Bose SoundTouch Service Manual page 16

Reference
Designator
C226 0.1uF, X7R, 0402, 16V, 10%
C227 0.01uF, X7R, 0402, 16V, 10%
C233 0.22uF, X5R, 0402, 10V, 10%
C300 10uF, X5R, 0603, 6.3V, 20%
C301 0.1uF, X7R, 0603, 16V, 10%
C302 10uF, X5R, 0603, 6.3V, 20%
C303 10uF, X5R, 0603, 6.3V, 20%
C304 0.1uF, X7R, 0603, 10%, 50V
C305 0.1uF, X7R, 0603, 10%, 50V
C307 470pF, X7R, 0402, 50V, 5%
C308 10uF, X5R, 0603, 6.3V, 20%
C309 470pF, X7R, 0402, 50V, 5%
C310 0.1uF, X7R, 0402, 16V, 10%
C311 1uF, X7R, 0603, 16V, 10%
C312 470pF, X7R, 0402, 50V, 5%
C314 1500pF, X7R, 0402, 16V, 10%
C315 0.1uF, X7R, 0402, 16V, 10%
C317 0.1uF, X7R, 0402, 16V, 10%
C318 1500pF, X7R, 0402, 16V, 10%
C319 22uF, X5R, 0805, 6.3V, 20%
C320 0.1uF, X7R, 0402, 16V, 10%
C321 22uF, X5R, 0805, 6.3V, 20%
C323 1500pF, X7R, 0402, 16V, 10%
C324 0.1uF, X7R, 0402, 16V, 10%
C326 1500pF, X7R, 0402, 16V, 10%
C328 1500pF, X7R, 0402, 16V, 10%
C330 1500pF, X7R, 0402, 16V, 10%
C332 1500pF, X7R, 0402, 16V, 10%
C334 1500pF, X7R, 0402, 16V, 10%
C335 0.1uF, X7R, 0402, 16V, 10%
C338 1500pF, X7R, 0402, 16V, 10%
C340 0.1uF, X7R, 0402, 16V, 10%
C341 0.1uF, X7R, 0402, 16V, 10%
C342 1500pF, X7R, 0402, 16V, 10%
C343 0.1uF, X7R, 0402, 16V, 10%
C344 1500pF, X7R, 0402, 16V, 10%
C346 0.1uF, X7R, 0402, 16V, 10%
C347 0.1uF, X7R, 0402, 16V, 10%
C348 1500pF, X7R, 0402, 16V, 10%
C349 1500pF, X7R, 0402, 16V, 10%
C352 0.1uF, X7R, 0402, 16V, 10%
C353 0.1uF, X7R, 0402, 16V, 10%
C354 1500pF, X7R, 0402, 16V, 10%
C355 1500pF, X7R, 0402, 16V, 10%
C357 0.1uF, X7R, 0402, 16V, 10%
C358 0.1uF, X7R, 0402, 16V, 10%
C359 1500pF, X7R, 0402, 16V, 10%
ELECTRICAL PART LIST
Wi-Fi Module PCB Assembly
Capacitors (continued)
Description
16
Part Number Note
293702-104
293702-103
342199-224
313766-106J
257154-104K16
313766-106J
313766-106J
191470-104
191470-104
268366-471
313766-106J
268366-471
293702-104
257154-105K16
268366-471
293702-152
293702-104
293702-104
293702-152
273592-226JM
293702-104
273592-226JM
293702-152
293702-104
293702-152
293702-152
293702-152
293702-152
293702-152
293702-104
293702-152
293702-104
293702-104
293702-152
293702-104
293702-152
293702-104
293702-104
293702-152
293702-152
293702-104
293702-104
293702-152
293702-152
293702-104
293702-104
293702-152
