2. Verify That the Hub Works

To verify that the hub works, follow these steps:
1. Plug the AC adapter's power cord into the hub's AC
receptacle.
Your hub is shipped with one of these AC adapters:
Australia/New Zealand/China/Argentina
Europe/Russia
Israel
Japan
Korea
South Africa/India
United Kingdom/Hong Kong
U.S./Canada/Mexico/Taiwan/Brazil/Colombia
Note If your installation requires a different AC adapter than
the one supplied with the hub, contact your
HP-authorized LAN dealer or your local HP sales office.
2. Plug the AC adapter into an AC power source. When
installing the Hub-8E, note that the AC outlet must be located
near the equipment and should be easily accessible.
Note: The hub does not have a power switch; it is powered
on when the power cord is plugged in.
2
AC adapter power
cord
(9100-5509)
(9100-5511)
(9100-5514)
(9100-5508)
(9100-5513)
(9100-5512)
(9100-5510)
(9100-5507)
