SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
Page 3
SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
Page 4
SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
Page 5
SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
Page 6
EM BUSINESS CENTER FTV PRODUCT PLANNING DEPT. SPECIFICATION RELEASE Version: V1.0 Issued Date: 2012.12.20 Model: L39D3320F/MT10B-LA/CMTM E20 V20 PICTURE Panel Size (inch) LCDTV Aspect Ratio 16:9 Color Temperature Warm / Standard / Cold SIGNAL FORMAT CAPABILITY Y,Pb/Cb,Pr/Cr:up to 720p,1080i,1080p @50Hz/60Hz g i l l l u Picture Effect...
Page 7
Power supply USB1 USB2 Audio Amp. Panel Head phone DDR3 T90517 DDR3 MT5310 LVDS DEMO IP/GPIO FLASH Flash HDMI RECEIVER 64Mbit CVBS DECODER 3D COMB FILTER MPEG4 DECODER Serial TS in SCALER Audio TMDS YPbPr 4052 HDMI1 IF+/- HDMI 1.3 HDMI2 SWITCH 3 IN 1...
Page 8
Factory Alignment Specification of normal SIACP TCL WW R&D FPD CENTER Factory Alignment Specification of normal SIACP For MT10-LA Version 1.0 PREPARED BY : DATE : 2011-4-22 APPROVED BY : DATE : Page 1 of 12...
Factory Alignment Specification of normal SIACP Table of Contents Feature Specification ............................4 INFO..................................5 1.Electrical Assembly Alignment ........................5 1.1 Preconditions – DC/DC Check........................5 1.2 SW download ..............................5 1.3 Panel ID check and modify ........................... 6 1.4 Functional Test .............................. 6 1.5 DDC &...
Page 10
Factory Alignment Specification of normal SIACP Disclosure The information contained in this document is proprietary to TCL SZ FPD lab and shall not be disclosed by the recipient to third persons without the written permission of the team leader or GM of R&D.
Factory Alignment Specification of normal SIACP Feature Specification These chassises are designed for South America LCD TV. The main chip is from Mediatec (MT5310 series) and supports below inputs and outputs: class item Status MT10B-LA MT10L-LA Cable&Antenna Cable&Antenna ( PAL- M/N, NTSC-M) Antenna Antenna (SBTVD-T)
Factory Alignment Specification of normal SIACP INFO All tests and measurements mentioned hereafter have to be carried out at a normal mains voltage (220 ~ 240 VAC) All voltages have to be measured with respect to ground, unless otherwise stated All final tests have to be done on a complete set including LCD panel in a room with temperature of 25+/-7°C The White Balance (color temperature) has to be performed into subdued lighted room after at...
Factory Alignment Specification of normal SIACP upgrade FLASH SW from USB”. Remenber to do “Reset all” after upgrade the SW. 1.3 Project ID check and modify There is different ID stored in the NVM depended on different Panels. Modify it with Hyper terminal if the initial ID or a wrong ID make the set can not display clearly.
Factory Alignment Specification of normal SIACP 1.6 HDCP Test For HDCP compliancy, it’s needed to check whether the HDCP key has been well set. 2.Final Assembly Alignment 2.1 FactoryMenu Follow the below steps to pop-up the Factory Menu in case of “FactoryKey” is disable : - press RemoteControl key “MENU”...
Factory Alignment Specification of normal SIACP Each panel has it’s own colour coordinates, Please refer to the following table. L32V6200/L32E5200 L42E5200F/L42V6200F C32E320/L32P60 C42E320F/L42P60F Normal 0.275 0.310 0.275 0.290 0.280 0.290 0.280 0.290 Cool 0.265 0.285 0.265 0.290 0.270 0.280 0.270 0.280 Warm 0.305...
Page 16
Factory Alignment Specification of normal SIACP Item Sub-item Value/Sub-item Note Burning Off/On Select panel On with left/right Mode key, Press “EXIT” key to enter the burning mode; Press “Menu” key on keyboard to exit the burning mode ADC Need not to do ADC when alignment White Balance Item Sub-item...
Page 17
Factory Alignment Specification of normal SIACP Reset ALL Item Sub-item Value Note Reset Clear NVM values and set to default value Power Mode Item Sub-item Value Note Power Boot/Standby/ Boot: Enter power on mode Mode Last Status Standby: Enter standby mode Last Status: power on according to last status USB Clone Mode...
