User Manual – QTFX-V1

11. Layout:

1) 2.5l Storage Bottle
2) Bottle safety lock
3) Carry Handel
4) Smoke Output
5) Wireless remote
160.456UK
8
User Manual – QTFX-V1

12. Rear Layout:

1) LED Display
2) Built in wireless receiver
3) DMX OUT (3 Pin)
4) DMX IN (3 Pin)
5) Power ON/OFF
6) IEC Power Input
7) DMX OUT (5 Pin)
8) DMX IN (5 Pin)
160.456UK
9
