Summary of Contents for Keys Fitness HealthTrainer HT601
- Page 1 HEALTHER TRAINER 601 TREADMILL OWNER’S MANUAL Model Name HT601 Serial Number Purchase Date Write down for future reference. Keys Technical Service, (888) 340-0482 KEYS Fitness Products, LP P.O. Box 551239 Dallas, TX 75239-1239 Part# 15-0147...
-
Page 2: Table Of Contents
Table of Contents Information Table of Contents Specification Sheet Important Safety Information Before You Start Warm Up Exercises Assembly, Moving Instructions Power Requirements Console Functions and Descriptions Program and Operating Instructions Program Descriptions and Profiles Belt Adjustments and Tension Change to MPH or Km/H Maintenance Instructions Troubleshooting Guide Error Messages... -
Page 3: Specification Sheet
Walking Belt Side Hand Rails Foot Print Folded Foot Print User Capacity Warranty Motor Warranty Parts Warranty Labor Warranty Frame HT601 2.0hp 5 Window LCD One touch 1.9” 0-10mph 18 X 51” 2 ply 29” x 61” 29 x 29”... -
Page 4: Important Safety Information
!The treadmills have a user maximum capacity of 275 pounds. !The treadmill should only be used on a level surface and is intended for indoor use only. The tread- mill should not be placed in a garage, patio, or near water and should never be used while you are wet. -
Page 5: Before You Start
Remember to take the time to perform the stretching exercises provided to avoid injury. ! Do not stand on the walking belt while pressing the Power button or Start/Stop button. ! Always adjust the speed of the treadmill in small increments as this treadmill is capable of high speeds. -
Page 6: Warm Up Exercises
Warm Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Warming up prepares the body for the exercise by increasing circulation, supplying more oxygen to the muscles and raising body temperature. -
Page 7: Assembly, Moving Instructions
Next, with a firm grasp on handrails, place one foot on the center of the base crossbar and carefully tilt the treadmill back until it rolls freely on the wheels. -
Page 8: Power Requirements
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges, and noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of treadmill damage, always use a surge protector (not included) with your treadmill. -
Page 9: Console Functions And Descriptions
(1-10) and shows position with a blinking action. !In Program mode, the treadmill will display the name of the program selected This is shown on the left hand side of the window. In Manual mode, the LAP counter will appear in the top center of the window, counting each 1/4 mile lap in sequence of completion (1, 2, 3, etc.) -
Page 10: Program And Operating Instructions
Program and Operating Instructions QUICK START / MANUAL MODE ! Plug into a surge protector outlet. Attach the Red Safety Key on to the treadmill console. ! Stand on the treadmill and straddle belt. Attach safety key clip to your clothes. -
Page 11: Program And Operating Instructions 10
WARM UP PROGRAM MODE Plug treadmill into a surge protector outlet. Attach the Red Safety Key on to the treadmill console. ! Stand on the treadmill and straddle belt. Attach safety key clip to your clothes. ! Press POWER button. There will be an eight (8) second delay before data can be entered. The TIME window will flash. -
Page 12: Program Descriptions And Profiles
1 2 3 4 5 6 7 8 9 1 0 The Warm Up Program is designed to gradually increase the treadmill Speed and Elevation in the first segment (warm up) and gradually decrease the treadmill Speed and Elevation in the last segment (cool down). -
Page 13: Belt Adjustments And Tension
¼ turn in the clockwise direction. Next, run the treadmill at 2.5 mph. You should see the belt start to correct itself by moving back towards the center. Repeat the above procedure until the walking belt is centered. -
Page 14: Change To Mph Or Km/H
All treadmills are calibrated at the factory for British Units (miles per hour). To change the display to read in kilometers, follow the steps described here: 1) Turn power OFF on the console. (Do not unplug treadmill) Attach the magnet safety key to the con- sole. -
Page 15: Maintenance Instructions
CLEANING Routine cleaning of your Keys Fitness treadmill will extend the life of your treadmill. WARNING! To prevent electrical shock, be sure the power to the treadmill is OFF and the unit unplugged from the wall electrical outlet before attempting any cleaning or maintenance. -
Page 16: Troubleshooting Guide
(Refer to “Power Requirements” on page 8) 3 Check the circuit breaker located on the front of the treadmill. If the switch protrudes, it has tripped. Wait five minutes and then press the switch back in. -
Page 17: Error Messages
Safety Interlock Error Messages SI 1 - Safety key missing, replace and try again. SI 2 - Over voltage protection trip. Notify Keys Fitness Technical Service. SI 3 - Tilt Switch Trip. Notify Keys Fitness Technical Service. Other Error Messages E11 - Lack of speed feedback data from belt motor. -
Page 18: Calibration Sequence
Calibration Sequence Your treadmill is equipped with a software package that will perform a calibration sequence unique to your specific model number. Please perform the following steps to calibrate the HEALTH TRAINER 601 TREADMILL. 1. Unplug power cord from outlet strip. -
Page 19: Parts And Diagrams
15&16 Console Assembly Please review the following drawing below to familiarize yourself with the listed parts. This man- ual covers several treadmills, so the one pictured below may not be identical to your particular model. HT601 05-0036 05-0036 04-0025 24-0218... -
Page 20: Warranty Registration (Mail In Form)
This Limited Warranty applies in the United States and Canada only to products manufactured or distributed by Keys Fitness Products, LP (“Keys”) under the Keys brand name. The warranty period to the original purchaser of the HT601 treadmill is (lifetime) on the frame and one (1) Year labor. In addition, the HT601 includes ten (10) years on the motor and a two (2) year parts warranty.
