SPECIAL FEATURES
MODEL CAT2-(
( G )
OPTIONS
(CE)
MARK REQUIRED FOR EUROPE
(CFX)
6.75" LONG RISER AND UNION FOR EXPLOSION-PROOF SYSTEM
CERTIFIED ENCLOSURES MOUNTED ON TURBINE. USED WITH
"X" RISER TURBINE OPTION.
NOTE:
(SP)
ANY SPECIAL FEATURES THAT ARE NOT COVERED IN THE
MODEL NUMBER, USE A WRITTEN DESCRIPTION OF THE –SP.
NOTES:
1. IF ENCLOSURE IS MOUNTED ON TURBINE FLOWMETER, RISER MUST
BE SPECIFIED ON METER.
2. PULSE SCALING IS SUPPLIED AS A STANDARD. THE PULSE OUTPUT
IS SCALED SO THAT THE MAX FLOW IS BETWEEN 75-150 HZ WHEN THE
ANALOG OPTION IS SELECTED.
HP-311
)-(
)-(
)-(
IF PROCESS TEMP IS < -40°C AND > 85°C, EX-PROOF
ENCLOSURE MUST BE MOUNTED REMOTELY.
)-(
)-(
)-(
G
