Summary of Contents for IQ CCTV IQC960S12
-
Page 1: Speed Dome Camera
960H HD 960H 12x Zoom PTZ Mini Speed Dome Camera 360° IP66 960H 960H 12x Zoom High Speed Weatherproof Low Lux Rated Level Resolution Pan & Tilt User Manual Version 1... -
Page 2: Table Of Contents
Contents 1. Product Overview ..............1.1. Product Features ........... 2. Product Contents ..............3. Installation ................4. Camera Operation .............. 4.1. Setup Camera Address ......... 5. OSD Menu ................5.1. Camera Setup ..........5.2. Focus Setup ..........5.3. Pan Tilt Setup ..........5.4. - Page 3 Warning Caution: To prevent electric shock and fire hazards, please don’t use a power supply not Warning: To reduce the risk of listed in the manual. electric shock, non-professional personnel should not remove the cover. This symbol alerts the user to operate and maintain the product according to the manual.
-
Page 4: Product Overview
1. Product Overview Thank you for purchasing the IQC960S12 Internal/External 12x Zoom Mini Speed Dome Camera from IQCCTV. The camera features a wide-angle megapixel lens to capture more without the need to adjust the camera. The dome is ideal for indoor or outdoor use (IP66 Rated) and has a cable managed and compact design. -
Page 5: Product Contents
2. Product Contents Before installing this product, please ensure that it contains the following; Contents 1x IQC960S12 Speed Dome Camera 960H HD 960H 12x Zoom PTZ Mini Speed Dome Camera 1x User Manual 360° IP66 960H 960H 12x Zoom High Speed... -
Page 6: Installation
3. Installation The IQC960S12 is designed to be wall or ceiling mounted using the cable managed brackets supplied. To install the camera, please follow the steps below. Ceiling Mount 1. Add the bracket extension to the 2. Using the bracket as a stencil, mark ceiling camera bracket. - Page 7 5. Feed the wires through the bracket. 6. Attach the camera bracket to the camera using a cross head screw driver and turning the screws clockwise 7. Lastly, screw the bracket into the ceiling.
-
Page 8: Wall Mount
Wall Mount 1. Using the bracket as a stencil, mark 2. If feeding wires through the wall you out the drill holes needed in the wall. will need to drill a hole through the wall for the wires to go. However, if placing through the bracket, you can just feed through the side. - Page 9 6. Then, attach the cable to the camera 5. Now, thread the cable from the main as shown below. camera back through the bracket. 7. Re-attach the main camera to the 8. Lastly, screw the bracket into the wall. bracket. To do this, use a cross head screw driver and turn screws in clockwise.
-
Page 10: Camera Operation
4. Camera Operation The Speed Dome camera will be controlled through the DVR using the arrow keys etc. However, it is advised to use an external Speed Dome controller, for more control over the camera. 4.1 Setup Camera Address 1. When the camera has initially been switched on, the OSD will display 485 baudrate, address and protocol (as shown below). -
Page 11: Osd Menu
5. OSD Menu Enter into the OSD menu by calling Preset 95. The menu allows you to adjust camera settings such as focus, pan tilt zoom and protocol. 5.1 Camera Setup MAIN MENU PAN TILT ZOOM CAMERA SETUP SHUTTER: AUTO FOCUS SETUP WHITE BALANCE: PAN TILT SETUP... - Page 12 Motion Detection Turn the motion detection function on or off. If set to on, you can set the detection areas and sensitivity. Privacy This option allows you to set the privacy zones on the camera. Turn the Noise Reduction function on to improve picture quality. You can set the NR levels according to your application.
-
Page 13: Focus Setup
5.2 Focus Setup MAIN MENU FOCUS SETUP CAMERA SETUP FOCUS TYPE: AUTO FOCUS SETUP AF AFTER MOVE: PAN TILT SETUP PRESET LOAD ZOOM: PATTERN SETUP DISPLAY ZOOM TIMES: PROTOCOL SETUP RETURN RESET MENU SETUP EXIT MENU EXIT MENU Focus Type Auto: Camera will automatically focus Manual:... -
Page 14: Pan Tilt Setup
5.3 Pan Tilt Setup MAIN MENU PAN TILT SETUP CAMERA SETUP TILT LIMIT SET: FOCUS SETUP TILT LIMIT RESET: PAN TILT SETUP PAN TILT LIMIT SPEED: PATTERN SETUP ZOOM LIMIT SPEED: PROTOCOL SETUP RETURN RESET MENU SETUP EXIT MENU EXIT MENU Tilt Limit Set Set the upward tilting limit. -
Page 15: Pattern Setup
5.4 Pattern Setup MAIN MENU PATTERN SETUP CAMERA SETUP PATTERN TOUR: STOP FOCUS SETUP PATTERN POINT NUM: PAN TILT SETUP PATTERN DWELL TIME: PATTERN SETUP PROTOCOL SETUP RETURN RESET MENU SETUP EXIT MENU EXIT MENU Pattern Tour Stop: Stop pattern Start: Start pattern Pattern Point Num This allows you to set the number of preset positions in the cruise. -
Page 16: Protocol Setup
5.5 Protocol Setup MAIN MENU PAN TILT ZOOM CAMERA SETUP PROTOCOL: PELCO D FOCUS SETUP ADDRESS: PAN TILT SETUP BAUDRATE: 9600BPS PATTERN SETUP PROTOCOL SETUP RETURN RESET MENU SETUP EXIT MENU EXIT MENU Protocol Change the protocol on the camera to match your speed dome controller. Adjust the protocol from Pelco D or P. -
Page 17: Reset Menu Setup
5.6 Reset Menu Setup MAIN MENU RESET MENU SETUP: CAMERA SETUP FACTORY DEFAULT SETUP: SET FOCUS SETUP PAN TILT SETUP PATTERN SETUP PROTOCOL SETUP RETURN RESET MENU SETUP EXIT MENU EXIT MENU Reset Menu Setup Set the PTZ menu to the factory default settings. Factory Default Set Reset all parameters to the original factory settings. -
Page 18: Osd Map
6. OSD Map MANUAL TYPE: DC / VIDEO LENS AUTO MODE: CLOSE / AUTO / OPEN SPEED: 0-255 HIGH LUMINANCE MODE: SHUT+AUTO IRIS/AUTO LENS BRIGHTNESS: 0-255 AUTO LOW LUMINANCE MODE: OFF/AGC SHUTTER BRIGHTNESS: x0.25, x0.5, x0.75, x1 /AGC MODE: SHUT+AGC SHUTTER: 1/50. -
Page 19: Camera Specifications
7. Speci cations Camera Specifications Image Sensor 1/3 Sony Super HAD CCD II Resolution 960H Lens Size 5 - 60mm Minimum Illumination 0.001 Lux Weight (Kg) Power Supply 12v DC 800mA Operating Temperature -10°C ~ 50°C Dimensions (WxHxD) 138x266x138mm Weatherproofing IP66... - Page 21 Manufactured for: TECHNICAL SUPPORT For technical support, please contact your local distributor. Alternatively, call 0871 222 1430 LIMITED WARRANTY This product is supplied with a 12 month warranty. The warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear.
