Infinova V6202IR-H02 Series Instruction Manual

Hd 2mp ir ip fixed camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V6202IR-H02 Series
HD 2MP IR IP Fixed Camera
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V6202IR-H02 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Infinova V6202IR-H02 Series

Summary of Contents for Infinova V6202IR-H02 Series

  • Page 1 V6202IR-H02 Series HD 2MP IR IP Fixed Camera INSTRUCTION MANUAL...
  • Page 2 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com.
  • Page 3 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic  radiation. Clean with a dry cloth.  Provide adequate ventilation. ...

  • Page 4: Table Of Contents

    CONTENTS Chapter I System Introduction............... 1 1.1 Product Description ................1 1.2 Product Features..................2 1.3 System Requirement ................3 1.4 Product Model..................4 1.5 Specifications..................5 1.6 Notice ..................... 7 Chapter II Installation..................8 2.1 Installation Precautions................8 2.2 Installation Introduction................. 8 Chapter III IE Browser Settings ..............11 3.1 Equipment Connection ................

  • Page 5: Chapter I System Introduction

    CHAPTER I SYSTEM INTRODUCTION 1.1 Product Description V6202IR-H02 series HD 2MP IR IP fixed camera features 1/2.8" progressive scan CMOS sensor built-in megapixel fixed lens (4mm/6mm/8mm/12mm optional). With H.264/M-JPEG compression format utilized, this camera can output HD full-frame videos with the resolution up to 1080P.

  • Page 6: Product Features

    Support simultaneous access and parameter setting via Web Server from  multiple clients Compatible or able to integrate with Infinova V2216 and other digital video  surveillance software Standard SDK is provided for easy integration with other systems ...

  • Page 7: System Requirement

    1.3 System Requirement Configuration of the computer to display image and control the camera: Intel Pentium 4, 2.4 GHz or above CPU: 512 MB or greater RAM: 100M Ethernet port Network Port: Operating System: Microsoft Windows 7, Microsoft Windows XP IE Browser Version: Microsoft Internet Explorer 6.0 or above...

  • Page 8: Product Model

    1.4 Product Model This manual is for the following models: V6202IR-H0225A HD Megapixel IR IP camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, 2.0Mpx, 12VDC, 4mm fixed lens V6202IR-H0225B HD Megapixel IR IP camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, 2.0Mpx, 12VDC, 6mm fixed lens V6202IR-H0225C HD Megapixel IR IP camera, Day/night, 1/2.8 inch...

  • Page 9: Specifications

    1.5 Specifications V6202IR-H02 Series Model 1/2.8" CMOS Image Sensor 72dB Dynamic Range 50dB S/N Ratio Fixed lens: F1.6, f=4mm, 6mm, 8mm, 12mm Lens Day/Night Functionality 0lux(IR on) Sensitivity Scene mode, Manual mode, Shutter priority Exposure mode Auto/Manual (1/30s~1/8000s) Shutter Auto/Manual/Incandescent light/Cool white...
  • Page 10 ≤180ms Network Delay Up to 4 areas Motion Detection Up to 4 masks Privacy Mask Available Local Recording Available Upgrade Online Available Password Protection One RJ45 10/100M self-adaptive Ethernet port Network Port Available via BNC port Analog Video Output IPv4, TCP, UDP, IGMP, DHCP, FTP, SNMP (V3), SMTP, NTP, RTP, RTSP, RTCP, HTTP, Applicable Protocols HTTPS, TSL, SSL, 802.1X, Qos, PPPoE, DNS,...

  • Page 11: Notice

    1.6 Notice 1. Firstly perform network settings after login. The gateway IP address should be set as that of the connected to the network camera. 2. The IP address is not allowed to conflict with that of other devices; otherwise, you cannot visit the camera.

  • Page 12: Chapter Ii Installation

    CHAPTER II INSTALLATION 2.1 Installation Precautions Do not drop the camera or subject it to strong knock.  Do not point the camera lens toward the sun or other strong light.  Do not install the camera in places with high humidity, frequent vibrations, ...
  • Page 13 Use 1/4-20UNC screws to mount the camera to the suitable bracket. Note: Infinova’s V1554-6 bracket is recommended to match with V6202IR-H02 series camera. But V1554-6 bracket is not the official accessory. Please order it if you need. See the figure below for the dimensions of V1554-6: (Unit: mm)
  • Page 14 The bracket provides 360° horizontal adjustment and 0~80° vertical adjustment. Please adjust the camera angle according to your surveillance need. Dimensions (Unit: inch, in the parentheses is mm) Figure 2-3...

