TCL MT01+DE200 Service Manual
  1. Manuals
  2. Brands
  3. TCL Manuals
  4. TV
  5. MT01+DE200
  6. Service manual
TCL MT01+DE200 Service Manual

TCL MT01+DE200 Service Manual

Color television
Hide thumbs

Advertisement

Quick Links

Download this manual
Color Television
Service Manual
Contents
1.
Block Diagram ....................................................................................................... 2
2.
Circuit Diagrams and PWB Layouts .................................................................... 3
3.
Alignments ........................................................................................................... 34
4.
Explode Views...................................................................................................... 41
5.
Spare Parts List.................................................................................................... 53
6.
Revision List ........................................................................................................ 87
AOE China, C.M.C., TCL Multimedia
Published Date: 2007-07-24
MT01+DE200
Chassis
Photo Only For Reference
Page

Advertisement

loading
Need help?

Need help?

Do you have a question about the MT01+DE200 and is the answer not in the manual?

Questions and answers

Related Manuals for TCL MT01+DE200

Summary of Contents for TCL MT01+DE200

  • Page 1: Table Of Contents

    Photo Only For Reference Service Manual Contents Page Block Diagram ....................... 2 Circuit Diagrams and PWB Layouts ..............3 Alignments ......................34 Explode Views...................... 41 Spare Parts List....................53 Revision List ......................87 AOE China, C.M.C., TCL Multimedia Published Date: 2007-07-24...

  • Page 2: Block Diagram

    TUNER&AV MERGING BOARD FOR 20 ”LCD From P13 POWER AMPLIFER FOR 20” LCD Mute TDA 1517P MT01 SIGNAL BLOCK DIAGRAM WM8501 D3953N Tuner Tuner MT8201 TDA9886T From P103 D9453D 2006-09-09 V1 ST333W Audio Preparing CVBS SIF CS5340 From P12 For USB Mute Reset POWER AMPLIFER FOR 32”LCD...

