Installation and Maintenance Manual
Please retain this manual for future reference.
P4000
Construction
Heater
For your safety: Do not use this heater in
a space where gasoline or other liquids
having flammable vapors are stored.
Revision 10-12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heat Wagon P4000
Summary of Contents for Heat Wagon P4000
- Page 1 Valparaiso, IN 46383 219-464-8818 • Fax 219-462-7985 www.heatwagon.com Installation and Maintenance Manual Please retain this manual for future reference. P4000 Construction Heater For your safety: Do not use this heater in a space where gasoline or other liquids having flammable vapors are stored.
- Page 2 If you need assistance or heater information such as an instruction manual, labels, etc. Contact your local Heat Wagon dealer or the manufacturer. Fire, burn, inhalation, and explosion hazard. Keep solid combustibles, such as build- ing materials, paper or cardboard, a safe distance away from the heater as recom- mended by the instructions.
-
Page 3: Table Of Contents
Wiring Diagram ..........8 WARRANTY All new Heat Wagon and Sure Flame heaters and fans are guaranteed against defective materials and work- manship for one (1) year from invoice date. -
Page 4: Specifications
SOLID PLASTIC GLOWING STAINLESS SOR TUBE FAN BLADES WHEELS STEEL HEATING ELE- MOTOR MENT 15 PCS SPECIFICATIONS Model No. P4000 Heat Output 51,200/102,400/136,500 BTU/Hr (Three stage selector) Watts 16,000/32,000/40,000 Electrical Rating: 480V 60Hz 3Ø, Amp draw 50 Amps 3Ø Ambient Thermostat Temp.Range 32 to 100˚F, 0-40˚C... -
Page 5: Operation
OPERATION REVIEW AND UNDERSTAND ALL WARNINGS IN THIS MANUAL. THEY ARE ESSENTIAL FOR SAFE USE OF THE HEATER. FOLLOW ALL LOCAL CODES. To start heating: 1. Place the heater on a stable and level surface. Make sure that no explosive or combustible fumes or dust are present. -
Page 6: Parts Breakdown
Item Part No. Description Item Part No. Description HWP 400001 HANDLE HWP 400016 STRAIN RELIEVER HWP 400002 HOOD HWP 400017 AMBIENT THERMOSTAT HWP 400003 HEAT EXCHANGE CHAMBER HWP 400018 THERMOSTAT KNOB HWP 400004 WHEEL ASSEMBLY HWP 400021 SWITCHES HWP 400005 WHEEL SHAFT HWP 400022 CONTACTORS... -
Page 7: Ladder Diagram
480 Volt 60 Hz 3 PH Transformer Control Switch (For Output +16KW) Fuse Control Switch (For Output +8KW Fan Motor Contactor & Coil (For Output 16KW) Overheat Limit Switch Contactor & Coil (For Output +16KW) Ambient Thermostat Contactor & Coil (For Output +8KW) Outlet Air Thermostat Fan Contactor Unit Cooldown Thermostat...
