- Page 1 GX Series HD Video Recording Server GX604 / GX609 / GX6016 Quick Start Guide...
-
Page 2: Table Of Contents
This manual is copyrighted. All rights are reserved. This manual should not be copied, reproduced or translated in whole or part without prior consent from Signal Communications Limited. TeleEye is a trademark of Signal Communications Limited and is registered in China, European Communities, Hong Kong, US and other countries. -
Page 3: Introduction
Various actions like sending video back to a designated receiving PC, video recording, email notification, etc. can be performed upon event triggering. TeleEye GX can also keep a comprehensive operation and event log for audit trail. - Page 4 Quick Start Guide PAGE 2 Item Description Item Description Quick start guide Power adaptor Registration code sheet HDD screws HDD recommendation Straight-through Ethernet sheet cable Alarm port connector & Warranty card alarm port cover Resistors Software CD (for tamper detection)
-
Page 5: Hardware Features
Quick Start Guide PAGE 3 1.2. Hardware Feature 1.2.1. Front View Notification LEDs Description Light up when power on Light up when performing recording Blink when an event is triggered... -
Page 6: Functional Features
Quick Start Guide PAGE 4 1.2.2. Back View 1. Power switch 2. Power input (16V DC) 3. Ethernet jack (10/100/1000 Base-T) 4. USB port 5. RS-485 in/out port 6. Audio in/out port, PA 7. Digital video input ports 8. Alarm/switch port 1.3. -
Page 7: Hard Disk Installation
Quick Start Guide PAGE 5 1.4. Hard Disk Installation 1. Make sure that the video recording server is turned off. 2. Loosen the screws that hold the cover. 3. Pull off the cover. - Page 8 Quick Start Guide PAGE 6 4. Loosen the screws of the hard disk holder. 5. Insert HDD into one of the available holders. Maximum 4 HDD can be installed.
- Page 9 Quick Start Guide PAGE 7 6. Mount the HDD to holder with attached screws. 7. Remount the hard disk holder to TeleEye GX. 8. Connect the SATA cable to the HDD.
-
Page 10: Setup For Remote Monitoring & Recording
Quick Start Guide PAGE 8 2. Setup for Remote Monitoring & Recording Equipment: TeleEye GX HD video recording server and its power adaptor Cameras and their power adaptors CAT-5 cable Network switch or router PC Requirements: CPU: Intel ® Core i3 Processor... - Page 11 4. Connect TeleEye GX to the network switch. 5. Switch on the power switch of TeleEye GX. 6. If all installed hard disks are not in TeleEye GX recognized format, they would be formatted automatically when startup completes. 7. By default, manual recording will be started automatically.
- Page 12 Quick Start Guide PAGE 10 2. Install TeleEye IP Setup Utility. .NET framework is also needed for the operations. Both can be found in the included software CD. 3. Run IP Setup Utility. 4. Find the video recording server according to the serial number provided by the provider.
- Page 13 Quick Start Guide PAGE 11 9. By default, basic security mode is applied and username is not required. Enter password and press [Connect]. (The default administrator password is “000000”. Details can be found in the registration code sheet) 10. Use screen mode selection panel and camera selection panel (circled in red color in below figure) to view video.
- Page 14 2. Enter the user name and password if login is required. Please refer to the setup manual of router. 3. Enter the IP address and port number of TeleEye GX in the NAT / port forward table of the router. Note that the naming for port forwarding may be different for different routers.
-
Page 15: Reference
Quick Start Guide PAGE 13 3. Reference For advanced operations, please refer to the TeleEye GX full user guide in the software CD.
