Marantz PS5200 Service Manual page 49

PS5200
VERS.
POS. PART NO.
COLOR
NO (FOR PCS)
C871
C873
C874
C875
C876
C877
C878
C881
C882
C883
C884
C885
C886
C887
C888
C889
C890
C891
C892
C894
C895
C896
R864
R865
R871
R873
R874
R875
R876
R877
R878
R879
R880
R881
R882
R883
R884
R885
R886
R889
R890
R891
R897
R899
D870
D871
D872
D873
D884
IC872
IC874
Q821
Q822
Q870
Q871
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PART NO.
DESCRIPTION
VIDEO CIRCUIT BOARD
VIDEO - CAPACITORS
CER.CHIP,47pF-J/50V-1608
ELECT,470µF-M/6.3V 8*11.5
CER.CHIP,47pF-J/50V-1608
ELECT,470µF-M/6.3V 8*11.5
CER.CHIP,47pF-J/50V-1608
ELECT,470µF-M/6.3V 8*11.5
ELECT,10µF-M/50V 5*11
ELECT,47µF-M/16V 5*11
CER.CHIP,0.1µF-K/50V-1608
CER.CHIP,0.1µF-K/50V-1608
ELECT,47µF-M/16V 5*11
ELECT,10µF-M/50V 5*11
CER.CHIP,100pF-J/50V-1608
CER.,0.01µF-M/16V
ELECT,100µF-M/10V 5*11
CER.,0.001µF-K/50V
ELECT,2.2µF-M/50V 5*11
CER.CHIP,100pF-J/50V-1608
ELECT,10µF-M/50V 5*11
ELECT,10µF-M/50V 5*11
CER.CHIP,100pF-J/50V-1608
VIDEO - RESISTORS
1K-J 1/6W
1K-J 1/6W
CHIP,10K-J 1/16W-1608
CHIP,47-J 1/16W-1608
1K-J 1/6W
CHIP,10K-J 1/16W-1608
CHIP,56-J 1/16W-1608
CHIP,10K-J 1/16W-1608
CHIP,75-J 1/16W-1608
CHIP,56-J 1/16W-1608
CHIP,75-J 1/16W-1608
CHIP,75-J 1/16W-1608
CHIP,75-J 1/16W-1608
2.2K-J 1/6W
1-J 1/6W
CHIP,2.2-J 1/16W-1608
CHIP,47K-J 1/16W-1608
33K-J 1/6W
68-J 1/6W
2.2K-J 1/6W
CHIP,10K-J 1/16W-1608
1K-J 1/6W
VIDEO - SEMICONDUCTORS
DIODE,1SS133T HD20015210
DIODE CHIP,KDS160 *HD201560R
DIODE,1SS133T HD20015210
DIODE,1SS133T HD20015210
DIODE,1SS133T HD20015210
IC,NJM2296M SOP16 HC10210090
IC,BU4094BCF-E2 SOP16 *HC400010R
TRS.2SA933S TO92M *HT100610R
TRS.2SC,KTC2874B TO92 *HT300880R
TRS.RC,KRC107M TO92M *BA001190R
TRS.RB,KRA107M *BA000190R
POS. VERS.
COLOR
NO
(MJI)
CP301V
nsp
J911
nsp
nsp
J916
nsp
nsp
nsp
nsp CN101
nsp
nsp
nsp
nsp
C953
nsp
nsp
nsp
R951
nsp
R952
nsp
nsp
nsp
CP302T
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
65
PART NO.
DESCRIPTION
(FOR PCS)
VIDEO - MISCELLANEOUS
CN.WAFER 2.0MM,
GIL-S-2P-S2T2-EF
CHIP,0-J 1/16W-1608
SPEAKER CIRCUIT BOARD
SPEAKER - MISCELLANEOUS
CN.WAFER 2.5MM,
52668-1317 ANG ZIP
TUNER INPUT
CIRCUIT BOARD
TUNER INPUT - CAPACITORS
CER.,0.1µF-Z/50V
TUNER INPUT - RESISTORS
470-J 1/6W
470-J 1/6W
TUNER INPUT-MISCELLANEOUS
CN.WAFER 2.0MM,
G1L-S-3P-S2T2-EF
PART NO.
(MJI)
nsp
nsp
nsp
nsp
nsp
nsp
nsp
