Page 1 G1E+ Hybrid IP Telephone System Programming Manual Rev 2.2d...
Page 2: Notification
Notification Notification is hereby given that TransTel Communications, Inc. reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, TransTel Communications, Inc. makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose.
Page 3: Table Of Contents
Table of Contents Notification..................................2 Table of Contents................................3 Introduction ................................. 13 New Systems ................................13 Basic Programming Commands ..........................13 Alphanumeric Entry: ..............................14 DK6 Key Telephone – Key Layout (36 Button) ......................15 DK6 Key Telephone – Key Layout (18 Button) ......................15 Program 01-tk-IP : Day Ringing And Ringing Line Preference Assignment ............
Page 4 02. Dial 9 Flag ................................24 03. Action for Call Duration Limiting ........................... 24 04. 12/24 Hours Clock ............................... 25 05. SLT Hook Flash Answer Delay ..........................25 06. Speed Dialing Distribution ............................ 25 07. Single Digit Intercom ............................25 08.
Page 5 Program 05-10-IP : System Timing Parameters – 10 ....................38 Program 05-11-IP : System Timing Parameters – 11 ....................39 01. DTMF Caller ID Leading Digit ..........................39 02. Number of DISA Passwords ..........................39 03. Select Music on Hold or Ring Back Tone ......................39 04.
Page 6 02. Reserved ................................49 03. DISA Single Digit Dialing Level ..........................49 04. VMU Language Service ............................50 05. Reserved ................................50 06. Reserved ................................50 07. ACP Data Output Format ............................. 50 08. Reserved ................................50 Program 05-17-IP : System Timing Parameters – 17 ....................51 01.
Page 7 Program 09-nnn-DP : System Speed Dial ......................... 63 Program 10-GP-IP : Intercom Single Digit Assignment ................... 64 Program 11-IP : Date and Time Setting ........................65 Program 12-nn : System Alarm Clock ........................65 Program 13-nn : Password ............................66 Program 14-01-IP : SMDR Specifications .........................
Page 8 Program 39-IP : Sensor Assignments ........................84 Program 40-stn-IP : Station Class of Service – 1 ..................... 85 01. Override Level ..............................85 02. Monitor Level ............................... 85 03: Limit call duration ..............................85 04. Station Loud Bell ..............................86 05.
Page 9 02. Message Waiting Level ............................97 03. Automatic Answer Capability (Keyphone) / Internal CLI (Caller ID) Function ............98 04. DISA/ISDN In Dial Recall Capability ........................98 05. Maximum Re-Transferred Times ......................... 98 06. Door Unlock / DND / CFWD Access ........................98 07.
Page 10 Program 77-Num : LCR – Modifying Table ......................116 Program 78-stn-IP : Station Class of Service – 6 ....................117 01. LCR Routing Level ............................. 117 02. LCR – Direct Access a Trunk ..........................117 03. Reserved ................................117 04. Call Forward Busy Transfer Group ........................118 05.
Page 11 Intercom Calls ................................132 Intercom Call Signalling ............................132 Step Call ................................132 Dial Tone Pattern ..............................132 Single Digit Intercom ............................132 Direct Station Select ............................. 132 Dial 0 (Call Operator) ............................132 Intercom Dialing Restriction ..........................132 Busy/During Conversation ............................133 Hold and Hold Recall ............................
Page 12 How to set up as a door phone..........................143 How to unlock the door from the ACP using Forced Account Codes ..............143 G1E Plus Programming Manual Rev 2.2d Page 12...
Page 13: Introduction
Introduction The manual contains all the parameters that are programmable inside the G1E+ Hybrid IP Telephone System. New Systems We recommend that all new systems have the system memory reset before system programming takes place. This ensures that any extraneous information that may be present in system memory is erased and that the system database will not be subject to existing corrupt data.
Page 14: Alphanumeric Entry
[TRF/FL]{FLASH}: Enters a FLASH command as part of a Speed Dial Entry. LCD will display F (upper case "F") to indicate a Flash command. This key also means clears a digit during other entries (Passwords, etc). [DSS 31]{MSG}: (Pulse to Tone) Enters a command to convert from pulse dialing to DTMF dialing into a Speed Dial Entry.
Page 15: Dk6 Key Telephone - Key Layout (36 Button)
DK6 Key Telephone – Key Layout (36 Button) DK6 Key Telephone – Key Layout (18 Button)
Page 16: Program 01-Tk-Ip : Day Ringing And Ringing Line Preference Assignment
Program 01-tk-IP : Day Ringing And Ringing Line Preference Assignment 01-tk-IP FLX DAY tk=Trunk No. (01-12), IP=Item Pointer (01-26) Assigned station number 111 000 000 000 General: This program assigns each incoming line to ring the programmed stations during Day Service. Program Mode 35-tk-07 assigns ringing type for each trunk.The ringing methods can be: LINEAR (ring the first available station), CIRCULAR (Ring the next station following the last station who just answered an incoming call),...
Page 17: Program 03-01-Ip : Door Phone Ringing Assignment
Program 03-01-IP : Door Phone Ringing Assignment IP= Item Pointer (01-26) 03-01-IP Door Assigned station number 111 112 113 114 General: This program assigns the Door Phone/s to ring the programmed stations. Description: 1. To assign an ACP or digital door phone to follow Mode 03 it must be set to “d” in mode 46-st-07. Otherwise it will ring the stations assigned in the Hunt Group allocated in mode 46-st-07 2.
Page 18: Program 05-01-Ip : System Timing Parameters - 01
Program 05-01-IP : System Timing Parameters – 01 IP=Item Pointer (01-08) 05-01-IP SYS PAR Value for each Item 1 1 1 1 4 2 2 1 Value Default Item Description 1= 60 sec. Hold Recall Time 1= 60 sec. Exclusive Hold Recall Time 1= 60 sec.
Page 19: Disa & Ecf Access Delay Time - Day
04. DISA & ECF Access Delay Time - Day This parameter sets the timer that a DISA/ECF (External Call Forwarding) trunk will ring assigned stations (set by Program 01-tk-IP, 02-tk-IP) prior to be connected to Auto Attendant (DISA) or another Trunk (ECF) in Day mode. Stations can answer the incoming trunk before it is connected to Auto Attendant or another Trunk.
Page 20: Program 05-02-Ip : System Timing Parameters - 02
Program 05-02-IP : System Timing Parameters – 02 05-02-IP SYS PAR IP=Item Pointer (01-08) Value for each item 5 5 1 6 4 1 2 6 Value Default Item Description 5= 15 Sec. SLT Dial Tone Timeout 5= 15 Sec. SLT Inter-Digit Timeout 1= 10 Sec.
