Dtmf; Prefix - Depaepe Telecom UC806 User Manual

Advanced Features
3. Click the to save the configuration.

DTMF

To configure the DTMF via Phone Interface
1. Press Menu ->Features ->Function Keys->Line or Memory keys as Function
Keys -> Memory key1(for example)
2. Select the wanted Line or Memory key.
3. Press and or press key to select the DTMF in the type field.
4. Enter the value
5. Press or Save soft key to save the configuration
To configure the DTMF via Web interface
1. Click Function keys -> Line or Memory key.
2. Select the desired Line or Memory key and select DTMF in the Type.
3. Fill the value.
4. Click the to save the configuration.

Prefix

To configure the Prefix via Phone Interface
1. Press Menu ->Features ->Function Keys->Line or Memory keys as Function
Keys -> Memory key1(for example)
2. Select the wanted Line or Memory key.
