VIA Technologies EPIA Mini-ITX Operation Manuallines page 5

VIA Technologies, Inc.
3.6 CIR Module Connector (Reference Designs for CIR module available):
J6 10 EMDATA
3.7 CD-ROM Line-in Connector:
J7
3.8 Wake up on Modem Connector:
J8
3.9 USB Port 2 & 3 Connector (Reference Design for USB module available):
J9
8 MS_DATA
6 EKBDATA
4 KB_DATA
2 Ground
1 +5V
3 USB P2 -
5 USB P3 -
7 - OC2
-5-
VIA EPIA Mini-ITX Mainboard
Operation Guidelines
9 EMCLK
7 MS_CLK
5 EKBCLK
3 KB_CLK
1 +5V
1 CD_L
2 Ground
3 Ground
4 CD_R
1 5V_SB
2 Ground
3 Wake up on Modem
2 Ground
4 USB P2 +
6 USB P3 +
8 -OC3