Page 21: Pstn Line Flash Time - Key Phone & Analog Phone
05-02-04 1000 1200 1400 1600 05. PSTN Line Flash Time - Key Phone & Analog Phone This parameter sets the Flash timer at PSTN trunk line when Key Phones pressing the [TRF/FL] key or an analog phone makes a flash and then dials 800 while accessing an outside line. After dialing 800 the flash signal will be sent to the PSTN line and the analog phone will be reconnected to the PSTN line again.
Page 22: Program 05-03-Ip : System Timing Parameters - 03
Program 05-03-IP : System Timing Parameters – 03 05-03-IP SYS PAR IP=Item Pointer (01-08) Value for each Item 1 0 0 9 0 2 0 0 Value Default Item Description 1= 40/60 Make / Break Ratio 0= Yes Automatic Trunk Search 0= Voice Intercom Call Signalling Method 9= 9...
Page 23: Toll Access Code
05. Toll Access Code It is the first dialing digit that will be checked as an effective Toll Call or not. This has no effect on toll control within the system. It is only used to notify SMDR that a call is Toll Call or not. Refer to Program 14-01-03. Record Local Calls. The Toll Access Code can be any one digit (0,1,2,3,4,5,6,7,8,9).
Page 24: Program 05-04-Ip : System Timing Parameters - 04
Program 05-04-IP : System Timing Parameters – 04 IP=Item Pointer (01-08) 05-04-IP SYS PAR Value for each Item 4 1 0 0 0 1 0 0 Value Default Item Description 4= 9600 System Baud Rate Setting 1= Enable Dial 9 Flag 0= Warning Action for Call Duration Limiting 0= 12 Hours...
Page 25: 24 Hours Clock
Related System Program: 40-st-03 04. 12/24 Hours Clock This parameter determines the clock display method on the LCD display of key phones. IP \ Value 05-04-04 12 Hour Clock AM/PM 24 Hour Clock 05. SLT Hook Flash Answer Delay This timer provides a guard time to prevent an SLT user from making an un-intended Hook Flash, such as lifting the handset but dropping on hook again, when it tries to answer a call.
Page 26: Slt Message Waiting Method
08. SLT Message Waiting Method IP \ Value 05-04-08 90V DC Ring Two 250 ms. Ring Burst Description: 0=90V Message light 90 Volts DC will operate industry standard neon light message waiting phones. 1=Auto Ring If the setting is Ring, the single line phone will receive 30 seconds intercom ringing every 5 minutes until the station answers.
Page 27: Program 05-05-Ip : System Timing Parameters - 05
Program 05-05-IP : System Timing Parameters – 05 05-05-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 0 0 0 7 1 1 0 Value Default Item Description Morning Call Type Reserved (for Meter Pulse Detection) Speed Dial Unrestricted-1 Speed dial Unrestricted-2 7=enable all...
Page 28: Name Function
05. Name Function This parameter enables the naming feature for trunks, extensions and speed dials. Features \ Values Display Name instead of number for Extension Directory Dial for Speed Dial Directory Dial for Extension V: The feature is enabled. Note 1: When any of the above features are enabled the total number of speed dial sets will be reduced. See Program 05-04-06.
Page 29: Program 05-06-Ip : System Timing Parameters - 06
Program 05-06-IP : System Timing Parameters – 06 IP =Item Pointer (01-08) 05-06-IP SYS PAR Value for each Item 4 4 1 1 0 3 0 0 Value Default Item Description 4=30 Sec. Transfer Busy Recall Time 4=30 Sec Transfer Idle Recall Time 1=u-law ISDN Audio Coding (a-law orμ- law) 1=enable...
Page 30: Polarity Reversal
04. Polarity Reversal This parameter is to enable the Polarity Reversal detection feature for incoming caller hang up detection in Australia and some European countries. See Mode 14-01-08 for SMDR setting. Telecom provider needs to enable its polarity reversal feature at the central office. When this reversal is enabled the system will hang up the CO line when the incoming caller hangs up and the CO sends a Polarity Reversal signal to the system.
Page 31: Program 05-07-Ip : System Timing Parameters - 07
Program 05-07-IP : System Timing Parameters – 07 05-07-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description 0=Disable Intercom Searching 0=Disable Toll Override Prevention from Quick Dial 0=Enable Paging Alert Tone 0=Enable...
Page 32: Key Phone Toll Override Prevention
05. Key Phone Toll Override Prevention If the setting is Disable, after accessing a line a user will be able to use a DTMF generator directly to the network rather than the DTMF signal generated within the KSU. The result of this is that Toll restrictions can be over-ridden. If the setting is Enable, then no audio will be sent from the handset until 3 digits are received by the KSU from the key station dial pad preventing Toll restrictions being overridden.
Page 33: Program 05-08-Ip : System Timing Parameters - 08
Program 05-08-IP : System Timing Parameters – 08 05-08-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 3 0 3 0 7 1 4 3 Value Default Item Description 3=6 seconds. Ring Hunt Time 0=Enable DSS Access To Other Trunk Group 0=disable SLT Camp On Tone 0=Station Group...
Page 34: Console Of Disa Transfer Group For No Answer
04. Console of DISA Transfer Group for No Answer This parameter defines which console will be rung if an unsuccessful DISA call needs to be transferred. The called station must be set in Program 46-st-04 to decide what transfer action will be taken. IP \ Value Console of the Called Station's group Console of the Incoming Trunk's group...
Page 35: Music Source Selection
08. Music Source Selection This parameter sets the Music Source for the Internal Background Music, Music on Hold for CO line and Door phone music-type ringing signal. (Program 05-03-09=9) Value Door 05-08-08 Internal Music Internal Music Internal Music 05-08-08 External Music 05-08-08 Internal Music External Music...
Page 36: Program 05-09-Ip : System Timing Parameters - 09
Program 05-09-IP : System Timing Parameters – 09 05-09-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 1 1 0 0 0 0 1 Value Default Item Description Reserved 1=Enable Busy Console Queuing (Intercom Calls) 1= >80ms Clear Forward Signal (Loop Disconnect) Detection 0=Disable DISA Busy Tone Detection...
Page 37: Disa Busy Tone Detection
04. DISA Busy Tone Detection This setting allows system to recognize busy tone from the central office line during DISA call to release the call. Value Value description 05-09-04 Disable 05-09-04 Australia: (420 Hz, 375ms on/off) (400 Hz, 375ms on/off) 05-09-04 Italian: (420 Hz, 500ms on/off) 05-09-04...
Page 38: Program 05-10-Ip : System Timing Parameters - 10
Program 05-10-IP : System Timing Parameters – 10 IP =Item Pointer (01-08) 05-10-IP SYS PAR Value for each Item d d d d d d d d Value Default Item Description 0-9,*,#,p,d d= No Digit Leading Digit 1 For Voice Mail Forwarding 0-9,*,#,p,d d= No Digit Leading Digit 2 For Voice Mail Forwarding...
