Siemens HEATWELL RDE Series Quick Instructions

RDE... Simple Instructions.
Front Panel:
Controls under the cover on the right hand side.
TO SET CLOCK
Press the Clock Button
Adjust to the current time, using the plus and minus buttons
(please note: the clock is in 24 hour time)
Once the time has set push the enter button
(The controller will then return to the main screen)
1
TO SET THE DAY
The day is the Black box's on the top of the screen with numbers in, Mon= day 1, Tue= day 2 etc
Press the 1... 7 Button, the day it is currently on will flash
Adjust the day by using the plus and minus buttons
Once the correct day is chosen push the enter button
TO SET THE HEATING TEMPERATURE
The Heating temperature is the temperature you would like to warm the room up to.
Press the sun button.
Adjust to the required temperature using the plus and minus buttons
Once the desired temperature is chosen push the enter button
TO SET THE ECONOMY TEMPERATURE
The Economy Temperature is the lowest temperature you ever want the floor to get to at anytime.
Press the moon button.
Adjust to the required temperature using the plus and minus buttons
Once the desired temperature is chosen push the enter button
(This can be made an OFF position by taking the temperature down to OFF. You need to hold the Minus
button for 5 seconds after you get down to the temperature 5 degrees)
For further information contact your underfloor heating installer.
__________________________________________________________
Or contact Siemens NZ Ltd, 09 580 5500 – HVAC Technical Support.
Programming Buttons
Programmed Heating
Constant Heating (Manual)
Economy Heating Temperature or OFF
0508 HEATWELL
or wait for 5 seconds.
or wait for 5 seconds.
or wait for 5 seconds.
or wait for 5 seconds.
0508 432 893
