- Page 1 960H HD 960H Dome Camera with 30m IR Night Vision IP66 Weatherproof Adjustable Viewing Resolution Night Vision Rated Angle (23 to 92°) User Manual Version 1...
-
Page 2: Table Of Contents
Contents Overview ......... 1. Product 1.1. Product Features ......2. Product Contents ........3. Installation ..........4. Installation Diagram ........5. Specifications .......... - Page 3 Warning Caution: To prevent electric shock and fire hazards, please don’t use a power supply not Warning: To reduce the risk of listed oin the manual. electric shock, non-professional personnel should not remove the cover. This symbol alerts the user to operate and maintain the product according to the manual.
-
Page 4: Product Overview
1. Product Overview Thank you for purchasing the IQC960VV Internal/External Dome Camera from IQCCTV. The camera features a high quality adjustable wide-angle lens (23-92°) to capture more, clear images. The mini dome is ideal for indoor or outdoor use (IP65 Rated) and has up to 30 Metres IR Night Vision. The IQC range of 960H cameras from IQCCTV are designed to offer crystal clear images and amazing value for money, this is achieved by removing high-end features not needed in everyday applications. -
Page 5: Product Contents
2. Product Contents Before installing this product, please ensure that it contains the following; Contents 1x IQC960VV Dome Camera 960H HD 960H Mini Dome Camera with 30m IR Night Vision 1x User Manual IP65 Weatherproof Adjustable Viewing Resolution Night Vision Rated Angle (23 to 92°) -
Page 6: Installation
3. Installation 12v DC Input Power Cable Video Cable 1. Unscrew the base of the camera by holding the bottom and moving the ring anti-clockwise. 2. Use the camera base as a template and mark out the holes in the wall/ceiling where you wish to install the camera. - Page 7 6. Screw the bracket and camera back onto the base by turning the ring clockwise. Please don’t tighten completely if you wish to change the camera angle. 7. Adjust the camera angle to the desired view. It would be advised to use a test monitor when choosing the angle, to get the perfect angle for your application.
-
Page 8: Installation Diagram
4. Installation Diagram Use a power splitter lead to power more than one camera. Plug & Play Cable Power Supply for camera(s) Power Lead (Do not use DVR PSU) Power Camera Power Lead Jack MAINS POWER BNC Input Power Supply Power For Camera Jack... - Page 9 To Connect Cable to Camera(s) Connect the power lead coming from the camera to the power jack on the Plug & Play cable Connect the BNC connector from the camera to the BNC on the Plug & Play cable To Connect Power to the Camera(s) Connect the power socket on the cable to the Power Supply –...
-
Page 10: Specifications
5. Speci cations Image Sensor High Resolution CMOS Image Sensor Resolution 800 TVL Lens Size 2.8 - 12mm Automatic Electronic Iris Automatic Electronic Shutter Automatic Gain Control DSP Functions Automatic White Balance Backlight Compensation Minimum Illumination 3 Lux (IR Off), 0 Lux (IR On) Night Vision 20-30m IR Night Vision Power Supply... - Page 11 Notes...
- Page 12 Manufactured for: TECHNICAL SUPPORT TECHNICAL SUPPORT For technical support, please contact your local distributor. For technical support, please contact your local distributor. Alternatively, call 0871 222 1430 Alternatively, call 0871 222 1430 LIMITED WARRANTY LIMITED WARRANTY This product is supplied with a 12 month warranty. The warranty excludes products This product is supplied with a 12 month warranty.
