Page 1 MARS-1030 WinCE. NET Rugged Portable Data Terminal User Manual...
Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
Page 3: Table Of Contents
Contents Chapter 1 Introduction ............. 2 About this Manual............. 2 User and Product Safety............ 3 Declaration of conformity ..........5 Product Labeling ............... 7 System Specifications ............9 Environment Standard............. 11 Warranty and after service ..........12 Technical Support and Assistance........12 Document Feedback............
Page 4 5.2.1 Calculator ..............126 5.2.2 Inbox ................126 5.2.3 Internet Explorer ............136 5.2.4 Media Player .............. 140 5.2.5 Messenger ..............140 5.2.6 Microsoft WordPad ............ 141 5.2.7 Remote connection ............ 147 5.2.8 Windows Explorer ............. 148 MARS-1030 User Manual...
Page 5 DiskOnChip ..............150 5.3.1 Saving to flash ............150 5.3.2 DiskOnChip location ..........150 5.3.3 DiskOnChip size ............151 Appendix A Barcode Setting..........154 Setup Tab............... 154 A.1.1 Symbology setup ............156 A.1.2 Decoder setup ............157 A.1.3 Options ............... 159 Update Tab ..............
Page 6 A.3.35 Korean Post ..............208 MARS-1030 User Manual...
Page 7 Introduction This chapter presents general informa- tion about the PDT.
Page 8: Chapter 1 Introduction
Chapter 1 Introduction Congratulations on purchasing the MARS-1030 Portable Data Terminal (PDT), a Microsoft Windows® CE .Net rugged PDT. Its special combina- tion of features makes it perfect for using in a wide range of applications. These features are: •...
Page 9: User And Product Safety
If the LCD panel is broken, never touch the liquid inside, for such contact would irritate the skin. • Although the MARS-1030 PDT has passed IP54 standard tests for water and dust resistance, avoid prolonged exposure to rain or other concentrated moisture. For these conditions exceed the IP54 stan- dard, and could result in water or other contaminants entering the PDT.
Page 10 Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufacturer. Discard used batteries accord- ing to the manufacturer’s instructions. Achtung! MARS-1030 User Manual...
Page 11: Declaration Of Conformity
1.3 Declaration of conformity FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence in a residential installation.
Page 12 1030 is limited in CH1~CH11 for 2.4GHz by specified firmware controlled in U.S.A. The FCC ID of MARS-1030 is M82-MARS-1030 This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure.
Page 13: Product Labeling
1.4 Product Labeling The PDT has several labels as shown in Figure 1-1 and 1-2. Figure 1.1: Product Labeling (Front side view) Chapter 1...
Page 14 Figure 1.2: Product Labeling (Back side view) MARS-1030 User Manual...
Page 15: System Specifications
1.5 System Specifications The MARS-1030 PDT detailed specifications follow. Unless otherwise noted, all the specifications are subject to change without prior notifica- tion. Table 1.1: System Specification MARS-1030 Processor - 400 MHz Intel PXA255 32 bits RISC CPU - 64 or 128 MB Flash ROM...
Page 16 - Weight: 560 g with Standard Battery Pack 500 g without Battery Pack Color - Black - Standard Packing list: 1. MARS-1030 Terminal 2. Stylus 3. USB Client Cable for Terminal 4. Earphone/ Microphone Set 5. Standard AC Adapter 5 V DC / 2.6 A 6.
Page 17: Environment Standard
1.6 Environment Standard Table 1.2: Environment Standard Operating Temperature 14 ~ 122° F (-10 ~ 50° C) Storage Temperature -4 ~ 158° F (-20 ~ 70° C) Humidity 5 ~ 80% (non-condensing) Drop 5 ft (1.5 m) Drop to Concrete Water &...
Page 18: Warranty And After Service
Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
Page 19 Getting Started This chapter describes the basic use of the PDT.
Page 20: Chapter 2 Getting Started
Figure 2.1: Inside the package MARS-1030 Terminal Standard Battery Pack (3.7 V, 3000 mAh) Earphone/Microphone Set Stylus USB Client Cable for Terminal CF Support Guide Standard AC Adapter 5 VDC / 2.6 A AC Power Cord Quick Guide (Not Shown) MARS-1030 User Manual...
Page 21: General View Of The Pdt
2.2 General View of the PDT 2.2.1 PDT front side view Figure 2.2: PDT Front side view 2.2.2 PDT back side view Figure 2.3: PDT back side view Chapter 2...
Page 22 17 Battery Cover Latch To keep the Battery Cover locked 18 Hand-strap This strap can be sealed tighter or looser 19 Speaker 1.5 W speaker for audio sound 20 DC Power Jack A connector to support AC power. MARS-1030 User Manual...
Page 23: Charging The Battery Pack
Protects the CF and SD slots from dust and 21 End Cap water 2.3 Charging the Battery Pack Charge the battery pack before using the PDT by following these steps. 2.3.1 Installing the battery pack Detach and loosen the hand-strap. Figure 2.4: Release the hand-strap from PDT Chapter 2...
Page 24 Turn the locking screws (right and left) downwards and lift the bat- tery cover away from the PDT. Figure 2.5: Detach the battery cover from PDT MARS-1030 User Manual...
Page 25 Insert the battery pack into the battery compartment with the label facing out, and ensure the battery snaps into place. Figure 2.6: Insert the battery pack Chapter 2...
Page 26 Charge the battery pack for about 6 hours, when charging for the first time. Subsequent charges need about 4 hours. When charging the battery pack, the charge indicator on the PDT turns Red. After the battery pack is fully charged, the indicator turns Green. MARS-1030 User Manual...
Page 27: Charging The Battery Pack With A Power Adapter
2.3.2 Charging the battery pack with a Power Adapter Connect the Power cord to the Power adapter. Plug in the connector of the power adapter. Connect the power cord to a power source. Figure 2.8: Charging with a power adapter When charging the battery pack, the charge indicator on the PDT turns Red.
Page 28: Charging The Battery Pack With A Single Dock
Red. After the battery pack is fully charged, the indicator turns Green. CAUTION: Single Cradle Adapter supplies 5 V DC / 6.5 A. This is different from the PDT Adapter (5 V DC / 2.6 A). Please use the Single Cradle Adapter only. MARS-1030 User Manual...
