Team Losi 8IGHT 2.0 Assembly And Operation Manual

1/8-scale 4wd competition nitro buggy kit
Hide thumbs Also See for 8IGHT 2.0:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual

Advertisement

Table of Contents
loading

Related Manuals for Team Losi 8IGHT 2.0

Summary of Contents for Team Losi 8IGHT 2.0

  • Page 2: Important Safety Notes

    Welcome Team Losi Racing 8IGHT 2.0 Owner! Thank you for selecting the 8IGHT 2.0 as your new racing buggy. The 8IGHT 2.0 has already distinguished itself as a top caliber racing chassis and as you will see, we have made every eff ort to produce a vehicle that is not only the most competitive but also easy to maintain. The simple step-by-step assembly sequence and easily followed instructions and drawings combined with Team Losi Racing's world famous quality fi tting parts will make using the 8IGHT 2.0 a most enjoyable vehicle.

  • Page 3: Table Of Contents

    6. Step E: Shocks ..........19-21 Team Losi Racing is continually changing and improving designs; therefore, the actual part may appear slightly diff erent than the illustrated part. Illustrations of parts and assemblies may be slightly distorted to enhance pertinent details.

  • Page 4: Step A: Steering Assembly

    STEP A STEP A STEP A-01 Steering Link Assembly STEP A-02 Servo Saver Assembly 4-40 x 1/2" A4406 A6256 A9168 L 4-40 x 3/16" Servo Saver Tube Steering Servo Arm A6306 Maintenance Tip A6045 Rod Ball End A6045 Rod End LOSI-LOK L 4-40 x 3/16"...
  • Page 5 STEP A STEP A STEP A-04 Steering/Top Plate Assembly 5-40 x 1/2" LOSI-LOK A4413 A6271 Front Chassis Brace LOSI-LOK A4424 Front Body Mount 5-40 x 1/2" A6278 5-40 x 3/8" A6270 6x10x3mm A6946 STEP A-05 Completed Steering Assembly...
  • Page 6 STEP B STEP B STEP B-01 Ring Gear Assembly STEP B-03 Complete Diff Assembly A3503 Outdrive Cup Solid Fill with 5000 wt oil just above the 2.5 x 12.80mm planetary gear A3518 3x12mm A3500 F 8x14x4mm A6948 A3509 Ring Gear A3505 O-ring A3502...
  • Page 7 STEP B STEP B STEP B-04 Front Diff Install F 8-32 x 1/8" To prevent fi ne dust from entering the A6926 gearbox, apply a thin bead of grease along the edge of the case as pictured. LOSI-LOK A3514 5x11x4mm Drive Adapter A6947 A4427...
  • Page 8 STEP B STEP B STEP B-06 Spindle/Carrier Assembly O 10-32 x 3/8" A6295 A1709 Left Spindle Carrier A6501 Hinge Pin A1703 Left Front Arm 8/32 x 3/4" A6263 A1701 Front Arm Bushing C 5-40 x 3/16" A6299 STEP B-07 Front Suspension Arms Assembly A4431 Front Inner Hinge Pin Cap...
  • Page 9 STEP B STEP B STEP B-08 Sway Bar Assembly A1750 Sway Bar Link Install the Sway Bar Ball onto the Sway Bar Wire until the end of the wire is fl ush with the ball as pictured above. A1750 Sway Bar Ball A1750 Sway Bar Mount 4-40 x 5/8"...
  • Page 10 STEP B STEP B STEP B-10 Center CV Assembly Solid 2.5mm x 14mm A3518 A3525 CV Coupling, Center LOSI-LOK A3526 F 5-40 x 1/8" Driveshaft, Front A6228 Center STEP B-11 Steering Rod Assembly Be sure to install the assembled Tie Rod onto the car with the groove (next to the center square section) on the driver’s left side for easier...

