OPERATOR'S MANUAL
MARINE RADAR
MODEL 1835
MODEL 1935
MODEL 1945
MODEL
www.furuno.co.jp
www.busse-yachtshop.de | info@busse-yachtshop.de

Advertisement

Table of Contents
loading

Related Manuals for Furuno 1835

Summary of Contents for Furuno 1835

  • Page 1 OPERATOR'S MANUAL MARINE RADAR MODEL 1835 MODEL 1935 MODEL 1945 MODEL www.furuno.co.jp www.busse-yachtshop.de | info@busse-yachtshop.de...
  • Page 2 How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery(ies), see the chapter on Maintenance. Follow the instructions below if a battery(ies) is used. In the European Union The crossed-out trash can symbol indicates that all types of batteries must not be discarded in standard trash, or at a trash site.
  • Page 3 Distance to Distance to Model 100 W/m point 10 W/m point Worst case 0.1 m 1835 Worst case 2.2 m Worst case 0.2 m 1935 Worst case 2.2 m Worst case 2.4 m 1945 Worst case 0.2 m www.busse-yachtshop.de | info@busse-yachtshop.de...
  • Page 4 SAFETY INSTRUCTIONS WARNING WARNING ELECTRICAL SHOCK HAZARD Use the correct fuse. Do not open the equipment. A wrong fuse can damage the equipment and cause fire. Only qualified persons can work inside the equipment. Keep heater away from the equipment. Turn off the power before you service the antenna unit.
  • Page 5 Transistor) LCD displays 99.999% Do not remove any label. If a label is missing or of its picture elements. damaged, contact a FURUNO agent or dealer The remaining 0.001% may drop about replacement. out or light, however this is an DISPLAY UNIT inherent property of the LCD;...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS FOREWORD........................ix SYSTEM CONFIGURATION ..................xii DESCRIPTION OF OPERATION ................1-1 1.1 Controls ........................1-1 1.2 How to Turn the Radar On/Off and Transmit..............1-2 1.3 Display Indications......................1-3 1.4 How to Adjust Display Brilliance, Panel Dimmer ............1-4 1.5 Menu Description......................1-4 1.6 Tuning.........................1-6 1.7 Display Modes ......................1-7 1.7.1...
  • Page 7 TABLE OF CONTENTS 1.24.7 How to restart, stop the trails ............... 1-33 1.24.8 Narrow trails ....................1-34 1.24.9 Your ship trail ....................1-34 1.25 How to Send the Target Position ................1-34 1.26 How to Hide the Heading Line Temporarily ............. 1-35 1.27 Presentation Brilliance .....................
  • Page 8 TABLE OF CONTENTS ARPA OPERATION ....................3-1 3.1 Precautions for Use ....................3-1 3.2 Controls for Use with ARPA ..................3-1 3.3 ARPA Display On/Off ....................3-2 3.4 How to Acquire and Track the Targets ...............3-2 3.4.1 Manual acquisition..................3-2 3.4.2 Automatic acquisition ..................3-3 3.5 How to Stop the Tracking of ARPA Target ..............3-3 3.5.1 How to stop the tracking of selected targets ..........3-3 3.5.2...
  • Page 9 TABLE OF CONTENTS 6.8 LCD Test ........................6-9 6.9 ARPA Test ....................... 6-10 6.10 GPS Test........................6-11 APPENDIX 1 MENU TREE ..................AP-1 APPENDIX 2 GEODETIC CHART LIST ..............AP-5 SPECIFICATIONS .....................SP-1 INDEX.......................... IN-1 viii www.busse-yachtshop.de | info@busse-yachtshop.de...

  • Page 10: Foreword

    A Word to the Owner of the MODEL 1835/1935/1945 Marine Radar Congratulations on your choice of the FURUNO MODEL 1835/1935/1945 Marine Radar. We are confident you will see why the FURUNO name has become synonymous with quality and reliabil- ity.
  • Page 11 FOREWORD Radar Type and Function Availability This radar series is available in four types: [River], [Sea], [IEC] and [Russian-River], and function availability depends on type. The table below shows type and function availability. [River]: For river, [Sea]: For sea, [IEC]: IEC compliant radar, [Russian-River]: For Russian river Type and function availability Type Item...
  • Page 12 FOREWORD Type Item River Russian-River Pulselength • 2NM/4KM/2SM: MP • 2NM/4KM/ • 4NM/8KM/4SM: LP 2SM: SP or • 4NM/8KM/ 4SM: MP or LP The rule for the Non-IEC system IEC system numbering of ARPA targets Marks temporary Heading line, all marks (EBL, VRM, Heading line, vector of your ship (with hidden by press- target alarm zone, etc.)

  • Page 13: System Configuration

    AIS, etc. RANGE GAIN External buzzer CUSTOM A/C SEA TRAILS Echo sounder, A/C RAIN STBY GPS navigator, ECONOMY AIS, etc. Rectifier RU-3423 Rectifier PR-62 12 - 24 VDC 100/110/220/230 VAC 100/110/115/220/230 VAC for MODEL 1835 for MODEL 1935/1945 www.busse-yachtshop.de | info@busse-yachtshop.de...

  • Page 14: Description Of Operation

    DESCRIPTION OF OPERATION Controls Display unit The display unit has 16 keys which have labels with their functions, three knob con- trols and a Cursorpad. When you correctly operate this equipment, the unit beeps one time. If your operation is wrong, the unit beeps three times. Control Description CANCEL...