Page 29 Place the spare battery pack into the Single Cradle’s spare Battery charging slot. Connect the power cord to the power adapter. Connect the power cord to a power source. Plug the connector of the power adapter into the Single Cradle. Insert the battery pack into the Single Cradle’s spare Battery slot.
Page 30: Handling The Pdt
When the PDT is powered on for the first time, it ini- tializes its system. A splash screen appears for a short period of time followed by the Win CE .NET 4.2 win- dow. Figure 2.10: Starting the PDT MARS-1030 User Manual...
Page 31: Power On/Off
2.4.2 Power on/off To turn on the PDT: Press the power key briefly ( ). If the PDT does not power on, perform a cold reset. See “Resetting the PDT” on page 51. As the PDT initializes its file system, it shows a splash screen for about 30 seconds followed by calibration screen.
Page 32: Adjusting The Brightness
Navigate the display, select menu items and open applications. Type characters on soft keyboard panel. Select an item from a drop-down list. CAUTION: Never use a pen, pencil, or other sharp object on the display to avoid damage of the touch screen. MARS-1030 User Manual...
Page 33: Using The Keypad
2.4.7 Using the Keypad Figure 2.12: MARS-1030 Keypad Chapter 2...
Page 34 Main Function Function None. (Reserved for Customer) Main Barcode Scan Power On/Off Internet Explorer Microsoft WordPad Inbox File Explorer Backlight Right Increase Backlight Left Decrease Down Page Down Page Up Audio Mute € Backspace TAB (Tabulation) Caps MARS-1030 User Manual...
Page 35 Change to letters Alphabetic + Fn + Main Main Function Main Function Function Function change (at) ’ (Plus Sign) Paste Del (Delete) (Minus Sign) Copy (AND) (Asterisk) Space . (Point) Start Menu Enter (Backslash) Table 2.3: Special Key Combinations Key Combination Functionality Definition Press “F1”...
Page 36 MARS-1030 User Manual...
Page 37 Definition Keep its function or by customer None. demand. Main Barcode Scan key activates the scan function of MARS-1030. key puts the terminal into Power On/Off and out of suspend mode. Application key 1. This key can Internet Explorer be redefined.
Page 38 The keypad stays in the alphabetic mode until you press the key again. key is used in combi- nation with other keys to type spe- Function change cial characters and perform system functions. MARS-1030 User Manual...
Page 39 Main Function Definition Number key “1” Number key “2” Number key “3” Number key “4” Number key “5” Number key “6” Number key “7” Number key “8” Number key “9” Number key “0” Point key Enter This key confirms data entry Chapter 2...
Page 40 You must press this key, then the Page Up key to move the cursor up one page. Mute or enable audio. Audio Mute Press the key, then the key to mute or enable audio. MARS-1030 User Manual...
Page 41 Key Sequence Definition Fn + Main Function The “TAB” function moves the cursor to the next tab stop or the next control on a form. (Tabulation) Press the key first, and then press key. Enter an {@, at} symbol by pressing the @ (at) key, then the key.
Page 42 Enter a space by pressing the key, Space and then the key. Enter the Start Menu by pressing the Start Menu key, and then the key. Enter a backslash by pressing the (Back- slash) key, and then the key. MARS-1030 User Manual...
Page 43 2.4.7.2 Alphabetic plane keys key enables you to toggle between the numeric and alpha- betic modes. Numeric mode is when you type numbers with number keys. Alphabetic mode is when you type letters with the number keys. When you press the key, an “Alphabetic”...
Page 44 To enter Press the Keys To enter Press the Keys MARS-1030 User Manual...
Page 45 To enter Press the Keys To enter Press the Keys Chapter 2...
Page 46 • key is not needed to key in a character if it isn’t the first capital alphabetic character being keyed in. MARS-1030 User Manual...
Page 47: Using Earphones And A Microphone
2.4.8 Using Earphones and a Microphone Connect earphones and a microphone to PDT earphone jack connector. The PDT doesn’t have a built in microphone; if you want to make voice recordings, you have to use an external microphone. Figure 2.13: Earphones Chapter 2...
Page 48: Navigating The Display
To automatically adjust the clock for Daylight Saving Time, enable the checkbox at the bottom of the screen. Select Apply to save your changes [and make additional modifica- tions] or select OK to exit the Date/Time settings. MARS-1030 User Manual...
Page 49: Entering The Data
2.5.2 Entering the Data To select and open programs, select Start > Programs from the taskbar to open a list of available programs. Or if the program has a icon on the desktop, double-tap it to open it. There are several ways to enter data on the PDT once in an application. •...
Page 50: The Taskbar
To open the SIP, tap the keyboard icon to open the menu and select Hide Input Panel to close the keyboard. Use the stylus to select letters, numbers, or symbols from the Soft Input Panel for the current application. MARS-1030 User Manual...
Page 51: Setting Up A Wireless Lan
2.5.6 Setting Up a Wireless LAN 1) Press “Start” > “Settings” > “Control Panel” > “WLAN Manager”. 2) Launch the WLAN Manager to Enable the WLAN device. 3) In the AP Browser tab, tap the Scan button to refresh the network. 4) Select a network, tap the Join button or double tap it for more options.
Page 52 The 802.11b WLAN is not connected to the network. The 802.11b WLAN has no signal. The 802.11b WLAN signal is low. The 802.11b WLAN signal is OK. The 802.11b WLAN signal is good. Figure 2.18: WLAN Manager Figure 2.19: WLAN Manager MARS-1030 User Manual...
Page 53: Scanning Barcode
2.5.7 Scanning Barcode To use the scanning function, complete the following steps: If you have not already done so, remove the protective plastic film before using devices equipped with a laser scanner. Select Start > Settings > Control Panel > Barcode Setting. Con- figure settings as described in “Barcode Setting”...
Page 54: Help
Note: this product scans using laser light. Never look directly into the laser light or shine the laser light into the eyes. 2.5.8 Help To tap “?” can get help information for each program. MARS-1030 User Manual...
Page 55: Power Management
2.6 Power Management 2.6.1 Suspend Mode The PDT will go into a suspend mode when it is idle for a period of time. The idle duration can be customized using the Power con- trol panel. Suspend mode works and looks just like you have turned the unit off.
