RS Series Screw Compressor Central Chiller Part Number: A0551794 Bulletin Number: AE3-635.2 Effective: 10/1/07 Write Down Your Serial Numbers Here For Future Reference: _________________________ _________________________ _________________________ _________________________ _________________________ _________________________ We are committed to a continuing program of product improvement. Specifications, appearance, and dimensions described in this manual are subject to change without notice. DCN No.
Page 2
Shipping Information Unpacking and Inspection You should inspect your Screw Compressor Central Chiller for possible shipping damage. Thoroughly check the equipment for any damage that might have occurred in transit, such as broken or loose wiring and components, loose hardware and mounting screws, etc. In the Event of Shipping Damage According to the contract terms and conditions of the Carrier, the responsibility of the Shipper ends at the time and place of shipment.
Table of Contents CHAPTER 1: SAFETY ...............VI How to Use This Manual .................... vi Safety Symbols Used in this Manual ..............vi Warnings and Precautions ..................vii Responsibility ......................viii General Responsibility..................viii Operator Responsibility ..................ix Maintenance Responsibility................... x Reporting a Safety Defect ..................x CHAPTER 2: FUNCTIONAL DESCRIPTION......
Page 4
Identifying Control Panel Indicator Lights and Switches for the Standard and Advanced Controllers ..................34 Controller Operation (Standard Controller) ............... 36 Using the Standard Touchscreen Interface ............36 Main Menu Screen ....................37 Compressor Status Screen .................37 Process and Recirculation Pump Status Screens ..........39 Active Alarm List and Alarm History Screens ............40 Configuration Menu Screen.................41 Viewing and Setting System Temperatures ............45...
Page 5
Central Chiller Identification (Serial Number) Tag............. 76 Technical Assistance....................77 Parts Department ....................77 Service Department.....................77 Sales Department....................77 Contract Department ...................77 Screw Compressor Central Chillers Chapter 1: Safety...
Chapter 1: Safety How to Use This Manual Use this manual as a guide and reference for installing, operating, and maintaining your screw compressor central chiller. The purpose is to assist you in applying efficient, proven techniques that enhance equipment productivity. This manual covers only light corrective maintenance.
Warnings and Precautions Our equipment is designed to provide safe and reliable operation when installed and operated within design specifications, following national and local safety codes. This may include, but is not limited to OSHA, NEC, CSA, SPI, and any other local, national and international regulations.
Responsibility These machines are constructed for maximum operator safety when used under standard operating conditions and when recommended instructions are followed in the maintenance and operation of the machine. All personnel engaged in the use of the machine should become familiar with its operation as described in this manual.
Operator Responsibility The operator’s responsibility does not end with efficient production. The operator usually has the most daily contact with the equipment and intimately knows its capabilities and limitations. Plant and personnel safety is sometimes forgotten in the desire to meet incentive rates, or through a casual attitude toward machinery formed over a period of months or years.
Clean the chiller and surrounding area DAILY, and inspect the machine for loose, missing or broken parts. Shut off power to the chiller when it is not in use. Turn the switch to the OFF position, or unplug it from the power source. Maintenance Responsibility Proper maintenance is essential to safety.
Chapter 2: Functional Description Models Covered in This Manual This manual provides operation, installation, and maintenance instructions for Screw Compressor Central Chillers. Model numbers are listed on the serial tag. Make sure you know the model and serial number of your equipment before contacting the manufacturer for parts or service.
Electrical Features Electronic expansion valve 2 remote single circuit condensers with variable speed lead fans and fan cycling (air- cooled models) NEMA 12 electrical enclosure Touch-safe branch circuit fusing Liquid line solenoid and shut-off valves Chilled water flow switches Controller Features Allen Bradley Micrologix 1500 PLC control with PanelView 300 Micro monochrome/key pad interface Digital low temperature freezestat...
Options Options marked with “*” indicate options that can be factory installed or retrofitted in the field. Advanced control package including: AB SLC 5/04 PLC with PanelView 1000 color touch screen, control of up to nine additional chillers, cooling tower system, water treatment system, and DH+ communication capabilities General Fault audible/visual alarm with elevated light stack Non-fused rotary thru-the-door disconnect switches...
Page 14
Fail Safe Operation If a safety device or circuit should fail, the design must be such that the failure causes a “Safe” condition. As an example, a safety switch must be a normally open switch. The switch must be held closed with the device it is to protect. If the switch fails, it will go to the open condition, tripping out the safety circuit.