Page 39: Program 05-11-Ip : System Timing Parameters - 11
Program 05-11-IP : System Timing Parameters – 11 05-11-IP SYS PAR IP =Item Pointer (01-08) Value for each Item 0 0 1 0 0 2 5 0 Value Default Item Description 0=None DTMF Caller ID Leading Digit DISA Password – 1 / 50 Sets 1=MOH Select Music on Hold or Ring Back Tone DISA &...
Page 40: 05: Disa Special Function Access
05: DISA Special Function Access This parameter defines which system functions are able to be accessed by external DISA callers. Value Value description DISA caller can access an outside line by [9] + Password. 05-11-05 DISA caller can access mail box or VM from external call by [#] DISA caller cannot access an outside line by [9] + Password.
Page 41: Program 05-12-Ip : System Timing Parameters - 12
Program 05-12-IP : System Timing Parameters – 12 IP = Item Pointer ( 01-08 ) 05-12-IP SYS PAR Value for each Item 0 0 0 2 7 0 0 0 Value Default Item Description 0=Key Phone Call Transfer Method – Key Telephone Reserved 0=Yes Exclusive hold capability...
Page 42: Voice Mail Call Forward Protocol Selection And Muting Leading Digits
IP \ Value unit 05-12-04 sec. 05. Voice Mail Call Forward Protocol Selection and Muting Leading Digits This parameter selects between Standard Voice Mail Call Forward Protocol and the Enhanced Protocol. For a full description of Voice Mail Protocol see Program 05-10.It will also set the muting of the leading digits Setting Value VMS Leading Digit Type Short Long...
Page 43: Led Indication Of Check In / Check Out
07. LED Indication of Check In / Check Out This parameter disables or enables the LED indication for Check in/Check out features for the DSS consoles and DSS Keys of DK phones. IP \ Value 05-12-07 Disable Enable The LED indications are as follows: Description Red and slow flash If the Reception has checked out an extension, the LED for extension will slow flash red.
Page 44: Program 05-13-Ip : System Timing Parameters - 13
Program 05-13-IP : System Timing Parameters – 13 05-13-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 1 0 0 0 5 0 6 7 Value Default Item Description 1=Enable Intercom Hot Key Dialing 0=Disable Immediate SMDR output 0=52 Sets Caller ID Buffer Block Size Reserved...
Page 45: Reserved
04. Reserved 05. Caller ID Record Storing Method for LCD Phones This parameter defines which information shall be stored into the Caller ID buffer in the DK phone. IP \ Value Value Value Description 05-13-05 Store Caller ID telephone numbers. 05-13-05 Store Caller ID names 05-13-05...
Page 46: Program 05-14-Ip : System Timing Parameters - 14
Program 05-14-IP : System Timing Parameters – 14 05-14-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 0 0 0 0 6 0 0 Value Default Item Description 0=Disable SLT LCR Switch on Delay for PSTN Reserved Reserved Reserved...
Page 47: Program 05-15-Ip : System Timing Parameters - 15
Program 05-15-IP : System Timing Parameters – 15 05-15-IP SYS PAR IP = Item Pointer ( 01-08) Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description Company Greeting Time 0=3.1K ISDN FAX protocol Reserved Reserved Reserved...
Page 48: Reserved
03. Reserved 04. Reserved 05. Reserved 06. Reserved 07. Reserved 08. Reserved...
Page 49: Program 05-16-Ip : System Timing Parameters - 16
Program 05-16-IP : System Timing Parameters – 16 IP = Item Pointer (01-08) 05-16-IP SYS PAR Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description 0=Disable Midnight Reset Reserved 0=One Level DISA Single Digit Dialing Level 0=Disable VMU language Service Reserved...
Page 50: Vmu Language Service
04. VMU Language Service This parameter enables two language services for VMU. Value Value Description 05-16-04 Feature is disabled 05-16-04 Press 1 to select second language service. 05-16-04 Press 2 to select second language service. 05-16-04 …. ……………. 05-16-04 Press 8 to select second language service. 05-16-04 Play 1 Language then play 2...
Page 51: Program 05-17-Ip : System Timing Parameters - 17
Program 05-17-IP : System Timing Parameters – 17 05-17-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 1 0 0 0 0 0 0 Value Default Item Description Reserved 1=32k Voice Compression 0=No Extension Number Announcement for DISA DISA &...
Page 52: Dtmf Caller Id Leading Digits
05. DTMF Caller ID Leading Digits This parameter enables/disables the display of leading digits on DTMF Call ID IP \ Value 05-17-05 Note 1 code Note: 1. Only display normal digits (0,1,2,.., 9) Example: D0289661356C Leading code =D Trailing code = C 06.
Page 53: Minimum Mail Box Record Time
Associated program modes 09, 05-05-05, 05-14-06, 43-51-05, 43-52-05, 43-53-05 08. Minimum Mail Box Record Time Some callers will after hearing a personal greeting and then the Beep hang up after a short period. This will then leave a short message usually of silence followed by the sound of a handset being replaced. This parameter will allow messages that do not reach a certain length to be deleted.
Page 54: Program 05-18-Ip : System Timing Parameters - 18
Program 05-18-IP : System Timing Parameters – 18 05-18-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 0 0 0 0 0 8 5 Value Default Item Description Reserved Hotel Alarm 0=Disable Dial out History Feature 0=Bellcore/ETSI Caller ID Compatibility Reserved...
Page 55: Caller Id Compatibility (Canada)
04. Caller ID Compatibility (Canada) Most telco central offices have adopted the Bellcore/ETSI standard for MDMF (Name and Number) Caller ID. However, there are some central offices in Canada which still utilize an obsolete Canadian only standard called Stentor. This parameter alters the Caller ID reception to support Stentor. IP \ Value 05-18-04 Bellcore/ETSI...
Page 56: Program 05-19-Ip : System Timing Parameters - 19
Program 05-19-IP : System Timing Parameters – 19 05-19-IP SYS PAR IP = Item Pointer (01-08) Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description Reserved Reserved Reserved 0=Disable VMU Silence Detection 0=Australia Distinctive Ring Selection Australia or New Zealand Reserved Reserved...
Page 57: Program 05-20-Ip : System Timing Parameters - 20
Program 05-20-IP : System Timing Parameters – 20 IP = Item Pointer (01-08) 05-20-IP SYS PAR Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description 0= Disable VMU Mailbox Delete All Messages (g1-A52x) DISA No Digits Dialed Destination (g1-A52yb5) Reserved...