  • Page 11: Step B: Front Clip

    STEP B STEP B STEP B-12 Front Clip Assembly 5-40 x 3/4" 5-40 x 3/4" A6279 A6272 A4453 Front Bulkhead Spacer 8-32 x 1/2" A6262 A4422 Front Bumper STEP B-13 Completed Front Assembly...
  • Page 12 STEP C STEP C STEP C-01 Ring Gear Assembly STEP C-03 Complete Diff Assembly Solid 2.5 x 12.80mm Fill with 5000 wt A3518 oil just above the planetary gear. 3x12mm A3502 A3500 Sun Gear A3506 Center Outdrive 6x11x0.2mm A3501 A3505 F 8x14x4mm O-ring A6948...
  • Page 13 STEP C STEP C STEP C-04 Center Top Brace Assembly STEP C-05 Linkage Assembly (.5mm)(.020”) 5mm E-clip A9168 F 5-40 x 1/8" A6109 Rear Brake Rod A6297 A9168 Front Brake Actuator LOSI-LOK A9168 Throttle Rod End 2-56 x 1/2" LOSI-LOK A6254 .250x.094x020"...
  • Page 14 STEP C STEP C STEP C-08 Brake Caliper Assembly A3546 Front Brake Pad A3546 Rear Brake Pad .307" .307” 7.80mm 7.80mm A4420 Center Diff Mount A3546 Brake Shoulder Screw A4420 Rear Center Diff Mount STEP C-09 Center Diff/Brake Rotor Assembly 5-40 x 3/8"...
  • Page 15 STEP C STEP C STEP C-10 Center Diff Installation NOTICE: Ensure that the driveshaft is inserted into the slot of the center outdrive while installing the Center Diff assembly. 8-32 x 1/2" A6262 STEP C-11 Completed Center Diff Assembly...
  • Page 16 STEP D STEP D STEP D-01 Ring Gear Assembly STEP D-03 Complete Diff Assembly Solid 2.5 x 12.80mm A3518 Fill with 2000 wt oil just above the A3502 planetary gear. Sun Gear 6x11x0.2mm A3501 3x12mm A3500 A3505 O-ring A3505 Diff Seal A3510 Rear Ring Gear A3502...
  • Page 17 STEP D STEP D STEP D-04 Rear Diff Installation A4414 F 8-32 x 1/8" Rear Chassis Support A6296 A3514 5-40 x 7/8" Drive Adapter LOSI-LOK A4414 A4451 14x17x0.25mm 14x17x0.10mm A4452 A4452 Bearing Insert, LR 5x11x4mm A6947 L 5-40 x 1/4" A6302 A4450 Rear Bulkhead...
  • Page 18 STEP D STEP D STEP D-06 Rear Suspension Arm Assembly A1749 3 toe/3 Anti- Squat Pivot Brace 5-40 x 1-7/8" A6273 A4431 Rear Outer Pivot Brace Cap Solid 4 x 66mm A6500 O 10-32 x 3/8" A6295 A1725 Left Rear Arm 5/40 x 3/4"...
  • Page 19 STEP D STEP D STEP D-08 Wing Mount Assembly A4435 Wing Mount Brace A4435 Right Wing Mount 5-40 x 3/4" L 5-40 x 1/4" A6279 A6302 A4435 Left Wing Mount 5-40 x 1/2" A6278 A4424 A5438 Rear Body Mount Shock Stand-Off L 8-32 x 11/32"...
  • Page 20 STEP D STEP D STEP D-10 Tie Rod Installation A6055 6.8mm Suspension Ball, Flanged A6544 5-40 x 3/4" 4mm Rear A6279 Turnbuckle A6542 Rod End 5-40 x 1/4" A6302 L 5-40 x 1/4" A6302 A6056 6.8mm Suspension Ball 5-40 x 1" 3.79"...

  • Page 21: Step D: Rear Clip

    STEP D STEP D STEP D-12 Rear Clip Assembly L 5-40 x 1/4" A6302 NOTICE: Ensure that the driveshaft is inserted into the slot of the center outdrive while installing the Rear Clip assembly. 8-32 x 1/2" 5-40 x 1/2" A6262 A6271 STEP D-13...

