Page 3: Table Of Contents
Wiring Parts List – Ford 423 (Variable Dump) ........................2-116 Wiring Parts List – Perkins (Variable Dump) ........................2-118 Wiring Parts List – Ford 423 (Manual Dump) ........................2-120 Wiring Parts List – Perkins (Manual Dump) ......................... 2-122 Decals ....................................2-124 American-Lincoln 7760...
Page 4 Carriage Bolt, 5/16 - 18 x 1.000 7-70-05138 Broom Chamber Shaft Weldment 8-55-08098 Dowel Pin 2-00-04887 Screw, 3/4 - 10 x 1.250 HHC 2-00-04890 Retaining Ring, 3.341 Int. 2-00-02558 Lubrication Fitting, 45° 1/8 NPT 8-75-01157 Flat Washer, 3/4 2-00-00432 Screw, 1/4-20 x .50 P-4738/9510 American-Lincoln 7760...
Page 5: Main Broom
MAIN BROOM - EXPLODED VIEW SEE BROOM LIFT LINKAGE P4738/9606 American-Lincoln 7760...
Page 6: Drive Broom Arm
2-00-00522 Lock Washer, ¾ Helical Spring H110 2-00-03039 Screw, ¼ - 20 x .625 HSHC H209 2-00-00586 Nut, Hex Jam 5/16 - 18 x .500 x .187 H303 2-00-05103 Flat Washer, .750 x .343 x .050 SS C1014/9903 American-Lincoln 7760...
Page 7 MAIN BROOM (60”) - EXPLODED VIEW H107 H106 H109 12 13 H110 H53 H47 H209 H303 REF BROOM CHMABER MAIN FRAME c1014/9903 American-Lincoln 7760...
Page 8: Lock Washer, Helical Spring 1/4 Med
Nut, Hex Fiber Insert 1/2 - 13 2-00-00566 Lubrication Fitting, Straight 1/8 NPT 7-21-04030 Edging 2-00-05059 Screw, 1/2-13 x 3.750 HHC 7-42-05084 Link 2-00-00605 Nut, #10-24 Fiber Lock 2-00-00056 Screw, #10-24 x 3/4 RHM 8-88-00053 Control Valve P-5151/9608 American-Lincoln 7760...
Page 9: Main Broom Lift Linkage
MAIN BROOM LIFT LINKAGE - EXPLODED VIEW 5 10 11 19 10 12 13 P-5151/9606 American-Lincoln 7760...
Page 10 Nut, Hex 5/16-18 2-00-03569 Carriage Bolt, 5/16-18 2-00-05350 Screw, 1/4-28 x .63 2-00-03979 Washer, 1.00 x .391 x .06 2-00-03808 Washer, 1.50 x .750 x .06 2-00-00594 Nut, Hex MS 1/4-20 x .125 2-00-04603 Clamp 2-00-04378 Clamp P-5149/9609 American-Lincoln 7760...
Page 11: Side Broom (Variable Dump)
SIDE BROOM (VARIABLE DUMP) - EXPLODED VIEW P5149/9609 American-Lincoln 7760...
Page 12 Broom Chamber Flap 7-08-00487 Flap Bracket Weldment 7-19-08053 Right Hand Broom Chamber Door 2-00-04190 Carriage Bolt, 1/4 - 20 x .63 2-00-01490 Screw, 1/4 - 20 x .875 HHC 2-00-00589 Nut, 1/4-20 Hex 2-00-00501 Washer, 1/4 Lock P-4603/9606 2-10 American-Lincoln 7760...
Page 13: Broom And Brush Chamber Door
BROOM & BRUSH CHAMBER DOOR - EXPLODED VIEW 5 4 2 10 9 8 7 6 P4603/9606 American-Lincoln 2-11 7760...
Page 14 Screw, 3/8-16 x 1.750 HHC 2-00-00409 Flat Washer, 5/16 BS 2-00-00585 Nut, Hex 5/16-18 7-25-08052 Lower Baffle Flap 7-13-07136 Lower Baffle Clamp 2-00-00198 Carriage Bolt, 1/4-20 x 2.000 2-00-00641 Nut, Fiber Lock 1/4-20 2-00-00405 Flat Washer 1/2 B.S C-0355/9606 2-12 American-Lincoln 7760...
Page 15: Hopper System (Manual Dump)
HOPPER SYSTEM (MANUAL DUMP) - EXPLODED VIEW 32 15 15 12 C-0355/9606 American-Lincoln 2-13 7760...
Page 16 Collar 7-08-07053 Bumper 7-89-07423 Stud 8-82-00058 Switch 55525A Knob 2-00-04345 Tye-Wrap 8-09-01082 Bushing 7-21-04041 Edging - Hopper 2-00-02227 2-00-04603 Clamp 7-08-00869 Bracket - Safety Arm Stop 7-29-00248 Gasket - Dump Door 7-29-00249 Gasket - Dump Door P5146/9907 2-14 American-Lincoln 7760...
Page 17: Hopper And Flaps (Variable Dump)
SET SCREW SET SCREW APPLY "NEVER SEIZE" LUBE TO ROD END BUSHINGS NOTE: ADJUST AGAINST CYLINDER TO ACTIVATE WHEN HOPPER IS DOWN WITH EITHER OPEN OR CLOSED DOOR NOTE: POSITION CARRIAGE BOLT AS SHOWN 2 PLACES P5146/9703 American-Lincoln 2-15 7760...
Page 18 Lock Washer, 1/2 HS Med. 2-00-04159 Washer, 9/16 x 1 3/8 x .109 2-00-00518 Lock Washer, Helical Spring 2-00-03575 Carriage Bolt, 1/4-20 x .750 2-00-00263 Setscrew, 1/4-20 x .250 HSKCP 2-00-00643 Nut, 3/8-16 Stop *Contained in Kit 0880-705 P-5148a 2-16 American-Lincoln 7760...
Page 19: Hopper Filter And Impeller
HOPPER FILTER & IMPELLER - EXPLODED VIEW P-5148a/9611 American-Lincoln 2-17 7760...
Page 20 Screw, 1/4-20 x 1.000 HHM 2-00-03702 Flat Washer, .625 x .281 x .062 7-31-06059 Handle 2-00-00498 Lock Washer, .250 Ext 7-33-02195 Hose Ref. 8-33-02328 Hose Ref. 7-33-02225 Hose Ref. 8-33-02178 Hose Ref. 8-33-02201 Hose Ref. 7-33-02187 Hose Ref. P-4877b/0603 2-18 American-Lincoln 7760...
Page 21 HOPPER LIFT CYLINDER - 8-33-02178 TO LOWER PORT OF DUMP DOOR CYLINDER - 7-33-02194 TO FRONT PORT OF HOPPER LIFT CYLINDER - 7-33-02225 FROM "T" PORT OF MAIN CONTROL VALVE - 8-33-02201 TO RETURN MANIFOLD - 7-33-02187 American-Lincoln 2-19 7760...
Page 22 Nut, ½ - 13 2-00-02312 Washer, .50 Split 2-00-00405 Flat Washer, 1.063 x .531 x .094-s 2-00-05244 Carriage Bolt, Zinc 2-00-00530 Lockwasher, 5/16 2-00-05087 Screw, 5/16 with Nylok 2-00-00594 Nut, Finish Hex, .25-20 2-00-00518 Washer, Helical Spring P-5158/9608 2-20 American-Lincoln 7760...
Page 23: Scrub Deck And Brushes
SCRUB DECK & BRUSHES - EXPLODED VIEW TO SOLUTION CONTROL VALVE APPLY NEVER SEIZE P5158/9608 American-Lincoln 2-21 7760...
Page 24 2-00-02360 Nut, 3/8 - 16 Hex 2-00-02312 Lock Washer, ½ HS Med. 2-00-00596 Nut, Hex ½ - 13 x .750 x .437 H213 2-00-01254 Screw, ½ - 13 x 1.500 HHCS H225 2-00-04851 Washer, Engine Mount C1009/9903 2-22 American-Lincoln 7760...
Page 25 SCRUB DECK & BRUSHES (60”) - EXPLODED VIEW H213 H225 C1009/9902 American-Lincoln 2-23 7760...
Page 26 Hose, Solution Feed (3/4” ID x 28” LG) 7-33-02391 Hose, Solution Feed (1/2” ID x 20” LG) HARDWARE USED: 2-00-00221 Screw, ¼ - 20 x .750 HHC 2-00-00641 Nut, 5/16 - 18 Insert Fiber 2-00-03702 Washer, .625 x .281 x .063 C1012/9903 2-24 American-Lincoln 7760...
Page 27: Scrub Deck Solution Feed (60")
SCRUB DECK SOLUTION FEED (60”) - EXPLODED VIEW TO SOLUTION CONTROL VALVE REF SCRUB DECK (60“) C1012 American-Lincoln 2-25 7760...
