Ford 2012 Explorer Owner's Manual page 329

Fuse/Relay Fuse Amp
Location Rating
18 40A**
19 30A**
20 20A**
21 20A**
22 30A**
23 30A**
24 30A**
25
26 40A**
27 20A**
28 30A**
29
30
31
32
33
34
35
36
37
38
39 40A**
40
41
42 30A**
43 40A**
44
45
46
2012 Explorer (exp)
Owners Guide, 2nd Printing
USA (fus)
I n f o r ma t i o n P r o v i d e d b y :
Roadside Emergencies
Power Distribution Box
Description
Front blower motor
Starter motor
Power point #1/cigar lighter
Power point #3 (cargo area)
3rd row seat module
Driver power seat, Memory
module
Trailer tow (TT) battery charge
— Not used
Rear window defroster, Heated
mirrors
Power point (console)
Climate controlled seats
— Not used
— Not used
— Not used
— Auxiliary blower motor relay
— Not used
— Blower motor relay
— Not used
— Not used
— TT right stop/turn lamps relay
— TT back up relay
Auxiliary blower motor
— Not used
— Not used
Passenger seat
ABS valves
— Rear washer relay
5A* Rain sensor
— Not used
329