  • Page 15: How To Turn The Radar On/Off And Transmit

    1. DESCRIPTION OF OPERATION How to Turn the Radar On/Off and Transmit Press the key to turn on the radar. To turn off the radar, press and hold down the key until the screen turns off. When you turn on the power, the initialization screen appears followed by the start-up screen.

  • Page 16: Display Indications

    1. DESCRIPTION OF OPERATION Display Indications Offcenter (M: Manual, A: Auto, C: Custom) Input source (shown when display Trail reference Heading unit functions as Trail time remote display) North marker 3 5 0 . 0 ° Range TRAIL(T) TUNEAUTO SLAVE H D G Tuning indicator 15 S...

  • Page 17: How To Adjust Display Brilliance, Panel Dimmer

    4. Press the CANCEL/HL OFF key to close the window. Menu Description This MODEL 1835 series has 15 menus and 6 sub menus. Below is the basic proce- dure for menu operation. 1. Press the MENU key to open the menu.
  • Page 18 1. DESCRIPTION OF OPERATION 2. Use the Cursorpad ( ) to select a menu or a sub menu. The cursor (yellow) in the Menu column indicates the menu currently selected. The menu items in the right window change according to the menu selected. Menu description [Brill/Color]: Adjust the brilliance and color.

  • Page 19: Tuning

    1. DESCRIPTION OF OPERATION Tuning In default, the radar receiver can be tuned automatically after turning the radar to TX. If you require fine tuning in manual, do the following: 1. Transmit the radar and select the maximum range with the RANGE key. 2.

  • Page 20: Display Modes

    1. DESCRIPTION OF OPERATION Display Modes This radar has the display modes shown below. All modes except head-up require a heading signal. The true motion mode additionally requires position data. Relative Motion (RM) • [Head Up] (H UP) • [Course Up] (C UP) •...

  • Page 21: Description Of Display Modes

    1. DESCRIPTION OF OPERATION the alarm message display. To stop the audio alarm, press any key. When the heading signal is restored, check the heading. To check the heading, press the F3 key. The numeric value is displayed at the heading indication when the heading signal is re- stored.

  • Page 22: True Motion Mode

    1. DESCRIPTION OF OPERATION True motion mode North marker Heading line Your ship and other objects in motion move with their true courses and speed. All fixed tar- gets, like landmasses, appear as fixed echoes in ground stabilized TM. When your ship reaches a point that is 75% of the radius of the display, the position is reset.

  • Page 23: How To Select A Range Scale

    1. DESCRIPTION OF OPERATION How to Select a Range Scale The selected range scale, range ring interval and pulselength are shown at the upper- left corner on the screen. When an objective target comes closer, reduce the range scale so that a target appears in 50-90% of the display radius. Use the RANGE key to select range.

  • Page 24: How To Reduce The Sea Clutter

    1. DESCRIPTION OF OPERATION 1.10 How to Reduce the Sea Clutter The reflected echoes from the waves appear around your ship and have the name "sea clutter". The sea clutter extends according to the height of waves and antenna above the water. When the sea clutter hides the targets, use the A/C SEA control to reduce the clutter, either manually or automatically.

  • Page 25: How To Reduce The Rain Clutter

    1. DESCRIPTION OF OPERATION 1.11 How to Reduce the Rain Clutter The reflections from the rain or snow appear on the screen. These reflections have the name "rain clutter". When the rain clutter is strong, targets in the rain clutter are hidden in the clutter.

  • Page 26: Automatic Adjustments Of Sea And Rain Clutters

    1. DESCRIPTION OF OPERATION Manual mode 1. Rotate the A/C RAIN knob to reduce the rain clutter. 2. Press the CANCEL/HL OFF key to close the window. Rain clutter at A/C RAIN control adjusted; screen center rain clutter reduced Rain clutter 1.12 Automatic Adjustments of Sea and Rain Clutters When you can not correctly reduce the sea clutter or rain clutter with related control,...

  • Page 27: Cursor

    1. DESCRIPTION OF OPERATION 1.13 Cursor The cursor functions to find the range and bearing (default function) to a target or the latitude and longitude position of a target. Use the Cursorpad to position the cursor and read the cursor data at the screen bottom. Cursor 110.1°...

  • Page 28: Interference Rejector

    1. DESCRIPTION OF OPERATION 3. Use the Cursorpad ( ) to select [Cursor Position] and press the ENTER key. Cursor Position options 4. Use the Cursorpad ( ) to select [Rng/Brg] or [Lat/Lon] then press the EN- TER key. (When the navigation data is displayed, cursor latitude and longitude po- sition cannot be displayed.) 5.

  • Page 29: How To Measure The Range To A Target

    1. DESCRIPTION OF OPERATION 1.15 How to Measure the Range to a Target You can measure the range to a target in three methods. You can use the fixed range rings, the cursor (if set to measure range and bearing), and the VRM (Variable Range Marker).

  • Page 30: How To Measure The Range With A Vrm

    1. DESCRIPTION OF OPERATION 1.15.2 How to measure the range with a VRM There are two VRMs, No. 1 and No. 2. The VRMs are dashed rings so that you can identify the rings from the fixed range rings. You can identify VRM 1 from VRM 2 by different lengths of dashes.

  • Page 31: How To Measure The Bearing To A Target

    1. DESCRIPTION OF OPERATION 3. Use the Cursorpad ( ) to select [VRM Unit] and press the ENTER key. NM: 0.1 NM or above YD: Less than 0.1 NM VRM Unit options 4. Use the Cursorpad ( ) to select the unit and press the ENTER key. 5.

