Summary of Contents for Infinova V5422IR-A8065ST-W
- Page 1 V5422IR-A8 Series High Resolution Day/Night IR Minidome Camera INSTRUCTION MANUAL...
- Page 3 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com.
- Page 4 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. ...
-
Page 5: Table Of Contents
CONTENTS Chapter I System Introduction ............... 1 1.1 Product Description ................1 1.2 Product Features ................. 2 1.3 Product Model ..................3 1.4 Specifications ..................4 1.5 Notice ....................6 Chapter II Menu Settings ................7 2.1 Image ..................... 7 2.2 Advanced .................... -
Page 7: Chapter I System Introduction
Thank you very much for purchasing our product! V5422IR-A8 series high resolution day/night IR minidome camera is specially designed by Infinova for the surveillance application of elevators. This camera adopts 1/1.9" progressive scan CMOS sensor. With built-in 2.8mm fixed lens and high resolution of 800 TV lines, users can acquire better image quality. -
Page 8: Product Features
1.2 Product Features Infinova’s V5422IR-A8 series camera has the following features and functions: 1/3" progressive scan CMOS sensor High Resolution: 800TV lines IR-Cut Removable (ICR) Filter for Day/Night switching 15m IR Range Supports OSD menu display function ... -
Page 9: Product Model
1.3 Product Model This manual is for the following models: V5422IR-A8065ST-W High Resolution Day/night IR minidome camera, 1/3-inch progressive scan CMOS sensor, 2.8mm lens, 800TV lines, PAL, 15m IR range, Indoor, White exterior, Surface mount, 12VDC V5422IR-A8065ST-B High Resolution Day/night IR minidome camera, 1/3-inch progressive scan CMOS sensor, 2.8mm lens,... -
Page 10: Specifications
1.4 Specifications Model V5422IR-A8 Series Image Sensor 1/3" progressive scan CMOS Video Format PAL/NTSC Effective Pixels PAL: 1280×960; (H×W) NTSC: 1280×952 Resolution 800TVL Day/Night Functionality Lens Fixed lens: F2.0, f=2.8mm Lens Mount X (Panning): 0°~360°; Camera Angle Y (Tilting): 0°~75° (-3°~0° deviation); Adjustment Z (Rotating): 0°~344°... - Page 11 Motion Detection Up to 4 programmable areas Sync. System Internal Video Output 1.0 Vp-p (75 Ohm) Power Supply 12VDC, ±10% Power 180mA (Maximum), 12VDC Consumption Operating -4°F~122°F (-20°C~+50°C) Temperature Storage -4°F~140°F (-20°C~+60°C) Temperature Operating 0%-90% RH (non-condensing) Humidity Unit Dimensions 2.87"×Ф3.66"...
-
Page 12: Notice
1.5 Notice 1. Do not place the camera under strong light for fear of damaging the CMOS chip. 2. Do not directly touch the CMOS element. If it is necessary to clean the element, use a soft cloth moistened with alcohol to wipe off the dust. 3. -
Page 13: Chapter Ii Menu Settings
CHAPTER II MENU SETTINGS Main menu settings are as follows: MAINMENU IMAGE ↲ ADVANCED ↲ DAY&NIGHT EXTERNAL LANGUAGE ENGLISH LOAD DEFAULT SOFT VERSION V2.00.00 SAVE&EXIT EXIT 2.1 Image 3D-DNR ↲ IRIS ↲ EXPOSURE CONTROL ↲ ↲ IMAGE ENHANCE ↲ ZOOM IN RETURN ↲... -
Page 14: Advanced
2.2 Advanced ZONE MASKING ↲ MOTION DETECTION ↲ MIRROR FLIP RETURN ↲ 2.2.1 Zone Masking COLOR MOSAIC AREA NO.1 ↲ AREA NO.2 ↲ AREA NO.3 ↲ AREA NO.4 ↲ AREA NO.5 ↲ AREA NO.6 ↲ AREA NO.7 ↲ AREA NO.8 ↲... -
Page 15: Motion Detection
2.2.2 Motion Detection SENSITIVITY HIGH AREA NO.1 ↲ AREA NO.2 ↲ AREA NO.3 ↲ AREA NO.4 ↲ RETURN ↲ 2.3 Day & Night DAY&NIGHT EXTERNAL【COLOR/B&W/AUTO】 2.4 Language LANGUAGE ENGLISH【中文】 2.5 Load Default LOAD DEFAULT 2.6 Soft Version SOFT VERSION V2.00.00 2.7 Save &... -
Page 16: Exit
2.8 Exit EXIT... -
Page 17: Appendix I Cable Diameter Calculation And Lightning & Surge Protection
APPENDIX I CABLE DIAMETER CALCULATION AND LIGHTNING & SURGE PROTECTION Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%. - Page 18 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
- Page 20 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.0 1512...