Page 58: Program 06-Ip : Relay Assignment
Program 06-IP : Relay Assignment 06-St-01 Relay St= Station Number Value for each Item Item Value Relay Description 00-06, 10, 11-18 Relay of Motherboard (Optional) 00-06, 10, 11-18 Relay of ACP (extension: xxx) Description: Relays on the Motherboard and ACP are dry-contact type relays. The relay provides no power, only a switching function.
Page 59: Program 07-Gp-Ip : Flexible Key Group Assignment
Program 07-Gp-IP : Flexible Key Group Assignment 07-Gp-IP KEY GRP Gp (Group)= 01-08, IP= (Item Pointer) 01-39 (DSS key number) TK= Trunk number (nn) TK: nn Gp (Group)= 01-08, IP= (Item Pointer) 01-39 (DSS key number) 07-Gp-IP KEY GRP xxx= Station number 07-Gp-IP KEY GRP Gp (Group)= 01-08, IP = (Item Pointer) 01-39 (DSS key number) FN: Function Number (ff)
Page 60: Dk6 - 36 Button Layout
DK6 – 36 Button Layout The Function for each FN Code FN Code Function FN Code Function One Touch DSS Speed Dial Program Do Not Disturb/Conference Message Waiting/Pulse-Tone/Call VMU Microphone/AUTO answer Speed Dial SAVE Redial Volume Up Forced Account Code Voice Set up User Speed Dial Set Up Console User Speed Dial Set up...
Page 61 Note: 1. [MSG] key: Message. It is assigned as default function key. When a message is left on your DK phone, this [MSG] key will be flashing. First situation (46-st-02 = 1~9): Extension call you and presses [MSG] on their phone when you are not available. Your [MSG] key will be flashing, pressing this flashing key will call back the caller automatically.
Page 62: Program 08-Gp-Ip : Flexible Dss Console Key Group Assignment
Program 08-Gp-IP : Flexible DSS Console Key Group Assignment 08-Gp-IP KEY GRP Gp (Group)= 01, IP = (Item Pointer) 01-66 (DSS key number) TK= Trunk number (nn) TK: nn 08-Gp-IP KEY GRP Gp (Group)=01, IP= (Item Pointer) 01-66 (DSS key number) xxx= Station number 08-Gp-IP KEY GRP Gp (Group)=01, IP= (Item Pointer) 01-66 (DSS key number)
Page 63: Program 09-Nnn-Dp : System Speed Dial
Program 09-nnn-DP : System Speed Dial 09-nnn-DP TK:tt mm nnn = 100-999 DP = 01-30 tt = 01-12 mm = 40-43 nnnnnnnnnnnnnnnn Telephone number General: This program permits the assignment of up to 900 sets of system speed dialing codes. If Names are enabled (default) then only 500 Speed dials are available.
Page 64: Program 10-Gp-Ip : Intercom Single Digit Assignment
Program 10-GP-IP : Intercom Single Digit Assignment Gp = 01-08, IP = Item Pointer (01-05) 10-Gp-IP S.D.I. Station number for single digit dialing (1 to 5) 000 000 000 000 000 General: This program permits calling party to call one or more stations by dialing one digit only. The settings in this Program shall be enabled by Single Digit Intercom (Refer to Program 05-04-07).
Page 65: Program 11-Ip : Date And Time Setting
Program 11-IP : Date and Time Setting 11-IP Date/Time IP =Item pointer (01-06) Value for each Item 08 27 06 18 16 4 Value Item Description 11-01 01-12 Month...... 11-02 01-31 Day......11-03 00-99 Year....... 11-04 00-23 Hour....... 11-05 00-59 Minute.....
Page 66: Program 13-Nn : Password
Program 13-nn : Password nn = Assigned Password Number (01-08) 13-nn Password Setting password dddddddd General: This program permits the assignment of 9 different passwords in the system. Description: The password length is from 1 to 8 digits. All unused digit positions must be padded with ’d’. Password Description Programming Password.
Page 67: Program 14-01-Ip : Smdr Specifications
Program 14-01-IP : SMDR Specifications IP = Item Pointer (01-08) 14-01-IP S.M.D.R. Value for each Item 0 0 0 0 0 21 0 0 Value Default Item Description 0=00 Sec. Call Duration Start Time 0=Record Record Incoming Call 0=Record Record Local Call 0=Record Record Incoming Call No Answer 0=Yes...
Page 68: Number Of Records Between The Title
06. Number of Records between the Title This parameter defines the number of records between each Title. It means the total lines of record per page. A setting of 00 will cause a heading to be printed with each call record. 07.
Page 69 CASE EXPLANATION: CASE October 2, 08:35 A.M., Station 112 made a call (telephone No. is 00116495256611) through line 1. The call lasted 2 minutes and 35 seconds, Account code No. 12345678 was entered for the call and 12-meter pulses were recorded. October 2, 08:45 A.M., An incoming call on line 2, rang for 10 seconds, station 115 answered the call and stored an Account No.
Page 70 SMDR OUTPUT DATA FORMAT - With CLI Output TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT 112 01 001188629645752 12345678 10/02 08:35 00:02'35" 00012 112 02 DDI Num:94150112 10/02 08:45 00:10'20" 00'10" CLI NoAns:294176288 10/02 12:00 00:00'00" 00'35" 111 05 CLI Num: 294150100...
Page 71: Program 17-Nn : Forced Account Code
Program 17-nn : Forced Account Code 17-nn FAC CODE nn = Forced Account Code (01-99) FAC code (8 digits max.) Toll class: d(Day) d(Night) __________ dd General: This program creates 99 Forced Account codes. Description: The use of forced account codes allows a station user to temporarily bypass the toll restrictions. If a Forced Account Code is assigned to a station during system programming, it becomes the only code capable of bypassing that station’s default toll restriction.
Page 72: Program 18-Nn-Tk : Assign Toll Plan To Trunk Lines
Program 18-nn-TK : Assign Toll Plan To Trunk Lines 18-nn-tk Toll nn = Toll Plan number (00-09), tk = Trunk No. (01-12) Toll class for each trunk (class 0-9) 0000000000 General: Toll Plan allows the assignment of dialing capabilities dependent upon specific CO lines as well as individual stations. This can be used to restrict dialing capabilities from some stations and to limit specific types of calls to certain special purpose telephone lines.
Page 73: Program 20-Nn- : Set Day - Time / Lunch Time Schedule
Program 20-nn- : Set Day – Time / Lunch Time Schedule 20-nn Day Time nn = Day schedule pointer (00-06) Setting data 00 00 00 00 00 00 00 00 General: This program assigns day, night and lunch time from Sunday to Saturday for automatic night switching. Description: The system is capable of switching automatically between Day / Lunch break / Night settings using the time parameters set in this program.
