Hyco HF05LQ Instruction Manual

5. Operation (Continued)
• The unit is fi tted with an auto-reset thermal cut-out which will operate for
safety reasons in the event of the unit over heating.To reset the thermal cut-out
switch off the power to the unit and allow it to cool down. Ensure the unit is
full, and then switch the unit back on. The thermal cut-out should reset itself.

6. TECHNICAL SPECIFICATIONS

MODEL
SUPPLY
POWER
CAPACITY
IP RATING
WEIGHT (EMPTY)
WEIGHT (FULL)
TIME TO HEAT TO 75°C
2
DIMENSIONS [mm] (H x W x D)
OVER-TEMPERATURE DEVICE
Based on an ambient temperature of 10°C
2

7. GUARANTEE AND SERVICE POLICY

This product is guaranteed against faulty materials and manufacture for a period of
one year from the date of purchase. Hyco will in its sole discretion replace, repair
or refund any faulty unit. Incorrect installation and consequences of limescale
deposits are excluded. Consequential costs such as labour charges or damage to
surroundings are expressly excluded.
3
HF05LQ
220V - 240V ~ 50Hz
2kW
5L
IP24
3.5 kg
8.5 kg
12 minutes
400 x 270 x 180
Auto reset
Hyco Manufacturing Ltd
California Drive
Whitwood
Castleford
West Yorkshire
WF10 5QH
Tel: 01977 517555 Fax: 01977 517666
Web: www.hyco.co.uk
E-mail: sales@hyco.co.uk
Handyflow
Oversink Point of
Use Water Heater
Model HF05LQ
Instruction Manual
Version 3.0 June 2010