  • Page 3: Circuit Diagrams And Pwb Layouts

    MT8201_SZ_V2 History Date 1. INDEX / POWER 2006/5/16 BY Dennis Ge SZ-V2 MODIFIED ACCORDING TO TTE'S REQUIREMENTS 2. LDO 3. MT8201 LQFP256 4. DDR MEMORY & FLASH 5. HDMI INPUT MT8293 6. VGA IN & PC AUDIO IN 7. AUDIO& VIDEO CONNECT 8.
  • Page 4 AVICM AVICM PWM2VREF PWM2VREF ASB18A PLLVDD PLLVDD TESTP3 PLLVDD TESTP3 120R TESTN3 TESTN3 TESTP4 TESTP4 TESTN4 TESTN4 ASB18A XTALVDD XTALVDD XTALVDD LVDDA LVDDA 120R LVDDB LVDDB LVDDC LVDDC REFP ADCVDD ADCVDD AV18A REFP VPLLVDD1 REFP REFN REFN 120R VPLLVDD1 VPLLVDD1 REFN ASB33A VPLLVDD2...
  • Page 5 SB33A SB18A DV18A DV33A Near the MT8201 SDV33 A_RA[0:11] CB51 CB52 A_BA[0:1] CB49 CB67 A_DQM0 A_DQM0 0.1U 0.1U A_DQ[0:15] 0.1U 0.1U A_CLK A_CLK 820K A_CKE A_CKE A_CS# A_CS# A_RAS# A_RAS# A_CAS# DV33A A_CAS# A_WE# A_WE# XTALI XTALO AMP_POWER AMP_POWER IOCE# IOCE# IOWR# IOWR#...
  • Page 6 A_RA0 D_RA0 A_RA1 D_RA1 A_RA2 D_RA2 A_RA3 D_RA3 A_RA7 D_RA7 A_RA6 D_RA6 A_RA5 D_RA5 A_RA4 D_RA4 A_RA11 D_RA11 A_RA9 D_RA9 A_RA8 D_RA8 F_D[0:7] A_DQ0 D_DQ0 IOCE# NOTE:R33 is mounted only for 29lv160 Flash IOCE# A_DQ1 D_DQ1 F_OE# F_OE# D_DQ0 A_DQ2 D_DQ2 IOWR# IOWR#...
  • Page 7 SW_VCC 8293_GPIO2 LD1117S18 A_HPD SW_VCC DV33B VCC18 120R VCC18 GPIO_SCL1 B_HPD HPD_SINK 9993_SDA 0.1U SDA_SINK 9993_SCL VCC9 SCL_SINK HPD2 HPD2 GND7 IOVCC B_DDC_SDA SDA2 GND6 B_DDC_SCL CLOCK- SCL2 CLOCK+ 0.1U GND11 120R GND12 VCC5 1.25x(1+48.7/110)=1.8V SW_VCC B_CLOCK- DATA0- B_CLOCK+ DATA0+ 0.1U TMDS341A VCC10...
  • Page 8 VGAHSYNC# VGAHSYNC# VGAVSYNC# VGAVSYNC# VGA IN 0.01U VGASOG VGASCL_IN VGASOG R100 VGA_PLUGPWR SDA0 SDA0 VGAROMWP SCL0 SCL0 VSYNC 0.01U GREEN BLUE BAV70 VGASOG HSYNC 4700P GREEN 120R VGASDA_IN 120R 120R 0.01U BLUE 120R 120R VGA_PLUGPWR 510R 2.2UH HSYNC VGAHSYNC# VGA_PLUGPWR VGAROMWP H : WP ENABLE VGASCL...
  • Page 9 Near the MT8201 R105 0.047U TU_CVBS_OUT CVBS0 Near the MT8201 R103 330P R104 0.01U SOY0 CVBS INPUT CVBS0 CVBS0 CVBS1 CVBS1 CVBS2 CVBS2 CVBS3 CVBS3 R106 R108 0.01U TU_CVBS_OUT Y0_IN TU_CVBS_OUT CVBS OUTPUT TUNER CVBS INPUT AV2_IN AV2_IN AV3_IN AV3_IN S_VIDEO OUTPUT DVB_SYNC AV CVBS INPUT...
  • Page 10 SCT1_AUL_IN SCT1_AUL_IN SCT1_AUR_IN SCT1_AUR_IN SCT2_AUL_IN SCT2_AUL_IN SCT2_AUR_IN SCT2_AUR_IN SCART AUDIO INPUT AV1R_IN AV1R_IN AV1L_IN AV1L_IN AV2R_IN AV2R_IN 5VSB AV2L_IN AV2L_IN YPBPRR_IN 5VSB YPBPRR_IN YPBPRL_IN YPBPRL_IN AUDIO INPUT R193 AVR_OUT 2N7002 2N7002 SCL_TUNER SDA_TUNER TUL_OUTPUT TUL_OUTPUT TUR_OUTPUT DV33B CE73 DV33B TUR_OUTPUT N-MOSFET N-MOSFET TUNER OUTPUT...
