Sonance ARCHITECTURAL SERIES AS38RS Quick Start Manual

S O N A N C E A R C H I T E C T U R A L S E R I E S
AS38RS AND AS68RS (ROUND AND SQUARE)
QUICKSTART GUIDE

Box Contents

(1) Quickstart guide
(1) AS speaker
(1) Round grille
Remove the paint shield from the finished
mounting platform.
Remove sanding shield support. Remove zip tie
from speaker wire.
(1) Square grille
(1) Grille painting instructions
(1) Set of speaker screws w/ Loctite
1
Cut the four tabs on the sanding shield support
structure in the speaker bracket. NOTE: The
speaker wire is connected to the zip tie for
easy access.
With Bandpass
3
Subwoofer
When using AS38RS/BPS6 or AS68RS/BPS8
System, switch to high pass ON. High pass
switch is located on the back of the crossover
cover. Switch high pass to OFF when choosing full
range and no BPS6 or BPS8.
®
®
2
4