  • Page 15: Chapter Iii Ie Browser Settings

    Directx 9.0c. InfiPlayerAX  3.1 Equipment Connection V6202IR-H02 series IP camera can be directly connected to a computer, or connected to a network. Note: Check whether the connection is tight or not before power-on. 3.2 Software Installation...
  • Page 16 successful login. Click the link to run, or store the exe file, then run it. Figure 3-1 If the installation fails, check whether there is video viewed through other IE window or page. You should close the video or the IE window directly. If it successes, click refresh, you can view the live video.
  • Page 17 up reboot prompt, please cancel reboot. Then close all the IE window and install InfiPlayerAX control once again. The live video will display as below: Figure 3-4 Note If InfiPlayerAX control installation falls, the live video won’t display. Then, you should change the IE security level. 1.

  • Page 18: Live View

    CHAPTER IV BASIC FUNCTION OPERATION This chapter mainly introduces the settings and operation of V6202IR-H02 series. 4.1 Live View Start IE browser after the server is powered on for about 90 seconds, and then enter IP address, such as http://192.168.1.100 (default), in the address field. Note: The default subnet mask is 255.255.255.0 and the default gateway IP address is 192.168.1.254.
  • Page 19 Figure 4-2 Live view H.264 V6202IR-H02 series IP camera supports H.264 and M-JPEG video compression formats. After successful login, it enters H.264 major stream live video interface. Stream Type: Users can also select H.264 minor stream or MJPEG from the dropdown list of stream type.
  • Page 20 Default: C:\InfiPlayerAX\Picture. V6202IR-H02 series supports local recording. Click the recording button to start recording; when the button changes to , click it to stop recording. During local recording, “REC” appears on the video screen. Click the button to enter the recording storage path.

  • Page 21: System

    Click the option tab “Setting” to enter the system setting interface. Figure 4-4 Settings Interface With the help of navigation menu on the left, Super user can perform the following operations: Basic Information View, Time Settings and Advanced Settings, Network Settings, Camera Settings (including Basic Set, Effect Set, White Balance, IR set, Reset), Video Settings, Alarm Settings, Account Settings (Add/Delete User, Change Password), Log, etc.
  • Page 22 H.264/MJPEG video settings, etc. 4.2.2 Time Settings Figure 4-5 “Time” Settings Time Zone Settings Time Zone: Select the desired time zone in the scroll box, and then click “Save” to save it. There are 33 time zones for your selection. If Daylight Saving Time is applied in your region, please enable daylight saving time.
  • Page 23 4.2.3 Advanced Settings Figure 4-6 “Advanced” Settings Software Update Free software update is provided for V6202IR-H02 series camera, and this update service can reduce system maintenance budget. Confirm the requirement submitted by user, we will provide the latest software for download, and help user to update the V6202IR-H02 series camera.
  • Page 24 Figure 4-7 Select update file, and press “Open” button. The selected update file will be displayed in the box before “Browse”. After that, click “Submit” button to update software, the following information will appear: Figure 4-8 Click “Yes” button, run the program to finish the update. The response time is due to the program type.
  • Page 25 After reboot, it will skip to new web page to run new program. Note: Available only for the super user. Factory Settings V6202IR-H02 series camera provides online reset function, which greatly facilitates reset adjustment. “Keep current IP unchanged”, click “Reset” button and the system will Select...
  • Page 26 2. Default IP address is 192.168.1.100, and default subnet mask is 255.255.255.0. 3. Do not power off during reset, or else the reset will fail. Online Reboot Click “Reboot” button, the dialog box “This operation will take 90 seconds, are Click “OK”...

