- Page 1 IP38-71 IP Key Phone Version：v1.0 User’s Manual Auto Telecom Company www.transtel.co www.hybrex.com IP38-71 IP Key Phone Version：v1.0...
- Page 2 Notification Notification is hereby given that Auto Telecom Company reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, Auto Telecom Company makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose.
-
Page 3: Table Of Contents
Table of Contents Description ..........................1 Make a Call ..........................4 Dialing a Number ..........................4 DSS Direct Dial ..........................4 Last Number Redial .......................... 4 Receiving a Call ........................4 Answer ............................. 4 Hold & Call Transfer ......................4 Hold &... - Page 4 Telephony / Alarm ......................... 13 System parameters ......................13 10.1 System Parameters/ Volume Setting ..................13 10.2 System Parameters/ NTP and Time ..................14 10.3 System Parameters/Ringer ....................... 14 Admin ..........................15 11.1 Admin / Save Configuration file, and run TFTD32 first to get TFTP IP address......15 11.2 Admin/ Save Configuration file, and enter TFTP IP address and click [Apply].
-
Page 5: Description
1. Description Press [Save] key, the LCD will show current DHCP IP address. 1. Handset 2. Telephone Hook Switch 3. Wall Mount Hook 4. Speaker 5. PHONE BOOK There are 100 sets, press Book and save key firstly, press VOL+ or VOL- to select want number then press Save key to dial out. - Page 6 a. Establish a call to party B, and put it on Hold. b. Establish a call to party C; now the caller and party C are in a conversation, press [CONF] key to initial 3-way conference. 7. SAVE When IP-Phone is idle, press this [SAVE] key, the LCD will show IP address and MAC.
- Page 7 put B on Hold, and B will hear music from the PABX. a2. Extension A calls extension C, when A hears Ring Back Tone, the extension A hook down will transfer C to B, before C answer, the B Music On Hold will change to RBT. Hold Method b1.
-
Page 8: Make A Call
2. Make a Call Dialing a Number To make a call by dialing a number on the Dial Keypad: Lift the handset, the dial tone will be heard. Dial the telephone number. Press the pound key [ # ] to send out the telephone number immediately, or wait for a few seconds and the phone will send out the number automatically DSS Direct Dial The DSS feature of the IP-Phone must be set up before the user uses it. -
Page 9: During Conversation
Dial the extension number of the transfer destination. Press [TRF] key to ring that extension and have the held call transferred to it. Way 2 (1) During the call, directly press the [Transfer] key, and press the phone No. you want to transfer to then press [#] to make the call. -
Page 10: Web Pages Setup
6. Web Pages Setup User name: Admin, Password: 1234. Enter the correct User Name and Password, and click Login into the home page as follows: www.transtel.co... -
Page 11: Network
7. Network NOTE: Default setting is DHCP. Network / HTTPS Network / RPS Default setting is shown below: When setting Server Type = Disable, it doesn’t go through APS. Auto Configuration and auto update also set off. (Automatic Provisioning Server). www.transtel.co... -
Page 12: Network / Auto Configuration
Network / Auto Configuration Data below comes from APS. The default settings are as follows. When the phone restarts, it will go through APS to get data. If the Server Type is set OFF, it won’t go through APS to get data. Network / Auto Update When the phone powers on, it needs a little time going through APS to check new software. -
Page 13: Sip
8. SIP SIP / SIP Account: Only one account. SIP / Ports SIP / Audio Codecs www.transtel.co... -
Page 14: Sip / Dtmf Settings
SIP / DTMF Settings SIP / SRTP Settings 9. Telephony Telephony / Phone Book There are 100 sets, press [Phone Book] and [Save] key first, then press [VOL+] or [VOL-] to select the number you want and press [Save] key to dial out. www.transtel.co... -
Page 15: Telephony / Dss Setting
Telephony / DSS Setting NOTE: Do not set the last digit as #. DSS 1 – DSS4: Park Hold Keys, let user to park the call. Key LED status: LED OFF : The Hold line is taken off and ready for new hold line to park Slow Flashing : A new hold line is parking on that key. -
Page 16: Telephony / Dnd Setting
Telephony / DND Setting Do Not Disturb. Telephony / Call Forward Setting This feature only works with the VP. www.transtel.co... -
Page 17: Telephony / Alarm
Telephony / Alarm When time’s up, the IP-Phone will keep ringing for one minute. 10. System parameters System Parameters/ Volume Setting www.transtel.co... -
Page 18: System Parameters/ Ntp And Time
System Parameters/ NTP and Time System Parameters/Ringer www.transtel.co... -
Page 19: Admin
11. Admin Admin / Save Configuration file, and run TFTD32 first to get TFTP IP address. www.transtel.co... -
Page 20: Admin/ Save Configuration File, And Enter Tftp Ip Address And Click [Apply]
Admin/ Save Configuration file, and enter TFTP IP address and click [Apply]. Admin/ Save Configuration file, after click [Apply], the IP-Phone will ah99ipdb.tgz create an file and save TFTP folder as below image. www.transtel.co... -
Page 21: Admin/ Restore Configuration File, And Run Tftd32 First To Get Tftp Ip Address, And Put Ip
Admin/ Restore Configuration File, and run TFTD32 first to get TFTP IP address, and put IP address in TFTP Server. IP Address is shown below. Admin/ Restore Configuration File. After click [Apply], the IP-Phone ah99ipdb.tgz will download file from TFTP server, and automatically reboot. -
Page 22: Admin / Update
Admin / Update We suggest you to use [Local PC] update. Admin/ Set to Default When set to default, some settings will change. 1. Network = DHCP 2. Auto Configuration and Auto update will follow the settings of APS. www.transtel.co... -
Page 23: Prg By Manual
12. PRG by Manual PRG Key= Back SAVE Key= OK VOL+ = UP VOL- =Down Phone Book 1. Search 2. Add Entry 3. Erase all Call History 1. Incoming 2. Dialed Numbers 3. Erase Record Phone Settings 1. Call Forward 1.
