Summary of Contents for IQ CCTV IQC1920CC
- Page 1 Full HD (1080P) HD-SDI Covert Pinhole Camera HD SDI Model IQC1920CC Full HD (1080P) Covert Pinhole Camera S/N: 1080P 1080P Low Lux 3D Digital HD Megapixel Resolution Light Level Noise Reduction Pinhole Lens User Manual Version 1...
-
Page 2: Table Of Contents
Contents 1. Introduction ..................4 2. Features ..................4 3. Package Content ................4 4. Overview ..................5 4.1 Connections ............... 5 4.2 OSD Control ............... 5 5. OSD Menu ..................7 5.1 Exposure ..............7 5.2 White Balance ............8 Full HD (1080P) HD-SDI 5.3 Day &... - Page 3 Safety Instructions Before using this product, please read this manual carefully to ensure that the user can correctly use this product to avoid danger. Please save this instruction manual in a safe place for future reference. WARNING Input voltage should be both the SELV (Safety Extra Low Voltage) and the limited power source with DC 12V.
-
Page 4: Introduction
1. Introduction Thank you for purchasing the IQC1920CC from IQCCTV. The IQCCTV IQC1920CC HD-SDI Covert Camera offers FULL HD 1080P resolution images in miniature form (up to 7x resolution of standard CCTV systems and better than SKY HD). 2. Features ●... -
Page 5: Overview
To use the OSD on the camera, you will need to use the joystick, as shown in 4.1. Below shows how the joystick, video and power wires are connected to the camera. HD SDI Model IQC1920CC Full HD (1080P) Covert Pinhole Camera S/N:... - Page 6 Then, connect the BNC connection to your HD-SDI DVR. The OSD menu on the camera can be controlled using the joystick once connected to the camera. (1) Up Direction (2) Down Direction (3) Right Direction (4) Left Direction (5) OK/Confirm Button...
-
Page 7: Osd Menu
5. OSD Menu To operate the OSD menu, you can use the joystick on the rear panel of the camera cable (as shown in chapter 4). To go into the OSD menu, press the ‘Enter/Confirm’ button on the joystick. In the OSD, you can configure the following; 1. -
Page 8: White Balance
5.2 White Balance Select WHITE BAL and push left or right to choose White balance mode including AWB, Manual and Preset. AWB: In this mode, the camera will constantly monitor the colour temperature among about 2500-9500°K of colour temp and adjust white balance automatically. -
Page 9: Dnr
HLC OSD: Turn the HLC on the camera on or off. HLC Level: Adjust the level of the HLC from 0~20. 5.5 3D-DNR This option allows you to set the 3D-DNR level on the camera. Select between Off, Low, Middle or High. 5.6 Image Enter this menu to adjust the image features on the camera. -
Page 10: System
5.8 System This menu allows you to adjust the system settings; RS-485, Image Range, Cam ID, Output mode, frame rate, CVBD and Language. RS-485: Set the RS-485 connection on the camera. You can select the ID, baudrate, protocol and ID display. CAM-ID: Input a camera ID to identify the camera. -
Page 11: Specification
6. Speci cations Model HD-SDI Covert Camera Sensor 1/3” Panasonic 2.1 Megapixel CMOS Pixels 2 Megapixels Min Illumination Colour: 0.2 Lux, B&W: 0.01 Lux Resolution 1080P Night Vision IR Range Weather Proof Camera Automatic White Balance Automatic Gain Control Digital Noise Reduction (DNR) 3D DNR, Smart DNR OSD Functions Backlight Compensation... - Page 12 Manufactured for: TECHNICAL SUPPORT For technical support, please contact your local distributor. Alternatively, call 0871 222 1430 LIMITED WARRANTY This product is supplied with a 12 month warranty. The warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear.