Page 28 Washer, .563 x .281 x .063 SS 2-00-04690 Screw, 1/4-20 x 1.00 HHC SS #304 2-00-02312 Lock Washer, 1/2 HS Med. 2-00-04687 Lock Washer, Helical Spring 1/4 Med. 2-00-04688 Nut, 1/4-20 Hex 2-00-00598 Nut, .50-13 Hex 7-89-08033 Weldment - LH Bracket P-5160/0403 2-26 American-Lincoln 7760...
Page 29: Rear And Side Squeegees
REAR & SIDE SQUEEGEE - EXPLODED VIEW P5160/0403 American-Lincoln 2-27 7760...
Page 30 2-00-00206 Screw, 5/16 - 18 x 1.000 HHC H259 2-00-05343 Bolt Carriage, .38 - 16 x 3.50 SS H260 2-00-00615 Nut, Hex Fin .63 - 22 H261 2-00-05344 Screw, .313 - 18 x 1.75 HHM SS C1010/9903 2-28 American-Lincoln 7760...
Page 31 REAR & SIDE SQUEEGEE (60”) - EXPLODED VIEW H260 13 H261 H259 H178 C1010/9903 American-Lincoln 2-29 7760...
Page 32 Flat Washer, .875 x .375 x .060 2-00-00209 Screw, 3/8-16 x 1.250 HHC 2-00-00522 Lock Washer ¾ Helical Spring 2-00-03293 Nut, Hex Finish, .75-10 2-00-05356 Screw - HHC .313-18 x 1.25 Grade 8 2-00-05103 Flat Washer .750 x .343 x .50 P-5154/9907 2-30 American-Lincoln 7760...
Page 33: Squeegee Lift
SQUEEGEE LIFT - EXPLODED VIEW P5154/9907 American-Lincoln 2-31 7760...
Page 34 Wheel - Caster 7-33-02380* Hose - Vacuum - 78.50” 7-13-07104* Clamp - Hose 7-76-00050-1 Spring - Extension 2-00-04937 Hose Tie w/Eyelet 2-95-04182 7-09-01057 Bushing 7-33-02381* Hose Vacuum - 23.50” 7-08-00916* Bracket, Squeegee Lift Ref. *Part of Kit 0780-467 P-5159/9907 2-32 American-Lincoln 7760...
Page 35: Swing Squeegee Support
SWING SQUEEGEE SUPPORT - EXPLODED VIEW REF MAIN FRAME APPLY LOCTITE TO SETSCREWS, TTP APPLY NEVER SEIZE H237 H237 H260 P5159/9907 American-Lincoln 2-33 7760...
Page 36 Screw, 1/4 - 20 x .500 HHC SS 2-00-05940 Plug, 1/4 NPT Nylon 2-00-03979 Flat Washer, 3/8 2-00-02360 Nut, Hex 3/8 2-00-04182 Nut, 3/8 Fiber Lock 7-16-07275* Cover, Solution Tank *Solution Tank Cover Hinge Assembly only: 7-89-06693 P4735/0303 2-34 American-Lincoln 7760...
Page 37: Solution Tank
SOLUTION TANK - EXPLODED VIEW SEE RECOVERY TANK LID FOR HINGE ASSEMBLY TO SOLUTION BRACKET P4735/0303 American-Lincoln 2-35 7760...
Page 38 Nut, Hex Hvy. 3/8 - 16 x .687 x .359 2-00-00211 Screw, 5/16 - 18 x 1.750 HHC 8-39-00002 Knob 2-00-05724 Plug, Pipe, 3/4 NPT, Nylon 2-00-02220 Hose Clamp 2-00-05131 Nipple, Closed 3/4 NPT x 1.38 P-4750/0703 2-36 American-Lincoln 7760...
Page 39: Solution Feed Linkage
SOLUTION FEED LINKAGE - EXPLODED VIEW CONTROL PANEL TO SCRUB BRUSHES TO SCRUB BRUSHES (7-33-02322 HOSE REF.) (7-33-02322 HOSE REF.) TO SOLUTION TANK TO SOLUTION TANK P-4750/0703 (7-33-02178 HOSE REF.) (7-33-02178 HOSE REF.) American-Lincoln 2-37 7760...
Page 40 2-00-00518 Lock Washer, Helical Spring 1/4 Med 2-00-03382 Spring Washer, .875 x .500 x .015 H150 2-00-00211 Screw, 5/16 - 18 x 1.750 HHC H252 2-00-00600 Nut, Hex Hvy. 3/8 - 16 x .687 x .359 C1013/9903 2-38 American-Lincoln 7760...
Page 41 SOLUTION FEED LINKAGE (60”) - EXPLODED VIEW REF OPERATOR COMPARTMENT H150 H252 SOLUTION CONTROL LEVER ASSEMBLES THROUGH OPERATOR COMPARTMENT AS SHOWN TO SCRUB DECK TO SCRUB NUT SUPPLIED DECK WITH VALVE (ITEM 3) c1013/9903 American-Lincoln 2-39 7760...
Page 42 Screw, HHC 3/8 - 16 X 1.500 2-00-00410 Washer, Flat, 3/8 2-00-02360 Nut, Hex, 3/8 - 16 2-00-00432 Washer, Flat, 1.125 x .766 x .063 2-00-00594 Nut, Hex, STD FIN 1/4-20 2-00-00643 Nut, Fiber, 3/8 - 16 P-4734/0303 2-40 American-Lincoln 7760...
Page 43: Recovery Tank
RECOVERY TANK - EXPLODED VIEW DRAINAGE HOSE NOTE: OPEN LINK TO NOTE: OPEN LINK TO ACCOMMODATE ACCOMMODATE SPACER SPACER P-4734/0303 American-Lincoln 2-41 7760...
Page 44 Pop Rivet, .125 Dia. 7-79-00081 Strap, Gasket Retainer 7-79-00082 Strap, Gasket Retainer 2-00-00455 Flat Washer #6 7-79-00087 Strap, Gasket Retainer 7-33-02321 Vac Hose Key No.s 4, 5 and 6 must be ordered together for proper fit. P-4605/9809 2-42 American-Lincoln 7760...
Page 45: Recovery Tank Lid
RECOVERY TANK LID - EXPLODED VIEW 26 27 17 18 2 10 27 26 20 25 23 22 21 UPPER COVER SOLUTION TANK RECOVERY P4605/9510 TANK American-Lincoln 2-43 7760...
Page 46 Screw, 5/16 - 18 x 3.500 HHC 7-16-07276 Fan Cover 0782-145 Vacuum Motor (Seal Kit: #7-70-00020) 7-21-04029 Edging 2-00-04707 Rivet, 1/8 x .312 7-79-00081 Strap, Gasket Retainer 7-79-00082 Strap, Gasket Retainer 2-00-00455 Flat Washer, #10 Brass 7-79-00087 Strap, Gasket Retainer P-4721/9609 2-44 American-Lincoln 7760...
Page 47: Vacuum Motor & Float
VACUUM MOTOR & FLOAT - EXPLODED VIEW RECOVERY TANK LID P-5150/9606 American-Lincoln 2-45 7760...
Page 48: Bearing
Roller Bearing, Cone 2-00-05024 Washer, 1 1/16 x 2.000 2-00-05026 Nut, Slotted Hex 1 - 14 UNF 2-00-02436 Cotter Pin, .187 x 1.500 8-23-03065 Nut, Chamfered ½ - 20 x .800 x .620 8-11-00030 Dust Cap P-5155/9809 2-46 American-Lincoln 7760...
Page 49: Front Wheel And Brake
FRONT WHEEL & BRAKE - EXPLODED VIEW P5155 American-Lincoln 2-47 7760...
Page 50 Dowel Pin, .250 x .625 2-00-03051 Screw, 1/4-20 x .750 SHCS 7-21-04031 Edging 2-00-05225 Washer, 1.25 ID x 2.25 OD x .13 8-80-05035 Stud, Wheel Ref. 8-70-00027 Nut (1 comes w/motor) *Motor Key (1 comes w/motor): 8-70-00026 P-4637 2-48 American-Lincoln 7760...
Page 51: Rear Wheel
REAR WHEEL - EXPLODED VIEW FRAME- SIDE CHANNEL P-4637 American-Lincoln 2-49 7760...
Page 52 Nut, Hex Jam 3/8-16 x .562 x .218 2-00-00208 Screw, 5/16-18 x .750 HHC 2-00-02597 Screw, 5/16-18 x 3.250 HHC 2-00-00409 Flat Washer, .687 x .343 x .062 7-75-01126 Spacer, .500 x .327 x .780 Part of #1) P-4737/9609 2-50 American-Lincoln 7760...