  • Page 11 BACKLIGHT INTERFACE( WITH ADAPTOR MODELS ONLY) CONNECTOR R226 5.0A R227 LVDSVDD 5.0A R229 DIMMING 120R IRF7314 R231 CB137 PWM0 BT3904 SELECT Hi For External LO = > LVDS POWER ON SELECT SELECT Low For Internal HI = > LVDS POWER OFF R235 ER03_GPIO BACKLIGHT_ON/OFF...
  • Page 12 STANDBY CONTROL 5VSB BL_ON/OFF 8201UP3_0 High == > OPEN FRAME POWER OFF GNDA GNDA POWER_STBY POWER_STBY ON/OFF R502 Q501 POWER_STBY BT3904 STANDBY POWER (ONLY FOR 20") L558 C204 0.01U L559 L560 U501 L561 L569 15UH L562 MP9583 L563 POWER CINCH GNDP R531 ON/OFF...
  • Page 13 or 1085-3.3v D2PAK 6.5V KD1084 3.3V D2PAK +3.3V_A VOUT MPZ1608S101A 220 OHM/100MHZ C192 C193 10U/16V 13-KD1084-33B 100U/16V +3.3V_D C198 10U/16V 220 OHM/100MHZ C148 10U/16V LD1117V33 VOUT 13-AS1117-ADB +3.3V_MOJO +3.3V_A LD1117V ADJ-1.2V +1.2V_D VOUT MPZ1608S101A C155 0.1U 0.1U C199 10U/16V 100U/16V C201 10U/16V +3.3V_D...
  • Page 14 +1.8V_T +1.8V_TA +3.3V_T C111 C112 C113 C110 C114 C115 C116 C117 100N +3.3V_T 100N 100N 100N R156 100N 100N 100N 100N +5V_T +3.3V_T +5V_T1 C119 100N R158 TD1316AF-MK3 C123 C124 C120 C121 C122 4.7K 0 NC RESET_FE_N 0.1U 10U/16V R160 100k 100N 100N...
  • Page 15 U38-2 U38-7 R126 10K TS_DATA[0..7] GPIO16/DTR0/VCXO_CLK TS_DATA0 RESET_FE_N TS_DATA0 RESET_FE_N GPIO0/IR_IN TS_DATA1 TS_DATA1 GPIO17/RX1 TS_DATA2 RESET_STV TS_DATA2 TS_SYNC TS_SYNC RESET_STV GPIO1/IR_OUT TS_DATA3 TS_DATA3 GPIO18/TX1 TS_DATA4 USER_EEPROM_WP TS_DATA4 TS_STROBE(CLK) TS_CLK USER_EEPROM_WP GPIO2/PWM/VS TS_DATA5 TS_DATA5 TS_DATA6 R129 RX/TX, NC TS_VALID TS_DATA6 TS_VAL GPIO3/VPP GPIO/ITU_OUT0/BOOT0 TS_DATA7...
  • Page 16 +3.3V_P A_MICLK +3.3V_D +3.3V_B A_MICLK A_MDI4 A_MIVAL A_MIVAL A_MDI3 220 OHM/100MHZ 0.1U 0.1U R95 100 I2C_LOCAL_SCL I2C INTERFACE +3.3V_P I2C_LOCAL_SCL I2C_LOCAL_SDA 0.1U I2C_LOCAL_SDA R96 100 TDA_CLK TDA_CLK MICLK MICLKA TDA_SYNC TDA_SYNC MISTRT MISTRTA TDA_VALID TDA_VALID MIVAL MIVALA MIU_ADDR[0..24] A_MISTRT MIU_ADDR7 PCMCIA_A7 TDA_DATA[0..7] A_MISTRT...
  • Page 17 +3.3V_A +3.3V_D 220 OHM/100MHZ C197 220 OHM/100MHZ 10U/16V 100n 0.1U 10U/16V I2S_OUT_SCK I2S_OUT_WS PLL0 I2S_OUT_SD DATA1 SFOR0 1.5K SFOR1 AUDIO_R MMZ1608S601C FSCLK 1U/16V SYSCLKPLL1 MUTE 4.7N DEEM/CLKO MMZ1608S601C C168 C178 R239 1.5K C169 AUDIO_L UDA1334BTS SSOP16 C179 1U/16V 4.7N 47U/16V 100n +3.3V_D U38-3...
