PolyScience Refrigerated Recirculating Chillers Operator's Manual page 11

Model T Series Chillers
Operating Temperature
Compressor
Cooling Capacity @
Flow Rate @ 0 psi
Pump Pressure (adjustable)
Reservoir Capacity
Shipping Weight
208-230 V, 60 Hz
Volts Range
Amps
240 V, 50 Hz
Volts Range
Over Voltage
Amps
Specifications subject to change without notice.
Notes: Refer to the serial number plate on the rear of the Chiller for model and electrical data.
Cooling capacity (watts x 3.41) = BTU/hour. Performance specifications determined at ambient temperature of 20° C (68° F).
For 50Hz models, derate cooling capacity 17%.
Positive Displacement Pump Models: External pressure reducing assembly (Cat. No. 060302) steps down high outlet
pressure to 10 to 45psi.
Environmental Conditions
Model: Rfg = Refrigerating Only
Rfg / Htg = Refrigerating & Heating
Turbine Pump ("T" Series Chillers)
Rfg
-10° to 40° C
3/4 HP
20° C 2500 watts
10° C 1700 watts
0° C 760 watts
3.5 gpm / 13.2 lpm
20 to 90 psi
138 to 621 kPa
1.1 gal / 4.2 liters
197 pounds
89 kg
11.9A
11.9A
Indoor use only
Maximum Altitude:
Operating Ambient:
Relative Humidity:
Pollution Degree:
Class 1:
Class 2:
Rfg / Htg Rfg
-10° to 70° C -10° to 40° C
8525 BTU/hr 2900 watts
5797 BTU/hr 1950 watts
2591 BTU/hr 1000 watts
187 to 253V
12.2A 12.2A
198 to 264V
Category II
12.2A 12.2A
2000 meter
5° to 30° C
80% for temperatures to 30° C
2
Residential, Commercial, Light Industrial
Heavy Industrial
11
Rfg / Htg
-10° to 70° C
1 HP
9889 BTU/hr
6649 BTU/hr
3410 BTU/hr
3.5 gpm / 13.2 lpm
20 to 90 psi
138 to 621 kPa
1.1 gal / 4.2 liters
199 pounds
90 kg
12.5A
12.5A