Page 56: Resuming
Press the <Power> key to suspend or resume (wake up). • Put the PDT into a dock. When a battery pack completely discharges while the unit is in suspend mode, the PDT remains suspended until the battery is charged. MARS-1030 User Manual...
Page 57: Resetting The Pdt
2.7 Resetting the PDT 2.7.1 Software (Warm) Reset A warm reset is a transition from the on, idle, or suspend power state that closes all applications and clears the working RAM, but preserves the file system. Reason to Warm Reset: If an application “hangs”, initiate a warm reset to terminate the application only.
Page 58 MARS-1030 User Manual...
Page 59 Setting This chapter provides basic instruc- tions for customizing the PDT by adjusting settings.
Page 60: Chapter 3 Setting
There are three items inside Settings: “Control Panel”, “Network and Dial-up” and “Taskbar and Start”. 3.2 Control Panel To view the Control Panel and settings tapping Start > Settings > Con- trol Panel. Figure 3.1: Control Panel MARS-1030 User Manual...
Page 61: Barcode Setting
3.2.1 Barcode Setting CAUTION: Please do not enter any Barcode Applications before completing barcode configuration. There are three tabs for scanner configuration set- ting: “Basic”, “Code Configure” and “Code ID”. In addition, there is a “Barcode Setup” for the “Code Configure” tab. Chapter 3...
Page 62 3.2.1.1 “Basic” Tab Figure 3.2: Basic Tab MARS-1030 User Manual...
Page 63 Table 3.1: Basic Explanation Field Name Function Explanation Select the number of beep tones after a suc- cessful scan. After scanning the barcode, do None not beep. Beep After Scan OK After scanning the barcode, One Time beep once. After scanning the barcode, Two Times beep twice.
Page 64 Universal product code seen on almost UPC-A all retail products in the USA and Can- ada. EAN-13: European Article Numbering international retail product code. EAN-13 / ISBN ISBN: Special use of the EAN-13 symbol to used internationally to mark books. MARS-1030 User Manual...
Page 65 Barcode Symbology Explanation Compressed version of EAN code for EAN-8 / JAN-8 use on small products. UPC-A, UPC-E, EAN-13, and EAN-8 may all include an additional barcode to the right of the main barcode. This sec- UPC-EAN Add-ON 2/5 ond barcode, which is usually not as tall as the primary barcode, is used to encode additional information for news- papers, books, and other periodicals.
Page 66 Barcode Symbology Explanation GTIN Global Trade Identification Number Korea Code 3 of 5 Reduced Space Symbology MARS-1030 User Manual...
Page 67 3.2.1.3 “Code ID” Tab Figure 3.4: Code ID Tab Table 3.3: Code ID Explanation The code ID is added to the prefix of the barcode to let users identify which kind of barcode is being scanned. Enable this functionality. Enable Code ID Select one default value: Set 1 ~ Set 5.
Page 68 Industrial 2 of 5 / IATA Interleaved 2 of 5 Plessey / MSI Code 11 Codabar / NW 7 Matrix 2 of 5 Code 39 / Code 32 Code 93 Code 128 Code 4 Korea Code 3 of 5 UCC128 / EAN128 MARS-1030 User Manual...
Page 69 3.2.1.4 Barcode Setup First select the barcode type then select a barcode setting. Press the “Default” button to reset all settings of this barcode to default values. Press the “Apply” button to apply these changes. Please see “Symbologies List” on page 64 for more detailed informa- tion on each barcode.
Page 70: Symbologies List
Ignore 1st digit Do not transmit 1st digit of the barcode. Format Transmit 1st digit Transmit 1st digit of the barcode. This controls whether or not to send the Send Check Digit check digit of the barcode. MARS-1030 User Manual...
Page 71 3.2.2.2 UPC-A If you set UPC-A, then those settings will be automatically applied to EAN-13 too. Figure 3.7: UPC-A Table 3.6: UPC-A Explanation Item Explanation Do not transmit the 1st digit of the Ignore 1st & 2nd digits barcode. Transmit 1st digit Transmit the 1st digit of the barcode.
Page 72 Transmit the 1st and 2nd digits of Transmit 1st & 2nd digits the barcode. This controls whether or not to send Send Check Digit the check digit of the barcode. This controls whether or not to use Enable ISBN Code the ISBN Code. MARS-1030 User Manual...
Page 73 3.2.2.4 EAN-8/JAN-8 Figure 3.9: EAN-8/JAN-8 Table 3.8: EAN-8/JAN-8 Explanation Item Explanation Ignore 1st digit Do not transmit 1st digit by barcode. Format Transmit 1st digit Transmit 1st digit by barcode. Whether send check digit by barcode. Send Check Digit When this option is selected the scanner will convert UPC-E to UPC-A by Convert to EAN-13 transmitting five zeroes …...
Page 74 The UPC-EAN Add-ON 2/5 code cannot be used alone. It must operate with UPC-E, UPC-A, EAN-13/ISBN or EAN-8/JAN-8. Figure 3.10: UPC-EAN Add on 2/5 UPC-EAN Add-On 2/5 Explanation Item Explanation Only reads the codes that have Only read the code with Addon addenda. MARS-1030 User Manual...
Page 75 3.2.2.6 Industrial 2 of 5 / IATA Figure 3.11: Industrial 2 of 5 / IATA Table 3.9: Industrial 2 of 5 / IATA Explanation Item Explanation This controls whether or not to send the check digits of the bar- Send Check Digit code.
Page 76 Max Length can be from 4 to 48 (Default: 4 / 48) Length Length 1 can be from 4 to 48 Length 2 can be from 4 to 48 Fixed Length 3 can be from 4 to 48 MARS-1030 User Manual...
Page 77 3.2.2.8 Plessey / MSI Figure 3.13: Plessey / MSI Table 3.11: Plessey / MSI Explanation Item Explanation Mode 10 Format Mode 10-10 Checksum mode for this barcode. Mode 11-10 This controls whether or not to send the Send Check Digit check digit of the barcode.
Page 78 Figure 3.14: Code 11 Table 3.12: Code 11 Explanation Item Explanation This controls whether or not to send the check Send Check Digit digit of the barcode. 1 Digit 1 digit checksum. 2 Digits 2 digits checksum. MARS-1030 User Manual...
