Page 1 Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with CD AM/FM stereo with in-dash six CD AM/FM stereo cassette with CD Climate Controls Manual heating and air conditioning Automatic temperature control Auxiliary passenger climate control Rear window defroster Lights Driver Controls...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire Information Tire Inflation Changing tires Lug Nut Torque Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control/AdvanceTrac Transmission operation Roadside Emergencies...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.
Page 12 Instrument Cluster Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
Page 13 Instrument Cluster Door ajar (if equipped): Illuminates when the ignition is in DOOR the ON position and any door is AJAR open. Overdrive off: Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.
Page 14: Gauges
Instrument Cluster Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. Turn signal warning chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 1/2 mile (0.8 km).
Page 15 Instrument Cluster Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 16 Instrument Cluster • Optional instrument cluster Press and release the TRIP/RESET button to toggle between odometer and trip odometer display. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position.
Page 17 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The arrow next to the fuel pump icon indicates which side of the vehicle the fuel filler door is located.
Page 18: Entertainment Systems
Entertainment Systems AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED) 14 15 16 17 18 VOL - PUSH ON BASS TREB FADE DISC SEEK COMP TUNE SHUFFLE 1. BAL (Balance): Press to shift sound to the left/right speakers. 2. FADE: Press to shift sound to the front/rear speakers.
Page 19 Entertainment Systems To set the minute, press and hold CLK and press TUNE to decrease or increase the minutes. 5. EJ (Eject): Press to eject a CD. 6. COMP (Compression): In CD mode, press to bring louder and softer levels into more comfortable listening level.
Page 20 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed.
Page 21 TEXT: TEXT is only available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Ford dealer. Detailed Satellite instructions are included with the dealer installed kit.
Page 22 Entertainment Systems Occupancy: Press DSP again to change the occupancy mode to optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. Press SEL to scroll through settings. 4. Mute: Press to MUTE playing media; press again to return to playing media 5.
Page 23 Audiophile radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your Ford dealer. Detailed satellite instructions are included with the dealer installed kit. Dealer installed satellite kit only available in the continental United States.
Page 24 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed.
Page 25 CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Ford dealer. Detailed Satellite instructions are included with the dealer installed kit.
Page 26 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 27 Entertainment Systems CD: Press to start CD play. With the dual media audio, press CD to toggle between single CD and CD changer play (if equipped). 7. MUTE: Press to MUTE playing media; press again to return to the playing media. 8.
Page 28 Entertainment Systems 12. SHUFFLE: Works in CD mode. Press to play tracks in random order. Press again to disable. 13. COMP (Compression): Works in CD mode. Press to bring soft and loud passages together for a more consistent listening level. A small “c” will appear in the display to indicate that compression is enabled.
Page 29 Entertainment Systems 19. BASS: Press BASS; then press to decrease/increase the bass output. TREB (Treble): Press TREB; then press SEL decrease/increase the treble output. 20. TUNE: Works in radio mode SEEK only. Press TUNE TUNE change frequency down/up. 21. SEEK: Press and release SEEK for previous/next strong station, selection or track.
Page 30 Entertainment Systems SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SINGLE CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED) 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection.
Page 31 Entertainment Systems 3. AUX: This function is not operational. 4. MUTE: Press to MUTE playing media; press again to return to playing media 5. EJ: Press to eject a CD. 6. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB;...
Page 32 Entertainment Systems volume setting. The level will appear in the display. Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Setting the clock: Press MENU until SELECT HOUR or SELECT MINS is displayed.
Page 33 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 34 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 35 Entertainment Systems become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information. 2. CD Eject: Press to eject a CD. The radio will resume playing.
Page 36 Entertainment Systems Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Press MENU until SPEED VOL X appears in the display. Then press SEL to increase/decrease the volume setting. The level will appear in the display. Dolby: In tape mode, press MENU until DOLBY B XX appears in the display.
Page 37 Entertainment Systems 11. TEXT/SEL: The filename, song title, artist or album text may be viewed while playing an MP3 selection. Press TEXT to scroll through the text fields. The display will scroll through all of the text in the current field before changing to the next field.
Page 38 Entertainment Systems 17. Memory preset buttons: To set a station: Press BAND to select the frequency band (AM/FM1/FM2), tune to a station, press and hold a preset button until sound returns. 18. Scan: Press to hear a brief sampling of all listenable stations, tape selections or CD tracks.
Page 39 Entertainment Systems AUDIOPHILE SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED) 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection.