  • Page 18 +3.3V_D 220 OHM/100MHZ 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 10U/16V 10U/16V SDRAM_ADDR0 SDRAM_ADDR12 U38-4 ADDR0 SDRAM_ADDR1 ADDR1 SDRAM_ADDR2 ADDR2 SDRAM_D0 SDRAM_ADDR0 SDRAM_ADDR3 SDRAM_D0 SDRAM_DATA0 SDRAM_ADDR0 ADDR3 SDRAM_D1 SDRAM_ADDR1 SDRAM_ADDR4 SDRAM_D1 SDRAM_DATA1 SDRAM_ADDR1 ADDR4 SDRAM_D2 SDRAM_ADDR2 SDRAM_ADDR5 SDRAM_D2 SDRAM_DATA2 SDRAM_ADDR2 ADDR5 SDRAM_D3 SDRAM_ADDR3 SDRAM_ADDR6...
  • Page 19 SCH: 01-MDE200-DI2 PCB: +1.2V_D U38-1 40-MDE200-DIB4XG 220 OHM/100MHZ VDDC_1V2 VSSC VDDC_1V2 VSSC 10U/16V 10U/16V 0.1U 0.1U 0.1U 0.1U 0.1U VDDC_1V2 VSSC VDDC_1V2 VSSC +3.3V_D VDDC_1V2 VSSC +3.3V_MOJO VDDP_3.3V VSSC VDDP_3.3V VSSC 220 OHM/100MHZ VDDP_3.3V VSSC VDDP_3.3V VSSC 10U/16V 10U/16V 0.1U 0.1U 0.1U 0.1U...
  • Page 20 POWER MENU P601 AGND AGND R607 R606 R605 R604 R603 R602 R601 AGND...
  • Page 21 C110 C112 P701 HP-R HP-L R342 R341 AV3-IN D3V3L4 AV3-IN AVCVBS3 YELLOW AV3L-IN1 WHITE AV3R-IN1 AVCVBS3 FB701 R701 FB702 R704 AV3L-IN1 AV3L-IN AV3R-IN1 AV3R-IN AV3L-IN R702 R703 C701 C702 C703 C704 AV3R-IN P702...
  • Page 22 P602 AGND R611 100R AGND AGND LED601 R610 4.7K Q601 BC846B AGND...
  • Page 23 SCT1_B_IN AV2L_IN AV2R_IN AV1L_IN SCART1 R126 R125 R111 SCT1_FB SCART1_FB 120R AV1L_IN1 AV1L_IN AVR_OUT_SCART1 SCT1_FS ADCIN0 AV1R_IN1 SCT1_R_IN SCT2_C1_IN AV2/SY1_IN AVL_OUT_SCART1 CVBS_OUT_SCART1 AV1L_IN1 SCT1_B_IN SCT1_FS CVBS_OUT_SCART2 SCT1_G_IN AV1R_IN AV1_IN R112 R120 FB17 R124 SCT2_FS ADCIN1 AV1R_IN1 120R AV1R_IN FB16 120R AV2L_IN1 AV2L_IN ɾ³ý...
  • Page 24 SCART_9V RST1 INT1 100U GPIO1 GPIO2 AVR_OUT GPIO5 INT2 OPAV120 RST2 GPIO5 100U 12V_IN SWV120_IN AVR_OUT_1 AVV50 SWV120_IN AVL_OUT OPAV120 BT3904 SWV120_IN ADCIN0 OPVREF AVR_OUT AVV50 ADCIN1 OPVREF AVR_OUT_SCART2 NJM4558V L107 OPVREF SCART_5V OPAV120 2.2UH TV_OUT AVR_OUT_1 OPVREF AVL_OUT_1 C127 USB_IR_INPUT CVBS_OUT1 AVCVBS1...
  • Page 25 LFB005 L001 22UH ADCVA OUTR+ VCC5+ If using LG panel ,must use Q5 and delete FB005 1.8UH ADCVL C005 DGND DGND 0.47U ADCVA VCC5+ ML6401/NC R003 C006 ADCVL C004 0.1U 330P U002 C009 C022 0.47U DVDD DGND R004 0.1U C007 R017 SDATA_OUT R002...
  • Page 26 01-0ON37A-PWY(1-Sep-06).sch-1 - Wed Aug 30 18:31:12 2006...
  • Page 27 Z601 TUNER(F07WP) 5V-OUT 5V-OUT AGND R607 R606 R611 L602 C611 R620 R615 10UH 100nF D612 BA982 R601 C602 C603 AGND 47UF/16V 100nF AGND IF-AGC R610 AGND Q611 220K AGND IF-AGC D601 BC848C LS4148 C609 C614 X601 R609 10nF 1n5F 4MHz C622 AGND R604...