Page 79 3.2.2.10 Codabar / NW7 Figure 3.15: Codabar / NW7 Table 3.13: Codabar / NW7 Explanation Item Explanation This controls whether or not to send start Start / Stop Digit and stop digits. ABCD abcd Start / Stop transmit type TN*E tn*e This controls whether or not to verify the Checksum...
Page 80 Max Length can be from 4 to (Default: 4 / 48) Length Length 1 can be from 4 to 48 Length 2 can be from 4 to 48 Fixed Length 3 can be from 4 to 48 MARS-1030 User Manual...
Page 81 B Type -- Alphanumeric Barcodes 3.2.2.12 Code39 / Code32 Figure 3.17: Code39 / Code32 Table 3.15: Code39 / Code32 Explanation Item Explanation Code39 Standard Enable Code 39 Standard characters Format Code39 Full ASCII Enable Code 39 Full ASCII character Code32 Enable Code 32 This controls whether or not to transmit Start / Stop Digit...
Page 82 3.2.2.13 Code93 Code93 has no configuration. Figure 3.18: Code93 MARS-1030 User Manual...
Page 83 3.2.2.14 Code128 / UCC EAN128 Figure 3.19: Code 128 / UCC EAN128 Code128 / UCC EAN128 Explanation Item Explanation Enable UCC128/EAN128. Enable UCC128/EAN128 Chapter 3...
Page 84: China Post
Max Length can be from 4 to 48 (Default: 4 / 48) Length Length 1 can be from 4 to 48 Length 2 can be from 4 to 48 Fixed Length 3 can be from 4 to 48 MARS-1030 User Manual...
Page 85 3.2.2.16 Code4 Code4 has no configuration. Figure 3.21: Code4 Chapter 3...
Page 86 3.2.2.17 GTIN GTIN has no configuration. Figure 3.22: GTIN MARS-1030 User Manual...
Page 87 3.2.2.18 Korea Code 3 of 5 Korea Code 3 of 5 has no configuration. Figure 3.23: Korea Code 3 of 5 Chapter 3...
Page 88 3.2.2.19 RSS Figure 3.24: RSS RSS Explanation Item Explanation The scanner will convert RSS to Convert to UCC128 UCC128. This controls whether or not to verify Checksum Verify the checksum of the barcode. MARS-1030 User Manual...
Page 89: Bluetooth Device Properties
3.2.3 Bluetooth Device Properties Table 3.17: Bluetooth Device Properties Icon Item and function • “Scan Device” Tab (See “Bluetooth Manager Windows” on page 84 * Tap the Scan Device button to initiate a scan for Bluetooth hardware. The Bluetooth manager lists the Bluetooth devices that it finds, see “Bluetooth Manager Windows”...
Page 90 Figure 3.25: Bluetooth Manager Figure 3.26: Bluetooth Manager Windows Windows Figure 3.27: Bluetooth Error Figure 3.28: Bluetooth Manager Windows Windows MARS-1030 User Manual...
Page 91 Figure 3.29: Bluetooth Enter PIN Figure 3.30: Bluetooth Manager Windows Windows If the device to which the mobile computer is bonding Note: does not appear in the list, ensure it is turned on, in discovery mode, and within range (30 feet / 10 meters) of the mobile computer.
Page 92 Bonded device icon Bonded Bluetooth device Mobile device icon Device is a mobile device Phone icon Device is a phone. Printer icon Device is a printer Network icon Device is a network. Linked icon Device is linked. MARS-1030 User Manual...
Page 93: Certificates
3.2.4 Certificates Certificates are used by some applications for establishing trust and for secure communications. Certificates are signed and issued by certificate authorities and are valid for a prescribed period of time. Windows CE manages multiple certificate stores. Table 3.19: Certificates Icon Item and function •...
Page 94 Figure 3.31: Certificates Figure 3.32: Certificates Figure 3.33: Certificates Figure 3.34: Certificates Figure 3.35: Certificates MARS-1030 User Manual...
Page 95: Control Center
3.2.5 Control Center The Control Center includes four applications, described below. Figure 3.36: Control Center 3.2.5.1 Information Table 3.20: Information Icon Item and function • “Information” Tab: * Provide Software version, MAC address, Bluetooth ID, Serial No. and Configuration No. Chapter 3...
Page 96 The table must be disabled when its item is not marked. backlight after The table has 15 seconds, 30 seconds, 1 minute, 2 minutes and 5 minutes. Save battery life functionally of idleness. Dim backlight after 20 seconds of idleness. MARS-1030 User Manual...
Page 97 Figure 3.37: Brightness 3.2.5.3 Backup Restore Table 3.22: Backup Restore Icon Item and function 1. You can backup/restore the system to/from a flash disk or inserted memory card. (A. Disk on Chip, B. CF Card, C. SD Card) (Figure 3-38) 2.
Page 98 Figure 3.38: Backup Restore Figure 3.39: Backup & Restore Start Figure 3.40: Backup OK Figure 3.41: Restore OK MARS-1030 User Manual...
Page 99 3.2.5.4 Fn-key Settings Table 3.23: Fn-Key Icon Item and function Fn-Key Setting (Figure 3-42) Fn Key The application program default settings Internet Explorer Microsoft WordPad Inbox My Computer To assign your favorite application program to F1, F2, F3 and F4 hot keys: * Choose F1, F2, F3 or F4 from the pull-down list.
Page 100: Date/Time
- If you need to use characters other than the ones listed here, use manual dialing. - Hyphens and spaces in dialing strings are ignored. - Some modems may not respond to the following characters, even though your device lets you add them to the dial string. MARS-1030 User Manual...
Page 101 Figure 3.44: Dialing Properties Figure 3.45: Dialing Properties Figure 3.46: Dialing Properties Figure 3.47: Dialing Properties Chapter 3...
Page 102: Display Properties
- View your color selection(s) in the Preview box. - To save the scheme, select “Save”. - In the “Save this color scheme as” box, enter a name for the scheme, and select “OK”. - Select “Apply”. Figure 3.48: Display properties Figure 3.49: Display properties MARS-1030 User Manual...