  • Page 32: Ebl Reference

    1. DESCRIPTION OF OPERATION 1.16.2 EBL reference "R" (relative) follows the EBL indication if the bearing is relative to the heading of your ship. "T" (true) follows the EBL indication if the bearing is in reference to the north. You can select relative or true in the head-up and true view modes.

  • Page 33: How To Select A Pulselength

    1. DESCRIPTION OF OPERATION 7. Read the bearing and range indications at the bottom of the screen. EBL 2 EBL 1 Target B VRM 2 Target D VRM 1 Target A EBL origin Target C 4 5 . 0 ° R 0 .

  • Page 34: Target Alarm

    1. DESCRIPTION OF OPERATION 2. Use the Cursorpad ( ) to select [Echo] and press the ENTER key. Echo menu 3. Use the Cursorpad ( ) to select [Pulse Length] and press the ENTER key. Pulse Length options 4. Use the Cursorpad ( ) to select [Short] or [Long] then press the ENTER key.

  • Page 35: How To Set A Target Alarm Zone

    1. DESCRIPTION OF OPERATION 1.19.1 How to set a target alarm zone The following procedure shows you how to set a target alarm zone. 1. Press the TARGET ALARM key to activate ALARM 1 or ALARM 2. Press the TARGET ALARM key to change the active ALARM between No. 1 and No. 2. The indication of the currently active ALARM is in a rectangle at the upper-right corner of the screen.

  • Page 36: How To Select The Alarm Type

    1. DESCRIPTION OF OPERATION 1.19.3 How to select the alarm type You can set the target alarm to activate against targets entering or exiting the alarm zone. “In” target alarm “Out” target alarm In and Out target alarms 1. Press the MENU key to open the menu. 2.

  • Page 37: How To Deactivate A Target Alarm

    1. DESCRIPTION OF OPERATION 2. Press the CANCEL/HL OFF key. The alarm indication now shows "ALM1(or 2)_ACK". To activate a sleeping target alarm zone, press the TARGET ALARM key to select the ALARM 1 or ALARM 2 and press the ENTER key. The alarm indication then changes to "ALM1(or 2)_IN(or OUT)".

  • Page 38: How To Off-Center The Display

    1. DESCRIPTION OF OPERATION 1.20 How to Off-center the Display You can off-center your ship position to expand the view field without selecting a larger range scale. The display can be off-centered manually, or automatically according to speed of the ship. Note: Off-centering is not available in the true motion mode.
  • Page 39 1. DESCRIPTION OF OPERATION Custom (Indication: "OFFCENT(C)") You can move your ship position to the position which you pre-set. Follow the proce- dure shown below to register the cursor position. 1. Press the OFF CENTER key several times until the off-center indication disap- pears.

  • Page 40: Zoom

    1. DESCRIPTION OF OPERATION 1.21 Zoom The zoom function expands the length and width of a selected target as much as twice its normal size, in the zoom window. You select the target to zoom with the zoom cur- sor. The selected target is zoomed in the zoom window. ARPA and AIS symbols can be displayed in the zoom window, but are not zoomed.
  • Page 41 1. DESCRIPTION OF OPERATION Target zoom mode The ARPA or AIS target as below can be displayed in the zoom window: ARPA: The symbol is enlarged twice its normal size. AIS: The symbol is enclosed in a broken square. (The symbol is not enlarged.) The zoom cursor moves with the ARPA or AIS target.

  • Page 42: Echo Stretch

    1. DESCRIPTION OF OPERATION 1.22 Echo Stretch The echo stretch feature enlarges the targets in the range and bearing directions to make the targets easier to see. This feature is available on any range. There are three levels of echo stretch, [1], [2] and [3]. [3] enlarges the targets the most. Note: The echo stretch magnifies the targets, sea and rain clutters, and radar interfer- ence.

  • Page 43: Target Trails

    1. DESCRIPTION OF OPERATION 4. Use the Cursorpad ( ) to select an echo averaging option and press the EN- TER key. [Off]: Deactivate the echo average. [1]: Identify true targets from the sea clutter and reduce the brilliance of unstable echoes.

  • Page 44: How To Start, Stop The Trails

    1. DESCRIPTION OF OPERATION 1.24.2 How to start, stop the trails 1. Press the TRAILS key to start the trails and select the trail time. The selected time with the trail mode is shown at the upper-right corner as in the figure shown below. The available trail time with the TRAILS key changes according to trail times, which you turn on in section 1.24.1.

  • Page 45: Trail Gradation

    1. DESCRIPTION OF OPERATION 3. Use the Cursorpad ( ) to select [Mode] and press the ENTER key. Mode options 4. Use the Cursorpad ( ) to select [Relative] or [True] then press the ENTER key. 5. Press the MENU key to close the menu. 1.24.4 Trail gradation Trails can be shown in single or multiple gradation.

  • Page 46: Trail Level

    1. DESCRIPTION OF OPERATION 1.24.6 Trail level You can select which target strength to display. 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [Target Trails] and press the ENTER key. 3. Use the Cursorpad ( ) to select [Level] and press the ENTER key.

  • Page 47: Narrow Trails

    1. DESCRIPTION OF OPERATION Note: If the newly selected range is less than or equal to 1/4 of the previous range, trails are erased. If the newly selected range is longer than the previous range, the previous trails are left to be displayed. 5.

  • Page 48: How To Hide The Heading Line Temporarily

    1. DESCRIPTION OF OPERATION 1.26 How to Hide the Heading Line Temporarily The heading line indicates the heading of your ship in all display modes. The heading line is a line from your ship position to the outer edge of the radar display area. The heading line appears at zero degrees on the bearing scale in head-up and true view modes.