Chapter 3: Installation Uncrating the Equipment WARNING! Due to the size and weight of the Screw Compressor Chiller, the manufacturer recommends using bonded professional millwrights to unload and move the chiller. 1. Rig the chiller from the frame only, using spreader bars to prevent load transfer to any chiller components.
Making Electrical Connections Screw Compressor Central Chilling systems are designed for three-phase voltage operation. Refer to the unit nameplate for proper voltage and amperage requirements. Note: Make sure you provide a correctly sized and protected supply of electrical power to the unit. Refer to National Electric Code (NEC) Article 430-24 through 430-26 for proper feeder conductor and supply disconnect sizing.
Note: Never switch contactor leads or motor leads for reversing rotation. Do not use contactor or motor leads for phase matching. Compressor damage will occur if the compressor is run in reverse. The compressor motor protector checks for correct phasing and will not allow it to start in reverse.
Making Process Water Connections All Models All central chilling stations have two chilled water connections per unit, and on water-cooled models, one more set of water connections for condenser water: The chilled water manifold allows one-point connections of Chilled Water piping. The Sch. 40 steel piping includes butterfly valves at each evaporator for flow balancing and circuit isolation;...
Making Tank Piping Connections If you have purchased the Screw Compressor central chilling station with the optional integral pump tank, please proceed with this section. Note: Thermocouplings for chillers must be installed on both the hot and cold sides of the tank. Freezestat Control The unit can be equipped with a freezestat control which shuts down the compressor if the chilled water temperature approaches the freezing point.
Page 20
Return (From Process) Bring the chilled water returning from the process to the pump tank warm (From Process) side. This line is sized according to the flow rate from the process to the pump tank. See Page 16 for more information on piping considerations. Caution! Do not use the Screw Compressor Central Chiller to support piping.
Water Connection Sizing Considerations Note: Run all external chilled water connections with adequate size to the process. Provide the largest possible openings and passages for the flow of chilled water through platens, dies, molds, or other pieces of equipment. Minimum external pressure drop is critical for proper operation. Galvanic Corrosion Considerations Water circuit piping components are primarily ferrous (iron) and react electro-chemically with non-ferrous metallic materials such as copper.
Page 22
Condenser Water Out The return outlet, located at the chiller side or rear is connected to a cooling tower inlet, a sewer or other approved discharge receiver. A water regulating valve is an optional feature in the condenser water out line. Adjust the butterfly valve for the pressure drop that corresponds to the model number of the chiller (Shown in the table below).
Installing the Remote Air-Cooled Central Chiller Condensers Remote air-cooled condensers use the surrounding air to cool the refrigerant from the compressor and release the process heat absorbed from the chilled water into the atmosphere. All models have variable speed fans and low ambient controls to allow proper operation down to -20°F (-29°C) outdoor air temperature.
Page 24
System Configuration The system can be configured in any of the arrangements shown on page of the Appendix. The configuration and distance between the chiller and the condenser affects pipe size, refrigerant charge, oil return, and oil charge. Therefore, there are limitations that must be adhered to for reliable and optimal operation.
Page 25
Liquid Line Sizing The liquid line should be sized as small as possible while maintaining acceptable pressure drop to minimize the refrigerant charge. Liquid line risers should not exceed 15 feet from the base of the air-cooled condenser. Horizontal runs do not require a pitch. Insulation is recommended to prevent heat losses/gains and condensation due to unusual ambient conditions.
Page 26
Discharge Line Sizing For horizontal runs, the discharge line should be pitched downward, in the direction of flow at a rate of ¼” for every 10 feet. This will allow oil to flow towards the condenser. Discharge line sizing is based on the velocity required for sufficient oil return back to the compressor.
Page 27
Refrigerant Charge Determination The approximate amount of refrigerant charge required by the system varies based on the total length of the refrigerant lines and the size of the chiller. Referring to Figure 6, determine the amount of charge based on discharge and liquid line sizes and lengths. Add these four numbers together to find the total operating charge.
Checking Motor Direction Compressor Caution! Check Compressor Rotation Before Starting Unit! Connect a phase monitor and phase incoming power ABC. Note: Unit must be wired in sequence (ABC) and checked before start up. Never switch contactor leads or motor leads for reversing rotation. Do not use contactor or motor leads for phase matching.