Page 40 Entertainment Systems 3. AUX: This function is not operational. 4. MUTE: Press to MUTE playing media; press again to return to playing media 5. EJ: Press to eject a CD. Press EJ and a memory preset to eject a specific disc. Press and hold to eject all loaded discs.
Page 41 Entertainment Systems Traffic: Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data). Traffic information is not available in most U.S. markets. FIND Program type: Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40.
Page 42 Entertainment Systems Folder/Track Mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE. 10. REPEAT: Repeats current CD/MP3 track when active (ON).
Page 43 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 44 Entertainment Systems FAMILY ENTERTAINMENT SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Family Entertainment System (FES). Refer to the DVD Supplement Guide for further information on your system. RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC).
Page 45 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 46: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.
Page 47 Climate Controls • To improve the A/C cool down, drive with the windows slightly open for 2–3 minutes after start up or until the vehicle has been “aired out.” For maximum cooling performance in panel ( ) mode: • Select MAX A/C mode. MAX A/C uses recirculated air with A/C to provide a cooler airflow.
Page 48: Automatic Temperature Control
Climate Controls Dual Automatic Temperature Control (DATC) system (if equipped) 16 17 DUAL AUTO 1. A/C control: Uses outside air to cool the vehicle. Press to turn on/off in all modes except 2. Recirculation control: Cools the vehicle more quickly by recirculating the cabin air instead of using outside air and helps prevent unpleasant outside odors or fumes from entering the vehicle.
Page 49 Climate Controls : Distributes outside air through the windshield defroster vents. : Distributes outside air through the windshield defroster vents and floor vents. : Distributes outside air through the floor vents. : Distributes outside air through the instrument panel vents and the floor vents.
Page 50 Climate Controls Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position. • To reduce humidity build up inside the vehicle, do not drive with the air flow selector in OFF or with recirculated air engaged. •...
Page 51 Climate Controls Auxiliary system (if equipped) Your vehicle may be equipped with auxiliary climate controls. These allow the front or rear seat passengers to control airflow direction, temperature and fan level of the rear compartment to quickly heat or cool the entire vehicle. Front auxiliary controls: 1.
Page 52 Climate Controls Rear auxiliary controls (if equipped): Once the front auxiliary control is set to REAR, the rear seat passengers may use the rear auxiliary controls in the overhead console to make the desired adjustments. 1. Temperature control: Determines temperature levels. If the main climate control system is cooling in MAX A/C or mode,...
Page 53: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the 3 (ON) position to operate the rear window defroster.
Page 54: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp system (if equipped) The autolamp system sets the headlamps to turn on and off automatically.
Page 55 Lights Daytime running lamps (DRL) (if equipped) To activate DRL: • the ignition must be in the ON position and • the headlamp control is in the position • the parking brake must be disengaged. Always remember to turn on your headlamps at dusk or during inclement weather.
Page 56 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel when exterior lights are on. • Rotate up to brighten. • Rotate down to dim. • Rotate to full up position (past detent) to turn on interior lamps. •...
Page 57 Lights 3. Turn on the low beam headlamps. The brightest part of the light should be below the horizontal line (4). If it is above the line the headlamp will need to be adjusted. 4. Open the hood. 5. Locate the vertical adjuster for each headlamp.
Page 58 Lights INTERIOR LAMPS Dome/reading lamps The dome lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated up until the courtesy lamps come on. • any of the remote entry controls are pressed and the ignition is OFF.
Page 59 Lights Replacing the interior bulbs Check the operation of the bulbs frequently. To replace any of the interior bulbs, see a dealer or qualified technician. Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E”...
Page 60 Lights Replacing headlamp bulbs Do not touch the glass of a halogen bulb. 1. Turn off the headlamps and open the hood. 2. Pry up the two retainer pins until they stop to release the headlamp assembly from the vehicle, then pull headlamp forward.
Page 61 Lights Replacing front parking lamp/turn signal/sidemarker bulbs 1. Turn off the headlamp switch to off. 2. Remove headlamp screw from the bulb assembly. 3. Disengage lamp assembly. 4. Rotate the bulb socket counterclockwise and remove it from the lamp assembly. 5.
Page 62 Lights Replacing foglamp bulbs 1. Make sure the headlamp switch is in the OFF position. 2. Remove the plastic splash shield by removing the two screws on the front of the fenderwell. 3. Remove the bulb socket from the foglamp by turning it counterclockwise.
