WORK INSTRUCTION CONTENT
Engineering Dept,China Manufacturing Center,TCL Multimedia
Customer
Model
40D2700B MS08BP-AP
File No.
Updated Rev.
NO.
OS-C000390.00
1.0
OS-C000390.00
1.0
1/23
OS-C000390.00
1.0
2/23
OS-C000390.00
1.0
3/23
OS-C000390.00
1.0
4/23
OS-C000390.00
1.0
5/23
OS-C000390.00
1.0
6/23
OS-C000390.00
1.0
7/23
OS-C000390.00
1.0
8/23
OS-C000390.00
1.0
9/23
OS-C000390.00
1.0
10/23
OS-C000390.00
1.0
11/23
OS-C000390.00
1.0
12/23
OS-C000390.00
1.0
13/23
OS-C000390.00
1.0
14/23
OS-C000390.00
1.0
15/23
OS-C000390.00
1.0
16/23
OS-C000390.00
1.0
17/23
OS-C000390.00
1.0
18/23
OS-C000390.00
1.0
19/23
OS-C000390.00
1.0
20/23
OS-C000390.00
1.0
21/23
OS-C000390.00
1.0
22/23
OS-C000390.00
1.0
23/23
Prepared：Bin Tang
Ass'y No.
H7-KD270NZG-UR0
Oper. Name
0
Content
Process 1 of boards
Process 1 of key board
Process 1 of IR board
Process of speakers
Screw key&IR board
Screw mainboard
Trim and stick fiber tape
Process 1 of taking the module
Process 2 of taking the module
Do EDS before pluging LVDS wire
Fix the rear cabinet
Screw small rear cabinet
Stick the films
Visual inspection 1
Visual inspection 2
Withstanding Higt-voltage Test
Adjustment of LCD function
Process of attachment
Process of carton-box
Packing 1 of TV sets
Packing 2 of TV sets
Packing 3 of TV sets
Packing 4 of TV sets
Checked by ：
Oper. Name
Content
Q'ty
MODIFIED RECORD
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OS-C000390.00
File No.：
2015/11/13
Issue Date：
Modified Date：
NO.
Section
0
CTV ASSEMBLY
Approved by ：
Rev.
1.0
Modifier

Advertisement

loading
Need help?

Need help?

Do you have a question about the 40D2700B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TCL 40D2700B

Summary of Contents for TCL 40D2700B

  • Page 1 WORK INSTRUCTION CONTENT OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Oper. Name Content Section Customer Model 40D2700B MS08BP-AP Ass'y No. H7-KD270NZG-UR0 CTV ASSEMBLY File No. Updated Rev. Oper. Name Q'ty MODIFIED RECORD Modifier OS-C000390.00...
  • Page 2 WORK INSTRUCTION OS-C000390.00 File No.： Rev. Issue Date： 2015/11/13 Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Process 1 of boards Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP T8-40APZG-MA7 mainboard 1/23 Ass'y No. H7-KD270NZG-UR0...
  • Page 3 WORK INSTRUCTION OS-C000390.00 File No.： Rev. Issue Date： 2015/11/13 Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Process 1 of key board Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 56-474720-0HA6R 2/23 push botton bracket Ass'y No.
  • Page 4 WORK INSTRUCTION OS-C000390.00 File No.： Rev. Issue Date： 2015/11/13 Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Process 1 of IR board Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 56-527190-0HH9A lens 3/23 Ass'y No.
  • Page 5 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Process of speakers Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 42-51308G-XCEG speaker 40D2700B MS08BP-AP 4/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY...
  • Page 6 WORK INSTRUCTION OS-C000390.00 File No.： Rev. Issue Date： 2015/11/13 Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Screw key&IR board Remark Electrostatic Mark Part Number Description Specification Q'ty 40D2700B MS08BP-AP 63-W30060-BF4G screw for KEY board Model 5/23 H7-KD270NZG-UR0...
  • Page 7 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Screw mainboard Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 6/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY 63-B3008T-BF5G screw for mainboard Ass'y No.
  • Page 8 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Trim and stick fiber tape Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 89-BX8915-JZ0U fiber tape with 80mm...
  • Page 9 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Process 1 of taking the module Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model T8-40D2700B-LPM10 module 40D2700B MS08BP-AP 8/23 H7-KD270NZG-UR0...
  • Page 10 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Process 2 of taking the module Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model T8-40D2700B-LPM10 module 40D2700B MS08BP-AP 9/23 H7-KD270NZG-UR0...
  • Page 11 WORK INSTRUCTION OS-C000390.00 File No.： Rev. Issue Date： 2015/11/13 Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Do EDS before pluging LVDS wire Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 10/23 Ass'y No. H7-KD270NZG-UR0...
  • Page 12 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Fix the rear cabinet Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 89-BX8915-JZ0U fiber tape with 80mm 11/23...
  • Page 13 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Screw small rear cabinet Remark Electrostatic Mark Part Number Description Specification Q'ty 40D2700B MS08BP-AP 64-B30060-105G screws for small back cover Model...
  • Page 14 WORK INSTRUCTION File No.： OS-C000390.00 Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Stick the films Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Side AV film Model 40D2700B MS08BP-AP 58-478500-40J9B 13/23 Lower AV film...
  • Page 15 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Visual inspection 1 Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 40D2700B MS08BP-AP 14/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 16 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Visual inspection 2 Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 71-MS08LB-SCR9A screen film 40D2700B MS08BP-AP 15/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 17 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Customer Oper. Name Withstanding Higt-voltage Test Remark Electrostatic Mark FIXTURES & INSTRUMENTS Model Name Specification 40D2700B MS08BP-AP 16/23 Q'ty H7-KD270NZG-UR0 Section CTV ASSEMBLY Withstanding voltage tester Ass'y No.
  • Page 18 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Adjustment of LCD function Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model remote conrtol 40D2700B MS08BP-AP 17/23 06-520W37-E009X H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 19 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Process of attachment Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model remote control 40D2700B MS08BP-AP 18/23 06-520W37-E009X H7-KD270NZG-UR0 Section CTV ASSEMBLY...
  • Page 20 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Process of carton-box Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 76-473550-0ATFD carton-box 40D2700B MS08BP-AP 19/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY...
  • Page 21 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Packing 1 of TV sets Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 74-106072-3WDEM 40D2700B MS08BP-AP 20/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 22 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Packing 2 of TV sets Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 74-106072-3WDEM 40D2700B MS08BP-AP 21/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 23 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Packing 3 of TV sets Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model attachment 40D2700B MS08BP-AP 22/23 H7-KD270NZG-UR0 Section CTV ASSEMBLY Ass'y No.
  • Page 24 WORK INSTRUCTION OS-C000390.00 File No.： Rev. 2015/11/13 Issue Date： Engineering Dept,China Manufacturing Center,TCL Multimedia Modified Date： Packing 4 of TV sets Customer Oper. Name Remark Electrostatic Mark Part Number Description Specification Q'ty Model 75-482400-CC0 TOP polyroam 40D2700B MS08BP-AP 23/23 H7-KD270NZG-UR0...