  • Page 49: Description Of Custom Setup Items

    1. DESCRIPTION OF OPERATION 1.28.2 Description of custom setup items Description of custom setup items Menu item Available settings See section [Custom1(2 or 3)] Turn on/off each custom program. [Copy] Copy settings from the [Echo] menu. The message "Com- plete" appears after the copying is completed. [Gain Mode] [Auto]: Automatic gain adjustment according to noise level [Manual]: Manual gain adjustment...

  • Page 50: How To Set Custom Setups

    1. DESCRIPTION OF OPERATION 1.28.3 How to set custom setups 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [Custom 1 (2 or 3)] and press the ENTER key. Custom menu 3. Set menu items. Note: For easy set up, you can copy the settings of the [Echo] menu (to [Custom 1], [Custom 2], [Custom 3]).

  • Page 51: Noise Rejector

    1. DESCRIPTION OF OPERATION 4. Use the Cursorpad ( ) to select a function from the list and press the EN- TER key. Below are the available functions. Rings Brill Echo Stretch WPT Mark Mark Brill Echo Average EBL Reference HL Brill Noise Rejector VRM Unit...

  • Page 52: Wiper

    1. DESCRIPTION OF OPERATION 1.31 Wiper The wiper feature automatically reduces the brilliance of unwanted weak signals (noise, sea clutter, rain clutter, etc.) and unnecessary signals, like radar interference, to clear the picture of unnecessary echoes. The result of wiper depends on the wiper setting used and whether echo averaging is turned on or off, as described below.

  • Page 53: Watchman

    1. DESCRIPTION OF OPERATION 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [Echo] and press the ENTER key. 3. Use the Cursorpad ( ) to select [2nd Echo Rejector] and press the ENTER key.

  • Page 54: Color Selections

    1. DESCRIPTION OF OPERATION 1.34 Color Selections 1.34.1 Preset colors This radar is preset with color combinations that provide best viewing in daytime, nighttime and twilight. Below are the default color settings for each display item and display color setting. Display item, color design and color DIsplay item Night...
  • Page 55 1. DESCRIPTION OF OPERATION 5. Use the Cursorpad ( ) to select [Background Color] and press the ENTER key. Black DK Blue Blue White Background Color options 6. Use the Cursorpad ( ) to select a background color and press the ENTER key.

  • Page 56: Navigation Data

    1. DESCRIPTION OF OPERATION 1.35 Navigation Data 1.35.1 Navigation data during standby The navigation data is shown in standby when [STBY Display] on the [Display] menu is set to [Nav]. Appropriate sensors are required to display the data. Standby indication Speed Trip Depth...

  • Page 57: Dynamic Range

    1. DESCRIPTION OF OPERATION To show or hide the navigation data at the bottom of the screen, do the following: 1. Press the MENU key to open the menu. ) to select [Display] and press the ENTER key. 2. Use the Cursorpad ( ) to select [Data Box] and press the ENTER key.

  • Page 58: Characteristics Curve

    1. DESCRIPTION OF OPERATION 1.37 Characteristics Curve You can change the characteristics curve to reduce unwanted weak echoes (sea re- flections, etc.). Select [1], [2] or [3] depending on conditions when unwanted weak echoes hide wanted targets. 1. Press the MENU key to open the menu. ) to select [Echo] and press the ENTER key.

  • Page 59: Waypoint Marker

    1. DESCRIPTION OF OPERATION 1.38 Waypoint Marker The waypoint marker shows the location of the destination waypoint set on a naviga- tion plotter. The heading signal or course data are required. You can turn on/off the waypoint marker as follows: Waypoint marker Waypoint marker...
  • Page 60 1. DESCRIPTION OF OPERATION 3. Use the Cursorpad ( ) to select [Alarm Status] and press the ENTER key. TRIGGER HEADING BEARING GYRO VIDEO POSITION NMEA_HDG IN OUT IN OUT COLLISION LOST PROXIMITY COLLISION PROXIMITY TX ANT CH1 CH2 CH70 FAIL MKD EPFS L/L SOG COG HDG ROT OVER_TEMP Alarm Status display...

  • Page 61: Echo Area

    1. DESCRIPTION OF OPERATION Alarm category Meaning AIS SYSTEM* TX stopped or TX error Antenna VSWR problem TDM2 RX1 board problem TDM2 RX2 board problem CH70 RX channel 70 problem FAIL System failure Minimum input device lost EPFS Navigator (GPS, etc.) problem Position data lost Speed data lost Course data lost...

  • Page 62: Initial Sub Menu

    1. DESCRIPTION OF OPERATION ) to select [Echo Area] and press the ENTER key. 3. Use the Cursorpad ( Echo Area options ) to select [Normal] or [Full Screen] then press the EN- 4. Use the Cursorpad ( TER key. 5.
  • Page 63 1. DESCRIPTION OF OPERATION NM (nautical miles) KM (kilometers) SM (statute miles) Available ranges for MODEL 1835 NM (nautical miles) KM (kilometers) SM (statute miles) Available ranges for MODEL 1935 NM (nautical miles) KM (kilometers) SM (statute miles) Available ranges for MODEL 1945 1-50 www.busse-yachtshop.de | info@busse-yachtshop.de...

  • Page 64: Units Sub Menu

    1. DESCRIPTION OF OPERATION [Wind Direction]: Wind direction is shown as [Apparent] or [True]. [NMEA Port 1]: Set the baud rate of the equipment connected to Port 1 ([Auto], [4800], or [38400] (bps)). [Auto] provides automatic detection of baud rate from 4800, 9600, 19200 or 38400 (bps).