Page 53: Brake Linkage
BRAKE LINKAGE - EXPLODED VIEW 5 28 FRAME (DIESEL ONLY) P4737 American-Lincoln 2-51 7760...
Page 54: Screw, 1/4 - 20 X .750 Hhc
Flat Washer, .750 x .281 x .062 2-00-02310 Lock Washer, Helical Spring 3/8 Med 2-00-00232 Screw, 3/8 - 16 x .75 Lg. HHC 2-00-01246 Nut, Hex Fiber Insert #10-24 2-00-00641 Nut, Hex Fiber Insert 1/4-20 2-00-00219 Screw, 1/4-20 x .500 HHC P-5068/9812 2-52 American-Lincoln 7760...
Page 55 FORWARD/REVERSE CONTROL (FORD 425) - EXPLODED VIEW P5068/9812 American-Lincoln 2-53 7760...
Page 56 Hose Clamp, .500 2-00-00405 Flat Washer, .500 7-03-04106 Transmission Arm 2-00-01246 Nut, Hex Fiber Insert #10-24 7-34-09018 Insulating Sleeve 2-00-00641 Nut, Hex Fiber Insert 1/4-20 2-00-00219 Screw, 1/4-20 x .500 HHC 2-00-00491 Grommet 7-08-00585 Hydroback Bracket P-5118a 2-54 American-Lincoln 7760...
Page 57 FORWARD/REVERSE CONTROL (PERKINS 104.19) - EXPLODED VIEW P5118a/9608 American-Lincoln 2-55 7760...
Page 58 Flatwasher - 1.063 x .328 x .062 7-81-00189 Safety Arm 7-75-01167 Spacer 2-00-05187 Carriage Bolt 3/8-16 x 1.25” 2-00-02369 Nut - Hex Jamb 3/8-16 8-15-01003 Set Screw Collar - .750 I.D. *Used on Variable Dump Machines Only. P-5153/9606 2-56 American-Lincoln 7760...
Page 59: Main Frame
MAIN FRAME - EXPLODED VIEW 3 17 FUEL LINE DIESEL ONLY P5153/0007 DIESEL FUEL LINE American-Lincoln 2-57 7760...
Page 60 Throttle Control Bracket 2-00-05261 Riv-Nut - ¼ - 20 THD 7-03-04165 Arm Rest Kit 7-72-05005 Slide Adjuster Kit 7-03-04165 Arm Rest Kit 2-00-04873 Clamp 2-00-00196 Carriage Bolt, 5/16-18 x 1.00 2-00-00409 Flat Washer, .687 x .344 x .062 P-5145/9707 2-58 American-Lincoln 7760...
Page 61: Driver Compartment
DRIVER COMPARTMENT - EXPLODED VIEW 32,43,44 P 5145/9809 American-Lincoln 2-59 7760...
Page 62 Hydraulic Hose ORS 8-90° to Str. 17" 2-00-04987 ORFS Union, 13/16-16 7-33-02190 Hydraulic Hose ORS 4 - 90º to Str. 67” *Used on Diesel-Powered Machines Only +Components of 0760-493, 7760 common hydraulic hose kit. ^Components of 0760-494, 7760 VD hydraulic hose kit. P-4813nm/0703 2-60 American-Lincoln 7760...
Page 63 HYDRAULIC HOSE SYSTEM (VARIABLE DUMP) - EXPLODED VIEW TO RETURN MANIFOLD FROM RESERVOIR TO DOUBLE GEAR PUMP PRIORITY PORT - TOP TO DOUBLE GEAR PUMP SECONDARY PORT - BOTTOM P4813-nm/0703 TO VAC MOTOR TO POWER RECOVERY TANK STEERING UNIT American-Lincoln 2-61 7760...
Page 64 Hydraulic Hose ORS 4-Str. to 4 Str. 37" 7-33-02190 Hydraulic Hose ORS 4-90° to Str, 67” 7-33-02184 Hydraulic Hose ORS 4-Str. Ends 25.5” (OPTION) 1 * Diesel Only + Hoses are components of 0760-493 7760 common hydraulic hose kit. C-0356i/0803 2-62 American-Lincoln 7760...
Page 65 HYDRAULIC HOSE SYSTEM (MANUAL DUMP) - EXPLODED VIEW SIDE BROOM OPTIONAL (SIDE BROOM VALVE & FITTINGS ADDED WITH OPTION) TO RETURN MANIFOLD FROM RESERVOIR C 3C C0356i/0803 American-Lincoln 2-63 7760...
Page 66 Hydraulic Hose ORS 4 - Str. Ends 37" 8-33-02183 Hydraulic Hose ORS 4 - Str. 49" 8-33-02200 Hydraulic Hose ORS 4-90º to Str. 55” #Components of 0760-493, 7760 common hydraulic hose kit. *Components of 0760-494, 7760 VD hydraulic hose kit. P4803g/0703 2-64 American-Lincoln...
Page 67 MAIN BROOM SIDE BROOM MOTOR VALVE MAIN CONTROL VALVE POWER STEERING UNIT DRIVE & AUXILIARY PUMP STRAINER RETURN MANIFOLD SCRUB BRUSH MOTOR POWER STEERING CYLINDER RESERVOIR SCRUB DECK CYLINDER DRIVE WHEEL MOTOR FILTER SQUEEGEE DECK CYLINDER P4803g/0703 American-Lincoln 2-65 7760...
Page 68 Hydraulic Hose ORS 16-Str. Ends 46" 7-33-02225 Hydraulic Hose ORS 4-90° to Str. 38" 7-33-02244 Hydraulic Hose, 1.000 dia. x 33.000" long 7-33-02180 Hydraulic Hose ORS 4-Str. to 4 Str. 37" 7-33-02184 Hydraulic Hose ORS 4-Str. Ends 25.5” (OPTION) 1 C-0379f/0803 2-66 American-Lincoln 7760...
Page 69: Suction & Return Hoses (Manual Dump)
MAIN BROOM MOTOR CYLINDER CONTROL OPTION VALVE SIDE BROOM VALVE POWER STEERING UNIT STRAINER DRIVE & PUMP AUXILIARY SCRUB BRUSH MOTOR RETURN MANIFOLD POWER STEERING CYLINDER SCRUB DECK CYLINDER DRIVE WHEEL FILTER MOTOR C0379f/0803 RESERVOIR SQUEEGEE DECK CYLINDER American-Lincoln 2-67 7760...
Page 70: Main Broom And Fittings
0882-040 Main Broom Motor 0880-448 Seal Kit for Motor 0882-040 2-00-04885 ORFS 90° Elbow, 3/4-16 to 13/16-16 8-33-02214 Hose Ref. 2-00-04895 ORFS Connector, 7/16-20 to 9/16-18 8-33-02200 Hose Ref. 2-00-04987 ORFS Union, 13/16 - 16 Ref. P-4381-2/9609 2-68 American-Lincoln 7760...
Page 71: Side Broom And Fittings
Seal Kit for 0880-293 (Serial Number 750056 & Above)1 7-33-02181 Hose Ref. 2-00-05373 Fitting, Union 9/16 - 18 ORS 7-33-02330 Hose Ref. 2-00-03702 Washer, Flat 2-00-04926 Fitting, 90° 7-88-00077 Valve, Housing - 3 way 2-00-05162 Fitting, Run tee 2-00-02589 Screw 2-00-00518 Lock Washer P-4379-1/9809 American-Lincoln 2-69 7760...
Page 72: Scrub Motors And Fittings
Fitting - 10 SAE - 8 ORS 2-00-04970 Fitting - 8 SAE - 8 ORS 7-33-02326 Hose - 17" 90° End 7-33-02327 Hose - 15.25" 90° End 0782-111 Scrub Motor Hyd. 0780-070 Seal Kit for Motor 0782-111 P-3810-B/0603 2-70 American-Lincoln 7760...
Page 73 TO "C4" PORT ON CYLINDER CONTROL VALVE P1824 KEY NO. PART NUMBER DESCRIPTION 2-00-04892 ORFS 90° Elbow, 7/16-20 to 9/16-18 7-17-05019 Hydraulic Cylinder (Squeegee) 7-17-05011 Hydraulic Cylinder (Scrub Deck) 8-33-02189 Hose Ref. 8-33-02218 Hose Ref. 7-33-02189 Hose Ref. P-4824/9609 American-Lincoln 2-71 7760...
Page 74 ORFS Connector, 7/16-20 to 9/16-18 8-33-02178 Hose Ref. 7-33-02225 Hose Ref. 2-00-04927 Run Tee Fitting 8-88-00045 Fitting, Check Valve 2-00-04997 Fitting Adapter, 9/16-18 ORFS - 1/4-18 NPT 2-00-04994 Adapter Fitting 2-00-05054 Adapter Fitting 7-33-02180 Hose Ref. P-4878 2-72 American-Lincoln 7760...