Page 63: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the INT1 speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 64 Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 65 Driver Controls Lift the lever back to its original position to lock the steering column. Never adjust the steering column when the vehicle is moving. CENTER CONSOLE Your vehicle may be equipped with a variety of console features. These include: •...
Page 66 Driver Controls Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 67 Driver Controls Storage compartment Press the latch to open the storage compartment. Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: • Place the VELCRO hook onto the side of the aftermarket transmitter opposite of the button.
Page 68 Driver Controls Illuminated visor mirror (if equipped) Lift the mirror cover to turn on the visor mirror lamps. Slide on rod feature Rotate the visor towards the side window and extend it rearward for additional sunlight coverage. Note: To stow the visor back into the headliner, visor must be retracted before moving it back towards the windshield.
Page 69: Power Windows
Driver Controls Cigar/Cigarette lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket. Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket. The lighter will be released from its heating position when it is ready to be used.
Page 70: Mirrors
Driver Controls Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the left side of the control. Press the right side to restore the window controls. Accessory delay With accessory delay, the window switches, audio system and moon roof may be used for up to ten minutes after the ignition switch is turned to...
Page 71 Driver Controls Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. Automatic dimming rear view mirror Your vehicle may be equipped with an inside rear view mirror with an auto-dimming feature. When the auto-dimming mirror is turned on, as indicated by an illuminated green LED to the left of the button on...
Page 72: Speed Control
Driver Controls Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h).
Page 73 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h). COAST Increasing speed while using speed control There are two ways to set a higher...
Page 74 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET + control. COAST Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed.
Page 75 Driver Controls Audio control features Press to select: • AM, FM1, FM2, • TAPE (if equipped), • CD (if equipped), or • DVD (if equipped). In AM, FM1, or FM2 mode: • Press MEM to select preset stations within the selected radio band.
Page 76 Driver Controls Climate control features Press TMP + or - to adjust temperature. Press + or - to adjust fan speed. MOON ROOF (IF EQUIPPED) You can move the glass panel of the moon roof back to open or tilt up to ventilate the vehicle.
Page 77 Driver Controls To open the moon roof: The moon roof is equipped with an automatic, one-touch, express opening feature. Press and release the rear portion of the control. To stop motion at any time during the one-touch opening, press the control again.
Page 78 Driver Controls Do not use the HomeLink Wireless Control System with any garage door opener that lacks safety stop and reverse features as required by U.S. federal safety standards (this includes any garage door opener model manufactured before April 1, 1982). A garage door which cannot detect an object, signaling the door to stop and reverse, does not meet current U.S.
Page 79 Driver Controls 3. Simultaneously press and hold both the HomeLink and hand-held transmitter button. Do not release the buttons until Step 4 has been completed. Some entry gates and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator and Canadian Programming”...
Page 80 Driver Controls Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink to accept the signal from the hand-held transmitter. After completing Steps 1 and 2 outlined in the “Programming” section, replace Step 3 with the following: Note: If programming a garage door opener or gate operator, it is...
Page 81 Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
Page 82 Driver Controls Compass The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antennas. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions.
Page 83: Message Center
Driver Controls 6. Continue to press until ZONE appears in the instrument cluster display, then release. The display should show the current zone number. 7. Press until the desired zone number appears. The display will flash and then return to normal operation.
Page 84 Driver Controls Selectable features Reset Press this control to select and reset functions shown in the INFO menu and SETUP menu. Info menu This control displays the following control displays: • Odometer/Compass • Trip odometer/Odometer/Compass • Average Fuel Economy • Trip Elapsed Drive Time •...
Page 85 Driver Controls degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error. Refer to Compass zone/calibration adjustment in this section. Compass zone/calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines.
Page 86 Driver Controls 9. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CIRCLE SLOWLY TO CALIBRATE indicator changes to CALIBRATION COMPLETED. This will take up to three circles to complete calibration. 10. The compass is now calibrated. Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel...
Page 87 Driver Controls Trip elapsed drive time Select this function from the INFO menu to display a timer. To operate the Trip Elapsed Drive Time perform the following: 1. Press and release RESET in order to start the timer. 2. Press and release RESET to pause the timer. 3.
Page 88 Driver Controls Setup menu Press this control for the following displays: • Autolock • Easy Entry/Exit • Autolamp Delay • Oil Change • Language • Units (English/Metric) • System Check Autolocks 1. Select this function from the SETUP control for the current display mode.