Page 29
Water-Cooled Central Chiller 1. Check the shipping papers against the serial tag to be sure chiller size, type and voltage is correct for the process. 2. Check the transformer primary voltage connections to be sure they are configured for the electrical power you are using. 3.
Page 30
19. Close the discharge butterfly valve then crack it open; open all pump suction butterfly valves fully, then start the pump and observe the gauge. 20. Check for proper pump rotation direction. To confirm proper rotation: a. Observe a pump pressure gauge connected to the suction and discharge sides of the pump casing through two ¼”...
Page 31
13. Check condenser fans for pressure switch settings as shown in the table below: Set on Set off number bars bars not applicable; Fan 1 is a variable-speed fan 1,069 10.7 1,172 11.7 1,276 12.8 1,035 10.3 1,379 13.8 1,138 11.4 14.
If the gauge indicates 20 psi (137.9 kPa/1.38 bars) or more below the pump curve, the pump is running backwards. Reverse rotation by interchanging any two power mains to the pump motor or starter. Recheck the pressure to be sure it increased. 22.
Chapter 4: Operation Start-up Water & Remote Air-Cooled Central Chiller Startup 1. Start the chiller by pushing the Start button on the control panel of the unit. 2. The touchscreen will display the Main Menu screen. 3. If your chiller has been setup to control the pump tank, the recirculation pump will turn on first, then after 5 seconds the process pump will turn on.
Controller Description Identifying Control Panel Indicator Lights and Switches for the Standard and Advanced Controllers System On The green System On indicator lights when the main power switch is on and the control circuit is energized. Start The Start push-button lets you energize the unit. Stop The Stop push-button lets you de-energize the unit.
Controller Operation (Standard Controller) Using the Standard Touchscreen Interface Introduction The Standard touchscreen interface lets you control your Screw Compressor central chilling station. You can do such things as: Control compressors and optional pumps View current statuses of operation, such as pressures, temperatures, and capacities Handle alarm conditions This section lists special instructions for operating the standard touchscreen interface.
Main Menu Screen To start the Standard touchscreen interface: Push the ON/OFF button on the cabinet. The chillers’ control panel energizes and the System On indicator turns on. The Main Menu screen displays: Main Menu Screen The Main Menu screen lets you gain access to: “COMPRESSOR STATUS”...
Page 38
To view the status of the chiller compressors, start at the Main Menu screen, then: 1. Press the buttons on the right side of the screen to highlight “COMPRESSOR STATUS” 2. Press The compressor status screen displays: Compressor Status Screen The Compressor Status screen shows the status for compressors within the system.
Process and Recirculation Pump Status Screens Note: If your chiller system was configured to operate the pump(s) of the chilled water pump tank, the user may view the status of the process and recirculation pumps. To view the status of the pumps, start from the Main Menu, then: 1.
Active Alarm List and Alarm History Screens These two screens let you view any active alarm conditions as well as the alarm history or the entire history. The list of system alarms that are tracked are as follows: Chilled Water High Temperature Alarm Chilled Water Low Temperature Alarm Compressor Motor Protector Fault (One for each compressor) Chilled Water Circuit Low Flow (One per chilled water circuit)
Configuration Menu Screen This screen allows the operator to configure the settings for the compressors, pumps, chiller setpoint, and high and low temperature alarm setpoints. Operating the chiller compressors To enable or disable the individual compressors, start at the Main Menu, then: 1.
Page 42
Compressor Enable Screen These screens allow the customer to toggle the compressors between ON-LINE and OFF- LINE. As the operator presses the F1 or F2 button, the corresponding compressor state changes between ON-LINE and OFF-LINE. Press F4 to leave this screen. Setting Compressor Rotation Times and Activating Compressor Lead/Lag Operation While in the Configuration Menu, the compressor rotation screen allows the customer to...
Page 43
Operating Chiller Pumps To turn on and off the pumps, start from the Main Menu, then: 1. Press the buttons to highlight either “CONFIGURATION MENU”. 2. Press 3. Highlight “PUMP ENABLES” 4. Press 5. Highlight the pump you want to operate. The Pump Enables Screen appears Pump Enables Screen Any pump that is disabled to the OFF-LINE position will not be called to operate.
Page 44
Setting Pump Rotation Times and Activating Pump Rotation Operation While in the Configuration Menu, the pump rotation screen allows the customer to enable or disable the rotation of compressors. While viewing the screen for the applicable rotation, pressing F1 will toggle the rotation function On or Off. Pressing the F2 button will present an entry screen which will allow the entry of a rotation interval.