  • Page 34: Alignments

    XD1 of schematic) to chip CIMAX SP2. 2) Components and schematic of CI section , 6. If not communication from ATV to digital module, Please check: I2C of the ATV( MT01 section) and digital module. TCL Multimedia Technology Holdings LTD.
  • Page 35 Enter the factory menu (can use the IR and press the remote key “vol-”to “0’, press mute remote key ,then press 9,7,3,5 remote key. Press right key to enter the sub-menu and press MENU key to return the main-menu 4、Balance Adjust TCL Multimedia Technology Holdings LTD.
  • Page 36 < 25nit C、repeat A&B, until all is ok D、Adjust the value of Black level 4). Adjust the value of Black level Measurements are using ‘SCALBRI2.UPA’ patterns with -1% to 10% video level bars. TCL Multimedia Technology Holdings LTD.
  • Page 37 Normal/Warm/Cool White R R White balance White G G White balance White B B White balance Gray R R Gray balance Gray G G Gray balance Gray B B Gray balance RGB Calibrate ADC adjust TCL Multimedia Technology Holdings LTD.
  • Page 38 Carrier Shift Saturation Mute FM mute FM mute High FM mute Low 6)．Sound Volume Curve Item Sub-item Sound VOL_0 VOL_10 VOL_50 VOL_90 VOL_100 TV Pre TV pre- amplify AV Pre TV pre- amplify SWPREQ For debug TCL Multimedia Technology Holdings LTD.
  • Page 39 Prepare MTKTOOL UPDATE, update board, serial line. (1)、Connect PC, update board, and J3 on the main board with serial line (2)、Provide the STB +5V for main board (3)、Open “MtkTool.exe” in MTK TOOL program, and set the parameter as below picture TCL Multimedia Technology Holdings LTD.
  • Page 40 (6)、After downloading SW, it will be long time for Initializing EEPROM. Solution 2： Preparative is same with above. Set SYSTEM->FactoryKey on factory MENU to OFF. Connect the device as below picture. Update the SW follow solution1- (3), (4), (5), (6) TCL Multimedia Technology Holdings LTD.

