Model VHD-2 VGA to TV / HDTV Scan Converter With Composite, S-Video, and Component (YPbPr) Outputs Linear Pan and Zoom UMA1087 REV. 1.4... - Page 4 Model VHD-2 TRADEMARKS USED IN THIS MANUAL Hall Research, HR, and are trademarks of Hall Research, Inc. Apple and Macintosh are registered trademarks of Apple Computer; Inc. IBM is a registered trademark of International Business Machines Corporation. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
-
Page 5: Table Of Contents
Table of Contents Package Contents..................3 Introduction ....................4 General ....................4 Supported Systems ................4 Features......................5 VHD-2 Description..................6 Installation and Setup ................... 7 Accessories ....................8 Operation ...................... 8 Main Menu ....................8 Remote Control................... 11 Troubleshooting..................13 Shipping and Packaging .............. -
Page 6: Package Contents
Model VHD-2 Package Contents VHD-2 Scan Converter Remote Control Unit HD15 Male to Male (VGA) Cable Composite Video Cable (Yellow RCA) S-Video Cable Y, Pb, Pr Cable Switching Power Supply Power Adapter Remote Control Y-Pb-Pr Cable Composite & S-Video Cables... -
Page 7: Introduction
VGA to TV & HDTV Scan Converter Introduction General The VHD-2 is a scan converter that converts computer VGA signals to TV (NTSC and PAL) as well as HDTV Component video. It can produce in real-time a clear and flicker-free TV image with 16.7 million-colors. It accepts all PC resolutions up to 1600 x 1200. -
Page 8: Features
Model VHD-2 Features • Real time PC to TV/HDTV Scan Converter • Outputs HDTV resolutions to 1080i • Supports Y Pb Pr (Component) video out to HDTV • Converts computer image into NTSC and PAL TV • Supports Composite (A/V) and S-Video out •... -
Page 9: Vhd-2 Description
S-VIDEO OUT..S-Video output for TV’s equipped with S-Video C.V. OUT....Composite-Video output DC IN......Adapter input connector POWER ....This LED lights up when VHD-2 is powered up MENU .......Pops up the on screen display menu NTSC/PAL ....Used to toggle between NTSC and PAL output HD Mode ....Toggle between 1080i, 720p, 480p, or 480i HD... -
Page 10: Installation And Setup
VHD-2 to it, using the S-Video cable 6. If there is no S-Video connector on the TV monitor, connect the CV output of VHD-2 to the composite video input on the TV 7. Set the TV monitor to “video” mode. -
Page 11: Accessories
The power LED on the VHD-2 should now be lit, indicating that the unit is on. Turn on the computer, its monitor (if being used), and the TV monitor. The TV should display the computer’s display. - Page 12 Model VHD-2 Note: Using your Remote Control can also operate the OSD Menu. OSD Main Menu: OSD Menu Setting Option Description: Video Quality: Erase Horizontal Video jitter; enhance the video quality on TV. Brightness: Increase or decrease the brightness level on TV.
- Page 13 VGA to TV & HDTV Scan Converter Flicker: (9-level Flicker Control adjustment) Adjust the flash intensity in horizontal line will offer optimal Computer Image to display on TV. H POS (Horizontal Position): Move the Computer Image on TV/HDTV screen horizontally. V POS (Vertical Position): Move the Computer Image on TV/HDTV screen vertically.
-
Page 14: Remote Control
Model VHD-2 Remote Control Remote Control button description Power: Switch the VHD-2 on/off. Home: The home setting will bring your image back to the normal position. Quality: Enhance video quality on TV. Zoom: Zoom in and out of the Computer Image on TV/HDTV screen. - Page 15 HDTV component output the resolution could be as low as 480 or as high as 1080 depending on the HDTV mode that you set. In 1:1 mode the VHD-2 does not perform any scaling of the input image signal and theoretically you will get the best image possible...
-
Page 16: Troubleshooting
Troubleshooting Symptom Possible Cause(s) No picture on TV 1. VHD-2 is not ON; Ensure that the adapter is plugged into a Monitor working wall outlet and its DC connector is plugged into the VHD-2. 2. TV monitor is not ON. -
Page 17: Technical Support
VGA to TV & HDTV Scan Converter Technical Support If you believe that the VHD-2 is malfunctioning, do not attempt to repair the unit. Contact Technical Support at 714-641-6607. Before you call us, please make a record of the history of the problem. We... -
Page 18: Specifications
Model VHD-2 Specifications VGA Input: Up to 1920 x 1200 on DB15 Female with 16.7 million colors Horizontal freq: 31.5 KHz to 80 KHz Vertical freq: 50Hz to 150Hz Vertical Lines: 1200 VGA modes: Auto Horizontal/Vertical frequency detection to adjust picture position... - Page 20 Model VHD-2 © Copyright 2009. Hall Research, Inc... All rights reserved. 1163 Warner Ave. Tustin, CA 92780 Ph: (714)641-6607, Fax -6698...