Page 75: Hopper Lift
TO RETURN MANIFOLD TO WORK PORT "B" ON HOPPER DUMP VALVE HOPPER LIFT HOPPER DUMP (VARIABLE DUMP ONLY) (VARIABLE DUMP ONLY) TO PORT "R" ON POWER STEERING UNIT TO PORT "L" ON POWER STEERING UNIT POWER STEERING P4878 American-Lincoln 2-73 7760...
Page 76: Shaft
2-00-05358 Fitting 8-03-02035 Fitting 7-03-00054 Fitting 2-00-04620 Seal 2-00-04895 Fitting 0885-051-1 Rear Wheel Motor 0880-238 Motor Seal 0880-237 Shaft Seal for Eaton P/N 110-1085-004 0880-586 Shaft Seal for Eaton P/N 110-1085-006 7-33-02223 Hose 8-33-02184 Hose Ref. P-5092/9809 2-74 American-Lincoln 7760...
Page 77: Rear Wheel Motors And Fittings
REAR WHEEL MOTOR & FITTINGS - EXPLODED VIEW RESERVOIR TO RIGHT WORK PORT OF TRANSMISSION TO LEFT WORK PORT OF TRANSMISSION TO RETURN MANIFOLD FRONT PORT REAR PORT P5092 American-Lincoln 2-75 7760...
Page 78 Screw, 5/16-18 x 1.000 HHC 2-00-02220 Hose Clamp, .812 - 1.500 2-00-03940 Screw, #10-24 x .500 TC/HH 7-33-02244 Hose 7-33-02331 Hose 7-33-02333 Hose 7-33-02224 Hose 7-33-02225 Hose 2-00-00293 Plug, Pipe 24** 2-00-05177 Plug 7/16-20 O Ring ** Manual Dump Only P-5088/9510 2-76 American-Lincoln 7760...
Page 79: Hydraulic Reservoir, Filter, And Fittings
HYDRAULIC RESERVOIR, FILTER, & FITTINGS - EXPLODED VIEW TO RETURN MANIFOLD TO AUX. PUMP ON TRANSMISSION TO DUST CONTROL MOTOR CASE DRAIN TO SQUEEGEE VAC. MOTOR CASE DRAIN TO CYLINDER CONTROL VALVE (T-PORT) 24** P-5088/9607 American-Lincoln 2-77 7760...
Page 80: Drive Pump And Fittings
ORFS 90° Elbow, 9/16-18 7-60-05026 Drive Pump 2-00-04922 ORFS 90° Elbow, 1 1/16-12 to 13/16-16 2-00-04978 Tee Fitting 7-60-05027 Auxiliary Pump (Double Gear) 7-33-02197 Hose Ref. 7-33-02223 Hose Ref. 7-33-02186 Hose Ref. 0880-685 Pump Assembly Kit 8-33-02245 Hose P-5070/9609 2-78 American-Lincoln 7760...
Page 81 Screw - 1/4-200 x 1.25 HHC 2-00-00641 Nut 0 1/4-20 Fibre Lock Hex 7-29-00207 Gasket 2-00-04822 Fitting - Elbow 2-00-04975 Fitting - 45º Elbow 2-00-04976 Fitting - 45º Elbow (Case Drain Port) 2-00-04885 Fitting - Elbow P-4871e/0603 American-Lincoln 2-79 7760...
Page 82 PART NUMBER DESCRIPTION 2-00-04892 Fitting, 90° #4 SAE x #4 ORS 2-00-04885 Fitting, 90° #8 SAE x #8 ORS 0882-041 Dust Control Motor 7-33-02332 Hose Ref. 7-33-02333 Hose Ref. 2-00-04970 Fitting, STRT #8 SAE x #8 ORS P-4837-1/9609 2-80 American-Lincoln 7760...
Page 83 TO PORT “T” ON CYLINDER CONTROL BLOCK KEY NO. PART NUMBER DESCRIPTION 7-60-05029 Power Steering Unit 2-00-04932 ORFS Boss Reducer, 3/4-16 to 9/16-18 2-00-05264 Fitting, Straight 2-00-04918 ORFS Connector, 9/16-18 7-33-02334 Hose Ref. 7-33-00225 Hose Ref. 7-33-02192 Hose, 67” Ref. P-4834/9705 American-Lincoln 2-81 7760...
Page 84 Lock Washer, 1/4 Split 2-00-00594 Nut, Hex 1/4 - 20 x .437 x .218 2-00-03702 Flat Washer For 1/4 Bolt 2-00-04895 Fitting - Straight 2-00-04885 ORFS 90° Elbow, 3/4-16 to 13/16-16 ** Diesel Only # Gas Only P-4833A/0603 2-82 American-Lincoln 7760...
Page 85 ORFS 90° Elbow, 7/16-20 to 9/16-18 2-00-00518 Lock Washer, 1/4 Split 7-12-02032 Cavity Plug 8-33-02184 Hose Ref. 7-33-02189 Hose Ref. 8-33-02218 Hose Ref. 2-00-05177 Plug 7-12-02031 Cartridge 250 PSI Relief Ref. 8-33-02189 Hose Ref. 7-33-02225 Hose Ref. P-4831a/9809 American-Lincoln 2-83 7760...
Page 86 Ref. 12** 8-33-02214 Hose Ref. 8-33-02245 Hose Ref. 13** 7-33-02202 Hose Ref. 8-33-02244 Hose Ref. 8-33-02184 Hose Ref. 8-33-02200 Hose Ref. 7-33-02180 Hose Ref. 7-33-02186 Hose Ref. * Variable Dump Hopper Only **Manual Dump Hopper Only P-5087/9705 2-84 American-Lincoln 7760...
Page 87: Screw, 1/4 - 20 X 1.250 Hhc
Fitting - Elbow 2-00-00641 Nut, 1/4 - 20 - Fiber Lock Hex 7-29-00192 Gasket, Oil Cooler 2-00-01980 Screw, 1/4 - 20 x 1.250 HHC 8-13-07088 Clip 7-33-02201 Hose Ref. 7-33-02433 Hose Ref. 8-62-01010 Oil Cooler 7-29-00207 Gasket P4383b/0603 American-Lincoln 2-85 7760...
Page 88 Ref. 2-00-04928 ORFS Run Tee, 13/16 - 16 2-00-04957 ORFS Cap, #8 ORS 8-33-02202 Hose Ref. 2-00-04932 Fitting, Reducer 7-33-02331 Hose, 16ORS 46" Ref. 2-00-04926 Fitting, 90° Elbow 7-33-02334 Hose, 52.25" Ref. 8-33-02327 Hose, 94" Ref. P5163\9609 2-86 American-Lincoln 7760...
Page 89 Ref. 2-00-04928 ORFS Run Tee, 13/16 - 16 2-00-04957 ORFS Cap, #8 ORS 8-33-02202 Hose Ref. 2-00-04932 Fitting, Reducer 7-33-02331 Hose, 16ORS 46" Ref. 2-00-04926 Fitting, 90° Elbow 7-33-02334 Hose, 52.25" Ref. 8-33-02327 Hose, 94" Ref. P5164\9609 American-Lincoln 2-87 7760...
Page 90: Lock Washer, Helical Spring 5/16 Med
Nut, Hex 5/16 - 18 x .500 x .265 7-90-07262 Wire, to Ground (Ford 423) 2-00-00196 Screw, 5/16 - 18 x 1.000 Carriage 2-00-05253 Cable Clamp, .500 2-00-05171 Boot, Protective (Red) 2-00-05173 Boot, Protective (Black) 7-90-07280 Battery (+) Cable (Diesel Only) P-5086a/9611 2-88 American-Lincoln 7760...
Page 91: Battery
BATTERY - EXPLODED VIEW GAS & LP TO STARTER TO GROUND 1,24,26 21,25 DIESEL ENGINE P-5086a/9611 American-Lincoln 2-89 7760...
Page 92 Nut, Hex Fiber Insert 1/4 - 20 7-78-05016 Engine Cover Stop 2-00-00409 Flat Washer, .687 x .343 x .062 2-00-01769 Screw, 1/4-20 x 1.75 HHC 2-00-01255 Screw, 5/16-18 x .88 HHC 7-55-08116 Striker Pin 7-08-00532 Engine Cover Bracket 8-08-07045 Edging 8-21-04038 Edging P-5152 2-90 American-Lincoln 7760...
Page 93: Engine Cover
ENGINE COVER - EXPLODED VIEW 6 7 8 9 10 11 12 13 14 2 3 4 4 19 P-5152/9705 American-Lincoln 2-91 7760...
Page 94 Fuel Tank 7-13-07100 Bracket 2-00-03702 Flat Washer, 1.062 x .265 x .062 2-00-04494 Compression Male 90° Elbow, 1/8 7-87-02148 Fuel Line (Gas Only) 8-08-07038 Fuel Line Bumper (Gas Only) 7-11-00029 Fuel Cap 7-87-02160 Fuel Line (Diesel Only) P-4747/9606 2-92 American-Lincoln 7760...