  • Page 65: Sector Blank

    1. DESCRIPTION OF OPERATION 1.43 Sector Blank You must prevent the transmission in some areas to protect passengers and crew from microwave radiation. Also, if the reflections of echoes from the mast appear on the screen, you must prevent the transmission in that area. You can set two sectors. 1.

  • Page 66: Other Menu Items

    1. DESCRIPTION OF OPERATION Area of no End bearing transmission Start bearing of sector of sector Sector blank 1.44 Other Menu Items This section describes the menu items not previously described. 1.44.1 Menu items on the [Brill/Color] menu [View Position]: You can select the angle from where you see the screen. View Position options [Echo Color Mode]: You can select the color palette from [System] or [Custom].
  • Page 67 1. DESCRIPTION OF OPERATION [Custom Echo Color]: You can customize the echo color with the following two meth- ods. This function is not available in the [IEC] or [Russian-River] mode. Custom Echo Color setting window Method 1: 1) Select the echo rank to change on the [Rank] (setting range: 1 - 31). 2) Set the RGB values for selected echo rank on the [Red], [Green] and [Blue] (setting range: 0 - 63).

  • Page 68: Menu Items On The [Display] Menu

    1. DESCRIPTION OF OPERATION 1.44.2 Menu items on the [Display] menu [Base Text Display]: You can select on/off for the text indications of the following items on the display. The settings on this function are used when you set [Echo Area] to [Full Screen] on the [Display] menu.

  • Page 69: Menu Items On The [Echo] Menu

    1. DESCRIPTION OF OPERATION 1.44.3 Menu items on the [Echo] menu [Color Erase]: Erase the lower echo color whose level is set here. Set a large value to display only the stronger echoes. Color Erase setting window 1.45 Remote Display You can use this radar as a remote display when you set [Input Source] to [Slave] on the [Installation] sub menu.
  • Page 70 1. DESCRIPTION OF OPERATION Items unavailable with Function key F1, F2 and F3 • [Pulse Length] ([Echo] menu) • [2nd Echo Rejector] ([Echo] menu) • [Watchman] ([Alarm] menu) • [Tuning Mode] ([Tuning] menu) Total TX time indication The total TX time (TX TIME XXXXXX.XH) does not appear on the diagnostic test or on the Normal standby display.
  • Page 71 1. DESCRIPTION OF OPERATION This page is intentionally left blank. 1-58 www.busse-yachtshop.de | info@busse-yachtshop.de...

  • Page 72: Description Of Radar

    The minimum range depends on the pulselength, antenna height, and signal process- ing (like main bang suppression and digital quantization). Use a shorter range scale as far as it gives favorable definition or clarity of picture. This MODEL 1835 series meets the requirements of IEC 62252 5.14.1 (Class A).

  • Page 73: Radar Resolution

    2. DESCRIPTION OF RADAR 2.1.2 Radar resolution The bearing resolution and range resolution are important in radar resolution. Bearing resolution The bearing resolution is the ability of the radar to display the echoes received from two targets at the same range as the separate echoes. The bearing resolution is pro- portional to the antenna length and the wavelength.

  • Page 74: Bearing Accuracy

    2. DESCRIPTION OF RADAR 2.1.3 Bearing accuracy One of the most important features of the radar is how accurately the bearing of a tar- get can be measured. The accuracy of bearing measurement depends on the narrow- ness of the radar beam. The bearing is taken relative to the heading of the ship. Correct adjustment of the heading line at installation is important to get accurate bear- ings.

  • Page 75: Sidelobe Echoes

    2. DESCRIPTION OF RADAR 2.2.2 Sidelobe echoes When the radar pulse is transmitted, some radiation escapes on each side of the beam, called "sidelobes”. If a target is where a target can be detected by the sidelobes as well as the mainlobe, the side echoes can be shown on both sides of the true echo at the same range.

  • Page 76: Shadow Sector

    2. DESCRIPTION OF RADAR 2.2.4 Shadow sector Funnels, stacks, masts, or derricks near the antenna interrupt the radar beam, and a non-detecting sector can occur. Targets can not be detected within this sector. Wharf and its echo Radar position Wharf and its echo Radar position Shadow sector Shadow sector occurs...

  • Page 77: Sart (Search And Rescue Transponder)

    2. DESCRIPTION OF RADAR SART (Search and Rescue Transponder) 2.3.1 SART description When any X-band radar reaches within a range of approximately 8 nm, a Search and Rescue Transponder (SART) sends a response to the radar signal. The transmitter signal of response is 12-sweeps signal between 9,500 MHz to 9,200 MHz. The time of slow sweep signal is 7.5 μs and the time of fast sweep signal is 0.4 μs.

  • Page 78: General Remarks On Receiving Sart

    2. DESCRIPTION OF RADAR 2.3.2 General remarks on receiving SART SART range errors When the SART is at a range greater than approximately 1 nm, the first dot is dis- played at 0.64 nm beyond the true position of the SART. When the range closes so that the fast sweep responses are seen also, the first range echoes are displayed at 150 m beyond the true position.

  • Page 79: Racon

    2. DESCRIPTION OF RADAR RACON A RACON is a radar beacon which emits radar-receivable signals in the radar frequen- cy spectrum (X- or S-band). There are several signal formats; in general, the RACON signal appears on the radar screen as a rectangular echo originating at a point just beyond the position of the radar beacon.

