Solahart Streamline Gas Owner's Manual

Gas boosted solar water heater
Hide thumbs Also See for Streamline Gas:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Installation & Owner's Manual
"Streamline Gas"
GAS BOOSTED
SOLAR WATER HEATER
OWNER'S MANUAL
AND
WARRANTY / INSTALLATION INFORMATION
WARNING: Plumber – Be Aware
Use copper pipe ONLY. Plastic pipe MUST NOT be used.
It is a requirement of a solar water heater installation that all
pipe work be in copper and not plastic, due to the effects of
high water temperatures and pressures.
Solahart Industries Pty Ltd
ABN 45 064 945 848
This water heater must be installed and serviced by an authorised person.
Please leave this guide with the householder.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Streamline Gas and is the answer not in the manual?

Questions and answers

Related Manuals for Solahart Streamline Gas

Summary of Contents for Solahart Streamline Gas

  • Page 1 It is a requirement of a solar water heater installation that all pipe work be in copper and not plastic, due to the effects of high water temperatures and pressures. Solahart Industries Pty Ltd ABN 45 064 945 848 This water heater must be installed and serviced by an authorised person.
  • Page 2 PATENTS This water heater may be protected by one or more patents or registered designs. ® Registered trademark of Solahart Industries Pty Ltd or Rheem Australia Pty Ltd. ™ Trademark of Solahart Industries Pty Ltd or Rheem Australia Pty Ltd.

  • Page 3: Table Of Contents

    Installation – Solar Collectors ............... 29 Connections – Plumbing ................31 Connections – Electrical................34 Commissioning ....................36 Lighting The Water Heater................38 Draining The Solar Collectors ............... 41 Draining The Water Heater ................42 Water Supplies ....................44 Warranty......................45 Solahart Offices....................48...

  • Page 4: Introduction

    It is with the above in mind that we at Solahart Industries Pty Ltd are confident that your purchase of the “STREAMLINE GAS” water heater will provide you reliable hot water with quality after sales service back up.

  • Page 5: About Your Water Heater

    To meet the requirements of the National Plumbing Standard the temperature of the stored water must not be below 60°C. Solahart recommends the thermostat is set at 60°C to maximise solar contribution. HOTTER WATER INCREASES THE RISK OF SCALD INJURY This water heater can deliver water at temperatures which can cause scalding.
  • Page 6 If the electrical conduit to the water heater is damaged, it must be replaced by an authorised person in order to avoid a hazard. Phone your nearest Solahart Dealer to arrange for an inspection. The warranty can become void if relief valves or other safety devices are tampered with or if the installation is not in accordance with these instructions.
  • Page 7 ABOUT YOUR WATER HEATER TO TURN OFF THE WATER HEATER If it is necessary to turn off the water heater: • Shut down the gas control (refer to “Close Down Procedure” on page 40). • Close the gas isolation valve at the inlet to the gas control. •...
  • Page 8 ABOUT YOUR WATER HEATER DOES THE WATER QUALITY AFFECT THE WATER HEATER? The water heater is suitable for most public water supplies, however some water qualities may have detrimental effects on the cylinder, solar collectors and fittings. If you are in a known harsh water area you must read page 44.
  • Page 9 ABOUT YOUR WATER HEATER FREEZE PROTECTION Although the system has a level of freeze protection, designed to guard the system from unexpected frost conditions, the system is not recommended for installation in areas subject to frost or freeze conditions. Freeze conditions occur below 6°C. The system has NO WARRANTY for freeze damage (refer to “Warranty Exclusions”...

  • Page 10: How Your Water Heater Works

    HOW YOUR WATER HEATER WORKS The Solahart Streamline system has its vitreous enamel lined solar storage tank installed at ground level, remotely from the solar collectors. As the sun heats the water in the solar collectors the increase in temperature activates the circulator. The circulator then moves the water from the solar collectors through an insulated copper pipe to the solar storage tank.

  • Page 11: Regular Care

    SERVICING For safe and efficient operation, the water heater should be serviced annually by your nearest Solahart Dealer. Only genuine replacement parts should be used on this water heater. Warning: Servicing of a gas water heater should only be carried out by authorised personnel.
  • Page 12 REGULAR CARE COLLECTOR GLASS Ensure the glass on your solar collectors is free of dust, salt spray or any other matter, which may reduce the effectiveness of the solar collectors. If the collector glass becomes dirty, hose down or if the solar collectors are accessible, wash the collector glass with water and a soft brush when the solar collectors are cool.

