PolyScience Refrigerated Recirculating Chillers Operator's Manual page 10

Specifications — 3/4-HP and 1-HP Chillers
Model
Operating Temperature
Compressor
Cooling Capacity @
Pressure at 0 Flow Rate
Flow Rate at 0 psi
Reservoir Capacity
Dimensions (h x w x d)
Shipping Weight
208-230 V, 60 Hz
Volts Range
Amps
240 V, 50 Hz
Volts Range
Over Voltage
Amps
Model P Series Chillers
Operating Temperature
Compressor
Cooling Capacity @
Flow Rate @ 0 psi
Pump Pressure (adjustable)
Reservoir Capacity
Shipping Weight
208-230 V, 60 Hz
Volts Range
Amps
240 V, 50 Hz
Volts Range
Over Voltage
Amps
Model: Rfg = Refrigerating Only
Rfg / Htg = Refrigerating & Heating
Magnetic Drive Centrifugal Pump
Rfg
-10° to 40° C
3/4 HP
20° C 2500 watts
10° C 1700 watts
0° C 760 watts
10 psi / 69 kPa
4.1 gpm / 15.5 lpm
1.1 gal / 4.2 liters
187 pounds
84.8 kg
9.2A
9.2A
Positive Displacement Pump ("P" Series Chillers)
Rfg
-10° to 40° C
3/4 HP
20° C 2500 watts
10° C 1700 watts
0° C 760 watts
3.5 gpm / 13.2 lpm
20 to 100 psi
138 to 689 kPa
1.1 gal / 4.2 liters
197 pounds
89 kg
11.9A
11.9A
Rfg / Htg Rfg
-10° to 70° C -10° to 40° C
8525 BTU/hr 2900 watts
5797 BTU/hr 1950 watts
2591 BTU/hr 1000 watts
4.1 gpm / 15.5 lpm
1.1 gal / 4.2 liters
22-5/8 x 14-1/2 x 27-5/8 in.
57.6 x 36.8 x 70.2 cm
187 to 253V
9.5A 9.5A
198 to 264V
Category II
9.5A 9.5A
Rfg / Htg Rfg
-10° to 70° C -10° to 40° C
8525 BTU/hr 2900 watts
5797 BTU/hr 1950 watts
2591 BTU/hr 1000 watts
3.5 gpm / 13.2 lpm
138 to 689 kPa
1.1 gal / 4.2 liters
187 to 253V
12.2A 12.2A
198 to 264V
Category II
12.2A 12.2A
10
Rfg / Htg
-10 to 70° C
1 HP
9889 BTU/hr
6649 BTU/hr
3410 BTU/hr
10 psi / 69 kPa
189 pounds
85.7 kg
9.8A
9.8A
Rfg / Htg
-10° to 70° C
1 HP
9889 BTU/hr
6649 BTU/hr
3410 BTU/hr
20 to 100 psi
199 pounds
90 kg
12.5A
12.5A
