5131712/04
INSTALLATION GUIDE
Carlton
or
Matlock
Electric Suite.
This suite is intended for use with electric heaters only. It must never be
used with a gas fire.
This guide should be read in conjunction with the installer and owner guides
supplied with the heater.
This guide is intended to help you install your Electric Suite. Please read carefully
before installing. However, if further information is required, our
Valor Fires Technical Helpline will be pleased to help.
Telephone 0844 8711 565 (National call rates apply in the United Kingdom)
In the Republic of Ireland call 0044 844 8711 565.
Important: Please keep your guide in a safe place for future reference.
© Baxi Heating U.K. Limited 2010.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carlton and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor Fires Carlton

  • Page 1 This guide is intended to help you install your Electric Suite. Please read carefully before installing. However, if further information is required, our Valor Fires Technical Helpline will be pleased to help. Telephone 0844 8711 565 (National call rates apply in the United Kingdom) In the Republic of Ireland call 0044 844 8711 565.
  • Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. If you require further assistance, the Valor Fires Technical Helpline will be pleased to help.
  • Page 3 INSTALLATION GUIDE SAFETY Always read this guide in conjunction with the guide supplied with the heater. Always switch off electric power when not needed. HANDLING AND UNPACKING Before continuing any further with the installation of this suite please read the following: Important instructions.
  • Page 4 INSTALLATION GUIDE CONTENTS Figure 1. Contents (Items are not to scale). DIMENSIONS Figure 2. Dimensions (Heater fascia may differ from that shown) Page 4 © Baxi Heating U.K. Limited 2010.
  • Page 5 INSTALLATION GUIDE ASSEMBLING THE HEARTH AND SURROUND. The installation of this Surround / Mantle and hearth requires a reasonable level of DIY skills. Please read this guide thoroughly before commencing installation and if in doubt, seek help from a competent person. Do I need any tools? You will need the following tools : A Pozidrive / Phillips / cross head screwdriver.
  • Page 6 INSTALLATION GUIDE Step 3. Fitting the wall fixing brackets. There are two styles of wall fixing bracket. Only one style will be supplied with the suite. Flat bracket. The brackets may already be secured to the suite. If not, follow the below: Place the wall fixing brackets along the outside edge of the legs...
  • Page 7 © Baxi Heating U.K. Limited 2010.
  • Page 8 © Baxi Heating U.K. Limited 2010.