  • Page 13: Timer Operation

    TIMER OPERATION FUNCTIONS OF THE TIMER The timer is an accurate, electronic device which allows up to six (6) ON-OFF periods to be set per day. It is recommended only one (1) period per day be programmed into the timer. This will be sufficient for most installations.
  • Page 14 TIMER OPERATION RECOMMENDED TIMER ON/OFF SETTING It is recommended the timer be set to enable boosting between 4:00 PM (16:00 Hours) and 6:30 PM (18:30 Hours). Note: The timer uses a 24 hour clock. This two and a half hour boosting period is sufficient to allow the gas burner to heat up the entire contents of the solar storage tank through a 45°C temperature rise.
  • Page 15 TIMER OPERATION TO SET ON/OFF TIMES To set “ON” time • MO TU WE TH FR SA SU Press and release the “PROG” button TIMER 16:00 If the timer has been reset, then “TIMER – ON”, “– – : – –” and “MO TU WE TH FR SA SU” will be displayed on the screen.
  • Page 16 TIMER OPERATION Note: If the timer is not set with an ON-OFF period, the solar water heater will not boost automatically. If the “MAN” button is pressed to activate the manual boosting “OVERRIDE” function and an ON-OFF period has not been set, the solar water heater will remain in boosting mode until the “MAN” button is pressed again to deactivate the manual boosting “OVERRIDE”...

  • Page 17: Save A Service Call

    • Collector area is too small For most installations, the number of solar collectors recommended in Solahart literature has been proven to provide the required solar energy to meet the average family needs. However, in some circumstances, it may be necessary to install an additional solar collector.
  • Page 18 Heavy flows of hot water until the water heater is cold - then stops until water reheats The gas control must be turned off using the knob on top of the gas control thermostat (refer to “Close Down Procedure” on page 40). Phone your nearest Solahart Dealer to arrange for inspection. EXPANSION CONTROL VALVE RUNNING...
  • Page 19 Warning: Collector glass must not be replaced whilst the solar collector is on the roof. The collector glass is not offered as a replacement part and no attempt should be made to remove it. Should the solar collector require replacement, contact your nearest Solahart Dealer.
  • Page 20 Consider recent changes to your hot water usage pattern and check if there has been any increase in tariffs since your previous account. IF YOU HAVE CHECKED ALL THE FOREGOING AND STILL BELIEVE YOU NEED ASSISTANCE, CALL YOUR NEAREST SOLAHART DEALER.

  • Page 21: Installation - Solar Storage Tank

    Check the water heater is suitable for the gas type available. (refer to the rating label on the water heater) The system can be installed with Solahart ‘L’ solar collectors. Although the system has a level of freeze protection, designed to guard the system from unexpected frost conditions, the system is not recommended for installation in areas subject to frost or freeze conditions.
  • Page 22 INSTALLATION – SOLAR STORAGE TANK As a guide the following requirements extracted from the Australian Gas Installations Standard AS 5601, must be observed: • At least 300 mm between the top of the solar storage tank and the eaves. • At least 500 mm between the solar storage tank and the edge of any opening into the building, measured horizontally and vertically.
  • Page 23 INSTALLATION – SOLAR STORAGE TANK TANK WATER SUPPLY If the water heater is supplied with water from a tank supply and a minimum water supply pressure of 200 kPa at the water heater cannot be achieved, then a pressure pump system must be installed to allow the solar circuit system to operate.
  • Page 24 INSTALLATION – SOLAR STORAGE TANK If a pressure limiting valve is installed on the cold water line to the solar water heater and the cold water line to a temperature limiting device branches off before this valve or from another cold water line in the premises, then a pressure limiting valve of an equal pressure setting may be required prior to the temperature limiting device.
  • Page 25 INSTALLATION – SOLAR STORAGE TANK REDUCING HEAT LOSSES The cold water line to and the hot water line from the water heater must be insulated in accordance with the requirements of AS/NZS 3500.4. The insulation must be weatherproof and UV resistant if exposed. The pipe work between the solar storage tank and the solar collectors must be fully insulated with closed cell polymer insulation or similar (minimum thickness 13 mm).
  • Page 26 INSTALLATION – SOLAR STORAGE TANK DIMENSIONS AND TECHNICAL DATA Streamline SOLAHART STREAMLINE 260SLV SOLAHART STREAMLINE 260SLV Model SLV260 Mass (tank) Empty 110 kg Full 370 kg Hourly Recovery (boost) Capacity & Boost 260 litres 100 litres (natural gas @ 50°C rise) Hourly Gas Min.
  • Page 27 INSTALLATION – SOLAR STORAGE TANK TYPICAL INSTALLATION – OUTDOOR LOCATION...
  • Page 28 INSTALLATION – SOLAR STORAGE TANK ASSEMBLY OF SOLAR HOT AND SOLAR COLD PIPE CONNECTIONS • Use thread sealing tape or approved thread sealant. • All olive compression fittings must use brass or copper olives. • Ensure air bleed valve is open when filling collectors. •...

  • Page 29: Installation - Solar Collectors

    INSTALLATION – SOLAR COLLECTORS SOLAR COLLECTOR LOCATION Consideration must be given to the position of the solar collectors in relation to the solar storage tank. There are limitations on the maximum length of the solar hot and solar cold pipes between the solar storage tank and the solar collectors.
  • Page 30 INSTALLATION – SOLAR COLLECTORS PIPE LENGTHS The maximum recommended combined length of the solar cold and solar hot pipes with bends is: Maximum recommended total combined pipe length and number of 90° bends 1 or 2 Collectors 3 Collectors 4 Collectors Pipe Size Pipe Length Pipe Length...

