Infinova V1700N-NE2 Series Operation Manual

Ip ptz dome
Hide thumbs Also See for V1700N-NE2 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
V1700N-NE2 Series
IP PTZ Dome Operation Manual
This manual mainly addresses the operation and programming of Infinova V1700N-NE2 series IP domes.
Based on network technology, V1700N-NE2 series IP domes could easily realize network digital video
transmission and network control function, and provide professional remote video services. They provide
high-reliable, cost-effective solutions to various applications.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V1700N-NE2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinova V1700N-NE2 Series

Summary of Contents for Infinova V1700N-NE2 Series

  • Page 1 V1700N-NE2 Series IP PTZ Dome Operation Manual This manual mainly addresses the operation and programming of Infinova V1700N-NE2 series IP domes. Based on network technology, V1700N-NE2 series IP domes could easily realize network digital video transmission and network control function, and provide professional remote video services. They provide...

  • Page 3: Copyright Statement

    This device must accept any interference received, including interference that may cause undesired operations. The V1700N-NE2 series IP Domes have been tested and found to comply with the limits for a Class A digital device, pursuant to the FCC rules. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.

  • Page 5: Table Of Contents

    Table of Contents Chapter I System Introduction............. 1 4.2 Player.................. 13 1.1 Product Description .............. 1 4.3 Stream Type ................ 13 1.2 Product Features ..............1 4.4 Motion Detection ..............13 1.3 Product Model............... 1 4.5 Privacy mask............... 14 1.4 Product Specifications ............1 4.6 Color Setting...............

  • Page 7: Chapter I System Introduction

    Infinova V1700N-NE2 series IP domes. dome menu • Privacy mask function effectively shade the unwanted areas V1700N-NE2 series IP PTZ dome camera is the newly developed • Indoor/outdoor mounts, high adaptability video surveillance product. Based on the network technology, the •...

  • Page 8: Notice

    Video Height 240mm × Ф214mm / Height 9.4" × Ф8.4" (Ceiling) Video Compression: H.264/M-JPEG Outdoor: Max Resolution: 4CIF @ H.264/M-JPEG Height 313mm × Ф240mm / Height 12.3" × Ф9.4" (Bracket); Optional Resolution: Height 300mm × Ф218mm / Height 11.8" × Ф8.6" (Ceiling) Major Stream: Shipping Dimension (Length×...

  • Page 9: Chapter Ii Ie Browser Setting

    Download OCX First, user has to log in with the Infinova super ID and password (For more information, please refer to Chapter 3.1 Login). After successfully logging in, you will be informed that the browsing...

  • Page 10: Chapter Iii Basic Function Operation

    OCX is needed, which is shown as below: Chapter III Basic Function Operation This chapter mainly introduces the settings and operation of V1700N-NE2 IP domes. 3.1 Login Please open IE browser after it powers on for about 50 seconds and enter http://192.168.1.100/ (the default IP address) in the IP address Figure 2-4 OCX Installation for example.

  • Page 11: System Information

    Figure 3-5. Setting Interface for Super User Figure 3-3. Common User Interface after Login The dome supports H.264/M-JPEG dual compression formats. The system default is H.264 compression format after login successfully, and you can click “M-JPEG” button to enter real-time video interface under M-JPEG format as shown in figure 3-4.

  • Page 12: Account Settings

    Click “OK” button, the image will be back to Figure 3-9. 3.3 Account Settings If the 9 user is to be added, the following box will pop up: There is one default super user: admin (password: admin). The super user can add or delete common users and alter the password of common users.

  • Page 13: Network Settings

    Users can set Address type, Unit IP address, Subnet mask and Figure 3-19 Gateway IP address. V1700N-NE2 series dome has the function of alarm associated with Address Type: display the way of IP address distribution: manually FTP uploading. configured. “Manually configured” means that the following items Configure server IP, user name and password in the FTP setting can be set in the interface.

  • Page 14: Smtp Settings

    3.4.4 SMTP Settings V1700N-NE2 series IP domes support signal switch alarm and motion detection alarm, triggering Email sending. To realize the functions, the mail server and receiver information shall be set in the SMTP setting interface.

  • Page 15: Ptz Settings

    Baud rate: set the communication baud rate of control and camera modules, the default value is 2400 bps. The options include 1200 V1700N-NE2 series IP domes support 2 switch value alarm inputs, bps， 2400 bps， 4800 bps， 9600 bps， 19200 bps， 38400 bps， 57600 and users can select the state of the alarm inputs.