  • Page 80: Arpa Operation

    ARPA OPERATION The Automatic Radar Plotter ARP-11 (option) manually or automatically acquires and tracks ten targets. Once a target is acquired automatically or manually, a target is au- tomatically tracked within 0.1 to 16 nm. Precautions for Use CAUTION CAUTION CAUTION CAUTION Do not depend on one navigation device...

  • Page 81: Arpa Display On/Off

    3. ARPA OPERATION ARPA Display On/Off You can turn the ARPA display on or off. The system continuously tracks ARPA tar- gets regardless of this setting. 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [ARPA] and press the ENTER key.

  • Page 82: Automatic Acquisition

    3. ARPA OPERATION 3.4.2 Automatic acquisition When you set an automatic acquisition area, the ARPA can acquire up to five targets automatically. The automatic acquisition area is 2.0 to 2.5 nm in range and ±45° on either side of the heading line in bearing.

  • Page 83: Vector Attributes

    3. ARPA OPERATION 3. Use the Cursorpad ( ) to select [All Cancel] and press the ENTER key. All Cancel options 4. Use the Cursorpad ( ) to select [Yes] and press the ENTER key. All symbols are erased from the screen and the long beep sounds. 5.

  • Page 84: Vector Of Your Ship

    3. ARPA OPERATION 3. Use the Cursorpad ( ) to select [Vector Time] and press the ENTER key. Vector Time setting window 4. Use the Cursorpad ( ) to select time and press the ENTER key. 5. Use the Cursorpad ( ) to select [Vector Reference] and press the ENTER key.

  • Page 85: History Display (Target Past Position)

    3. ARPA OPERATION Vector of your ship Cursor Data box History Display (target past position) This radar can display time-spaced dots (maximum ten dots) that mark the past posi- tions of any tracked ARPA target. You can evaluate actions of a target by the spacing between dots.

  • Page 86: Arpa Target Data

    3. ARPA OPERATION 6. Use the Cursorpad ( ) to select [History Interval] and press the ENTER key. History Interval options 7. Use the Cursorpad ( ) to select the time interval and press the ENTER key. 8. Press the MENU key to close the menu. ARPA Target Data You can show the data for a tracked ARPA target in the data box at the bottom of the screen.

  • Page 87: Cpa/Tcpa Alarm

    3. ARPA OPERATION CPA/TCPA Alarm Set CPA (Closest Point of Approach) alarm range and TCPA (predicted Time to CPA) alarm time to alert you to targets that can be on a collision course. When CPA and TCPA of any ARPA target become less than the preset CPA and TCPA alarm settings, the audio alarm sounds.

  • Page 88: Proximity Alarm

    3. ARPA OPERATION 5. Use the Cursorpad ( ) to select [TCPA] and press the ENTER key. TCPA options 6. Use the Cursorpad ( ) to select TCPA and press the ENTER key. 7. Press the MENU key to close the menu. 3.10 Proximity Alarm The proximity alarm alerts you when an ARPA target is within the range you set.

  • Page 89: Lost Target

    3. ARPA OPERATION 3.11 Lost Target When the system detects a lost target, the audio alarm sounds and the alarm mes- sage "LOST" appears. The target symbol becomes a flashing square like the following illustration. When the system detects the target again, the target symbol becomes a normal symbol.

  • Page 90: Ais Operation

    AIS OPERATION Connected to the FURUNO AIS Transponders FA-150, FA-100, FA-50 or the AIS Re- ceiver FA-30, the MODEL 1835 series can show the name, position and other naviga- tion data of the nearest 100 AIS transponder-equipped ships. This radar accepts position data fixed by WGS-84 geodetic datum. Set the datum to WGS-84 on the GPS navigator connected to this radar.

  • Page 91: Ais Symbols

    4. AIS OPERATION 3. Use the Cursorpad ( ) to select [Display] and press the ENTER key. AIS-Display options 4. Use the Cursorpad ( ) to select [Off] or [On] then press the ENTER key. 5. Press the MENU key to close the menu. AIS Symbols When the AIS is turned on, AIS targets are displayed with AIS symbol as below.

  • Page 92: Ais Target Data

    4. AIS OPERATION When there are many activated targets on the screen, you can not easily distinguish the activated targets from the radar images or ARPA targets. You can sleep an acti- vated target for easy view of radar images. Sleeping target To activate a target: Put the cursor on the target and press the ENTER key.

  • Page 93: How To Sort Targets

    You can set the AIS system to show only those AIS targets within the range you set. The setting range is 0.1-36 nm for MODEL 1835, 0.1-48 nm for MODEL 1935, 0.1-64 nm for MODEL 1945. Actual range depends on the AIS Transponder. If the target sort- ing method is selected to [Range], the target data within the range set here is trans- mitted to this radar.

  • Page 94: How To Display The Targets Within A Specific Sector

    4. AIS OPERATION How to Display the Targets within a Specific Sec- You can display AIS targets only within a specific sector. If the target sorting method is selected to [Sector], the target data within the sector set here is transmitted to this radar.

  • Page 95: Vector Attributes

    4. AIS OPERATION 4. Use the Cursorpad ( ) to select the number of targets to display and press the ENTER key. 5. Press the MENU key to close the menu. 4.10 Vector Attributes 4.10.1 What is a vector? A vector is a line extending from a tracked target. A vector shows speed and course of the target.