Factory Alignment Specification of normal SIACP Appendix “How to download FLASH SW” Prepare MTK SW tool for update. 1. Connect the PC to the serial connector on board using a special serial device (USB or COMx). 2. Provide the a correct voltage to the board 3.
Factory Alignment Specification of normal SIACP try again. Upgrade without loader(The TV set should be able to display normally): 1. Save the new software file(*.pkg) in the root directory of USB, and modify it’s name as a software number, such as “V8-0MT1006-LF1V017.pkg”. 2.
Page 29
1 Have no anything, No backlight/No Video/No Audio etc... Can not Power On +3V3_STB(P100 Check AC input and Pin7) is OK? P100 ON/OFF PIN1,2,4=24V is POWER (P100 Check PSU OK?(+24V) PIN 10)is >2V? Remote Power On Check IR net is CHECK STB LEVER Check IR net IF CHANGE(R156) ?
Page 30
2 Only Backlight, No Video Reset the TV set LVDS 1 Check the Q900 and Q901 is Working. Power(P902 PIN 2 Check the LVDS cable connect normally. 1) is 12V ? The P902 Check LVDS PIN13,31 clock is Check the U500 working normally. cable.
Page 31
3 Picture is normal, but speaker no Audio Have picture, no audio I2S signal is right? And R876\R877\R878\R879 R876\R877\R878\R879 should have sign at anytime be have sign at anytime Check the U700...
Page 32
DC-DC CONVERTER CIRCUIT 1 CHECK if the 12V 1.CHECK if the 24V OUTPUT from U100(L114) INPUT at U100 PIN2? CHECK if the 12V CHECK if the 1.1V INPUT at U107 OUTPUT at U107 (L100) PIN2 CHECK if the 5V CHECK if the 12V OUTPUT at U1 PIN2,4 INPUT at U1 PIN3...
Page 33
DC-DC CONVERTER CIRCUIT 2 1.CHECK if the 24V CHECK if the 5V OUTPUT INPUT at U106 from U106+Q100 OUT,L102 PIN1+Q100 PIN 5? CHECK if the 5V CHECK if the DVDD 3V3 INPUT at U104 OUTPUT at U104 PIN2 PIN3 CHECK if the CHECK if the 5V DDRV(1V5) OUTPUT INPUT at U111 PIN3...
Page 34
LVDS signal output is OK, but Panel is back Check the P100 PSU or LVDS cable and PIN12, if is H(3.3V). PANEL issue Check if L118,C163 Failure from Q102 and around Q102 ADIN3_SRV to L118 is right U500 issue...
Page 35
Key and IR Check if the P900 PIN2 have P100 PIN1 is 3.3V Check IR BOARD and RC the RC waveform Check if the IR net(L920,L926) and cable is Failure point right U500 issue Check if the P901 PIN2 value is variational When you press P901 PIN1 is 3.3V Keyboard issue...
Page 38
RAW BAG PE 80MM×100MM (AUTO LOCK) -- 0 装挂架螺钉 H4-39F339Z-AGSC0AA 74-007026-60CR POLYBAG (70MMX260MMX0.06MM) 收装电源线 H4-39F339Z-AGSC0AA 72-MT10LA-ELA1A PRI IB MT10L-LA TCL EN R=Y H4-39F339Z-AGSC0AA 70-STDF33-EEM1B TV PRI ADDENDUM SHEET F3300 STAND ASSY R H4-39F339Z-AGSC0AA 67-M94268-0G01ACK RAW STAND BRACKET -- 00 00 00 R=E H4-39F339Z-AGSC0AA 67-M93408-0G0...
Page 41
08-PE371C5-PW300CA 67-H88490-EA0 RAW HEATSINK POWER 00 00 R=Y 08-PE371C5-PW300CA 67-H88490-EA0 RAW HEATSINK POWER 00 00 R=Y FOR U401 08-PE371C5-PW300CA 67-H88056-BA0 RAW HEATSINK PE3210 BA0 00 R=Y FOR QW3 08-PE371C5-PW300CA 66-20516X-1B0 RAW HOLDER FUSE -- 01 00 R=Y FOR F1 08-PE371C5-PW300CA 64-Z30080-114G Screws FOR QW3 08-PE371C5-PW300CA 64-Z30080-114G...