Page 74: Program 25 : Reset Data To System Default
Program 25 : Reset Data to System Default 25 - Reset Data 0 - 9 Default General: This program resets all data to System Default. All new systems must be reset to default before any programming in case corruption has been caused during handling or shipping. It will also be necessary to reset to default after a software upgrade is installed.
Page 75: Program 29-Tk-Ip : Trunk Specifications - 2
Program 29-tk-IP : Trunk Specifications – 2 Tk=Trunk No. (01-12), IP = Item Pointer (01-08) 29-tk-IP TK SPEC Value for each Item 0 0 0 2 0 0 0 0 Value Default Item Description 0= 0 db Trunk Receive Gain 0=Disable ACD-1 Function Enable 0= 0db...
Page 76: Set Ring Frequency (Dk Handsets)
04. Set Ring Frequency (DK Handsets) This feature allows each trunk to ring at DK handsets with its own individual ring frequency and override the frequency set by the user for all calls. IP \ Value 29-01-03 As per the key phone’s ring setting. Use the ringing frequency 1~8 of key phone as the trunk’s ring. 05.
Page 77: Program 35-Tk-Ip : Trunk Specifications - 1
Program 35-tk-IP : Trunk Specifications – 1 35-tk-IP TK SPEC tk =Trunk No. (01-12), IP = Item Pointer (01-08) 0 1 0 0 3 0 0 0 Value for each Item Value Default Item Description 0=CO Trunk Type 1=DTMF Dialing Signal 0=No External Call Forward 0=No...
Page 78: External Call Forward - Ecf
03. External Call Forward – ECF External Call Forwarding allows an incoming CO line to be re-directed to another location through the use of another CO line. When a CO line senses incoming ringing, it answers the call and accesses another CO line. It then selects a pre-programmed system speed dial number, dials the call and connects the two CO lines together.
Page 79: Loud Bell
06. Loud Bell Refer to Program 06 to assign Relay to operate for a Loud Bell. Value Value Description 35-tk-06 No Operation. 35-tk-06 Relay on Motherboard / ACP will be activated when the trunk is ringing. Note: The system does not provide any voltage from the assigned relay. A separate ring voltage and ring device will need to be provided by the installer 07.
Page 80: Inward Line Ringing Method Assignment (Night)
08. Inward Line Ringing Method Assignment (Night) As described in Program 02-tk-IP, there are four ringing methods plus a Private line setting: All settings in item 08 are the same as item 07. Value Value Description 35-tk-08 Night - COMMON AUDIBLE 35-tk-08 Night - LINEAR 35-tk-08...
Page 81: Program 36-Gp-Tk : Trunk Group Assignments
Program 36-gp-tk : Trunk Group Assignments 36-gp-IP TK GRP gp = Group (01-08), IP = Item Pointer (01-12) trunks to be included 04 03 02 01 00 General: This program permits each trunk line to be assigned to different Trunk groups. There are eight groups in total. Description: In the bottom data-setting area, the trunk number (01-12) means that the trunk is included in the specified group.
Page 82: Program 37-Tk : Busy Out Trunks
Program 37-tk : Busy Out Trunks tk = Trunk No. (01-12) 37-tk Busy Out Busy out Type 0000000000 General: This program permits the trunk line to be locked by a Technician. Description: This feature is used when the user does not want to use the trunk or to remove a problem line. When the trunk is set to BUSY OUT, the LCD display on the phone will display "Access denied "...
Page 83: Program 38-Gp-Tk : Dial 87 Trunk Group Assignments
Program 38-gp-tk : Dial 87 Trunk Group Assignments gp = Group (01-08), IP = Item Pointer (01-12) 38-gp-IP TK GRP Trunks to be included 01 02 03 04 05 General: This program permits each trunk line to be assigned to different Trunk groups which can be accessed by dialing [87]. There are 8 groups in total.
Page 84: Program 39-Ip : Sensor Assignments
Program 39-IP : Sensor Assignments 39-STN-IP Sensor STN = Station No. ( 00 / 000 / 0000) 2/3/4 digits sensor on the motherboard FN S STN = ACP station number 39-STN-IP Sensor Sensor on the ACP FN S Value Item Description 39-STN-01 00-18 Function No.
Page 85: Program 40-Stn-Ip : Station Class Of Service - 1
Program 40-stn-IP : Station Class of Service – 1 40-stn-IP STCOS stn = Station No.(2-4 digits), IP = Item Pointer (01-08) Value for each Item 0 0 0 0 0 0 0 00 Value Default Item Description 0= Not allowed Override Level 0= Not allowed Monitor Level...
Page 86: Station Loud Bell
04. Station Loud Bell Refer to Program 06 to assign Relay to operate for a Loud Bell. Value Default 40-stn-04 No operation 40-stn-04 Operate relay on the motherboard when calls are received on this station. The system does not provide any voltage from the assigned relay. A separate ring voltage and ring device will need to be provided by the installer.
Page 87: Program 41-Stn-Ip : Station Specifications
Program 41-stn-IP : Station Specifications stn = Station No.(2-4 digits), IP = Item Pointer (01-07) 41-stn-IP STSPE Value for each Item 1 1 0 1 0 0 SN Value Default Item Description Station Group Key Group For Key phone 0=None Shift Key Group For Key phone Dial 9 trunk group Toll plan - Day...
Page 88: Dial 9 Trunk Group/ Slt Port As Moh Source
04. Dial 9 trunk group/ SLT Port as MOH Source When a station selects a trunk line by dialing 9, the system finds an available trunk according to the dial 9 group assignment. If a trunk is not in a stations assigned dial 9 group then the station will not be able to make outgoing calls on that trunk.
Page 89: Program 42-Stn-Ip : Register Memory Blocks For Individual Speed Dial
Program 42-stn-IP : Register Memory Blocks for Individual Speed Dial st = Station No. (2-4 digits) IP = Item Pointer (01-02) 42-stn-IP SPD-T blocks (2 max.) for a Station b1 b2 Block 1 of Individual Speed Dial Codes (00-09 or DSS11~DSS20) Block 2 of Individual Speed Dial Codes (DSS1-10) (Digital phone only) General: This program divides sets of Individual Speed Dial into blocks for use by Stations.
Page 90: Program 43-Cn-Ip : Port Specifications
Program 43-cn-IP : Port Specifications 43-pn-IP Port pn = Port No. (2 digits) IP = Item Pointer (01-06) Value for each Item nnnn 0 1 0 00 02 pn = Port Number (11-56) 11~18: station port on G1E-MBU 21~28: station port on the 1 G1E-STU card.
