D312I IP PHONE
WARNING:
Please DO NOT power cycle the D312I during system boot up or firmware
upgrade, you may corrupt firmware images and cause the unit to malfunction.
WARNING:
Use only the power adapter included in the D312I package. Using an
alternative non-qualified power adapter may possibly damage the Unit.
Quick Installation Guide
D312I VoIP User Manual V1.0
Advertisement
Related Manuals for Vogtec D312I
Summary of Contents for Vogtec D312I
- Page 1 D312I IP PHONE Quick Installation Guide WARNING: Please DO NOT power cycle the D312I during system boot up or firmware upgrade, you may corrupt firmware images and cause the unit to malfunction. WARNING: Use only the power adapter included in the D312I package. Using an...
- Page 2 D312I VoIP User Manual V1.0 Overview: D312I IP Phone is a stand-alone device, which requires no PC to make international calls. It is fully compatible with SIP industry standard and can inter operate with many other SIP compliant devices and software in the market. Its stability, easy operation, practicality and other aspects are incomparable.
-
Page 3: Installation
D312I VoIP User Manual V1.0 Installation 1. Connect the handset and main phone case with the phone cord. 2. Connect the WAN port of the phone to the RJ-45 socket of hub/switch or a router using the Ethernet cable. 3. Connect the DC output plug to the power jack on the phone; plug the power adapter into an electrical outlet. - Page 4 D312I VoIP User Manual V1.0...
- Page 5 D312I VoIP User Manual V1.0 Key Button Key Button Definitions Digital, star and pound keys are also used for setting and call process. Memory key Store key Auto key Mute key Flash key Redial key Speaker key LED Definitions Call Ringing...
-
Page 6: Make A Call
Transfer Call For the call transfer, we use three phones to demo the operation; all these phones register to the same server. (Phone A: D312I, phone B, C: also D312I or other IP phone) Blind Transfer IP phone A Call B, B answer the call, after this, phone A press 【FLASH】... - Page 7 D312I VoIP User Manual V1.0 1. Ensure your phone is connected to the Internet and the power socket. 2. Pick up handset or press 【SPEAKER】 button get the dial tone and then press 【AUTO】and【#】 IVR will tell you the current Network parameters.
- Page 8 D312I VoIP User Manual V1.0 User subscriber information: User ID, Authentication ID, Password (provided by your VoIP service provider). Please contact your ITSP for additional setting that may be necessary to configure the phone. Note: After you finish your setting, you can just click the apply button on the web page, then Phone will save the setting automatically and new setting will take effect.