  • Page 22: Step E: Shocks

    STEP E STEP E STEP E-01 Shock Assembly • Clean the 2-56 x 1/4" Button Head Screw and apply Losi-Lok to the threads. • Install the #54 Shock Piston on the front shock shaft and a #56 Shock Piston on the rear shock shaft using the 2-56 x 1/4" Button Screw into the Shock Shaft with a .050"...
  • Page 23 STEP E STEP E STEP E-02 Shock Boot & Spring Assembly x2 x2 Rear Front A5426 Shock Boot A5451 A5458 Silver Front Spring Green Rear Spring A5435 Spring Cup STEP E-03 Front Shock Installation A5435 Shock Mount Bushing L 5-40 x 1/4" A6302 5-40 x 20mm A6281...
  • Page 24 STEP E STEP E STEP E-04 Rear Shock Installation A5435 Shock Mount Bushing L 5-40 x 1/4" A6302 5-40 x 20mm C 4-40 x 1/8" A6281 A6227 STEP E-05 Completed Shock Assembly...

  • Page 25: Step F: Radio Tray

    STEP F STEP F STEP F-01 Chassis Guard Installation A4432 Chassis Guards 5-40 x 3/8" A6270 STEP F-02 Switch Installation Supplied with switch 4-40 x 3/8" Optional Blank Switch Mount Plate (not included) A6206 If not using a switch, install the optional Blank Switch Mount Plate in place of the Switch Plate.
  • Page 26 STEP F STEP F STEP F-03 Servo Chart/Wiring Diagram Servo Servo Servo Manufacturer, Make/Model Spacer Horn Steering Servo Wires All (DZ9100T/S Needs Spacer) 94357Z, 94358Z, 94649Z, 94360Z, 94452Z, 94758Z, 94737Z, 94738Z 94102Z, 94112Z Throttle Switch Servo All (S9102 DOES NOT FIT) Wires Wires PDS-2123, 2344, 2363, 2365, 2366...
  • Page 27 STEP F STEP F STEP F-05 Steering Servo Installation A99040 Airtonics Horn Insert, 23S Spline A99041 JR/SPM Horn Insert, 23 Spline A99042 Hitec Horn Insert, 24 Spline 4-40 x 1/2" A99043 Futaba Horn Insert, 25 Spline A6204 #4 x .030" A6350 A4453 Servo Spacer...
  • Page 28 STEP F STEP F STEP F-07 Receiver Battery Door Optional Battery Covers 4-40 x 1/2" High Profi le Cover should be used with A6256 Hump pack type receiver packs. Low Profi le Cover should be used with A4421 LiPo type receiver packs. Battery Cover, High Profi le A4421...
  • Page 29 STEP F STEP F STEP F-09 Servo Horn Installation Supplied with servo (Not Included) Ensure the servo gear is centered before attaching the Servo Horns. This is best accomplished by connecting the servos to the radio system and setting the trim to center. STEP F-10 Completed Radio Tray Installation...
  • Page 30 STEP G STEP G STEP G-01 Clutch Assembly A9107 Composite Clutch Shoe A9113 LOSI-LOK Clutch Spring Green A9105 Aluminum Flywheel Composite A9105 Shoe Flywheel Collet A9114 Aluminum Clutch Spring Gold Shoe A9106 A9108 A9103 Clutch Pins Aluminum Clutch Shoe Clutch Nut STEP G-02 Clutch Bell Assembly Use the appropriate number...
  • Page 31 STEP G STEP G STEP G-03 Engine Mount Assembly LOSI-LOK 5-40 x 1/2" A6240 Ball Stud A6215 Pipe/Header (Not supplied) A9154 Right Engine A9154 Mount Left Engine Mount STEP G-04 Air Filter Assembly Tech Tip With a clean rag or paper towel take the air fi lter and squeeze it between the rag to remove any excess air fi lter oil.
  • Page 32 STEP G STEP G STEP G-05 Air Filter Installation STEP G-06 Pipe Mount Assembly Trim pipe mount in small 8-32 x 1/8" A6298 increments as needed to A9165 Pipe Wire mount pipe. Ensure that the wire clears all steering components. LOSI-LOK A9165 Pipe Wire Mount...