Page 91: Flexible Dss Key Group Assignments For Dss Console
be placed on hold by one of the extensions and retrieved from the other or can be transferred to other extensions by the normal method. The Station COS of the digital phone will be allocated to the SLT automatically. 3) Type 7 allows an SLT port to be used as an additional MOH input allowing tenanted systems to have different messages played to different trunk groups during Call Hold.
Page 92: Maximum Message Length
Description: 1. pn= Port Number of Station. 2. The pn of virtual mail box is: 51 to 56 Each voice unit has 30 or 120 seconds storage depending on CF card and Compression rate. Memory is 128MB / 32 Kbps compression rate: 915 voice units, each voice unit is 30 seconds, total 7.63 hours storage time.
Page 93: Program 44-Stn-Ip : Station Class Of Service - 2
Program 44-stn-IP : Station Class of Service – 2 44-stn-IP STCOS stn = Station No. (2-4 digits), IP = Item Pointer (01-08) Value for each Item 0 0 0 0 1 0 0 0 Value Default Item Description 0=Enable System Alarm 0=Enable Hold feature 0=Enable...
Page 94: Manual Line
04. Manual Line If the setting is enabled, lifting the handset of the station will call the operator directly without dialing any digits. IP \ Value 44-stn-04 Disabled Enabled 05. Headset Feature When headset feature is enabled by the user (code is [SPK] [775]) they can then use the [SPK] key to go on or off hook.
Page 95: Program 45-Stn-Ip : Station Class Of Service - 3
Program 45-stn-IP : Station Class of Service – 3 Stn=Station No. (2-4 digits), IP = Item Pointer (01-08) 45-stn-IP STCOS Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description 0=Disable Intercom Call Limitation 0=No ACP hear BGM at idle state 0=No...
Page 96: Intercom Calls To Different Station Groups
05. Intercom Calls to Different Station Groups If this function is disabled then stations will not be able to make intercom calls outside their own station group (Mode 41-st-01). This parameter is for use in tenancy arrangements where each company wish's to remain totally separate although some stations can still be allowed this function, for instance a shared Receptionist.
Page 97: Program 46-Stn-Ip : Station Class Of Service - 4
Program 46-stn-IP : Station Class of Service – 4 46-stn-IP STCOS stn= Station No. (2-4 digits), IP = Item Pointer (01-08) Value for each Item 1 1 2 3 0 7 d 0 Value Default Item Description 1= 1 Dial [87] Trunk Group 0= 1 Send Message Wait Signal Level 0= Auto Answer /MIC Off...
Page 98: Automatic Answer Capability (Keyphone) / Internal Cli (Caller Id) Function
03. Automatic Answer Capability (Keyphone) / Internal CLI (Caller ID) Function For Digital Key Telephone This parameter if enabled will automatically switch on the microphone of the station if it receives an intercom call. This setting is independent of whether the system is set to voice or ring signalling for intercom calls. Value Value Description 46-stn-03...
Page 99: Acp Door Phone Hunt Group / Permanent Call Forward Group - No Answer
07. ACP Door Phone Hunt Group / Permanent Call Forward Group – No Answer IP \ Value 46-st-07 Group 1 Group 2 Group 3 Group n+1 Program 3 This parameter allocates the Station Hunt Group that the ACP will call if it is programmed as a Door Phone and the Call button is pressed.
Page 100: Program 47-Stn-Ip : Hot Line Assignment
Program 47-stn-IP : Hot Line Assignment 47-stn HOT LINE St = Station No. (2-4 digits) Data. ( Extension Mode ) St= Station No. (2-4 digits) 47-stn HOT LINE Data. ( Speed Dial Mode ) SPD:000 General: This feature allows a user to lift the handset and directly call a specific outside party through System Speed Dial or an Intercom Extension without dialing any digits.
Page 101: Program 48-Stn-Ip : Station Class Of Service - 5
Program 48-stn-IP : Station Class of Service – 5 stn=Station No. (2-4 digits), IP= Item Pointer (01-08) 48-stn-IP STCOS Value for each Item 0 0 0 0 0 0 0 0 Value Default Item Description 0= Disable Automatically Record Incoming trunk calls 0= Disable Automatically Record Outgoing trunk calls 0= Enable...
Page 102: Reserved
hear the oscillation noise on the speaker. Pressing [MIC] key twice to mute the handset’s microphone will eliminate this noise. Definition of Parameter: IP \ Value 48-stn-03 Enable Group Listen Disable Group Listen 04. Reserved 05. Reserved 06. Reserved 07. Reserved 08.
Page 103: Isdn Incoming Call Display Type-Digital Phone
IP \ Value 50-stn-02 Disable Enable 03. ISDN Incoming Call Display Type-Digital Phone: This parameter selects what will be displayed on the screen of an LCD phone when an incoming call is received, either the CLI number or the ISDN In dial number. This will also select what will be displayed on the SMDR output for incoming calls.
Page 104: Acp Phone Operation / Hotel Alarm Type
08. ACP Phone Operation / Hotel Alarm Type This parameter offers two features: When the extension is an ACP phone, the Phone Operation Type is as follow: Value Value Description 50-stn-08 Door Phone 50-stn-08 Wall Mounted Phone Description: 1. Door Phone: Pressing [Bell] button on the ACP will call assigned extension according to Program 3.
Page 105: Program (51 To 59)-Code-Ip : Toll Plans - Allowed Digits - Class 1 To 9
Program (51 to 59)-code-IP : Toll Plans – Allowed Digits – Class 1 to 9 51-code-01 Allow Code=Code No. (01-16), IP = Item Pointer (01-12) Value for the Item - - - - - - - - - - - - - General: This program sets allowed exception numbers for Toll Class 1.
Page 106: Program (61 To 66)-Code-Ip : Toll Plans - Restricted Digits - Class 1 To 6
Program (61 to 66)-code-IP : Toll Plans – Restricted Digits – Class 1 to 6 61-code-01 Restrict code= Code No. (01-16), IP =Item Pointer (01-12) Value for the Item dddddddddddd General: This program sets Restricted numbers for Toll Class 1. These Modes should be read in conjunction with Modes 51 to Description: There are 16 codes for each Toll Class and each code contains up to 12 digits In default any station allocated to Toll Plans 1 to 6 will be able to dial unrestricted until the associated Modes are...
Page 107: Program 67-Gp-Ip : Hunt Group Pilot Number
Program 67-gp-IP : Hunt Group Pilot Number Gp = Group No. (01-10) 67-Gp HUNT NO Value for each Item - - - 0 Value Default Item Description 00-10 _ _ _ Hunting Group Pilot Number 0 = Common Hunting Group Ring Method This program sets Pilot Numbers for Hunting Groups 1 to 10 and their ringing method.