  • Page 53: Spare Parts List

    RES SMD 1K OHM 1/10W 0603 R033 19-AB0102-JTX RES SMD 1K OHM 1/10W 0603 R055 19-AB0102-JTX RES SMD 1K OHM 1/10W 0603 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 TCL Multimedia Technology Holdings LTD.
  • Page 54 RES. SMD 22 OHM 1/10W +/-5% 0603 R005 19-AB0220-FTX RES. SMD 22 OHM 1/10W +/-5% 0603 R002 19-AB0223-FTX SMD. RES 22K OHM 1/10W +/-1% R262 19-AB0223-FTX SMD. RES 22K OHM 1/10W +/-1% R263 19-AB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 0603 TCL Multimedia Technology Holdings LTD.
  • Page 55 SMD. RES 47K OHM 1/10W 0603 R173 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 TCL Multimedia Technology Holdings LTD.
  • Page 56 CAP. ELEC 47 UF 16V +/-20% C178 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20% C129 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20% C143 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20% C127 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20% C141 TCL Multimedia Technology Holdings LTD.
  • Page 57 CAP. CER 1800 PF 50V +/-10% C140 28-AB0182-KBX CAP. CER 1800 PF 50V +/-10% C139 28-AB0222-KBX CAP.SMD 2200PF 50V +/-10% 0603 C157 28-AB0222-KBX CAP.SMD 2200PF 50V +/-10% 0603 C162 28-AB0222-KBX CAP.SMD 2200PF 50V +/-10% 0603 C161 TCL Multimedia Technology Holdings LTD.
  • Page 58 L111 33-KLL229-KTX SMD. COIL 2.2UH +/-10% 0603 L107 33-KLL229-KTX SMD. COIL 2.2UH +/-10% 0603 L110 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% FB011 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% FB012 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% TCL Multimedia Technology Holdings LTD.
  • Page 59 RES SMD 1K OHM 1/10W 0603 R220 19-AB0102-JTX RES SMD 1K OHM 1/10W 0603 R221 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R224 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R228 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R229 TCL Multimedia Technology Holdings LTD.
  • Page 60 13-IC1084-CMB IC AIC1084-33CM 3.3V (TO-263) 13-IMAXSP-2LB CIMAXSP2L-PQFP128 13-K4S281-63B SDRAM K4S281632I-UC60 13-LD1117-18B 1.8V REGULATOR IC LD1117S18TR 13-LD1117-33B IC LD1117 3.3V 13-LD1117-50B 5.0V IC LD1117S50TR 13-LD1117-50B 5.0V IC LD1117S50TR 13-LVC245-PWB IC 74LVC245APW 13-M24C64-W6B IC 64K EEPROM M24C64-WMN6 TCL Multimedia Technology Holdings LTD.
  • Page 61 RES SMD 10K OHM 1/10W 0603 R119 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R129 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R138 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R136 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R134 TCL Multimedia Technology Holdings LTD.
  • Page 62 RES SMD 33 OHM 1/10W +/-5%0603 R296 19-AB0330-JTX RES SMD 33 OHM 1/10W +/-5%0603 R174 19-AB0330-JTX RES SMD 33 OHM 1/10W +/-5%0603 R297 19-AB0331-JTX RES. SMD 330 OHM 1/10W 0603 R178 19-AB0331-JTX RES. SMD 330 OHM 1/10W 0603 R176 TCL Multimedia Technology Holdings LTD.
  • Page 63 SMD. CAP 50VDC 0.1UF +/-10% 06 C219 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F C111 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F C112 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F TCL Multimedia Technology Holdings LTD.
  • Page 64 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F TCL Multimedia Technology Holdings LTD.