Page 103 Figure 3.50: Display properties Figure 3.51: Display properties Figure 3.52: Display properties Chapter 3...
Page 104: Input Panel
<Enter> key on the keypad. * To exit the Input Panel, press “OK” on the control bar, or press the <Enter> key on the keypad. Figure 3.53: Input Panel Figure 3.54: Input Panel Properties Properties MARS-1030 User Manual...
Page 105: Internet Options
3.2.10 Internet Options Table 3.28: Internet Options Icon Icon and function • “General” Tab: (Figure 3-55) * Type in the URL of desired start page and the desired search engine. You can also change the Cache Size, clear the Cache and clear the History. •...
Page 106 Figure 3.55: Internet Settings Figure 3.56: Internet Settings Figure 3.57: Internet Settings Figure 3.58: Internet Settings MARS-1030 User Manual...
Page 107: Keyboard
3.2.11 Keyboard Table 3.29: Keyboard Icon Icon and function • “Repeat” Tab: (Figure 3-59) * To change the amount of time between depressions before repetition starts, adjust the Repeat delay slider * To change the repeat rate, adjust the Repeat rate slider.
Page 108: Network And Dial-Up Connections
The connection you just created appears as an icon in the “Network and Dial-up Connections” folder. - Set up a Point-to-Point Protocol (PPP) account with an ISP and obtain the following information: > Access telephone number > User name > Password MARS-1030 User Manual...
Page 109 Icon Icon and function Once you have established an account, create a new connection on your device. When creating this connec- tion, you should be able to use all of the default TCP/IP settings provided in the Make New Connection Wizard. If you can’t connect using the default settings, contact your ISP or access your ISP’s Web site for specific TCP/IP information such as primary and secondary DNS...
Page 110 Figure 3.62: Network and Dial-up Figure 3.63: Network and Dial-up Connections Connections Figure 3.64: Network and Dial-up Figure 3.65: Network and Dial-up Connections Connections MARS-1030 User Manual...
Page 111 Figure 3.66: Network and Dial-up Figure 3.67: Network and Dial-up Connections Connections Figure 3.68: Network and Dial-up Figure 3.69: Network and Dial-up Connections Connections Chapter 3...
Page 112 Figure 3.70: Network and Figure 3.71: Network and Dial-up Dial-up Connections Connections MARS-1030 User Manual...
Page 113: Owner
3.2.13 Owner Table 3.31: Owner Icon Icon and function • “Identification” Tab: (Figure 3-74) * Fill in or edit the data as desired. * To have this information displayed when you start your device, select “Display Owner Identification” at Power On. * To set up identification for remote networks, see Setting up identification for remote networks.
Page 114: Password
“Enable password protection for screen saver” * To exit the Password control panel, press “OK” from the control bar, or press the <Enter> key on the key- pad. Figure 3.74: Password Properties MARS-1030 User Manual...
Page 115: Pc Connection
3.2.15 PC Connection Table 3.33: PC Connection Icon Icon and function • “PC Connection” Tab: (Figure 3-77) * Select the first checkbox to enable direct connections to the desktop computer. (Figure 3-77) * Tap the “Change Connection…” button to modify the connection method to USB or Serial.
Page 116: Power
* Show the remaining power capacity of the main battery. * If a “Main Batteries Very Low” warning message shows, the MARS-1030 will shut down in 30 minutes. (Figure 3-83) * The PDT will shutdown when the main battery’s capac- ity is around 0% * To exit the battery control panel, press “OK”...
Page 117 Figure 3.77: Power Figure 3.78: Power Figure 3.79: Power Figure 3.80: Power Figure 3.81: Power Chapter 3...
Page 118: Regional Settings
* Review the Appearance samples in the bottom half of the screen. * Select the tab at the top for any settings you wish to change. Settings to modify include Number, Currency, Time, and Date. Figure 3.82: Regional Settings MARS-1030 User Manual...
Page 119: Remove Programs
3.2.18 Remove Programs Table 3.36: Remove Programs Icon Icon and function • “Remove Programs” Tab: * Only user installed programs can be removed. - Select the program you wish to remove from the list and press the “remove” button. Chapter 3...
Page 120: Storage Manager
- To save and exit the Storage Properties control panel, press “OK” from the control bar, or press the <Enter> key on the keypad. Caution: Dismounting or formatting the DiskOnChip will erase all files and programs stored in flash mem- ory. Figure 3.83: Storage Manager MARS-1030 User Manual...
Page 121: Stylus
3.2.20 Stylus Table 3.38: Stylus Icon Icon and function • “Double-Tap” Tab: (Figure 3-86, Figure 3-87) * Double-tap the checkerboard grip at a comfortable speed. * Double-tap clapboard to test your settings * The function is OK if the figures are changed from Fig- ure 3-86 to Figure 3-87.
Page 122 Figure 3.86: Stylus Properties Figure 3.87: Stylus Properties MARS-1030 User Manual...
Page 123: System
3.2.21 System Table 3.39: System Icon Icon and function • “General” Tab: (Figure 3-90) * To show: - Firmware information - Information about processor type, memory size, and expansion cards • Memory”: (Figure 3-91) “ * Move the slider to adjust memory allocation. Default storage memory is normally is normally set to about 8 MB with the reminder assigned to program memory.
Page 124 Figure 3.88: System Properties Figure 3.89: System Properties Figure 3.90: System Properties Figure 3.91: System Properties MARS-1030 User Manual...
Page 125: Volume & Sounds Properties
3.2.22 Volume & Sounds Properties Table 3.40: Volume & Sound Icon Icon and function • “Volume” Tab: (Figure 3-94) * The factory default volume level is the four. You can adjust the volume to your environment and comfort. - Set the volume by adjusting the slider from Soft to Loud, or press the right or left edge of the navigation keys.
Page 126: Taskbar And Start Menu
- Show Clock or not • Advanced” Tab: “ * Tap the “Clear” button to remove the contents of the Documents Menu. * Enable “Expand Control Panel” to list all icons of the Control Panel from top to bottom. MARS-1030 User Manual...
Page 127 Communication This chapter describes how to use the communication features of the PDT.
Page 128: Chapter 4 Communication
To use the cable, connect the USB/Serial cable to the PDT. Connect the USB/Serial dock or cable to the Host PC’s serial port or USB port. Connect the dock or PDT to the power adapter and power source. MARS-1030 User Manual...