Page 108: Program 68-Gp-Ip : Hunt Group Assignment - Day
Program 68-gp-IP : Hunt Group Assignment – Day Gp = Group No. (01-10), IP = Item Pointer (01-16) 68-Gp-IP HUNT DA Value for each Item 000 000 000 000 General: This program sets Stations into Hunting Groups 1 to 10 for the G1E and assigns the order in which they will be accessed during Daytime.
Page 109: Program 69-Gp-Ip : Station Hunt Group Assignment - Night
Program 69-gp-IP : Station Hunt Group Assignment – Night Gp = Group No. (01-10), IP= Item Pointer (01-16) 69-Gp-IP HUNT NI Value for each Item 000 000 000 000 General: This program sets Stations into Hunting Groups 1 to 10 for the G1E assigns the order in which they will be accessed during Night time.
Page 110: Program 70-Cd-Ip : Isdn Interface Specifications Program - G1E
Program 70-Cd-IP : ISDN Interface Specifications Program – G1E Cd = 01-04, IP = Item Pointer (01-06) 70-Cd-IP S/T TYP Value for each Item 111111 General: To assign the ISDN interface to “S” interface or “T” interface. Description: Cd= 01 is to assign the “S” or “T” interface for the ISDN port on G2-SIU card Value Value Description 70-01-IP...
Page 111: Program 71-Cd-Ip : Calling Line Identification Presentation
Program 71-Cd-IP : Calling Line Identification Presentation 71-Cd-IP CLIP Table Cd = 01-06, IP = Item Pointer (01-12) Value for each Item dddddddddddd General: To assign up to 6 specific numbers that an extension can present to the Exchange on an outgoing call. Description: This parameter can substitute CLIP information that will be presented to the Exchange when a Station makes an outgoing call.
Page 112: Program 72-St : Isdn Called Party Extension Number Assignment
Program 72-St : ISDN Called Party Extension Number Assignment Stn= Station Number (2-4 digits) 72-Stn ST NUM Value for each Item dddddddddddd 00 General: To assign an ISDN MSN/DDI number to a station or station hunting group. Description:  Each incoming ISDN MSN or DDI number can ring a station or a hunting group. ...
Page 114: Program 75-Num-Ip : Lcr - Analysis Table
Program 75-Num-IP : LCR - Analysis Table Num = Number (001-500) 75-Num-IP Dg Tab Value for each Item ---------- Value Default Item Description 01-10 0~9, *,#,_,d _,_,..,_ Number of routing analysis 11-12 01~20 Routing Table General: This program assigns the routing table for the specific dialed number. Description: 500 specified dialed numbers can be assigned.
Page 115: Program 76-Num-Tm : Lcr - Routing Table
Program 76-Num-Tm : LCR – Routing Table 76-Num-Tm Rou Ta Num = 01~60 Tm = Time Schedule (A, B, C) 00 00 0 00 0 00 Setting Value Value Default Item Description 01,02 00~23 Start Hour of this Route Table 03,04 00~23 End Hour of this Route Table...
Page 116: Program 77-Num : Lcr - Modifying Table
Program 77-Num : LCR – Modifying Table 77-Num-IP Mo Tab Num = Number (01~99) Value for each item 00 dddddddddd Value Default Item Description 01-02 00~10 Deleted Digit Length 03-12 0~9, *,#, -, d, T, p dddddddddd Added Digits General: This program designs the rules for changing the dialed number to the routed number.
Page 117: Program 78-Stn-Ip : Station Class Of Service - 6
Program 78-stn-IP : Station Class of Service – 6 78-stn-IP STCOS stn= Station No. (2-4 digits), IP=Item Pointer (01-08) Value for each item 0 0 0 0 0 0 0 0 Value Default Item Description 0= Disable LCR LCR - Routing Level 0= Not Allowed LCR –...
Page 118: Call Forward Busy Transfer Group
04. Call Forward Busy Transfer Group This parameter sets the Permanent Call Forward on Busy to destination Hunt Group for the Station. If the Station user sets a Call Forward manually then it will override this setting but after cancelling the manual Call forward then this setting will be enabled again.
Page 119: Program 83-St-Ip : Register Memory Block For Cli History Buffer
Program 83-st-IP : Register Memory Block for CLI history buffer 83-stn-IP CLI-T Stn=Station No. (2-4 digits), IP =Item Pointer (01-02) blocks (2 max.) for a Station b1 b2 b1/b2 : Block 1/2 of CLI buffer for each extension General: This program divides sets of CLI history buffer into blocks for use by extensions. Description: Program 05-13-03, the Individual CLI history buffers are assigned: ...
Page 120: Program 84-Ip : Home Area Code
Program 84-IP : Home Area Code NNN = Assigned home area code (3 digits maximum) 84-01-01 General: This program assigns the home area code for the CLI redial feature. Description: 3-digit input maximum for this entry.  The home area code can include the toll access code prefix. ...
Page 121: Program 86-Nnn-Ip : Office Code Redial Pattern
Program 86-nnn-IP : Office Code Redial Pattern 86-nnn nnn = office code N = Redial Pattern General: This program assigns the redial pattern for different office codes. Description: Item Description Redial pattern is NXX-XXXX (Local call: 7 Digit) Redial pattern is 1-NXX-XXXX (Local Toll: 1 + 7 Digit) Redial pattern is 1-NXX-NXX-XXXX (Local Toll: 1 + 10 Digit) CID Redial Feature for USA Market Retrieve the...
Page 122: Program 87-Cn-Ip : Assign Door Phone For Key Card
Program 87-CN-IP : ASSIGN DOOR PHONE FOR KEY CARD nn=Key card Number (01~99), IP=Item Pointer (01-24) 87-nn-01 Card In Setting for each ACP 000000000000000 General: This program assigns which Key cards (RFID) can be used on which ACP port to unlock a door. Description: Before a key card can be used to operate a door relay it must be set to be allowed in this program mode.
Page 123: Program 88-Dp : Register Key Card
Program 88-DP : REGISTER KEY CARD Station number of ACP Register Card ST:___ This program registers key cards for use. The station you enter in this field is the extension number of the ACP which you will use to activate the card. It only tells the system which ACP you are using to register the card into the system database.
Page 124: Program 89-Cn-Ip : Delete Key Card
Program 89-CN-IP : DELETE KEY CARD 89-nn-01 Serial nn = card number FFFFFFFF General: This program assigns allows the De-registration of the key cards from a system. Description: Enter the number (01-99) of the key card to de-register De-Register Card Card:01 Press SAVE 89-01-01 Serial...
Page 125: Program 91-Tm : Acp Time Lock - Assign Time
Program 91-TM : ACP TIME LOCK – Assign Time 91-TM Table TM = Time Schedule (00~15) 00 00 00 00 General: This program assigns different time schedules for the ACP time lock. Cards assigned in such programmed period can be used to open the ACP door. Description: The first 4 digits are starting time and the last 4 digits are stopping time.