  • Page 27: Network Settings

    4.3 Network Settings Click “Network” in the navigation bar, and the following interface will display: Figure 4-10 Network Settings 10 option tabs are available: Network, FTP, SMTP, HTTPS, 802.1X, QOS, IGMP, SIP, DDNS and UPnP. 4.3.1 Network Settings IP mode: support both IPv4 and IPv6 modes. Network parameters are slightly different under different IP modes.
  • Page 28 Users can also enable/disable PPPoE in this interface. If enabled, users can set the user name and password. V6202IR-H02 series camera supports heartbeat function. In SNMP settings, set and save the heartbeat sever IP address and Heartbeat interval, and then the heartbeat package will be sent to the server or client, which greatly facilitates the server or client to know about the camera’s network status.
  • Page 29 4.3.2 FTP Settings Figure 4-12 FTP Settings V6202IR-H02 series camera has the function of alarm associated with FTP upload (alarm triggered image snapshot). Configure server IP, user name and password in the FTP settings and activate FTP handling way in alarm settings, then alarm triggered images FTP upload can be achieved.
  • Page 30 If user selects “mail” in “Alarm Settings” interface, system will send mails according to SMTP settings. 4.3.4 HTTPS Settings Figure 4-14 HTTPS Settings V6202IR-H02 series camera supports HTTPS protocol. You can import the CA certificate in the interface. 4.3.5 802.1X Settings Figure 4-15 802.1X Settings...
  • Page 31 V6202IR-H02 series camera supports 802.1X protocol. You have to enable 802.1X authentication when needed. Then, select an EAP method and enter the user name and password. 4.3.6 QOS Settings Figure 4-16 QOS Settings There are 4 network Qos modes to be selected:...
  • Page 32 users can select the stream type and set the state, multicast IP address and RTP port. 4.3.8 SIP Settings Figure 4-18 SIP Settings SIP Server: to configure SIP server for device; SIP Server IP: the IP address of SIP server; Port: the port number of SIP server;...
  • Page 33 request to the server. Position Information: the mounting information or instruction for device. Longitude: the longitude of mounting position, as precise to two places of decimal; Latitude: the latitude of mounting position, as precise to two places of decimal. 4.3.9 DDNS Settings Figure 4-19 DDNS Settings Dynamic Domain Name System (DDNS) synchronizes the host name and dynamic IP address continuously.
  • Page 34 4.3.10 UPnP Settings Create mapping between private network and the Internet via UPNP protocol. Select UpnP option and enter the configuration page. The added mapping list appears on the page. Figure 4-20 UPnP Settings In “Operation” column, means to delete; means to edit user information.

  • Page 35: Camera Settings

    4.4 Camera Settings Click “Camera” in the navigation bar to enter the interface shown as below: Figure 4-22 Basic Settings 6 option tabs are included in the camera settings page: Basic set, Exposure, Effect set, White balance, IR setand Reset. 4.4.1 Basic Settings You can set the following parameters:...
  • Page 36 Flicker frequency: 50Hz or 60Hz. CVBS: it automatically changes with the flicker frequency. Notes: The analog video is closed when the MJPEG video stream is enabled. To enable the analog video, please close the MJPEG video stream. Enable or disable horizontal and vertical mirror, backlight compensation or WDR.
  • Page 37 4.4.2 Effect Settings In the Effect Settings interface, users can adjust the brightness, sharpness, hue, contrast; saturation and 3D denoise in two ways: General or Mode, as shown in the figure below: Figure 4-24 Effect Set - General Drag the slider to adjust the brightness, sharpness, hue, contrast, saturation and 3D denoise.
  • Page 38 Figure 4-25 Effect Set - Mode The camera supports 6 video effect modes. Users can set name for each mode. IR mode, brightness, Each mode matches with a group of parameters, such as sharpness, hue, contrast, saturation and 3D denoise. Users can set and save effect parameters for each mode.
  • Page 39 4.4.3 White Balance Settings Figure 4-26 White Balance Settings The camera has rich white balance modes, including Auto, Manual, Incandescent light, Cool white fluorescent light, Sun light, Cloudy and Natrium light. If set to manual mode, you can set the red gain and blue gain.
  • Page 40 4.4.4 IR Settings Figure 4-27 IR mode: set IR illuminators working mode. Options: Day, Night, Auto (turn on or off as per ambient light). Switch time: in auto mode, the response time for day/night switch. Power set: the adjusting mode of illuminators’ power consumption. Options: Auto, Manual.