Page 129: Using Activesync
4.2 Using ActiveSync Use ActiveSync to transfer and synchronize files between the PDT and the Host PC. 4.2.1 Setting up a Partnership During the Microsoft ActiveSync installation, you were prompted to create a partnership with your mobile device. When you set up a partnership, you select synchronization and file conversation settings, which are contained in a file on your desktop computer.
Page 130: Activesync File Synchronization
4.3 Networking Please see the 3.2.14 Owner, Table 3-33 Owner on page 3-45 for setting up the network ID. And see the 2.5.6 Setting Up Wireless LAN RF to setup the 802.11b Wireless LAN for RF connecting. MARS-1030 User Manual...
Page 131 Software Applications This chapter describes software imple- mentation procedures.
Page 132: Chapter 5 Software Applications
Synchronize e-mail messages with Microsoft Exchange or Outlook on the Host Computer. Send and receive e-mail messages by connecting directly to an e- mail server through an Internet server provider (ISP) or a network. To setup “Inbox”: Select Start> Programs> Inbox. MARS-1030 User Manual...
Page 133 Select Service> Options from the command bar. Drag the dialog to show the right edge so that you can configure e-mail. Select “Add…” (Note 1) In the “Service Type” list, select POP3 Mail or IMAP4 Mail. (POP3 is the most common mail protocol for ISPs). Enter a unique name for the e-mail service in the “Service name”...
Page 134 – Get Full Copy of messages: Select to receive a full copy of all messages. In addition to the message body, any options you select in When getting full copy will be downloaded. Selecting this option increases the amount of time needed to download messages. MARS-1030 User Manual...
Page 135 – Only synchronize folder hierarchy under Inbox (IMAP4 only): Select to reduce download time by preventing the com- plete downloaded of the folder list every time you connect. – Get meeting requests (POP3 only): Select to download and store copies of meeting requests when getting full copies of messages.
Page 136 Once the message is moved, you will be able to access the message only from your device. Folder- • Create a folder: – Select File> Folder> New Folder – Type a name for the folder. MARS-1030 User Manual...
Page 137 • Delete a folder: – Select the folder you want to delete – Select File> Delete • Designate a folder as offline: Only IMAP4 folders can be designated as offline. All IMAP4 default folders, such as Inbox, are automatically designated as offline.
Page 138 Download message from the server: – When you download messages, you need to create two connec- tions: a remote connection and a mail server connection. The remote connection connects you and your ISP or network. The MARS-1030 User Manual...
Page 139 mail server connection enables messages to be downloaded from your mail server to the Inbox on your device. When you select Services> Connect to Inbox, the Inbox starts a remote connection using the connection you specified when setting up the current mail service. If you are already connected through a remote connection other than the one you specified in the ser- vice, you will be asked if you want to use the current connec- tion.
Page 140 Attachments> Show Attachments. Store an attachment: – Select Service> Options> Storage tab. – Select to store attachments in internal RAM or on a storage card. – If you use more than one storage card, select it from the list. MARS-1030 User Manual...
Page 141 Note: Once you make the above selection, all attachments will be moved to the selected card. Delete an attachment: – To delete an attachment from a message you are sending, select the attachment, and then select Edit> Clear or press the DEL key on the keypad.
Page 142: Internet Explorer
View menu. From the top menu bar, select View > Hide Tool- bars. Once hidden, it is necessary to “cold reset” these features to access them again. (Refer to “2.7.2 Cold Reset” for more information.) MARS-1030 User Manual...
Page 143 5.2.3.4 Set up a proxy server Proxy servers are often used when connecting to the Internet through a local network for added security. Select View > Internet Options > Connection Tab. Select Access the Internet using a proxy server. Enter the proxy server address and port. For more information, see your administrator.
Page 144 Open the file in a word processing program, such as WordPad. 5.2.3.15 Change home and search page settings Select and open the page to use as the home or search page. Select View > Go > Home or Search. MARS-1030 User Manual...
Page 145 5.2.3.16 Save a copy of current page It is possible to save web pages and view them later when disconnected from the Internet or Intranet, without using cached memory. Select File > Save As Specify a folder location and give the file a name. 5.2.3.17 Copy a web page to a document Select all or part of the web page to be copied.
Page 146: Media Player
Windows Messenger supports high-quality voice calling on a Windows CE device. Communicate using Session Initiation Protocol (SIP) or Hotmail contacts Windows Messenger supports. Communication with col- leagues using a SIP based communications service. Talk to Hotmail contacts using .NET Messenger. MARS-1030 User Manual...
Page 147: Microsoft Wordpad
5.2.6 Microsoft WordPad Create and edit documents and templates in WordPad, using buttons and menu commands that are similar to those in the desktop version of Microsoft Word. It is possible to work with files in Normal or Outline views. WordPad documents are usually saved as .pwd files, but it is possible to save documents in other file formats, like .rtf or .doc.
Page 148 – Select the text you want to change. To select all text, select Edit > Select All. – From the Font list, select the desired font. – From the Font Size list, select a size. Note: To see more formatting options, select Format > Font. MARS-1030 User Manual...
Page 149: Adjusting The Display
Change font formatting – Select desired text. – Select the Bold, Italic, or Underline button. – To change the font color, select Format > Font and select the color from the Color list. Adjust the paragraph alignment – Select the paragraph to align using the mouse and cursor. –...
Page 150: Working In Outline View
If Network is selected from the Port list, enter the path to the net- work printer to the Net Path box. 5.2.6.7 Setting a password for a document Select File > password. Type and verify the password. Saving the document is necessary (File > Save) to return the pass- word. MARS-1030 User Manual...
Page 151 5.2.6.8 Converting Documents About document conversion If an e-mail program is installed and receives an attached Word document or template created in Word version 6.0 or later, Word- Pad can convert the file. To view the document, simply open the attachment in WordPad.
Page 152 WordPad file back to a WordPad document. • OLE Objects OLE Objects are removed during conversion. • Revisions marks, annotations, and comments Revision marks are visible but cannot be changed. Annotations and documents are removed during conversion. MARS-1030 User Manual...