Page 95: Fuel Tank
FUEL TANK - EXPLODED VIEW P4747 American-Lincoln 2-93 7760...
Page 96 Screw, 3/8-16 x .75 Lg. HC 7-75-01187 Spacer, Engine Mounting (1.00” Lg.) 7-08-00919 Bracket - Outboard Engine Mounting 7-81-00140 Support, Rear Engine 2-00-00234 Screw, 3/8-16 x 1.50 Lg. HHC 7-21-04028 Edging 7-21-04043 Edging 8-21-04019 Edging 7-79-00102 Strap - Neutral Switch Retaining C1968/0108 2-94 American-Lincoln 7760...
Page 97 FORD 425 ENGINE - EXPLODED VIEW TO NEG. BATTERY POST C1968/0007 American-Lincoln 2-95 7760...
Page 98 Lower Radiator Hose 2-00-04873 Cable Clamp, .500 2-00-02312 Lock Washer, HS ½ Med. 7-08-00620 FWD/RVS Cable Bracket 2-00-00596 Nut, Hex 1/2-13 x .750 x .437 3 2-00-01372 Nut, #8-32 Hex Fiber Lock 7-08-00579 Engine Mounting Bracket 7-21-04031 Edging P5122btx/0108 2-96 American-Lincoln 7760...
Page 99 PERKINS 104.19 ENGINE - EXPLODED VIEW 65 12 TO GLOW P-5122b/0007 PLUG RELAY GLOW PLUG BUS BAR American-Lincoln 2-97 7760...
Page 100 Hose, Fuel Line 2-00-00501 Lock Washer, ¼ Int. 2-00-00828 Terminal .25 Ring 2-00-04578 Terminal .156 Male Bullet 8-60-05028 Fuel Pump 8-24-04138 Fuel Filter (Service) 2-00-05261 Threaded Insert ¼ - 20 2-95-04388 Hose Clamp 8-33-02146 Hose, Fuel Line P5082B 2-98 American-Lincoln 7760...
Page 101 THROTTLE, CHOKE, & FUEL PUMP - EXPLODED VIEW EXISTING EXISTING P-5082/B American-Lincoln 2-99 7760...
Page 102 7-87-02160 Fuel Line (Steel Tube) 8-08-07050 Fuel Line Bumper 8-08-00710 Fuel Filter Bracket 8-33-02257 Fuel Line (Pump to Filter) 7-08-00584 Water Extractor Mount Bracket 2-00-00209 Screw, 3/8-16 x 1.250 HHC 2-00-00234 Screw, 3/8-16 x 1.500 HHC P-5125/9609 2-100 American-Lincoln 7760...
Page 103 FUEL & WATER EXTRACTOR (DIESEL) - EXPLODED VIEW LAST INJECTOR WATER EXTRACTOR ENGINE INJECTOR PUMP DRIVE COMPARTMENT FUEL PUMP FUEL FUEL FILTER TANK FRAME American-Lincoln 2-101 7760...
Page 104 Strip, Terminal 8-74-00012 Starter Relay 2-00-00503 Lockwasher, Int/Ext Tooth ZN 7-33-05098 Housing, Flywheel 0875-125 Electronic Control Module (Service P/N) 0875-145 Service PN after Serial No. 752365 2-00-00089 Screw, #10 - 24 x 1.500 RHM 7-21-04043 Edging P-4931/0903 2-102 American-Lincoln 7760...
Page 105: Air Intake – Ford
AIR INTAKE (FORD) - EXPLODED VIEW 14 15 P4931/0903 American-Lincoln 2-103 7760...
Page 106 Hose Clamp, .875 - 2.750 7-08-00582 Bracket, Air Cleaner Mounting 2-00-00518 Lock Washer, Helical Spring 1/4 Med 2-00-00594 Nut, Hex 1/4 - 20 x .437 x .21 7-33-02236 Hose, Air Intake 2-00-00221 Screw, 1/4 - 20 x .750 HHC P-5123/9609 2-104 American-Lincoln 7760...
Page 107 AIR INTAKE (DIESEL) - EXPLODED VIEW P5123 American-Lincoln 2-105 7760...
Page 108 Screw, M10 x 1.5 25mm MHHC ( w/ Engine) 2-00-00233 Screw, 3/8 - 16 x 1.000 2-00-02310 Lock Washer, 3/8 2-00-02360 Nut, 3/8-16 2-00-04040 Exhaust Clamp 7-49-00031 Muffler 0780-384 Purifier Muffler (Option) 7-31-07017 Muffler Clamp 2-00-04040 Muffler Clamp 7-56-04055 Tail Pipe P-3602B/9609 2-106 American-Lincoln 7760...
Page 109 PART OF ENGINE P-5124b/9612 KEY NO. PART NUMBER DESCRIPTION 7-56-04056 Exhaust Pipe 7-34-09015 Insulating Sleeve 2-00-03404 Hose Clamp 7-56-04055 Tail Pipe 7-31-07017 Hanger 8-82-00045 Switch - Momentary On/Off 2-00-04040 Exhaust Clamp 7-49-00031 Muffler 0780-385 Purifier Muffler Option P-5124B/9609 American-Lincoln 2-107 7760...
Page 110 Fan Shroud (Gas Only) 7-72-00008 Fan Shroud (Diesel Only) 2-00-01676 Flat Washer, 1.062 x .265 x .06 2-00-00209 Screw, 3/8 - 16 x 1.250 HHC Ref. 2-00-00589 Nut, Hex Jam 1/4-20 x .437 x .156 2-00-04913 Hose Plug P-4607/9606 2-108 American-Lincoln 7760...
Page 111: Radiator And Shroud
RADIATOR & SHROUD - EXPLODED VIEW P-4607/9606 American-Lincoln 2-109 7760...
Page 112 Screw, 1/4 - 20 x .500 BHS 7-52-00081 Circuit Breaker Panel 7-52-00080 Instrument Panel 7-52-00083 Blank Panel 7-33-05096 Console Housing 2-00-03702 Flat Washer 7-08-00510 Console Support Bracket 2-00-00219 Screw, .25-20 x .50 2-00-03466 Screw, #10-16 x .500 T/F RHM P-4717 2-110 American-Lincoln 7760...
Page 113: Steering And Instrument Panel
STEERING & INSTRUMENT PANEL - EXPLODED VIEW P-4717/9606 American-Lincoln 2-111 7760...
Page 114 Switch, Glow Plug (Diesel Only) 2-00-00624 Nut, #6 - 32 Hex. 2-00-03061 Screw, #10 - 24 x .500 THM 8-08-00748 Bracket, Relay 8-64-05011 Relay (20 Sec. Time Delay) 2-00-02330 Nut, #10 - 32 Hex. 2-00-00512 Washer, #10 Int. C-1304/9809 2-112 American-Lincoln 7760...
Page 115: Instrument Panel
SCRUB SHAKER PRESSURE ROTATION MOTOR SWITCH SWITCH SWITCH K-SW GP-SW (DIESEL ONLY) NOTE: IF ALL OPTIONS ARE NOT ORDERED, PLUG (1) 8-11-00015 INTO EACH WIRE NOT USED. CB-2 CB-5 CB-4 CB-3 CB-1 CB-7 CB-6 CB-9 CB-8 C-1304/0603 American-Lincoln 2-113 7760...
Page 116 Washer, #6 Lock 8-82-00045 Switch, Glow Plug (Diesel Only 2-00-00624 Nut, 6-32 Hex 2-00-03061 Screw, #10-24 X .500 THM 8-08-00748 Bracket, Relay 8-64-05011 Relay (20 Sec. Time Delay) 2-00-02330 Nut, #10-232 Hex 2-00-00512 Washer, #10 Int. C-1305/9609 2-114 American-Lincoln 7760...
Page 117: Instrument Panel ( Manual Dump)
LIGHT TD-2 SCRUB SCRUB PRESSURE ROTATION SWITCH SWITCH K-SW GP-SW (DIESEL ONLY) NOTE: IF ALL OPTIONS ARE NOT ORDERED, PLUG (1) 8-11-00015 INTO EACH WIRE NOT USED. CB-2 CB-1 CB-5 CB-4 CB-3 CB-7 CB-6 CB-9 CB-8 C-1305/0603 American-Lincoln 2-115 7760...
Page 118 Screw, 1/4 - 20 x .750 THM 2-00-04952 Boot, Protective (Red) 8-09-01082 Bushing - Universal Ref. 2-00-03878 Grommet Ref. 8-90-07328 Cable, Ground 0775-226 Diode Assembly 2-00-00498 Lock Washer, 1/4 Ext. 2-00-01974 Washer, #10 Sealing 2-00-04721 Grommet 0895-113 Harness, Engine 2-00-04873 Clamp Ref. C-1306/9903 2-116 American-Lincoln 7760...