Page 89 Driver Controls Oil Change 1. Select this function from the SETUP control for the current display mode. 2. Press the RESET control to reset oil change. Language 1. Select this function from the SETUP menu for the current language to be displayed. 2.
Page 90 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. FUEL LEVEL 2. WASHER FLUID LEVEL 3. OIL LIFE IN XX% 4. ADVTRAC 5. ENGINE TEMP 6. OIL PRESSURE 7.
Page 91 Driver Controls Warning display Status Check engine temperature Warning returns after 10 minutes Transmission overheated Check transmission Low fuel level Check fuel cap Check charging system Low brake fluid level Low oil pressure Warning-tire very low (if equipped) ETC-engine failsafe mode Check tire pressure (if equipped) Warning returns after the ignition key is turned from...
Page 92 Driver Controls LOW FUEL LEVEL. Displayed as an early reminder of a low fuel condition. CHECK FUEL CAP. Displayed when the fuel filler cap is not properly installed. Check the fuel filler cap for proper installation. Refer to Fuel filler cap in the Maintenance and Specifications chapter. ETC-ENGINE FAILSAFE MODE.
Page 93 Driver Controls LOW WASHER FLUID LEVEL. Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Windshield washer fluid in the Maintenance and Specifications chapter. CHECK ADVANCETRAC (if equipped). Displayed when the AdvanceTrac with RSC system is not operating properly.
Page 94 Driver Controls 3. Press and hold the RESET control for 2 seconds and release. Oil life is set to 100% and “OIL LIFE SET TO 100%” is displayed. After you have done steps 1 through 3, you can reset the oil monitoring system to your personalized oil life %: 4.
Page 95 Driver Controls POSITIVE RETENTION FLOOR MAT Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
Page 96 Driver Controls Make sure the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle. This will also reduce the risk of passengers and cargo falling out. CARGO COVER (IF EQUIPPED) Your vehicle may be equipped with a cargo area cover that covers the luggage compartment of your vehicle.
Page 97 Driver Controls 5 passenger stowage: When the lid is open, it will stand up on its own. 1. To open, lift the release handle and the lid. 2. To close, lower the lid, lift the release handle and press down on the lid.
Page 98: Locks And Security
Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your dealer supplied keys, replacement keys are available through your authorized dealer.
Page 99 Locks and Security Childproof door locks • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 100 Locks and Security The remote entry system allows you to lock or unlock all vehicle doors and liftgate and open the liftgate window without a key. The remote entry lock/unlock feature operates in any ignition position. The liftgate glass feature operates as long as the vehicle’s speed is less than 3 mph (5 km/h).
Page 101 Locks and Security 2. Press and release again within three seconds to confirm that all the doors are closed and locked. Note: The doors will lock again, the horn will chirp and the lamps flash once. Note: If any door, the liftgate or the liftgate glass are not closed properly, the horn will make two quick chirps.
Page 102 Locks and Security Deactivating the memory seat feature To deactivate this feature: 1. Press the SET control on the driver’s door panel. 2. Within 5 five seconds, press any control on the remote transmitter which you would like to deactivate and then press the SET control on the driver’s door panel.
Page 103 Locks and Security Note: Replacement of the battery will not cause the remote transmitter to become deprogrammed from your vehicle. The remote transmitter should operate normally after battery replacement. Replacing lost remote entry transmitters If you would like to have your remote entry transmitter reprogrammed because you lost one, or would like to buy additional remote entry transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for...
Page 104 Locks and Security Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The illuminated entry system will turn off the interior lights if: • the ignition is turned to the 3 (ON) position, or •...
Page 105: Programming Personal Entry/Erasing Personal Code
Locks and Security Programming a personal entry code To create your own personal entry code: 1. Enter the factory set code. 2. Within five seconds press the 1 • 2 on the keypad. 3. Enter your personal 5-digit code. Each number must be entered within five seconds of each other.
Page 106 Locks and Security To unlock all doors and liftgate, press the 3 • 4 control within five seconds. To open the liftgate window, press the 5 • 6 control within five seconds. To lock all doors, liftgate and liftgate window, press the 7 • 8 and the 9 •...
Page 107 Locks and Security Power door unlock/lock procedure You must complete steps 1-5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds. 1. Turn the ignition to the 3 (ON) position.
Page 108 Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 109 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the 2 (ACCESSORY) position. The theft indicator will flash every two seconds when the vehicle is armed. Automatic disarming Switching the ignition to the 3 (ON) position with a coded key disarms the vehicle.