  • Page 41: Video Settings

    4.5 Video Settings Click the button “Video” in the navigation bar to display the following interface. Figure 4-28 Video Settings Video, OSD, Motion, Privacy, ROI, Shelter and Path can be set in this interface. Click the related option tab to enter the setting interface. 4.5.1 Video Users can set the video parameters in the format of H.264 major or minor stream and MJPEG stream, such as resolution, frame rate and IP rate.
  • Page 42 1280×720, and closed optional. Frame Rate: the number of compressed frames produced by camera per second. The bigger the frame is, the better the image continuity will be, but the CPU performance is lowered. The smaller the frame is, the worse the image continuity will be, but the CPU could handle more events.
  • Page 43 Image Quality: it can be set under MJPEG stream. Options: Highest, High, Average, Low and Lowest. The higher the image quality is, the more bandwidth it will occupy. 4.5.2 OSD Figure 4-29 OSD settings include: Text OSD, Image OSD and Date OSD. Click the button “On”...
  • Page 44 set its transparency, delete its white ground and set the display position of the image. The camera supports only one image uploaded on the video screen. Click the “Browse” button after the “Image”, select the image and click “Upload”. X-axis &Y-axis: The title axis location. Both X-axis and Y-axis can be any of whole numbers from 0 to 99.
  • Page 45 4.5.3 Motion Detection Figure 4-30 Motion Detection Settings V6202IR-H02 series camera support motion detection. Users can easily set the motion detection areas (up to 4) with the mouse. Note: do turn on motion detection function in Live View interface before motion detection setting.
  • Page 46 To cancel a motion detection area, just cancel the box ticking. 4.5.4 Privacy Mask V6202IR-H02 series camera supports privacy mask function. If there is certain location within the surveillance area where operators are not allowed to see, and thus, Privacy Mask can be applied. System covers and shields the sensitive area via Privacy Mask setting, to avoid operators observing certain sensitive locations on monitor.
  • Page 47 How to set and cancel privacy mask is similar to the operations of motion detection, refer to Section 4.5.3. 4.5.5 ROI The camera supports four ROI encoding areas. Figure 4-32 ROI Settings ROI settings method: Tick off the serial number of the region for setting and click the button “Drag Box”.
  • Page 48 Cancel the tick-off of the serial number of the region, then ROI settings are cancelled . Figure 4-33 Region 1 settings 4.5.6 Active video tampering The camera supports active video tampering.
  • Page 49 Figure 4-34 Active video tampering settings You can open or close this function on this page. When the function is open and active video tampering is detected, the alarm lamp on the top of the page turns red. 4.5.7 Storage Path You can set the photo saving path and recording saving path in the following interface.

  • Page 50: Alarm Settings

    Default video saving path: C:\InfiPlayerAX\ Video. Photo and video formats can also be set. The default photo format is .jpg and the default video format is .avi. To change the saving path, click the button “Browse” and select the path from the popup dialog box.

  • Page 51: Account Settings

    Alarm schedule V6202IR-H02 series camera can set the effective alarm schedule. Select the alarm period (if Sunday is selected, alarm will be enabled during the set period of each Sunday; if “Everyday” is selected, alarm will be enabled during the set period of everyday), and then, set the time period.
  • Page 52 Figure 4-37 Account Settings 1. Add Users (1) Click “ ”, enter the interface of “Add a User”. Figure 4-38 Add a User (2) Enter the desired User Name and Password (Note: User name and password shall include letter, number and underline only. No special character is allowed. The string length of user name is legal between 1 and 30 characters and that of password is between 5 and 20 characters.) (3) Click “OK”...
  • Page 53 2. Delete Users In the “Account setting” interface, click button of the “Operation” item to delete user. The following dialog box will display: Figure 4-40 Click “OK” button, the selected user would be deleted and the account list would be automatically updated. 3.

  • Page 54: System Log

    Note: The login interface will pop up if change Super user password changed. Input Super user name and password in the interface to log, then the prompt will inform password has been edited successfully. 4.8 System Log Click the “Log” option tab, the date, time and log information will appear on the right of the screen.

  • Page 55: Appendix I Magnetic Ring Filter Instruction

    APPENDIX I MAGNETIC RING FILTER INSTRUCTION To reduce electromagnetic interference that power supply generates, it is necessary to install a magnetic ring filter with the power cable of Infinova front-end IP device. To install a magnetic ring filter with power supply: Step 1: Open the magnetic ring filter and lead the power cable through.

  • Page 56: Appendix Ii Questions & Solutions

    APPENDIX II QUESTIONS & SOLUTIONS The following table describes the symptoms causes and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable Repair or replace power Power supply failure supply PCB fuse damage Replace the fuse Immediate startup after Restart 10 seconds later The network...

  • Page 57: Appendix Iii Lightning & Surge Protection

    APPENDIX III LIGHTNING & SURGE PROTECTION The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 58 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.1 1409...
