helion RC
Before using your product, review all documenta-
tion and inspect the products carefully. If for some
reason you decide it is not what you wanted, then
do not continue with unpacking, setup or operation
of your product. Your local hobby dealer cannot
accept a product for return or exchange after par-
taking in actions that produce wear and tear.
Read, understand and follow all instructions and
accompanying material carefully before operat-
ing or assembling your vehicle to prevent serious
damage to your vehicle. Failure to complete these
tasks properly or intentional aversion to the con-
tent will be considered abuse and/or neglect.
Product specifications are subject to change
without notice. Due to ongoing development, the
actual product may vary from images shown.
This product contains chemicals known to the
State of California to cause cancer and birth de-
fects or other reproductive harm.
This product is not a toy! (14+) Recommended
for ages 14 and up. Adult supervision required for
ages under 18 years old. Contains small parts,
keep out of reach of children 3 years of age and
younger.
2014-09-29 11:27:02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMPAKT and is the answer not in the manual?

Questions and answers

Summary of Contents for Helion IMPAKT

  • Page 1 18 years old. Contains small parts, CHARGER AC 0.5A BALANCING keep out of reach of children 3 years of age and younger. *APPROXIMATE OUT-OF-THE-BOX WEIGHT 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 1 2014-09-29 11:27:02...
  • Page 2: Package Contents

    NOTICE!!! Although your Helion RC product is adjusted and tested at the factory prior to final packaging, some issues may arise during shipping and handling that can be easily resolved at home. For other issues it should be known that hobby grade radio controlled products such as those offered by Helion RC differ from toy grade, in that they are intended to be user-servicable products where the user can disassemble and maintain their own product using factory replacement parts.
  • Page 3: Charging The Battery

    Warning: Recommended charge current is 1.5A however, never charge the included battery at a charge current exceeding 2A. 6. Remove charger from wall plug. 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 3 2014-09-29 11:27:03...
  • Page 4 WARNING! THE MOTOR WILL BE HOT AFTER RUNNING, USE CAUTION WHEN › TESTING THE MOTOR TEMPERATURE. DO NOT TOUCH THE MOTOR DIRECTLY, CAREFULLY TOUCH THE PLASTIC GUARD WHICH COVERS THE MOTOR TO CHECK THE TEMPERATURE. 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 4 2014-09-29 11:27:03...
  • Page 5: Storage And Disposal

    Your product is equipped with LiPo batteries which are considered electronic waste and should never be discarded in standard garbage containers. Please visit your local hobby dealer and use the FREE battery disposal center for proper disposal/recycling. 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 5 2014-09-29 11:27:03...
  • Page 6: Safety Tips

    Always use caution and common sense as failure to operate your Helion RC product in a safe and responsible manner can result in damage to the product or other properties. Therefore this product is not intended for use or maintenance by children without direct adult supervision.
  • Page 7: General Care And Maintenance

    It will bond skin and can cause injury if used improperly. Follow manufacturer’s warnings and directions when using CA glue. It is always recommended to wear eye protection when maintaining your vehicle. 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 7 2014-09-29 11:27:03...
  • Page 8: Troubleshooting Problems

    Even a small pebble can get lodged into the teeth of the pinion gear, which would practically destroy the spur gear in a very short period of time. 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 8 2014-09-29 11:27:03...
  • Page 9: Troubleshooting Guide

    Vehicle only has Center the TH trim and power-cycle the forward or reverse The TH trim is not centered transmitter and vehicle. throttle but not both 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 9 2014-09-29 11:27:03...
  • Page 10: Gearbox Assembly

    GEARBOX ASSEMBLY HLNA0508 HLNA0505 HLNA0508 HLNA0507 HLNA0515 HLNA0505 HLNA0506 HLNA0505 HLNA0483 HLNA0504 HLNA0517 HLNA0540 HLNA0516 HLNA0535 HLNA0513 HLNA0504 HLNA0514 HLNA0516 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 10 2014-09-29 11:27:04...
  • Page 11: Rear Suspension Assembly

    1/12th SCALE 2WD ELECTRIC CAGED BUGGY REAR SUSPENSION ASSEMBLY HLNA0535 HLNA0518 HLNA0490 HLNA0510 HLNA0525 HLNA0522 HLNA0493 HLNA0512 HLNA0493 HLNA0522 HLNA0490 HLNA0518 HLNA0535 HLNA0512 HLNA0521 HLNA0526 HLNA0488 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 11 2014-09-29 11:27:05...
  • Page 12: Rear End Assembly

    REAR END ASSEMBLY HLNA0535 HLNA0498 HLNA0498 HLNA0498 HLNA0535 HLNA0536 HLNA0536 HLNA0535 HLNA0535 HLNA0536 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 12 2014-09-29 11:27:05...
  • Page 13 1/12th SCALE 2WD ELECTRIC CAGED BUGGY REAR LINKS AND SHOCKS HLNA0518 HLNA0509 HLNA0518 HLNA0509 HLNA0524 HLNA0524 HLNA0524 HLNA0524 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 13 2014-09-29 11:27:07...
  • Page 14 FRONT SUSPENSION ASSEMBLY HLNA0492 HLNA0494 HLNA0495 HLNA0536 HLNA0535 HLNA0519 HLNA0492 HLNA0512 HLNA0491 HLNA0512 HLNA0511 HLNA0522 HLNA0491 HLNA0518 HLNA0491 HLNA0525 HLNA0518 HLNA0535 HLNA0522 HLNA0518 HLNA0535 HLNA0518 HLNA0535 HLNA0491 HLNA0525 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 14 2014-09-29 11:27:08...
  • Page 15: Steering Assembly

    1/12th SCALE 2WD ELECTRIC CAGED BUGGY STEERING ASSEMBLY HLNA0525 HLNA0536 HLNA0496 HLNA0538 HLNA0535 HLNA0535 HLNA0518 HLNA0497 HLNA0538 HLNA0535 HLNA0523 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 15 2014-09-29 11:27:10...
  • Page 16 ERS UNIT INSTALLATION HLNA0482 HLNA0485 HLNA0518 HLNA0535 HLNA0535 HLNA0536 HLNA0518 HLNA0518 HLNA0518 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 16 2014-09-29 11:27:13...
  • Page 17 1/12th SCALE 2WD ELECTRIC CAGED BUGGY REAR END ASSEMBLY HLNA0520 HLNA0520 HLNA0499 HLNA0525 HLNA0532 HLNA0535 HLNA0489 000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 17 2014-09-29 11:27:15...
  • Page 18: Replacement Parts List

    HLNA0490 ..Rear Hub Carriers (12KT) ................... HLNA0491 ..Spindles and Carriers (12KT) ..................HLNA0492 ..Front Suspension Arms (12B) ..................HLNA0493 ..Rear Suspension Arms (12B) ..................HLNA0494 ..Front Bulkhead (12KT) ....................000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 18 2014-09-29 11:27:17...
  • Page 19 HLNA0537 ..Flanged Locknuts, M4, Black ..................HLNA0538 ..Steering Hardware Kit (12KT) ..................HLNA0539 ..LiPo Charging Bag, 2s 1500mAh 10C ................. HLNA0040 ..Pinion Gears, 2.3 x M0.6 12T, 14T (12KT) ..............000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 19 2014-09-29 11:27:17...