Viewing and Setting System Temperatures To view the actual process temperature, select the “COMPRESSOR STATUS”, “PROC PUMP STATUS”, or the “RECIRC PUMP STATUS” screens from the main menu. The process temperature is located on the bottom-right of the screen. For example, the compressor status displays: Compressor Status Screen Note: If you have a metric version of the Central Chiller controller, the screens...
Hourmeters Screen Viewing Compressor Run Times From the Main Menu, use the buttons to highlight the “HOURMETERS” menu. Scroll to select the compressors. Then press to display the hourmeter. Note: this is a complete list of all components that may be included in the system. Any component that is not included in the system will not accumulate time.
Page 47
Viewing Pump Run Times From the Main Menu, use the buttons to highlight the “HOURMETERS” menu. Scroll to select the pump. Then press to display the hourmeter. Note: this is a complete list of all pumps that may be included in the system. Any pump that is not included in the system will not accumulate time.
Controller Operation (Advanced Controller) Using the Advanced Touchscreen Interface Introduction The Advanced touchscreen interfaces let you control your Screw Compressor Central Chilling station. You can do such things as: Control compressors and optional pumps View current statuses of operation, such as pressures, temperatures, and capacities Handle alarm conditions This section lists special instructions for operating advanced touchscreen interfaces.
Accessing the Main Menu Screen To start the Central Chiller Advanced touchscreen interface: Push the ON/OFF button on the cabinet. The chiller control panel energizes and the System On indicator turns on. The Main Menu screen displays: Figure 4: Main Menu Screen The Main Menu screen lets you gain access to: ”Chilled Water System Status”...
Page 50
“Compressor Hourmeters” contains the lifetime and resettable hour meters to show the number of hours that the compressors have been running “Chilled Water Process Pump Hourmeters” and “Chilled Water Recirc Pump Hourmeters” contains the lifetime and resettable hour meters to show the number of hours that the process and recirculation pumps have been running.
Viewing Compressor Status Staging 1. The system uses a PID control algorithm to regulate the chilled water temperature. As the required control effort increases or decreases, the system compressors are loaded and unloaded or turned on/off to keep the temperature at the specified set- point.
Page 52
1. OFFLINE – This indicates that the compressor has been turned off in the compressor enable/disable screen. The compressor will not be called to operate until it has been re-enabled. The color code for this indication is black. 2. READY – Indicates that the compressor is enabled and ready to run. However, the current loading does not require the compressor to be running.
Viewing Chiller Pump Status Note: If your chiller system was configured to operate the pump(s) of the chilled water pump tank, the user may view the status of the process and recirculation pumps. To view the status of the pumps, start from the Main Menu, then: 1.
3. ON LINE – Pump is currently running. The color code for this indication is green. 4. FAULT – A safety on the pump indicates a fault condition and the pump has been deactivated. Once the problem is remedied, the pump will return to a READY state unless it is put in the OFFLINE state.
Page 55
To acknowledge the alarm, press the alarm silence button to clear it. It will then appear in the alarm history screen. Except for High and Low Water Temperature, and Low Refrigerant Pressure, these alarms are considered fatal and maintenance must be preformed in order to allow the chiller to fully run.
Configuration Menu Screen This screen allows the operator to configure the settings for the compressors, pumps, chiller setpoint, and high and low temperature alarm setpoints. Operating the chiller compressors To enable or disable the individual compressors, start at the Main Menu, then: 1.
Page 57
Operating Chiller Pumps To turn on and off the pumps, start from the Main Menu, then: 1. Press the Up or Down buttons to highlight either “Chilled Water Pump Tank Configuration”. 2. Press The Pump Enables Screen appears Figure 9: Chilled Water Pump Tank Configuration Screen Any pump that is disabled to the OFF-LINE position will not be called to operate.
The system automatically rotates the compressor order to generate a Lead/Lag rotation. Any time a compressor is faulted or manually taken OFF-LINE, it will be removed from the Lead/Lag rotation. Once the fault is cleared or manually put ON-LINE, the compressor is returned to the Lead/Lag rotation at the end of the rotation order.
Page 59
To view the actual process temperature start at the Main Menu and 1. Use the Up or Down arrows to highlight “Chilled Water System Status” 2. Press The system status displays: Figure 10: Chilled Water System Status Screen Note: If you have a metric version of the controller, the screens display in converted metric values.