  • Page 96: History Display (Target Past Position)

    4. AIS OPERATION 4.11 History Display (target past position) This radar can display time-spaced dots (maximum ten dots) that marks the past po- sitions of any tracked AIS target. You can evaluate actions of a target by the spacing between dots. Below are examples of dot spacing and target movement. (a) Ship turning (b) Ship running (d) Ship increased...

  • Page 97: Cpa/Tcpa Alarm

    4. AIS OPERATION 4.12 CPA/TCPA Alarm Set CPA (Closest Point of Approach) alarm range and TCPA (predicted Time to CPA) alarm time to alert you to targets that can be on a collision course. When CPA and TCPA of any AIS target (including a sleeping target) become less than the preset CPA and TCPA alarm settings, the audio alarm sounds.

  • Page 98: Proximity Alarm

    4. AIS OPERATION 4.13 Proximity Alarm The proximity alarm alerts you when an AIS target is within the range you set. The au- dio alarm sounds and the alarm message "PROXIMITY" appears. The target symbol changes to a dangerous target symbol (red) and flashes with its vector. Press any key to stop the audio alarm and flashing.

  • Page 99: Symbol Color

    4. AIS OPERATION 4. Use the Cursorpad ( ) to select [Yes] and press the ENTER key. All lost targets symbols are erased from the screen and the long beep sounds. 5. Press the MENU key to close the menu. 4.15 Symbol Color You can select the AIS symbol color among Green, Red (unavailable in the [IEC] or...

  • Page 100: Gps Operation

    GPS OPERATION If the FURUNO GPS Navigator GP-320B is connected to this radar, you can set GP- 320B from this radar. Navigator Mode 1. Press the MENU key to open the menu. ) to select [GPS] and press the ENTER key.

  • Page 101: Waas Setup

    5. GPS OPERATION WAAS Setup Geostationary satellites, the type used with WAAS, provide more accurate position data when compared to GPS. These satellites can be tracked automatically or manu- ally. Auto tracking automatically searches for the best geostationary satellite from your current position.

  • Page 102: Satellite Monitor

    5. GPS OPERATION Satellite Monitor The Satellite Monitor provides the information about GPS and WAAS satellites. See your GPS navigator's owner's manual for detailed information. 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [GPS] and press the ENTER key. 3.

  • Page 103: Cold Start

    5. GPS OPERATION Cold Start Cold start, which clears the Almanac from the GPS receiver, can be necessary in the following conditions: • If you have turned off the power of the GPS receiver for a long time. • The ship has moved far away from the previous fixing position (e.g., more than 500 km).

  • Page 104: Maintenance, Troubleshooting

    MAINTENANCE, TROUBLE- SHOOTING This chapter has information about maintenance and troubleshooting that the user can follow to care for the equipment. WARNING ELECTRICAL SHOCK HAZARD Do not open the equipment. Only qualified personnel can work inside the equipment. Turn off the power before you service the antenna unit.

  • Page 105: Preventive Maintenance

    6. MAINTENANCE, TROUBLESHOOTING Preventive Maintenance Regular maintenance helps keep your equipment in good condition and prevents fu- ture problems. Check the items shown in the table below to help keep your equipment in good condition for years to come. Maintenance Interval Item Check point...

  • Page 106: Fuse Replacement

    Magnetron Life When the life of the magnetron is reached, the targets do not appear on the display. If long-range performance appears to have decreased, contact a FURUNO agent or dealer about replacement of the magnetron. Model Magnetron type Code No.

  • Page 107: Simple Troubleshooting

    6. MAINTENANCE, TROUBLESHOOTING Simple Troubleshooting This section provides simple troubleshooting procedures which the user can follow to restore normal operation. If you cannot restore normal operation, do not check inside the unit. Have a qualified technician check the equipment. Simple troubleshooting Problem Remedy You cannot turn on the power.

  • Page 108: Advanced-Level Troubleshooting

    6. MAINTENANCE, TROUBLESHOOTING Advanced-level Troubleshooting This section describes how to cure hardware and software troubles which the qualified service persons must do. Advanced-level troubleshooting Probable cause or Problem Remedy check points Power cannot be 1) Mains voltage/polarity 1) Correct the wiring and input turned on.
  • Page 109 6. MAINTENANCE, TROUBLESHOOTING Probable cause or Problem Remedy check points Radar is correctly 1) [2nd Echo Rejector] is [On] 1) Turn off the [2nd Echo Re- tuned but sensitivi- jector], from the [Echo] ty is poor. menu. 2) Dirt on radiator face 2) Clean radiator.

  • Page 110: Diagnostic Test

    6. MAINTENANCE, TROUBLESHOOTING Diagnostic Test The diagnostic test checks the system for correct operation. This test is for use by ser- vice technicians, but the user can do this test to provide the service technician with information. 1. Press the MENU key to open the menu. 2.
  • Page 111 6. MAINTENANCE, TROUBLESHOOTING • HEADING PULSE, BEARING PULSE: The results of the pulse input are dis- played as OK or NG. When [Antenna Rotation] is set to [Stop], or [Watchman] is set to [Off] in the STBY mode, this test is skipped and "- -" is shown for both heading and bearing.

  • Page 112: Lcd Test

    6. MAINTENANCE, TROUBLESHOOTING LCD Test 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [Tests] and press the ENTER key. 3. Use the Cursorpad ( ) to select [LCD Pattern] and press the ENTER key. MENU MENU MENU...

  • Page 113: Arpa Test

    6. MAINTENANCE, TROUBLESHOOTING ARPA Test If the optional ARPA board is installed, its program number and test results (OK or NG) are shown on the screen. [ARPA Test] menu item is inoperative with no ARPA board. The radar must be transmitting to test ARPA function. 1.