Page 126: Program 93 : Not Used In North America
Program 93 : Not Used in North America...
Page 127: Program 94-Tk-Ip : Lunchtime Ringing And Ringing Line Preference Assignment
Program 94-tk-IP : Lunchtime Ringing And Ringing Line Preference Assignment 95-tk-IP FLX DAY Tk =Trunk No. (01-12), IP=Item Pointer (01-26 ) Assigned station number 11 12 13 14 15 General: This program assigns each incoming line to ring the programmed stations during Lunch Time. The ringing methods can be: LINEAR (ring the first available station), CIRCULAR (Ring the next station following the last station who just answered an incoming call),...
Page 128: Program 95-Tk-Ip : Trunk Specifications - 3
Program 95-tk-IP : Trunk Specifications – 3 95-tk-IP TK SPEC Tk=Trunk No. (01-12), IP=Item Pointer 01-08) 0 0 0 0 0 0 0 0 Value for each Item Value Default Item Description 0=Disable Detect Fax Signal Reserved Reserved 0=No DISA & ECF Lunch Time Enable Reserved Reserved Reserved...
Page 129: Reserved
02. Reserved 03. Reserved 04. DISA & ECF Lunch Time Enable This parameter will enable the DISA or ECF during the lunch time or not. As to the setting for Day will be assign at Program 35-tk-03. Night is Program 35-tk-04 respectively. IP \ Value 95-tk-04 Disable...
Page 130: Programming Cross Reference
Programming Cross Reference Incoming Calls Ringing Assignment Item Description 01-tk-stn Day Ringing And Ringing Line Preference Assignment 02-tk-stn Night Ringing And Ringing Line Preference Assignment 05-01-05 Busy Reminder Tone Interval (Off-Hook Ringing / Busy - Camp-On) 05-02-07 Ring On Timer (Minimum ring to be detected) 05-02-08 Ring Off Timer (Time to hold signal during silent period) 05-08-01...
Page 131 35-trk-01 Trunk Type (PABX/CO) 35-trk-02 Trunk Signalling Type (dial pulse/DTMF)
Page 132: Speed Dial
Speed Dial Item Description 05-01-06 Pause Duration for Speed Dial pauses 05-03-02 Automatic Trunk Search During Speed Dial, Auto Redial, Saved Redial, etc. 05-04-06 Speed Dial Distribution 05-05-03/04 Speed Dial Unrestricted / system 09-spd-xx System Speed Dial Locations 42-stn-01/02 Register Memory Block for Personal Speed Dial 45-st-07 Speed Dial Unrestricted / Station Auto-Redial...
Page 133: Busy/During Conversation
Busy/During Conversation Hold and Hold Recall Item Description 05-01-01 Hold Recall Timer (Time until station is warned of hold call) 05-01-02 Exclusive Hold Recall Timer (Same operation as hold recall) 05-01-03 Hold Recall Time out (Time before call is rerouted to Operator - After Hold Recall Timer has expired.) 05-07-04 DISA Recall Capability...
Page 134: Night Service
DISA S INGLE IGIT IALING Item Description 05-11-08 DISA Single Digit Dialing 20-nn Day/Night Service Schedule Night Service Item Description Night Ringing And Ringing Line Preference Assignment 09-spd-nn System Speed Dial 101~109 for ECF 20-nn Day/Night Service Schedule 35-tk-03 External Call Forward Location (Speed Dial Assignment) 35-tk-04 DISA/ECF, Day/Night Status Group Assignments...
Page 135: Call Control
Call Control Toll Restriction Item Description 05-05-03 Set a portion of system speed dial for no restriction (Hundreds) 05-05-04 Set a portion of system speed dial for no restriction (Tens) 05-03-05 Toll Access Code (Usually a ‘0') for SMDR only 18-pln-trk Assigning Toll Class by Toll Plan/Trunk used 41-stn-05...
Page 136: System Clock
System Clock Date and Time Setup 05-04-04 12/24 hour time format Set system time 20-nn Day/Night schedule Definition System Alarm 12-nn System Alarm Clock 44-stn-01 Stations to include (notify) in system alarms Wake Up calls 05-05-01 Wake up signalling type Station Numbering 05-03-06 Digit length selection (2, 3, or 4 digits)
Page 137: Hot Line
Hot Line 09-spd-nn System Speed Dial number for Hot Line use 47-stn-xx Hot Line destination for a station Optional Services Door phone & Door switch 03-01-ext Stations to ring upon Door Phone Activation 05-12-04 Door Relay Activation Timer 06-01-fn Relay Assignment (for Door Phone latch release) Voice Mail Integration Item Description Day Ringing Assignment...
Page 138: Operation
ACD-1 operation ACD-1 operation is best described as Operator Overflow handling for incoming calls. It operates on any inbound ringing trunk except for Direct In dial calls ringing their assigned station. It does not allow the caller to dial a destination.
Page 139: Disa And Auto Attendant Operation
DISA and Auto Attendant operation DISA operation includes the Auto Attendant for handling Caller selected routing for incoming calls and the option to dial through the system utilizing system trunks to dial another destination.. It operates on any inbound ringing trunk except for Direct In dial calls ringing their assigned station.
Page 140: Recording Disa Messages
Recording DISA Messages A Console must be used to record messages. In default the Console station is 111. From the console dial 8901 and follow the voice prompts to record Company Greeting messages. Full instructions for recording greetings are given by the Voice prompts.
Page 141: Programming Single Digit Disa
DISA is enabled on a trunk by trunk basis in Mode 35-tk-04. The options are as follows: Day Time Night Time Disable Disable Disable DISA Enable DISA Enable Disable DISA Enable DISA Enable Disable ECF Enable ECF Enable Disable ECF Enable ECF Enable DISA Enable ECF Enable...
Page 142: How Can I Use An Acp
How can I use an ACP? Simple door phone with door unlock from internal extensions only. A door phone with door unlocking by code from the door phone. A door phone with unlocking by proximity card from the door phone. A door phone with unlocking by proximity card AND/OR code from the door phone.
Page 143 How to set up as a door phone. The door phone can be connected to any Digital port on the system. There is an A/B jumper on the PCB to select Port 1 or Port 2. When the phone is installed, if the Call button is pushed without any programming, the user will hear an error tone.
Page 144 1562 Park Lane South, Suite 400 Jupiter, FL 33458 http://www.transtelcommunications.com All data and specifications are subject to change without notice.

TransTel Communications G1E+ User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for TransTel Communications G1E+

Summary of Contents for TransTel Communications G1E+

Table of Contents