  • Page 16: Record Management

    in working. 3.10.2 Replay Click “Record Management” in the navigation bar, and then select "Replay" to display the interface below: Figure 3-26 It is recommended to enable the Deinterlaced function of the system when there are much of dynamic scenes, and to disable the function when the major scenes are static.

  • Page 17: Security

    3.12.1 Software Update Local download path: Set the path to save the downloaded files. If Free software update is provided for V1700N-NE2 series IP domes, resetting required, click the button “Browse”. and this update service can reduce system maintenance budget. You Click the button “Start Download”, and then the files in the list will...

  • Page 18: Factory Settings

    Click “Reboot”, the system will be automatically re-started. And after 80 seconds the webpage closes. Note: only the super users can set this option. Figure 3-35 At this time, re-check the updating file and camera system, or otherwise choose other program to update. Note: After update successfully, it needs to restart the system.

  • Page 19: Chapter Iv H.264 Video And Parameter Settings

    Chapter IV H.264 Video and Parameter Infinova Player: select Infinova player to play video. Quick Time: select Quicktime Player to play video. Settings Note: When “Quick Time” is selected, system will prompt you to When login successfully, the interface will be “H.264” (as shown in input username and password to conduct confirmation, and the figure 3-2 or 3-3).

  • Page 20: Privacy Mask

    Figure 4-5 4.8 OSD Settings Click “OSD” button in the navigation bar to display the following V1700N-NE2 series domes support privacy mask function. If there interface: is certain location within the surveillance area where operators are not allowed to see, and thus, PRIVACY MASK can be applied.

  • Page 21: Qos Setting

    4.9 Qos Setting Click “QoS” button, and network Qos setting interface will be shown as follows: Figure 4-10 I/P rate means the ratio of I frame to P frame in compressed video images. Different I/P bit rates could be selected according to different system configurations.

  • Page 22: Audio

    The variable rate can adjust the bandwidth that it occupies Note: automatically according to the complexity of image, because the When Infinova Player is selected, set the In/Out button to complexity of real video sequence keeps changing, details, speed, enable/disable the audio in/out function. When QuickTime Player is...

  • Page 23: Chapter V M-Jpeg Video Setting

    Chapter V M-JPEG Video Setting other events. As shown above: User can also click “M-JPEG” button to enter “M-JPEG” video (as The frame rate can be chosen from: 2, 4, 5, 10, 15. shown in figure 3-4). Super users can set such settings via the buttons on the left as resolution, image quality, frame rate, snapshot 5.4 Snapshot and so on, while common users can only view resolution and image...

  • Page 24: Chapter Vi Menu Settings

    Chapter VI Menu Settings Note: When the address and baud rate is set via DIP switch, the ID and baud rate displayed on the menu are unchangeable. Note: The common users have no such settings. There are two ways for users to enter menu: 1.2 DOME TITLE SET 1.
  • Page 25 unadjustable. For 28X domes, WDR is unadjustable. 3.6 MOTOR SPEED SET Speed level 2.6 SPECIAL FUNCTION Set mirror mode Select the running speed of motor, there are HIGH, LOW and Set freeze mode MEDIUM for selection. The default is MEDIUM. Set sharpness Enable/disable NR mode 4.

  • Page 26: Chapter Vii Camera Control

    Chapter VII Camera Control 7.2 Lens Function Setting The camera control keyboard is illustrated as below: When the mouse moves on , the button will turn light when clicking it with the mouse, it returns to former status, which Lens Direction means it works.

  • Page 27: Speed Adjustment

    7.3.1 Speed Adjustment 7.3.4 Setting Autopan and Calling up Autopan Pan Speed: Adjust pan speed of dome. 8 grades are available: the Setting Autopan greater the number is, the faster the speed is. (1) Enter the autopan number in Tilt speed: Adjust tilt speed of dome. 8 grades are available: the (2) Use the direction button to perform a series of pan and tilt and greater the number is, the faster the speed is.

  • Page 28: Appendix I Magnetic Ring Filter Instruction

    Appendix I Magnetic Ring Filter Instruction To reduce electromagnetic interference that power supply generates, it is necessary to install a magnetic ring filter with the power cable. To install a magnetic ring filter with power supply: Step 1: Open the magnetic ring filter and lead the power cable through. Step 2: Wire the power cable on the magnetic ring filter 3 rounds or more (Make sure the filter can be well closed).

  • Page 29: Appendix Ii Questions & Solutions

    Appendix II Questions & Solutions The following table describes the symptoms causes, and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable The IP dome does not perform Power supply failure Repair or replace power supply initiation sequence after powering on Power PCB fuse damage Replace the fuse...
  • Page 30 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V2.1 1301...