Page 153: Disconnecting Without Ending A Session
5.2.7 Remote connection The Remote Desktop Connection can log onto the Windows Terminal Server and then access and use all the programs installed on the server. For example, instead of running Microsoft Pocket Word, you can run the desktop version of Microsoft Word. 5.2.7.1 Connecting to terminal server Select Start >...
Page 154: Windows Explorer
To view icons, select View > Large Icons or Small Icons. To view a list, select View > Details. 5.2.8.3 Working with files and folders Create a new folder – If necessary, open the folder in which the new folder is to be placed. MARS-1030 User Manual...
Page 155 – Select File > New Folder. Add a folder to your Favorites list – Open the folder – Select Favorites > Add to Favorites. – In the Name box, type the shortcut name. Tips: • To open a favorite file or folder, select Favorites and then select the folder.
Page 156: Diskonchip
File > Save As > navigate to the DiskOnChip location and save it. 5.3.2 DiskOnChip location To access the contents of files in the DiskOnChip storage: Double-tap the My Computer icon on the desltop. Double-tap the DiskOnChip icon to view DiskOnChip. Figure 5.6: DiskOnChip MARS-1030 User Manual...
Page 157: Diskonchip Size
5.3.3 DiskOnChip size The size of the DiskOnChip will vary, depending on the size of system firmware. Inside the DiskOnChip directory, tap File > Properties. The DiskOnChip Properties dialog: The number listed after Free is the amount of memory bytes currently available on the device for the Dis- kOnChip system.
Page 159 Barcode Setting This appendix provides instructions for customizing the barcode engine.
Page 160: Appendix A Barcode Setting
Selecting the decode menu item displays the decode Decoder Setup options dialog box. Selecting the Options Menu item displays the Setup Options dialog box MARS-1030 User Manual...
Page 161 Item Explanation The application has the capacity to save the Config file. The Config file that is saved when this item is selected is correlated to the Config that is currently active. A dialog is presented and requests selection of Save Current a name for the file to save.
Page 162: Symbology Setup
Default All Defaults all symbology options for all symbologies to Symbologies the internal defaults. Enable All Enables all symbologies, but does not change other Symbologies symbol options. Disable All Disables all symbologies without affecting other Symbologies symbol options. MARS-1030 User Manual...
Page 163: Decoder Setup
A.1.2 Decoder setup Functions: Item Explanation Maximum time (in milliseconds) that the imager attempts to decode before declaring a “No Decode” condition. If attempting to decode using the trigger key, the imager quits decode attempts even if the trigger key No Read remains depressed.
Page 164 Information includes the AIM ID, SymID (Code ID), and symbol modifier. Display No Enables / disables display “No Decode” message if no Decode bar code symbol is decoded by either a timeout or trig- Message ger release. MARS-1030 User Manual...
Page 165: Options
A.1.3 Options Functions: Item Explanation Select the scanning timeout duration (in seconds) from Trigger Timeout the pull-down list. <3 ~ 10 sec, Default: 6> None After showing barcode, no action. After showing the barcode, jump to next CRLF Termination row. Code Space After showing the barcode, jump one unit.
Page 166: Update Tab
A.2 Update Tab MARS-1030 User Manual...
Page 167 Functions: Item Explanation When this item is selected, the imager is queried for the current firmware version information. The Firmware Revision version information is then displayed in the text window. This item allows new engine firmware to be installed into the imager. When Flash New Firmware is selected, a prompt to select the firm- ware file appears.
Page 168: Symbologies List
Enable if you are scanning Aztec Runes, the smallest type of Aztec Code symbols, which Enable Aztec Runes have the capacity to encode a very short license plate message. The minimum and maximum length ranges Message Length for the barcodes are 1 - 3750. MARS-1030 User Manual...
Page 169: Codabar
A.3.2 Codabar Functions: Item Explanation Enable this barcode. Symbol Enable The scanner can read barcode data with a check digit. If this item is not checked, the bar Check Char/Digit code is read as though no check digit was Enable present.
Page 170: Code 11
This option sets whether 1 or 2 check digits are required with Code Check Char/Digit Enable 11 type barcode. The minimum and maximum length Message Length ranges for the barcode are 1 - 80. Check Digits Required Default = Two Check Digits. MARS-1030 User Manual...
Page 171: Code 128
A.3.4 Code 128 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 0 - 80. Appendix A...
Page 172: Code 39
Transmit transmit this character at the end of the scanned data. This setting is only valid if check char/digit is enabled. Start/Stop characters identify the leading Start/Stop Transmit and trailing ends of the barcode. MARS-1030 User Manual...
Page 173 Item Explanation If this box is checked, the scanner can Append Mode Enable append the data from several Code 39 barcodes together before transmitting them to the host computer. When this function is enabled, the scanner stores those Code 39 barcodes that start with a space (excluding the start and stop symbols), and doesn’t immediately transmit the data.
Page 174: Code 49
A.3.6 Code 49 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for the Message Length barcode are 1 - 81. MARS-1030 User Manual...
Page 175: Code 93
A.3.7 Code 93 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 0 - 80. Appendix A...
Page 176: Composite Codes
A.3.8 Composite Codes Functions: Item Explanation Enable this barcode. Symbol Enable Enable to scan UPC-A/EAN-13 Composite Enable UPC-A/ codes. EAN-13 Composite The minimum and maximum length ranges for Message Length the barcode are 1 - 2435. MARS-1030 User Manual...
Page 177: Data Matrix
A.3.9 Data Matrix Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 1500. Appendix A...
Page 178: 172
Addenda Required addenda. When this feature is selected, the data is output with a space between the data from the main barcode and the Include Addenda Separator data from the addenda. When turned off, there is no space. MARS-1030 User Manual...
Page 179: 173
A.3.11 EAN-13 Functions: Item Explanation Enable this barcode Symbol Enable The output of the check digit at the end Check Char/Digit Transmit of the scanned data. Option allows decoding and outputting of a 2 digits addendum on the end of Enable 2 Digit Addenda all scanned EAN-13 data.
Page 180: Interleaved 2 Of 5
Check Char/Digit Transmit the end of the scanned data. This setting is only valid if check char/digit is enabled. The minimum and maximum length Message Length ranges for the barcode are 2 - 80. MARS-1030 User Manual...