Page 119 MAIN HARNESS IN THE MIDDLE OF THE OPENING FOR LIGHT OPTIONS FOR THE REST OF THE HARNESS TO FIT 16 46 3 17 ROUTE HARNESS ABOVE LIGHT OPTIONS ALONG REAR OF FRAME C1306/9903 23 21 22 37 American-Lincoln 2-117 7760...
Page 120 Nut, 1/4-20 Hex 8-09-01082 Bushin,g Star Ref. 2-00-03878 Grommet 8-90-07328 Cable, Ground Ref. 2-00-00498 Lock Washer, ¼ Ext. 2-00-00605 Nut, #10-24 Hex 2-00-01974 Washer, #10 Sealing 0795-112 Harness, Engine 2-00-00530 Lock Washer, .31 Ref. 0775-226 Diode Assembly P-3659/9903 2-118 American-Lincoln 7760...
Page 121 20,21,49 OP-SW FUEL TANK ALT. 30,36,46 3 16 NOTE: THESE (3) WIRES MUST EXIT MAIN HARNESS IN THE MIDDLE OF THE OPENING FOR LIGHT OPTIONS FOR THE REST OF THE HARNESS TO FIT 41 40 22 39 American-Lincoln 2-119 7760...
Page 122 Wire, Start 11 Sol To Start Sol. 2-00-00183 Screw, 1/4-20 X .750 THM 2-00-04952 Boot, Protective (Red) 2-00-01128 Butt Splice 8-90-07328 Cable, Ground 2-00-00498 Washer, 1/4 Ext. Lock 2-00-01974 Washer, #10 Sealing 0895-099 Harness, Engine 2-00-04873 Clamp Ref. P-3663 2-120 American-Lincoln 7760...
Page 123 LP VERSION (GAS ONLY) ALT. BATTERY 14 34 P-3663 3 17 16 46 ROUTE HARNESS ABOVE LIGHT OPTIONS ALONG REAR OF FRAME UESC 20,21,23 6,8,32,33 23 21 22 37 TO FORD CARB ENG. HARN. STARTER STARTER (B+) American-Lincoln 2-121 7760...
Page 124 Cable, Ground 2-00-00498 Washer, Lock Ext. 2-00-00605 Nut, 10-24 Hex 2-00-01974 Washer, #10 Sealing 2-00-01128 Butt Splice 2-00-00594 Nut, 1/4-20 Hex 2-00-00605 Nut, #10-24 Hex 2-00-01974 Washer, #10 Sealing 0895-112 Harness, Engine 2-00-00530 Lock Washer, .31 Ref. C-1303/9609 2-122 American-Lincoln 7760...
Page 125 OP-SW FUEL TANK ALT. 30,36,41 3 16 C-1303/9608 NOTE: THESE (3) WIRES MUST EXIT MAIN HARNESS IN THE MIDDLE OF THE OPENING FOR LIGHT OPTIONS FOR THE REST OF THE HARNESS TO FIT 44 18 22 15 American-Lincoln 2-123 7760...
Page 126 Side Broom-Pull to Raise Moving Belts-Stay Clear Moving Fan Blade-Stay Clear Exhaust Warning Pinch Point-Stay Clear Cover/Hopper Could Close No Step 8-18-00487 Blank Square-Option Covers 8-18-00527 Alto (medium) 8-18-00526 American-Lincoln (large) 8-18-00525 American-Lincoln (medium) 8-18-00541 7760 Serial Plate 2-00-04115 Rivet...
Page 127: Decals
DECALS - EXPLODED VIEW P5169A/2-04 American-Lincoln 2-125 7760...
Page 128 NOTES 2-126 American-Lincoln 7760...
Page 129 Spare Parts Kit, Gas/LP(Variable Dump) ....................3-50 Spare Parts Kit, Diesel (Variable Dump) ....................3-51 Spare Parts Kit, Gas/LP (Manual Dump) ....................3-52 Spare Parts Kit, Diesel (Manual Dump) ..................... 3-53 Index ..............................3-54 Warranty ..............................3-59 American-Lincoln Technology 7760...
Page 130 American-Lincoln Technology 7760...
Page 131 7760 SCHEMATIC DIAGRAM - GAS/LP (VARIABLE DUMP) MACHINE TO ALARMSTAT (C) & AUTOMATIC OVERRIDE #1 C1316/9603 ® American-Lincoln Technology 7760 Owner's Manual...
Page 132 7760 SCHEMATIC DIAGRAM - DIESEL (VARIABLE DUMP) MACHINE C1317/9602 ® American-Lincoln Technology 7760 Owner's Manual...
Page 133 7760 SCHEMATIC DIAGRAM - GAS/LP (MANUAL DUMP) MACHINE C1318/9603 ® American-Lincoln Technology 7760 Owner's Manual...
Page 134 7760 CONNECTION DIAGRAM - DIESEL (MANUAL DUMP) MACHINE C1319/9602 ® American-Lincoln Technology 7760 Owner's Manual...
Page 135 7760 CONNECTION DIAGRAM - GAS/LP (VARIABLE DUMP) MACHINE INSTRUMENT LIGHTS SQUEEGEE DECK SW BRUSH DECK SW SIDE BROOM SW MAIN BROOM SW ARE OPTIONS TD-2 REC. HIGH CB-WH 15 15 LIGHT SHAKER SCRUB SCRUB SOL. LOW MOTOR SW OPTION ROTATION SW PRESSURE SW.
Page 136 7760 CONNECTION DIAGRAM - DIESEL (VARIABLE DUMP) MACHINE INSTRUMENT LIGHTS GAS ONLY SQUEEGEE DECK SW BRUSH DECK SW ARE OPTIONS SIDE BROOM SW MAIN BROOM SW TD-2 REC. HIGH CB-WH 15 15 LIGHT SHAKER SCRUB SOL. LOW SCRUB MOTOR SW...
Page 137 7760 CONNECTION DIAGRAM - GAS/LP (MANUAL DUMP) MACHINE INSTRUMENT LIGHTS SQUEEGEE DECK SW BRUSH DECK SIDE BROOM MAIN BROOM OPTIONS TD-2 REC. HIGH CB-WH 15 15 LIGHT SCRUB SOL. SCRUB ROTATION PRESSURE LIGHT WIRES C D E F C D E F 15B,35 &37...
Page 138 7760 CONNECTION DIAGRAM - DIESEL (MANUAL DUMP) MACHINE INSTRUMENT LIGHTS SQUEEGEE DECK SW BRUSH DECK OPTIONS SIDE BROOM MAIN BROOM ONLY TD-2 REC. HIGH CB-WH 15 15 LIGHT OPTION SCRUB SOL. SCRUB ROTATION PRESSURE LIGHT C D E F C D E F...
Page 139 Screw, 1/2 - 13 x 1.000 HHC 2-00-02352 Nut, Hex 1/2 - 13 x .875 x .484 2-00-02312 Lock Washer, Helical Spring 1/2 Med 2-00-01444 Flat Washer, .750 x .520 x .062 2-00-00240 Screw, 1/2 - 13 x 1.250 HHC P-4621/9703 American-Lincoln Technology 3-11 7760...
Page 140 Pad Driver (Right Hand Thread - Black) 0772-066 Pad Driver (Left Hand Thread - Red) 7-32-03015 Center-Lok II for Clockwise Rotation 7-32-03013 Center-Lok II for Counterclockwise Rotation 7-32-03016 Holder for Clockwise Rotation 7-32-03014 Holder for Counterclockwise Rotation P4195c/9609 3-12 American-Lincoln Technology 7760...
Page 141 BRUSH OPTIONS - EXPLODED VIEW P4195C/9706 American-Lincoln Technology 3-13 7760...
Page 142 Lock Washer, Helical Spring 3/8 2-00-00232 Screw, 3/8-16 x .75- HHC 7-18-00215 Side Broom Label 8-82-00044 Switch 2-00-04918 Fitting 8-33-02216 Hose, ORS-4-Str. Ends 2-00-04895 Fitting 2-00-00218 Screw, 5/16-18 x 2.00 HHC 2-00-05350 Screw, 1/4-28 x .625 HHC C-0360/9609 3-14 American-Lincoln Technology 7760...
Page 143 SIDE BROOM OPTION (MANUAL DUMP) - EXPLODED VIEW CONTROL C0360/9609 BLOCK American-Lincoln Technology 3-15 7760...