  • Page 33: Step G: Engine Installation

    STEP G STEP G STEP G-07 Engine Installation • Adjust the gear mesh between the Clutch Bell and the Spur gear by Body Clip sliding the engine mounts in the slots of the chassis. In order to function A8200 properly, the Gears should be as close as possilbe, but still have a small amount of backlash (space between the Gear teeth).
  • Page 34 STEP H STEP H STEP H-01 Tire Mounting A7763B ™ , Blue A7730 1/8 Buggy Insert A7751 1/8 Buggy Wheel, Yellow STEP H-02 Tire Gluing • The tires are already glued to the wheels. Here are the steps to show you how to complete this process. This can be done by using a fast-curing super glue or cyanoacrylate glue (LOSA7880, LOSA7881), available at your local hobby shop.
  • Page 35 STEP H STEP H STEP H-03 Tire Installation LOSI-LOK A3531 Wheel Hexes LOSI-LOK STEP H-04 Wing Installation A8130 Wing Button Body Clip A8200 A8130 Rear Wing...
  • Page 36 Stickers: After the body is mounted, REMOVE THE PROTECTIVE FILM ON THE OUTER SURFACE, now you can apply the stickers. Remove protective fi lm after painting A8095 8IGHT 2.0 Body...
  • Page 37 STEP H STEP H STEP H-06 Body Mounting A8095 Body Spacer Body Clip A8200...
  • Page 38 STEP H STEP H STEP H-07 Completed Chassis Assembly...
  • Page 39 BEFORE RUNNING YOUR NEW 8IGHT 2.0 OFF-ROAD RACING BUGGY for the fi rst time, you should run down the following checklist in order and complete the listed tasks. We’re sure you’re anxious to get out and run your new 8IGHT 2.0 now that it’s built, but please note that fi ne-tuning of the initial setup is an essential part of building a high-performance racing buggy such as your new 8IGHT 2.0.

  • Page 40: Setup Guide

    Team Losi Racing development team has put hundreds of hours on the 8IGHT 2.0 to arrive at the setup we put in the instruction manual. If you fi nd that you have lost the “handle” go back to the vehicle (stock) setup, as this setup has proven to be reliable, consistent and easy to drive.
  • Page 41 Differentials: The 8IGHT 2.0 comes equipped with 5000 wt in the front and center diff , and 2000 wt in the rear diff . Thinner front diff erential oil increases off - power steering, but if the oil is too thin the steering will become grabby and inconsistent. Thicker front diff erential oil increases off -power stability and increases on-power steering.
  • Page 42 Outdrives and Traction: When your 8IGHT 2.0 is new it will have a lot of chassis roll and be a little loose on throttle due to lack of friction in the out drives and crossbones. After about 45-60 minutes of running, the 8IGHT 2.0 will gain traction and stability. Once your 8IGHT 2.0 is broken in, replacing the out drives and crossbones with new parts will have more corner speed.
  • Page 43 Differentials Front: Standard Smart Spring Wire Dia: Qty of Springs: Ramp Plate: Grease: Diff Fluid: Center Standard Smart Spring Wire Dia: Qty of Springs: Ramp Plate: Grease: Diff Fluid:...
  • Page 44 HARDWARE HARDWARE Cap Head Flat Head 1 Flat Head 2 Button Head 2-56 x 1/4" (A6255) 2-56 x 1/4" (A6232) 3 x 8mm (A9106) 8-32 x 3/8" (A6264) 2-56 x 1/2" (A6254) 4-40 x 1/4" (A6234) 3 x 12mm (A3500) 4-40 x 3/8"...
  • Page 45 8 2.0 Race Roller Vehicle Setup Differentials 2 degrees of toe-out Front: Standard Smart 27mm Spring Wire Dia: -1 degree Qty of Springs: Stock (20 degrees) Ramp Plate: 2.3mm Grease: 5000 wt Losi 54/40 wt Losi Diff Fluid: Silver 4.4 lbs 95mm Center Standard...
  • Page 46 TLRACING.COM Printed 01/2011 © 2011 Horizon Hobby, Inc. Team Losi, 8IGHT, XBT, Nitrotec, TLR logo and Losi-Lok are trademarks or registered trademarks of Horizon Hobby, Inc. 14536.2 Team Losi Racing, Horizon Hobby, Inc. Horizon Hobby UK Horizon Hobby an exclusive brand of...