  • Page 31: Connections - Plumbing

    CONNECTIONS – PLUMBING CONNECTION SIZES • Hot water connection: RP¾/20 • Cold water connection: DN20 compression fitting (cold water inlet of tank: RP¾/20). • Solar hot (from collector) connection: DN15 compression fitting. (solar hot water inlet of tank: RP¾/20). • Solar cold (to collector) connection: DN15 compression fitting.
  • Page 32 CONNECTIONS – PLUMBING This water heater has either a plastic dip tube or fitting liner in the inlet and outlet fittings (see diagram). These must be in place for the water heater to function properly. Do not remove or damage them by using heat nearby. They will be pushed into the correct position as the fitting is screwed in.
  • Page 33 CONNECTIONS – PLUMBING BLEED VALVE DRAIN A copper drain line must be fitted to the bleed valve to carry the discharge clear of the water heater and solar controls. Connect the drain line to the bleed valve using a disconnection union. The pipe work from the bleed valve to the drain should be as short as possible and fall all the way from the valve with no restrictions.

  • Page 34: Connections - Electrical

    CONNECTIONS – ELECTRICAL The power supply to the water heater must not be switched on until the water heater is filled with water and a satisfactory megger reading is obtained. All electrical work and permanent wiring must be carried out by a qualified person and in accordance with the Standards Australia Wiring Rules AS/NZS 3000 and local authority requirements.
  • Page 35 CONNECTIONS – ELECTRICAL A double pole isolating switch must be incorporated in the fixed wiring, according to the SAA Wiring Rules, AS 5601 and local authority requirements. Circuit Diagram – Water Heater...

  • Page 36: Commissioning

    COMMISSIONING TO FILL AND TURN ON THE WATER HEATER The power supply to the water heater must not be switched on and the gas pilot or burner must not be lit until the water heater is filled with water and a satisfactory megger reading is obtained. •...
  • Page 37 COMMISSIONING BLEEDING THE SOLAR COLLECTORS Upon completion of the installation, it is necessary to purge the air from the collector circuit. To purge air from the collector circuit: • Ensure the water heater is full of water and all of the hot taps are turned off.

  • Page 38: Lighting The Water Heater

    Leave the area and call your nearest Solahart Dealer or a qualified service technician. Use only your hand to turn the gas control knob, never use tools. If the control knob will not turn by hand, don’t try to repair it, call a qualified service technician.
  • Page 39 When the pilot flame remains alight with the gas control knob released, turn the knob anticlockwise to the setting of "6". This will give a water temperature of about 60°C. Solahart recommends the thermostat is set at 60°C to maximise solar contribution. Refer to “Temperature Adjustment”...
  • Page 40 5% of the specified value, refer to your nearest Solahart Dealer. • If unable to get the water heater working properly, contact your nearest Solahart Dealer. • When satisfied everything is working properly instruct the user in the correct method of operation.

  • Page 41: Draining The Solar Collectors

    DRAINING THE SOLAR COLLECTORS To drain the solar collectors and the solar hot and solar cold pipes: • Open a hot water tap and allow the water to run for five minutes immediately prior to draining the solar collector(s). This will assist in the transfer of any high temperature water in the solar collector(s) to the solar storage tank.

  • Page 42: Draining The Water Heater

    DRAINING THE WATER HEATER To drain the water heater: • Open a hot water tap and allow the water to run for five minutes immediately prior to draining the solar storage tank. This will assist in the transfer of any high temperature water in the solar collector(s) to the solar storage tank.
  • Page 43 This page is intentionally blank...

  • Page 44: Water Supplies

    WATER SUPPLIES Your water heater is manufactured to suit the water conditions of most Australian metropolitan supplies. However, there are some known water supplies which can have detrimental effects on the water heater and its operation and/or life expectancy. If you are unsure of your water quality, you can obtain information from your local water supply authority.

  • Page 45: Warranty

    WARRANTY EXCLUSIONS 1. REPAIR AND REPLACEMENT WORK WILL BE CARRIED OUT AS SET OUT IN THE SOLAHART WATER HEATER WARRANTY, HOWEVER THE FOLLOWING EXCLUSIONS MAY CAUSE THE WATER HEATER WARRANTY TO BECOME VOID AND MAY INCUR A SERVICE CHARGE AND / OR COST OF PARTS.
  • Page 46 Receiver/Drier, Evaporator and associated pipe work. Solahart reserves the right to transfer fully functional components from the defective water heater to the replacement water heater if required. The term “water heater” used in the Warranty, Warranty Conditions and Warranty Exclusions means the Solahart supplied water heater(s), solar storage tank(s), solar collector(s), kit(s) and components.
  • Page 47 If a Solahart unit Tank Serial No Date of manufacture Collector Serial No’s Comments Installer Certification – I certify this installation has been installed and tested in accordance with Solahart Industries Pty Ltd specifications Signature: Installer Customer Date White Copy: Head Office...

  • Page 48: Solahart Offices

    + 31 492 579 694 Facsimile International: + 1 334 260 1514 Australia For SERVICE Telephone - 1800 638 011 For Sales Telephone - 1300 769 475 or your nearest Solahart Dealer or your nearest Solahart Dealer Revision Date: 2007 April 126548A...