  • Page 65 CAP.SMD 390P 50V +/-5% 0603 28-AB0391-JCX CAP.SMD 390P 50V +/-5% 0603 28-AB0391-JCX CAP.SMD 390P 50V +/-5% 0603 28-AB0472-KBX CAP.SMD 4700PF 50V +/-10% 0603 C179 28-AB0472-KBX CAP.SMD 4700PF 50V +/-10% 0603 28-AC0104-ZFX SMD. CAP 16VDC/100NF/+80%/-20% C210 TCL Multimedia Technology Holdings LTD.
  • Page 66 CHIP BEAD 220 OHM +/-25% 33-ELN221-NTX CHIP BEAD 220 OHM +/-25% 33-ELN221-NTX CHIP BEAD 220 OHM +/-25% 33-ELN221-NTX CHIP BEAD 220 OHM +/-25% 33-ELN221-NTX CHIP BEAD 220 OHM +/-25% 33-ELN221-NTX CHIP BEAD 220 OHM +/-25% TCL Multimedia Technology Holdings LTD.
  • Page 67 PIN BASE TU2005WNR-2X6 46-39720W-20XG BASE A1272WV-2X10P 47-PCM006-XX0 PCMCIA SOCKET 135-1450101901 47-RCA213-XX0G RCA SOCKET 1PIN AV-3.2-1W50 48-TAC001-XX0 TACT SWITCH 64-B20140-102G MACHINE SCREW（M2×14） 64-B20140-102G MACHINE SCREW（M2×14） 64-B20140-102G MACHINE SCREW（M2×14） 64-B20140-102G MACHINE SCREW（M2×14） T8-JM611ML-FCN ASS'Y - FRONT CABINET 54-829050-000 SPONGE（800X15X1.0） TCL Multimedia Technology Holdings LTD.
  • Page 68 MICRO STICK SWITCH K66T-2-BL-2.0-5 48-TAC001-XX1 MICRO STICK SWITCH K66T-2-BL-2.0-5 48-TAC001-XX1 MICRO STICK SWITCH K66T-2-BL-2.0-5 48-TAC001-XX1 MICRO STICK SWITCH K66T-2-BL-2.0-5 48-TAC001-XX1 MICRO STICK SWITCH K66T-2-BL-2.0-5 48-TAC001-XX1 MICRO STICK SWITCH K66T-2-BL-2.0-5 T8-JM611ML-KEYZ ASS'Y - KEY PARTS(ART) 56-822770-0HN1AG PUSH BUTTON TCL Multimedia Technology Holdings LTD.
  • Page 69 RES. SMD 0 OHM 1/16W +/-5% 19-AA0000-JTX RES. SMD 0 OHM 1/16W +/-5% 19-AA0000-JTX RES. SMD 0 OHM 1/16W +/-5% 19-AA0000-JTX RES. SMD 0 OHM 1/16W +/-5% 19-AA0000-JTX RES. SMD 0 OHM 1/16W +/-5% R434 TCL Multimedia Technology Holdings LTD.
  • Page 70 SMD. RES 22 OHM 1/16W +/-5% 19-AA0220-JTX SMD. RES 22 OHM 1/16W +/-5% 19-AA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R254 19-AA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R255 19-AA0222-JTX RES. SMD 2.2K OHM 1/16W +/-5% TCL Multimedia Technology Holdings LTD.
  • Page 71 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 R147 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 R275 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 R125 TCL Multimedia Technology Holdings LTD.
  • Page 72 19-AB0472-JTX RES SMD 4.7K OHM 1/10W 0603 19-AB0472-JTX RES SMD 4.7K OHM 1/10W 0603 19-AB0511-JTX RES SMD 510 OHM 1/10W 0603 19-AB0511-JTX RES SMD 510 OHM 1/10W 0603 19-AB0622-FTX SMD.RES 6.2K OHM 1/10W +/-1% R621 TCL Multimedia Technology Holdings LTD.
  • Page 73 23-A08330-JBX NETWORK RES. 33 OHM +/-5% RN10 23-A08330-JBX NETWORK RES. 33 OHM +/-5% 23-A08330-JBX NETWORK RES. 33 OHM +/-5% RN11 23-A08330-JBX NETWORK RES. 33 OHM +/-5% RN12 23-A08470-JBX CHIP ARRAY RES. 47 OHM +/-5% 0603*4 TCL Multimedia Technology Holdings LTD.
  • Page 74 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% 28-AA0105-KBX SMD.CAP 1UF 10V +/-20% TCL Multimedia Technology Holdings LTD.
  • Page 75 CAP. SMD 0.1UF 50V +80%~-20% F CB61 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F CB60 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F CB47 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F CB50 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F TCL Multimedia Technology Holdings LTD.
