  • Page 1 USER MANUAL Installation and Programming Model: IP39-80 v. 2.1 www.transtel.co...
  • Page 2 Notification Notification is hereby given that Auto Telecom Company reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, Auto Telecom Company makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose.

  • Page 3: Table Of Contents

    Table of Contents IP39-80 NGT USER MANUAL ..................1 Installation for Stand .................... 1 Installation for Tablet .................... 2 Un-Installation for Tablet ..................3 Un-Installation for Stand ..................3 Top View & Description ..................4 Rear View & Description ..................6 Operation for IP39-80 ...................

  • Page 4: Ip39-80 Ngt User Manual

    IP39-80 NGT User Manual 1. Installation for Stand www.transtel.co...

  • Page 5: Installation For Tablet

    2. Installation for Tablet www.transtel.co...

  • Page 6: Un-Installation For Tablet

    3. Un-Installation for Tablet 4. Un-Installation for Stand www.transtel.co...

  • Page 7: Top View & Description

    5. Top View & Description Function Keys: Back Home Recents Sleep / Wake Massage (Access the voice mailbox in the PBX) Call history DND, Activate or deactivate the “Do Not Disturb” function Mute/MIC, Turn the microphone On or Off of the Handsfree or Handset Redial the previously dialed numbers Conference, Operate the “Conference”...
  • Page 8 Volume Down, Turn down the volume Volume Up, Turn up the volume SPK, Activate or deactivate the dialing function. Answer the call without lifting the handset. Hold, Put the current call on hold TRF, During a call, this key offers the “Transfer” function www.transtel.co...

  • Page 9: Rear View & Description

    6. Rear View & Description External power supply 5VDC 3A input (if no POE applied) POE/LAN connection PC Port USB port USB port Headset Jack Push to remove tablet from docking Hardware Reset Volume Down/Up 10. Power key 11. Camera 12.

  • Page 10: Operation For Ip39-80

    7.1.2 DSS Direct Dial The DSS feature of the IP39-80 must be set up before the user can use it. The [DSS/BLF] buttons indicates the status of the assigned stations (online, offline, busy, or idle). The user can call that station by simply pressing the respective [DSS/BLF] button.

  • Page 11: Call Pickup

    7.2.2 Call Pickup This feature allows a user to answer a call ringing at another station. As extensions are assigned into different groups, Call Pickup can be done in two different ways: ■ Pick up a call in the same group: Lift the handset or press the [SPK] key.

  • Page 12: During Conversation

    [TRF/FL] key or On hook to transfer the call. If the transference is declined, the user can press the [HOLD] key to resume conversation with the held caller. Or… Press the [TRF/FL] key or On hook to immediately transfer the call. 7.4 During Conversation 7.4.1 Mute...

  • Page 13: Three-Way Conference

    7.4.4 Three-way Conference Establish a call with party A. Press the [ Hold ] key to place party A on hold. Establish a call with party B, and press [ CNF] key. Party A, B and the caller are now in a three-way conference. Hang up the phone to end the conference.

  • Page 14: Ip39-80 Ngt Programming Manual

    IP39-80 NGT Programming Manual You have to set your SIP account like username, password and domain/IP address then Apply for first time NGT app running. www.transtel.co...
  • Page 15 Press then to change more parameters of SIP setting. Press Exit after finished. Press [Account] then choice account you want to setup. www.transtel.co...
  • Page 16 Press [Audio] then choice Echo cancellation to Enable or Disable echo cancel function. Press [Audio] then choice Echo cancellation calibration for echo cancellation testing. Press [Audio] then choice Codecs for more setting of codec. www.transtel.co...
  • Page 17 Press [Video] then Enable or Disable functions of video by choosing Video Initiate video calls / Accept incoming video requests Press [Video] then choice codec for video supported www.transtel.co...
  • Page 18 Press [Video] then choice Preferred video size for video size selected (720p is not recommended). Press [Advance] then choice Call to select DTMF relay mode for SIP INFO www.transtel.co...
  • Page 19 Press [Advance] then choice Network. They are 9 Item and listed as follows: Example for Stun server setting, SIP register port setting….. www.transtel.co...
  • Page 20 Choice [Media encryption] if SRTP feature is requested. www.transtel.co...
  • Page 21 Press [Advance] then choice Other. They are 3 Item in list below. Press [Pickup Setup] for Pickup code setting (‘*9’ is an example when IP39-80 registered on GDS). www.transtel.co...
  • Page 22 Press [Blf Type] for Blf type select. Press [Voice Mail] for voice mail access code setting. (‘86’ is an example when IP39-80 registered on GDS) www.transtel.co...
  • Page 23 Press [Camera Website] to define RTSP path (URL) of their IP camera. Example: Setting of IP394x is “rtsp:192.10.1.126:8554/ip-394x”. www.transtel.co...
  • Page 24 To view IP camera by pressing then Press [Open Door Code] for door open code setting of IP39-4x. Press [Call Service] setting of IP3980 that works for normal sip server or GDS G2-ISUN. www.transtel.co...
  • Page 25 Press [Phone Lock] then [Password] for phone un-locked password setting. Note: Remember password, otherwise NGT is unable to operate. www.transtel.co...
  • Page 26 To enable by pressing then and password requested before operation. Note: Remember password, otherwise NGT is unable to operate. www.transtel.co...
  • Page 27 IP39-80 APP Press to enter or exit Contact Manage setting. Press to add www.transtel.co...
  • Page 28 24 DSS keys setting: press DSS key and hold for 2 seconds. Press [Apply] after finished. Press to hide or show keypad. Keypad is hidden. www.transtel.co...
  • Page 29 Calls is dialing by pressing DSS or dialing number from keypad then Video connecting if called party video supported. www.transtel.co...
  • Page 30 Calls incoming, press to answer or to reject. If calls missed: History icon in RED , press to view. Press again to go back. www.transtel.co...
  • Page 31 Status of History: outgoing , incoming , missed call www.transtel.co...
  • Page 32 Choices calls to manage: Press to add calls to contact manage. Press to delete a call. Press to answer a call. Press [Missed Call] to view all missed calls. www.transtel.co...
  • Page 33 Press to Enable or Disable Do not Disturb. Do not Disturb is on. www.transtel.co...
  • Page 34 AUTO TELECOM COMPANY www.transtel.co www.hybrex.com...