Page 144 KEY NO. PART NUMBER DESCRIPTION 8-08-03180 Proex and Wire 8-08-03190 Proex 8-08-03191 Natural Fiber and Wire 8-08-03193 Nylon 8-08-03200 Poypro Prolene 8-08-03196 Nylon, High Density 8-08-03198 Fiber and Wire, High Density 8-08-03107 Poly Prolene 8-08-03177 Nylon P-4195a/9609 3-16 American-Lincoln Technology 7760...
Page 145 Flat Washer, .687 x .343 x .062 2-00-00518 Lock Washer, Helical Spring 1/4 Int. 2-00-00594 Nut, Hex 1/4 - 20 2-00-00624 Nut, #6 - 32 Hex 8-64-00008 Circuit Breaker 15 AMP 2-00-00507 Star Washer 1/4 INT. P-4899/9609 American-Lincoln Technology 3-17 7760...
Page 146 Light Switch, Push/Pull 8-40-05029 Taillight 7-90-07229 Wire 2-00-00409 Flat Washer, .687 x .343 x .062 2-00-04876 Screw, 1/4 - 20 x .500 BHS 8-28-05011 Fuse, FU-1 15 Amp P-4822/9609 HEADLIGHTS/TAILLIGHTS/INSTRUMENT LIGHTS/ BRAKE LIGHTS & TURN SIGNALS: 0880-355 3-18 American-Lincoln Technology 7760...
Page 147 LIGHTS OPTION - EXPLODED VIEW PANEL HARNESS LIGHT SWITCH REAR FRONT P4822/9609 MAIN HARNESS American-Lincoln Technology 3-19 7760...
Page 148 2-14-03197 Rubber Washer, 1.000 x .187 x .125 8-82-00025 Turn Signal Switch 8-40-05027 Turn Signal Light 2-00-00455 Flat Washer # 10 8-28-05011 Fuse, FU-1 15 Amp 2-00-00220 Screw, 1/1 - 20 x .625 HHC P 4823/9609 3-20 American-Lincoln Technology 7760...
Page 149 TURN SIGNAL OPTION - EXPLODED VIEW PANEL HARNESS LIGHT SWITCH REAR 28 15 BACKSIDE OF FRONT CIRCUIT BREAKER PANEL FROM FROM HARNESS USED WITHOUT LIGHT OPTIONS FUSE HOLDER BUTT SPLICE FLASHER TURN SIGNAL SWITCH P4823/9706 MAIN HARNESS American-Lincoln Technology 3-21 7760...
Page 150 Nut, Hex MS #10 - 24 x .375 x .125 LIGHT SUPPORT KEY NO. PART NUMBER DESCRIPTION 8-81-00145 Weldment 8-90-07362 Wire Assembly 2-00-00491 Grommet CIRCUIT BREAKER KEY NO. PART NUMBER DESCRIPTION 8-64-00008 Circuit Breaker (15AMP) 8-11-00044 Boot 8-11-00015 Terminal P-4902/9609 3-22 American-Lincoln Technology 7760...
Page 151 WARNING LIGHTS (STANDARD) - EXPLODED VIEW P4902 American-Lincoln Technology 3-23 7760...
Page 152 Flat Washer, .500 x .218 x .062 2-00-00512 Lock Washer, #10 Int 2-00-00605 Nut, Hex MS #10 - 24 x.375 x .125 CIRCUIT BREAKER KEY NO. PART NUMBER DESCRIPTION 8-64-00008 Circuit Breaker (15AMP) 8-11-00044 Boot 8-11-00015 Terminal P-4901/9609 3-24 American-Lincoln Technology 7760...
Page 153 WARNING LIGHTS with OVERHEAD GUARD - EXPLODED VIEW 25 26 C B 5 R E D C B 9 B LA C K P4901/9511 American-Lincoln Technology 3-25 7760...
Page 154 FIRE EXTINGUISHER DRIVER’S COMPARTMENT P4872-3/9704 KEY NO. PART NUMBER DESCRIPTION 8-83-04033 Fire Extinguisher 2-00-00221 Screw, 1/4 - 20 x .750 HHC 980657-1 Lock Washer, 1/4 Split 2-00-00594 Nut, Hex 1/4 - 20 x .437 x .218 P-4872-3/9704 3-26 American-Lincoln Technology 7760...
Page 155 FLAME ARRESTING GAS CAP P4875 OPTION NO. 0880-105 KEY NO. PART NUMBER DESCRIPTION 8-11-00024 Flame Arresting Gas Cap 8-83-04022 Fuel Tank with Gauge P-4875/9601 American-Lincoln Technology 3-27 7760...
Page 156: Air Cleaner
SAFETY AIR CLEANER END CAP AIR CLEANER P-4839/9607 TO CARBURETOR KEY NO. PART NUMBER DESCRIPTION 8-23-03064 Wing Nut Assembly 8-24-04111 Filter Element P-4839/9601 3-28 American-Lincoln Technology 7760...
Page 157 C0354/9609 KEY NO. PART NUMBER DESCRIPTION 7-06-00001 Debris Basket 7-27-07156 Debris Basket Frame 2-00-04685 Screw, 1/4-20 x .750 HHC 2-00-04590 Sealing Washer, 1/4 2-00-04686 Lock Washer, 1/4 2-00-04688 Nut, Hex 1/4-20 3-73-00024 Edging 3.75 ft. C-0354/9609 American-Lincoln Technology 3-29 7760...
Page 158 Fitting, 90º Swivel Elbow 2-00-04608 Fitting, ¾ NPT Couping 2-95-02518 Fitting, ¾ NPT Close Nipple 2-00-04469 Fitting, 90º Elbow 7-24-04022 Solution Inlet Filter 2-00-04736 Fitting, ¾ NPT Connector 2-00-05035 Reducing 90º Elbow ¼ to 1/8 NPT P-5170/0007 3-30 American-Lincoln Technology 7760...
Page 159 DETERGENT & SOLUTION TANK, ESP OPTION - EXPLODED VIEW H107 H108 FLOAT H206 TO DETERGENT PUMP COUPLING AT SOLUTION TANK H107 H108 DETERGENT TANK SOLUTION TANK FROM PUMP DETERGENT PUMP STRAINER P5170-1/9704 American-Lincoln Technology 3-31 7760...
Page 160 Bellows Module Service Parts Kit Ref. 2-00-04751 Fitting, 90° Swivel Elbow 2-00-04608 Fitting, 3/4 NPT Coupling 2-95-02518 Fitting, 3/4 NPT Close Nipple 2-00-04469 Fitting, 90° Elbow 7-24-04022 Solution Inlet Filter 2-00-04736 Fitting, 3/4 NPT Connector P-5171/9809 3-32 American-Lincoln Technology 7760...
Page 161 RESTRIP & REPLACE WITH 2-00-04626 REF. 7-08-00437 CAMEL WIRING HARNESS 22 10 TO SOLUTION TANK TO SOLUTION FEED LINKAGE RIGHT HAND SIDE MAIN BROOM CHAMBER P5171/9706 CUT OFF EXISTING TERMINAL, RESTRIP & REPLACE WITH 2-00-04281 TO SCRUB BRUSHES American-Lincoln Technology 3-33 7760...
Page 162 2-00-03702 Washer, Flat 7-50-05143 2-00-02708 Screw, HHC 5/16-18 x 1.00Lg. 2-00-00585 Nut, Hex 5/16-18 THDs 2-00-00530 Washer, Lock 5/16 2-00-00409 Washer, Flat 2-00-02310 Washer, Lock 3/8 2-00-04432 Hole Plug (Fuel Gauge) 2-00-04757 Hole Plug (Choke) P4787-5/9609 3-34 American-Lincoln Technology 7760...
Page 163 LP TANK SYSTEM OPTION - EXPLODED VIEW SEAT BRACKET PLASTIC CAP ENGINE SEAT PEDESTAL P-4787-5 American-Lincoln Technology 3-35 7760...
Page 164 Fitting, 1/8 NPT x 3/8 Hose 90° 2-00-01128 Butt Connector 3-61-00189 Wire, 16 Gauge Black 2-00-00828 Terminal, Ring .25 8-33-02266 Elbow 2-00-02216 Hose Clamp 8-87-02110 Adapter NOTE: All parts marked with an * are contained in LP Engine Kit # 7-11-04015 P-4918-1/9610 3-36 American-Lincoln Technology 7760...
Page 165 LP FORD ENGINE - EXPLODED VIEW 9 10 BULKHEAD FITTING American-Lincoln Technology 3-37 7760...
Page 166 Screw, #10-24 x .500 RHM 2-00-04626 Terminal, Holl. FP5336F or Equiv. 2-00-04576 Terminal, Holl. XMP9654S or Equiv. 2-00-01128 Terminal, Butt Splice 2-00-00519 Washer, #10 Lock 2-00-04345 Tye Rap 3-61-00189 Stranded, 16 awg. Black 20’ 2-00-00605 Nut, #10-24 P-4959/9609 3-38 American-Lincoln Technology 7760...