  • Page 76 SMD. CAP 100 PF 50V +/-5% 0402 C202 28-HB0102-KBX SMD. CAP 1 NF 50V +/-10% 0402 28-HB0102-KBX SMD. CAP 1 NF 50V +/-10% 0402 28-HB0102-KBX SMD. CAP 1 NF 50V +/-10% 0402 28-HB0102-KBX SMD. CAP 1 NF 50V +/-10% 0402 TCL Multimedia Technology Holdings LTD.
  • Page 77 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB14 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB74 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB92 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB93 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB57 TCL Multimedia Technology Holdings LTD.
  • Page 78 CB88 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB140 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB105 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB104 28-HC0104-ZFX SMD.CAP 100NF 16V +80% -20% CB91 TCL Multimedia Technology Holdings LTD.
  • Page 79 SMD. RES 0 OHM 1/10W +/-5% 33-ELN121-NTX SMD.COLL 33-ELN121-NTX SMD.COLL 33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 33-ELN201-NTX CHIP BEAD 200 OHM +/-25% TCL Multimedia Technology Holdings LTD.
  • Page 80 IND FXD 0603 EMI 100MHZ 33-KLN121-NTB IND FXD 0603 EMI 100MHZ 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L102 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% TCL Multimedia Technology Holdings LTD.
  • Page 81 RCA SOCKET AV-3.2-3W-051 47-VGA002-XX1 VGA SOCKET VGA-15W08 50-05000G-CUU3G FUSE -0603-5A 0467-005 46-FF060T-07M02G HS 7PIN TCL1578 FOR J8 46-FL006T-10X01G HS 10PIN TCL1505 FOR P2 67-387190-0A0 HEAT SINK FOR U6 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 R100 TCL Multimedia Technology Holdings LTD.
  • Page 82 TRIANGLE M/C SCREW M 4 X 8(black) 64-B40080-303G TRIANGLE M/C SCREW M 4 X 8(black) 64-Z30080-1040AG SCREW 67-M82461-0G0 底座左支架 67-M82600-1G0 SUPPORT 67-M82601-1G0 SUPPORT 67-M82604-0G0 BRACKET 67-M82882-0G0 BRACKET 67-M82883-0G0 BRACKET T8-JM611ML-RCNZ ASS'Y - REAR CABINET(ART) 55-824310-5CL1AG REAR CABINET TCL Multimedia Technology Holdings LTD.
  • Page 83 SMD. RES 8.2K OHM 1/10W +/-5% 0603 R703 19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% J701 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C110 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C112 28-AB0470-JCX CAP.SMD 47PF 50V +/-5% 0603 C703 TCL Multimedia Technology Holdings LTD.
  • Page 84 RES. SMD 100K OHM 1/16W +/-5% R630 19-AA0123-JTX SMD. RES 12K OHM 1/16W J 0603 R601 19-AA0123-JTX SMD. RES 12K OHM 1/16W J 0603 R615 19-AA0222-JTX RES. SMD 2.2K OHM 1/16W +/-5% 19-AA0222-JTX RES. SMD 2.2K OHM 1/16W +/-5% R633 TCL Multimedia Technology Holdings LTD.
  • Page 85 CAP. SMD 0.1UF 50V +80%~-20% F C634 28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F C633 28-AB0152-KBX SMD. CAP 1500 PF 50V +/-10% B C614 28-AB0200-JCX CAP.SMD 20P 50V +/-5% 0603 C613 28-AB0201-JCX CAP.SMD 200PF 50V +/-5% 0603 C631 TCL Multimedia Technology Holdings LTD.
  • Page 86 SMD. RES 75 OHM 1/10W 0603 R655 V8-T03M61-18F02 SOFTWARE CODE FOR U5 V8-L32M1D-DTEE03 SOFTWARE CODE FOR U17 06-RCTW43-A001X REMOTE CONTROLLER RCT311TU1G 46-QU020T-02A01G HS 2PIN TCL1572 46-40237H-01XG HS 1PIN Y0608074 41-40163H-00XG WIRE LCSAP08600004 41-40282H-02X WIRE LCSAP001AV0404 46-KF090F-14X22G HS 14PIN TCL1521 TCL Multimedia Technology Holdings LTD.

  • Page 87: Revision List

    Chassis: MT01+DE200 Reversion: V0 6．Revision List TCL Multimedia Technology Holdings LTD.
