ING - 6 VIDEODOOR ENTRY MONITOR WITH CONFIDENTIALITY FEATURE

GENERAL FEATURES

The ALCAD video entry system gives you full control over the access of visitors to your
property and, in addition, it allows you to identify the person who calls. The system offers
confidential communication operation as only one monitor is activated at any one time,
guaranteeing the total privacy of the conversation between the house and the person
who is calling.
An additional feature of the monitor is an automatic switch-on system. This function lets
you see the image captured by the video unit in the entrance panel without having to first
receive a call. The automatic switch-on function is useful in situations of surveillance or
when you wish to communicate with the entrance panel for whatever reason.
VIDEODOOR ENTRY SYSTEM MONITOR DESCRIPTION
1- Monitor handset
2- Button to open the street door
3- Monitor screen
4- Indicator of the status of the
system
When the indicator light is on then the
monitor is operative. The indicator light
will flash when turning on the auto
swith-on function.
5- Auxiliary button (P1)
Allows additional functions (opening a
s e c o n d d o o r. . . ) . C o n s u l t y o u r
installer.
1
2
7
9 1 0
8
6- Auxiliary button (P2)
Same characteristics as P1.
7- Automatic switch-on button
8- ON/OFF switch for the video
9- Image contrast control
10- Image brilliance control
3
4
5
6