Page 167 FORD ENGINE SHUTDOWN - EXPLODED VIEW AUTOMATIC OVERRIDE ALARMSTAT ENGINE YELLOW HARNESS GREEN PRESSURSTAT P4959/9607 American-Lincoln Technology 3-39 7760...
Page 168 Wire, Pressurestat C to Alarmstat NC 8-90-07401 Wire, Pressurestat NC to Alarmstat NO 8-63-05012 Alarmstat Regulator 8-09-01070 Alarmstat Bushing, 3/8-1/2 NPT 2-00-02474 Pipe Plug, 1/2 NPT 2-95-02537 2-00-04638 Reducer, 3/8 to 1/2 8-63-05013 Pressurestat Regulator P-5126/9609 3-40 American-Lincoln Technology 7760...
Page 169 PERKINS ENGINE SHUTDOWN - EXPLODED VIEW TO WARNING LIGHT TO AO#1 TO AO#3 TO AO#2 P5126/9706 American-Lincoln Technology 3-41 7760...
Page 170 Screw, 5/16-18 x 1.500 HHC 2-00-00409 Flat Washer, .687 x .343 x .062 8-71-00016 Shim Block 2-00-02322 Lock Washer 5/16 2-00-00644 Nut, 5/16-18 Lock 8-09-04272 Armrest Kit (Includes both Armrests) 0780-109 Suspension Seat Option (Includes all the Above) P-5080/9601 3-42 American-Lincoln Technology 7760...
Page 171 TIRE OPTIONS KEY NO. PART NUMBER DESCRIPTION 7-89-08068 Rear Drive Tire, 6" Wide 7-89-08071 Siped Rear Drive Tire 0780-098 Front Tire, Urethane P-4554/9601 American-Lincoln Technology 3-43 7760...
Page 172 OPTION NO. 0780-382 KEY NO. PART NUMBER DESCRIPTION 7-13-07097 Clip 2-00-04312 Screw, #10 - 24 x .625 T/C HH 7-03-00040 Adapter 634118-4 Clarke Hose 639804-4 Clarke 1 1/2" Wand Assembly 638828-4 14" Squeegee 7-18-00121 Decal, Warning P-4930/9601 3-44 American-Lincoln Technology 7760...
Page 173 Lock Washer, 1/4 Int. 2-00-00518 Lock Washer, Helical Spring 1/4 Med 2-00-00594 Nut, Hex 1/4 - 20 x .437 x .218 7-15-01031 Spacer 2-00-05046 Fitting, 90° Elbow 7-33-02192 Hose Ref. 8-33-02214 Hose Ref. 7-82-00020 Switch 7-90-07228 Wire, Jumper P-4881/9601 American-Lincoln Technology 3-45 7760...
Page 174 Knob 2-00-01703 Screw, #8-32 x .875 RHM 2-00-02296 Lock Washer, #10 Ext. 7-30-05057 Guard, Rheostat 2-00-00529 Lock Washer, Helical Spring #8 Med. 2-00-00602 Nut, Hex MS #8-32 x .375 x .125 7-18-00136 Decal, Detergent Flow C1231 3-46 American-Lincoln Technology 7760...
Page 175 INSTRUMENT PANEL, ESP OPTION - EXPLODED VIEW INSTRUMENT EXISTING INSTRUMENT PANEL PANEL HARNESS H191 H190 H124 H191 H190 H124 C1231-1/9704 American-Lincoln Technology 3-47 7760...
Page 176 Lock Washer, HS #10 Med. 2-00-00605 Nut, Hex MS #10-24 x .375 x .125 2-00-04749 Radial Locking Spring Pin .125 x 1.375 2-00-03059 Screw, #10-24 x .375 THM 8-11-00015 Terminal, .250 FISO 2-00-04578 Terminal, .156 Male C1217/9609 3-48 American-Lincoln Technology 7760...
Page 177 DETERGENT TANK SOLUTION TANK RECOVERY TANK DL-SW EXISTING SH-SW ESP HARNESS ESP HARNESS SECTION B SECTION A RH-SW INSTRUMENT PANEL DETG. 5 GPM PUMP PUMP MACHINE WIRING HARNESS REMOVE EXISTING H206 TERMINALS SOLUTION CONTROL LINKAGE C1217-1/9704 American-Lincoln Technology 3-49 7760...
Page 178 Engine Air Cleaner Element 7-24-04032 Hydraulic Return Filter Element 7-24-04046 Rubber Rear Squeegee Inner ENGINE RELATED COMPONENTS Ford LSG gas/LPG Engine 8-24-04128 Engine Oil Filter 8-24-04138 Fuel Filter 2-00-05334 Belt - Governor 2-00-05335 Belt - Alternator 3-50 American-Lincoln Technology 7760...
Page 179 8-24-04106 Engine Air Cleaner Element 7-24-04032 Hydraulic Return Filter Element 7-24-04046 Hopper Panel Filter ENGINE RELATED COMPONENTS Ford Model 104.19 Diesel Engine 2-60-02240 Engine Oil Filter 2-60-02241 Fuel Filter 2-60-02242 Belt - Alternator & Water Pump American-Lincoln Technology 3-51 7760...
Page 180 Rubber Rear Squeegee Inner FILTERS 8-24-04106 Engine Air Cleaner Element 7-24-04032 Hydraulic Return Filter Element ENGINE RELATED COMPONENTS Ford LSG 423 GAS/LPG Engine 8-24-04128 Engine Oil Filter 8-24-04138 Fuel Filter 2-00-05334 Belt - Governor 2-00-05335 Belt - Alternator 3-52 American-Lincoln Technology 7760...
Page 181 Rubber Rear Squeegee Inner FILTERS 8-24-04106 Engine Air Cleaner Element 7-24-04032 Hydraulic Return Filter Element ENGINE RELATED COMPONENTS Perkins Model 104.19 Diesel Engine 2-60-00240 Engine Oil Filter 2-60-02241 Fuel Filter 2-60-02242 Belt -Alternator & Water Pump American-Lincoln Technology 3-53 7760...
Page 182 DUST CAP ............................1-48 DUST CONTROL IMPELLER AND FITTINGS ................2-80 DUST CONTROL SWITCH ......................1-16 ELECTRICAL SCHEMATIC, DIESEL (MANUAL DUMP) ..............3-6 ELECTRICAL SCHEMATIC, DIESEL (VARIABLE DUMP) ............. 3-4 ELECTRICAL SCHEMATIC, GAS/LP (MANUAL DUMP) ............... 3-5 3-54 American-Lincoln Technology 7760...
Page 183 HYDRAULIC SCHEMATIC (MANUAL DUMP) ................1-39 HYDRAULIC SCHEMATIC (VARIABLE DUMP) ................1-38 HYDRAULIC SYSTEM, CLEANING THE ..................1-37 HYDRAULIC TORQUE REQUIREMENTS ..................1-10 HYDRAULICS ..........................1-37 IGNITION SWITCH ......................... 1-14 INDEX ............................3-54 INSTRUMENT PANEL ........................2-112 American-Lincoln Technology 3-55 7760...
Page 184: Perkins Diesel Engine
RADIATOR ............................1-48 RADIATOR AND SHROUD ......................2-108 REAR AND SIDE SQUEEGEES ..................... 2-26 REAR WHEEL ..........................2-48 REAR WHEEL MOTOR & FITTINGS ..................... 2-74 REAR SQUEEGEE ......................... 1-44 RECOVERY OR ESP SYSTEM, HOW IT WORKS ................ 1-24 3-56 American-Lincoln Technology 7760...
Page 185: Squeegee And Scrub Deck Cylinders And Fittings
STEERING AND INSTRUMENT PANEL ..................2-110 SUCTION & RETURN HOSES (MANUAL DUMP) ................. 2-66 SUCTION & RETURN HOSES (VARIABLE DUMP) ............... 2-64 SUSPENSION SEAT, OPTION ....................... 3-42 SWEEPING & DUST CONTROL SYSTEM, HOW IT WORKS ............1-26 American-Lincoln Technology 3-57 7760...
Page 186: Vacuum Motor And Fittings
VACUUM MOTOR & FLOAT ......................2-44 VOLT METER ..........................1-17 WARNING LIGHTS (STANDARD) ....................3-22 WARNING LIGHTS with OVERHEAD GUARD ................3-24 WARRANTY ............................ 3-59 WATER TEMPERATURE GAUGE ....................1-17 WET SWEEP BYPASS ........................3-45 WIRING, ESP OPTION ........................3-48 3-58 American-Lincoln Technology 7760...

Alto 7760 Operator's Manual, Instruction Book And Parts List

Quick Links

Need help?

Questions and answers

Related Manuals for Alto 7760

Summary of Contents for Alto 7760

Table of Contents
