Mazzer GRINDER-DOSER MIN User Manual

Advertisement

CONTENTS
1) Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 2
2) Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
3) General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4) Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
5) Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
6) Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7) Installation and wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
8) Operation of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
9) Warnings regarding operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
10) Safety devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
11) Warnings regarding safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
12) Noise levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
13) Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
14) Cleaning the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ENGLISH
1

Advertisement

loading

Summary of Contents for Mazzer GRINDER-DOSER MIN

  • Page 1: Table Of Contents

    ENGLISH CONTENTS 1) Foreword ..........page 2 2) Dimensions .
  • Page 2: Foreword

    1) FOREWORD Read this manual from cover to cover before using the appliance as it contains important instructions for the safety, operation and maintenance of the appliance. Look after this manual and keep it in a safe place. The manufacturer reserves the right to make changes to the product and to the manual.
  • Page 3: General Description

    ENGLISH 3) GENERAL DESCRIPTION HOPPER COVER HOPPER (coffee bean container) COFFEE GRINDING ADJUSTMENT DISK GRINDING ADJUSTMENT DISK HANDLE SERIAL NUMBER LABEL DOSER COVER LOCKING SLIDE DOSER COUNTER DOSING LEVEL COFFEE PRESSING DEVICE FILTER HOLDER FORK SWITCH 4) PACKAGING On opening the packaging, check carefully to make sure the appliance is intact and that there are no signs of damage.
  • Page 4: Use

    6) USE This appliance has been designed solely for grinding coffee beans.Any other use is understood to be improper, and consequently hazardous.The manufacturer cannot be held responsible for any damage as a result of improper or incorrect use. Do not use the appliance for grinding other types of food, or anything else. Do not use the doser (grinder-doser version) to store foods or measure them.
  • Page 5: Operation Of The Appliance

    ENGLISH to a equipotential node if the installation is to be correct. • The motor must rotate clockwise. If the rotation of three-phase motors is to be inverted, by inverting the two power supply wires inside the plug, this must be carried out by skilled personnel.
  • Page 6 ADJUSTING GRINDING In order to achieve finer or coarser grinding, the adjustment disk located under the hop- per must be adjusted using the relevant COARSER GRINDING FINER GRINDING handle. In order to increase the coarseness of the ground coffee, the disk must be rotated clockwise;...
  • Page 7 ENGLISH By turning the small knob clockwise, the portion is reduced. Turning it anti- clockwise results in an increase. In order to collect the portions of ground coffee dispensed, insert the coffee machine’s filter holder all the way onto the fork-shaped support under the ground coffee outlet. In order to release a portion of ground coffee, the doser lever must be pulled all the way and allowed to return on its own.
  • Page 8: Warnings Regarding Operation

    9) WARNINGS REGARDING OPERATION • Do not leave the appliances turned ON without coffee in the hopper. • In the grinder-doser version, avoid pulling the doserlever partially, always pull it all the way. • In the coffee grinder version it is essential that nothing hinders the flow of ground coffee from the outlet in any way in order to prevent the risk of the appliance stopping.
  • Page 9: Warnings Regarding Safety

    ENGLISH • SAFETY SCREWS • The hopper must always be attached to the upper grinding blade hol- der using the relevant screw, which must not be removed by the user under any circumstances. • In order to prevent the adjustment disk from being removed - which would COFFEE OUTLET HOPPER...
  • Page 10: Noise Levels

    • In the event the appliance is not working properly or is faulty, contact skilled technical personnel, and do not attempt to make repairs yourself. • BEFORE PERFORMING ANY WORK ON THE APPLIANCE, INCLUDING CLEANING AND/OR MAINTENANCE, DISCONNECT IT FROM THE POWER SUPPLY BY UNPLUGGING.TURNING OFF THE APPLIANCE USING ITS MASTER SWITCH DOES NOT ASSURE THE SAME CONDITIONS OF SAFETY.
  • Page 11: Maintenance

    ENGLISH 13) MAINTENANCE It is essential to check the state of the supply cable and plug periodically. IN THE EVENT THE SUPPLY CABLE OR PLUG ARE DAMAGED, CALL IN SKIL- LED TECHNICAL PERSONNEL TO REPLACE THEM, THIS TO PREVENT ANY RISK.
  • Page 12 Grinding system Remove the safety screw which prevents the adjustment disk from being removed. Unscrew the adjustment disk by turning it clockwise. Having removed the upper grinding blade holder, clean the grinding blades, threads and the entire grinding system thoroughly using a clean brush and cloth. Having refitted the upper grinding blade holder in the relevant slot, screw the adju- stment disk back on, put the self-locking screw back in whichever of the two holes on the disk enables the best adjustment and, having refitted the hopper and secu-...
