- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5CRR66EP4 Fan Total fan weigh READ AND SAVE THESE INSTRUCTIONS with light...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Secure mounting neck to the mounting plate Loosen set screws that holds ball. Lift mounting neck to mounting Plate and align with four screws to become a complete mount- screws. ing bracket. Loosen lock nuts and screws on yoke Loosen set screws that holds ball. Slide ball down and remove pin save till you can not feel screw on inside Total of 2 screws on the downrod...
- Page 4 Loosen set screw on the side of the Install arches and replace screws Slide arches over downrod and tight- arch assembly ball. taken out before. Tighten securely. en set screw. Tighten set screws to hold ball in Place ball on downrod. Replace pin place.
- Page 5 Make wire connections to power source using wire nuts provided. Make sure that no filiments Lift canopy to ceiling aligning the key are outside of the wirenut. After making the hole slots with the screws on the Install 6 X 15 watt incandescent can- bottom of the mounting bracket.
- Page 6 NOTE: Skip to step 52 if you are not installing the light kit. Place the steel plate on the switchcap.Next, Install lockwasher and hex nut pro- Remove and save the switch housing place the finial plate first then place screws. vided and tighten securely.
- Page 7 Loosen and remove the switch hous- Install reverse module into switch Install capacitor into switch cap by ing screws. cap by replacing screw saved. replacing screw saved. Place the steel plate on the switch cap. Next, place the finial plate then place the finial cap then place the Plug connector from fan to connector crystal ball over.
-
Page 8: Fan Speed
Remote Control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. LOW SPEED HIGH SPEED FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER... -
Page 9: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 10 6/21/06 REV.0 New made from 5GMR manual...