Page 181: Maxicode
A.3.13 MaxiCode Functions: Item Explanation Enable this barcode Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 150. Appendix A...
Page 182: Micropdf417
A.3.14 MicroPDF417 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 366. MARS-1030 User Manual...
Page 183: Ocr-A, Ocr-B, Us Currency
A.3.15 OCR-A, OCR-B, US Currency The imager is able to read machine readable fonts used in optical charac- ter recognition (OCR). The imager can read from 6 to 60 point OCR type- face. OCR Mode • OCR-A • OCR-B Appendix A...
Page 184 “80086996” can read as “80086996” or “96698008.” The default is Left-to-Right, (LtoR). MARS-1030 User Manual...
Page 185 A.3.15.1 OCR Templates A custom “template,” or character string defines the length and content of OCR strings that will be read with the imager. Several choices are avail- able when creating a custom template for the application. Create a tem- plate for a single format, string together several formats, or you can create a template for a user-defined variable.
Page 186 Hex value that represents the character(s) to match. Use the Programming Chart (inside the back cover) to scan the numbers that represent these characters. Example: It is required to read three digits, three specific characters like “ABC” and then three more digits. MARS-1030 User Manual...
Page 187 The template would be: To create this template, enable the OCR-A font. Scan the Enter OCR Template symbol. Scan the d from the OCR Programming Chart three times. Then scan 414243 from the inside back cover (the hex characters for “A,” “B,” and “C”), and scan the d three more times. Scan Save OCR Template.
Page 188 Scan d four times, scan l two times, then scan d two more times. Scan Save OCR Template. This would let you read either type of format, for example: It is possible to string together as many templates as are required. MARS-1030 User Manual...
Page 189 A.3.15.8 OCR Template Codes Note: Reading more than three rows of OCR is not recommended. Contact the factory if you have an application that requires reading four or more rows of OCR. † One or more two-digit numbers and Save are required after reading this programming symbol.
Page 190 ASCII Conversion Chart (Code Page 1252) MARS-1030 User Manual...
Page 191 ASCII Conversion Chart (Code Page 1252) Appendix A...
Page 192 OCR Programming Chart MARS-1030 User Manual...
Page 193 Programming Chart Appendix A...
Page 194 MARS-1030 User Manual...
Page 195: Pdf417
A.3.16 PDF417 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for the Message Length barcode are 1 - 2750. Appendix A...
Page 196: Postnet
Explanation Enable this barcode. Symbol Enable The scanner can only read US Post- net bar codes printed with a check Check Char/Digit Transmit character, and will transmit this char- acter at the end of the scanned data. MARS-1030 User Manual...
Page 197: Qr Code
A.3.18 QR Code Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 3500. Appendix A...
Page 198: Reduced Space Symbology
Explanation Enable RSS Expanded code. RSS Expanded Enable Enable RSS Limited code. RSS Limited Enable Enable RSS 14 code. RSS 14 Enable The minimum and maximum length Message Length ranges for the barcode are 4 - 74. MARS-1030 User Manual...
Page 199: Upc-A
A.3.20 UPC-A Functions: Item Explanation Enable this barcode. Symbol Enable The output of the check digit at the end Check Char/Digit Transmit of the scanned data. Option allows decoding and outputting of a 2 digit addendum at the end of all Enable 2 Digit Addenda scanned UPC-A data.
Page 200: Upc-E
Include Addenda Separator data from the addenda. When turned off, there is no space. Transmits the numeric system digit of Send Number System a UPC-E symbol. MARS-1030 User Manual...
Page 201: Upc-E1
A.3.22 UPC-E1 Functions: Item Explanation Enable this barcode. Symbol Enable The output of the check digit at the Check Char/Digit Transmit end of the scanned data. Option allows decoding and output- ting of a 2 digit addendum at the end Enable 2 Digit Addenda of all scanned UPC-E1 data.
Page 202: Isbt
A.3.23 ISBT Functions: Item Explanation Enable this barcode. Symbol Enable MARS-1030 User Manual...
Page 203: British Post
A.3.24 British Post Functions: Item Explanation Enable this barcode. Symbol Enable Appendix A...
Page 204: Canadian Post
A.3.25 Canadian Post Functions: Item Explanation Enable this barcode. Symbol Enable MARS-1030 User Manual...
Page 205: Australian Post
A.3.26 Australian Post Functions: Item Explanation Enable this barcode. Symbol Enable Australian Post is a 4-state symbology that was designed with a non-defined user area. The user can define how that area field is interpreted. Most systems have dedicated decoders that will not decode a symbology Send Bar Width Data that is not already defined.
Page 206: Iata 2 Of 5
A.3.27 IATA 2 of 5 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 48. MARS-1030 User Manual...
Page 207: Codablock F
A.3.28 Codablock F Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 1 - 2048. Appendix A...
Page 208: Japanese Post
A.3.29 Japanese Post Functions: Item Explanation Enable this barcode. Symbol Enable MARS-1030 User Manual...
Page 209: Planet Code
A.3.30 Planet Code Functions: Item Explanation Enable this barcode. Symbol Enable The scanner only reads Planet bar- codes printed with a check character, Check Char/Digit Transmit and transmits this character at the end of the scanned data. Appendix A...
Page 210: Kix (Netherlands) Post
A.3.31 KIX (Netherlands) Post Functions: Item Explanation Enable this barcode. Symbol Enable MARS-1030 User Manual...
Page 211: Msi
A.3.32 MSI Functions: Item Explanation Enable this barcode. Symbol Enable The scanner only reads MSI barcodes printed with a check character, and Check Char/Digit Transmit transmits this character at the end of the scanned data. The minimum and maximum length Message Length ranges for the barcode are 4 - 48.
Page 212: Tcif Linked Code 39
A.3.33 TCIF Linked Code 39 Functions: Item Explanation Enable this barcode. Symbol Enable MARS-1030 User Manual...
Page 213: Matrix 2 Of 5
A.3.34 Matrix 2 of 5 Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for the Message Length barcode are 1 - 80. Appendix A...
Page 214 A.3.35 Korean Post Functions: Item Explanation Enable this barcode. Symbol Enable The minimum and maximum length ranges for Message Length the barcode are 2 - 80. MARS-1030 User Manual...
