Summary of Contents for Vogtec 3195IF
-
Page 2: Table Of Contents
2‐4. REJECT A CALL ........................ 7 2‐5. CALL TRANSFER ........................ 8 2‐6. THREE PARTY CONFERENCE .................... 9 3. CONFIGURATION THROUGH PHONE INTERFACE ................ 10 3‐1. IP DISTRIBUTION MODE SELECTION .................. 10 3‐2. CONFIGURATION WITH KEYPAD AND LCD DISPLAY ............ 10 4. QUICK START FOR WEB CONFIGURATION .................. 11 4‐1. LOGON WEB ........................ 11 4‐2. VOIP SETTINGS......................... 11 5. RESET YOUR PHONE ........................ 13 SAFETY NOTICES .......................... 14 3195IF VoIP Phone User Manual Short_V2.0... -
Page 3: Before Using The Phone
1. Before Using the Phone 1-1.Package Contents • 3195IF VoIP phone base unit. • Handset • Coiled handset connecting cord • One straight Ethernet cable • One power supply • User Guide • 2 wall mount brackets • 1 table bracket... -
Page 4: 1-2.Installation
You could choose one of below two ways to install 319fIF VoIP phone • As a desktop • As a wall mounting phone Desktop installation Assembly table bracket to base unit as shown below Wall Mounting Installation 3195IF VoIP Phone User Manual Short_V2.0... - Page 5 Insert with narrow side down as Way No.1 Insert with narrow side up as Way No.2 Wedge Way No.1 Way No.2 It is advisable to choose Way No.2 when you assemble the phone with wall mount brackets. 3195IF VoIP Phone User Manual Short_V2.0...
-
Page 6: Phone Operations
Dial out a number from CallLog In on-hook, press 【 】 to enter CallLog, choose your desired number from Dialed/Received/Missed Call following LCD indication, then press 【 】or pick up the handset to dial out 3195IF VoIP Phone User Manual Short_V2.0... -
Page 7: 2-3. Hold, Volume Adjustment And Pick Up New Incoming Call
When there is a new incoming call, press 【FL 】to pick up the new call, at the same time, previous call would be held 2-4. Reject a Call When there is an incoming call, you could press 【ESC/REC 】to reject. It would be forwarded to your voice mail if you have configured voice mail 3195IF VoIP Phone User Manual Short_V2.0... -
Page 8: Call Transfer
】 after you hear the back ring. Then your phone would hang up automatically Attended Transfer 1). During a call, press 【FL 】. 2). Do one of the following steps: — Input the number which you would like to transfer to, end with # to finish transfer. 3195IF VoIP Phone User Manual Short_V2.0... -
Page 9: Three Party Conference
】 if you get the permission. 2-6. Three Party Conference During conversation, press 【FL 】, then dial another number plus # button, while line connected, press 【FL 】and 【 】 to make conference call 3195IF VoIP Phone User Manual Short_V2.0... -
Page 10: Configuration Through Phone Interface
In standby, press 【Menu】 button till LCD shows " Input Password: " input correct password (default is 123), press 【Menu】 key to enter the menu list. Then follow below menu list to set parameters accordingly. During configuration, operations as follows -For browse and edit Configuration, press 【 】and 【 】; 3195IF VoIP Phone User Manual Short_V2.0... -
Page 11: Quick Start For Web Configuration
Default user name and password is admin. You could configure your phone with this account In this guide, only Logon as Administrator Account would be introduced 4-2. VoIP Settings After you logon in successfully, web would show as below 3195IF VoIP Phone User Manual Short_V2.0... - Page 12 Configure SIP register server IP address or Domain Name -Server Port Configure SIP register server signal port -Account Name/Password/Phone Number Configure Account Name/Password/Phone Number -Enable Register Choose to enable settings -Apply Click to apply above settings 3195IF VoIP Phone User Manual Short_V2.0...
-
Page 13: Reset Your Phone
3. LCD would show POST MODE 4. Press *#168, LCD would display Conf Reset 5. Plug out power supply, then plug in again to accomplish reset After above procedures, the phone settings would turn back to factory default 3195IF VoIP Phone User Manual Short_V2.0... -
Page 14: Safety Notices
Don’t try to dry your product in a microwave oven. The ground Don’t drop your product. Vogtec Technology Co., Ltd Office Add.: 5th Floor, Bldg. 1, Software Park,Keji Zong 2 Rd., High-Tech Zone, Nan Shan District, Shenzhen, 518057, China Tel: +86-755-86168442 Fax: +86-755-86168417 3195IF VoIP Phone User Manual Short_V2.0...