  • Page 114: Gps Test

    6. MAINTENANCE, TROUBLESHOOTING 6.10 GPS Test You can check the FURUNO GPS receiver GP-320B interfaced with this radar for cor- rect operation as follows: 1. Press the MENU key to open the menu. 2. Use the Cursorpad ( ) to select [GPS] and press the ENTER key.
  • Page 115 6. MAINTENANCE, TROUBLESHOOTING This page is intentionally left blank. 6-12 www.busse-yachtshop.de | info@busse-yachtshop.de...

  • Page 116: Appendix 1 Menu Tree

    APPENDIX 1 MENU TREE MENU key Brill/Color Echo Brill (1 - 8) Rings Brill (Off, 1, 2, 3, 4) Mark Brill (1, 2, 3, 4) HL Brill (1, 2, 3, 4) Character Brill (1, 2, 3, 4) View Position (Left, Left-Center, Center, Right-Center, Right) Display Color (Day, Night, Twilight, Custom) Echo Color (Yellow, Green, Orange, Multi) Background Color (Black, DK Blue, Blue, White)
  • Page 117 APPENDIX 1 MENU TREE (Continued from previous page) Custom1 (Off, On) Custom 1 Copy Gain Mode (Auto, Manual) Manual Gain (0 - 100) Sea Mode (Auto, Manual) Manual Sea (0 - 100) Rain Mode (Auto, Manual) Auto Rain (Calm, Moderate, Rough) Manual Rain (0 - 100) A/C Auto (Off, On) Pulse Length (Short, Long)
  • Page 118 Color (Green, Red, Blue, White, Black) Number of Targets (10 - 100) Sort By (Range, Sector, CPA, TCPA) Range (0.1NM - 36.0NM*) *: 36.0NM for MODEL 1835 Sector Start (0° - 359°) 48.0NM for MODEL 1935 Sector End (0° - 359°) 64.0NM for MODEL 1945...
  • Page 119 APPENDIX 1 MENU TREE (Continued from previous page) Key Beep (Off, On) System Initial Offcenter Speed (1kn - 99kn) Compass Type (Magnetic, True) Range Preset Wind Direction (Apparent, True) NMEA Port 1 (Auto, 4800bps, 38400bps) NMEA Port 2 (Auto, 4800bps, 38400bps) NMEA Mixing Out (Off, On) Self Test Tests...

  • Page 120: Appendix 2 Geodetic Chart List

    APPENDIX 2 GEODETIC CHART LIST 001: WGS84 091: NORTH AMERICAN 1927BH : Bahamas (excl. San Salvador Is.) 002: WGS72 092: NORTH AMERICAN 1927SS : Bahamas, San Salvador Is. Mean Value (Japan, Korea & Okinawa) 003: TOKYO 093: NORTH AMERICAN 1927CN : Canada (incl.
  • Page 121 APPENDIX 2 GEODETIC CHART LIST : Tanzania : Con Son Is. (Vietnam) 176: 221: INDIAN 1960 ARS-B : Thailand : Ascension Is. 222: INDIAN 1975 177: ASCENSION IS. 1958 Indonesia 223: INDONESIAN 1974 : Mean Value (Florida & Bahama Is.) 178: CAPE CANAVERAL 224: CO-ORDINATE SYSTEM 1937 OF ESTONIA : Estonia : Easter Is.

  • Page 122: Specifications

    MODEL 1945: Within ±20° of main lobe: -24dB Outside ±20° of main lobe: -30dB Polarization Horizontal Antenna rotation speed MODEL 1835: 24 rpm, MODEL 1935/1945: 24 rpm/48 rpm Wind resistance MODEL 1935/1945: Relative wind speed 100 kn for 24 rpm/ 70 kn for 48 rpm...
  • Page 123 FURUNO MODEL 1835/1935/1945 TRANSCEIVER MODULE (CONTAINED IN ANTENNA UNIT) Radiation type Frequency 9410 MHz±30MHz Peak output power MODEL 1835/1935: 4 kW, MODEL 1945: 6 kW Duplexer Circulator with diode limiter Modulator switching IF amplifier Log-amplifier IF frequency 60 MHz Tuning...
  • Page 124 Antenna unit N9.5 Display unit N2.5 COMPASS SAFE DISTANCE Antenna unit Standard: MODEL 1835: 0.90 m, MODEL 1935/1945: 1.00 m Steering: MODEL 1835: 0.70 m, MODEL 1935/1945: 0.75 m Display unit Standard: 0.45 m Steering: 0.30 m E3579S01B-M SP - 3...

  • Page 125: Index

    INDEX Display mode course-up ..........1-8 A/C RAIN control........1-12 A/C SEA control ........1-11 head-up ........... 1-8 north-up ........... 1-8 true motion ..........1-9 activating targets ........4-2 true view ..........1-9 controls for ..........4-1 Dynamic range ........1-44 display on/off ...........
  • Page 126 INDEX Menu ............1-4 trail copy..........1-33 your ship trail..........1-34 MENU key ..........1-4 Multiple echoes ..........2-3 Temperature unit........1-51 Test ARPA .............6-10 Navigation data diagnostic ..........6-7 at screen bottom ........1-43 GPS............6-11 stand-by ..........1-43 LCD ............6-9 Noise rejector ...........1-38 TLL key ............1-34 North-up mode ...........1-8 TRAILS key ..........1-31 Troubleshooting OFF CENTER key ........1-25...

This manual is also suitable for:

19351945

Table of Contents