The chiller setpoints are set through the chiller configuration menu. Starting from the Main Menu: 1. Press the Up or Down buttons to highlight “Chiller Configuration” 2. Press 3. Touch the “Process Set-point” button The input display screen appears: Figure 11: Temperature Input Display Screen 4.
Page 61
From the Main Menu, use the Up or Down buttons to highlight the “Compressor Hourmeters” menu. Then press to display the hourmeters. Note: this is a complete list of all compressors that may be included in the system. Any compressor that is not included in the system will not accumulate time.
Viewing Pump Run Times From the Main Menu, use the Up or Down buttons to highlight either the “Chilled Water Process Pump Hourmeters” or “Chilled Water Recirc Pump Hourmeters” menu. Then press to display the hourmeters. Note: this is a complete list of all pumps that may be included in the system. Any pump that is not included in the system will not accumulate time.
Operation Procedures Standard Controller Advanced Controller Shutdown 1. Ready process and related equipment for shut down. 2. Do not turn off the main power until chiller completes the shutdown sequence (approximately 2 minutes). 3. Close the water make up valve. 4.
Chapter 5: Maintenance Maintenance Schedule The checklist below contains a list of items which should be inspected and/or replaced to keep your Central Chiller operating at peak efficiency. Perform each inspection at the regular intervals listed below. System model # Serial # Date/ Date/...
Preventative Maintenance A systematic preventive maintenance program helps avoid costly down time. It is recommened that this service be performed on an annual basis to keep equipment operating at peak efficiency. Call the Service Department to arrange a schedule of inspections. Inspections include: 1.
Water-Cooled Proper water treatment will greatly reduce cleaning intervals. Remove dirt in the condenser tubes with a nylon tube brush. Mineral deposits can be removed by circulating Liquid De-Scaling Solution (Model Number A0502600) through the water side of the condenser. Follow the directions on the container. The refrigerant side is sealed and requires no routine maintenance.
Chapter 6: Troubleshooting Introduction The utmost in safety precautions should be observed at all times when working on or around the machine and the electrical components. All normal trouble-shooting must be accomplished with the power off, line fuses removed, and with the machine tagged as out of service.
Page 68
Problem Possible cause Corrective action Freeze control set higher than Lower freeze control setting to temperature of liquid in 10°F (6ºC) below the leaving system. (Freezestat alarm) temperature you want. Remote Air cooled units: Check condenser fans for proper rotation. Check for dirty condenser.
Page 69
Problem Possible cause Corrective action Restricted condenser air flow. Clean condenser. Check superheat on expansion Refrigerant not feeding. valve. Make sure that coolant mixture Improper water/glycol solution. protection is right for the process. Unit runs continuously, but not Poor heat transfer in evaporator. Backflush and clean evaporator.
Chapter 7: Appendix Optional Components The following is a list of options which your Screw Compressor Central Chiller may have been equipped with: Advanced control package including: AB SLC 5/04 PLC with PanelView 1000 color touch screen, control of up to nine additional chillers, cooling tower system, water treatment system, and DH+ communication capabilities General Fault audible/visual alarm with elevated light stack Non-fused rotary thru-the-door disconnect switches...
Spare Parts List Part No. Part Description Quantity Check your Customer Information Packet for a complete list of spare parts and part numbers for your central chilling station. Screw Compressor Central Chiller Chapter 7: Appendix...
Returned Material Policy Credit Returns Prior to the return of any material authorization must be given by the manufacturer. A RMA number will be assigned for the equipment to be returned. Reason for requesting the return must be given. ALL returned material purchased from the manufacturer returned is subject to 15% ($75.00 minimum) restocking charge.
Inside Enclosure Protected Earth Lifting Point Ground Central Chiller Identification (Serial Number) Tag (Located on back of Chiller) Company Logo XXX-XX Series Central Chiller Model Number XXX-30 Max Capacity HR 460V Serial Number 060701R Date of Manufacture Month/Year Over-current Protection Device (s) Total Frequency 50/60Hz Street Address City, State Zip Code...
Technical Assistance Parts Department Call toll-free 7am–5pm CST [ 800 ] 423-3183 or call [ 847 ] 273-7700, Fax [847] 273-7804 The ACS Customer Service Group will provide your company with genuine OEM quality parts manufactured to engineering design specifications, which will maximize your equipment’s performance and efficiency.