Page 110 Locks and Security Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition. 2. Turn the ignition from the 1 (OFF/LOCK) position to the 3 (ON) position. Keep the ignition in the 3 (ON) position for at least three seconds, but no more than 10 seconds.
Page 111: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 112 Seating and Safety Restraints Push control to lower head restraint. Adjusting the front manual seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 113 Seating and Safety Restraints Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
Page 114 Seating and Safety Restraints Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Memory seat/adjustable pedals/easy entry-exit feature (if equipped) This system allows automatic positioning of the driver seat to...
Page 115 Seating and Safety Restraints • To program position three, push buttons 1 and 2 simultaneously. A position can only be set or recalled when the transmission gearshift is in P (Park) or N (Neutral). A memory seat position may be programmed at any time.
Page 116 Seating and Safety Restraints Heated seats (if equipped) To operate the heated seats: • Push control located on the seat to activate. • Push again to deactivate. The heated seat icon in the Dual Automatic Temperature Control (DATC) will illuminate when activated. REAR SEATS Folding down the 60/40 rear seats (if equipped) If the rear seat is equipped with adjustable head restraints, they should...
Page 117 Seating and Safety Restraints 1. Pull upward on the release handle to cycle the seats to the load-floor position. 2. Rotate the seatback downward into the load floor position. 3. Press down on the top outboard area of the seatback until a click is heard.
Page 118 Seating and Safety Restraints Adjusting the 2nd row recline The 2nd row reclines for additional comfort. To adjust the 2nd row recline, pull the handle forward and push the seat back rearward. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
Page 119 Seating and Safety Restraints Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
Page 120 Seating and Safety Restraints Folding the middle 2nd row seat (If equipped) To fold the seatback down: 1. Locate the lever on the top left of the seatback. 2. Pull the lever up and push the seatback toward the front of the vehicle.
Page 121 Seating and Safety Restraints Lower the head restraints before putting the seat in the stowed position. To put seat in stowed position: 1. Pull the seat release lever located on top of the seatback while pushing the seatback down onto the seat cushion.
Page 122: Safety Restraints
Seating and Safety Restraints 2. Pull the seat release lever located on top of the seatback while lifting the seatback into the upright position. 3. The seatback will latch into place. The third row seat is equipped with combination lap and shoulder belts in both seating positions.
Page 123 Seating and Safety Restraints How does the Personal Safety System work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and occupant conditions. A collection of crash and occupant sensors provides information to the Restraints Control Module (RCM).
Page 124 Seating and Safety Restraints safety belt pretensioner activation depending upon safety belt usage. Refer to Safety restraints section in this chapter. Front safety belt pretensioners The safety belt pretensioners at the front outboard seating positions are designed to tighten the safety belts firmly against the occupant’s body during frontal collisions, and in side collisions and rollovers when the vehicle is equipped with the Safety Canopy system.
Page 125 Seating and Safety Restraints Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit in the back seat where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 126 Seating and Safety Restraints Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Energy Management Feature •...
Page 127 Seating and Safety Restraints • Front and rear seats All safety restraints in the vehicle are combination lap and shoulder belts. All of the passenger combination lap and shoulder belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 128 Seating and Safety Restraints How to use the automatic locking mode • Buckle the combination lap and shoulder belt. • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 129 Seating and Safety Restraints After any vehicle collision, the combination lap and shoulder belt system at all passenger seating positions must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly, in addition to other checks for proper safety belt system function.
Page 130 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments for the front and second row outboard seating positions. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, squeeze the button and slide the height adjuster up or down.
Page 131 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds.
Page 132 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare 36700 crashes occur every day. The more we events” drive, the more we are exposed to “rare” events, even for good drivers.
Page 133 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the BeltMinder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the BeltMinder feature please follow the directions stated below.
Page 134 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 135: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
Page 136 Do not attempt to service, repair, or modify the airbag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame,...
Page 137 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 138 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 139 Seating and Safety Restraints • diagnostic module. • and the electrical wiring which connects the components. The diagnostic module monitors its own internal circuits and the supplemental airbag electrical system wiring (including the impact sensors), the system wiring, the airbag system readiness light, the airbag back up power and the airbag ignitors.
Page 140 Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 141 Seating and Safety Restraints How does the Safety Canopy system work? The design and development of the Safety Canopy system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 142 Seating and Safety Restraints The Safety Canopy is mounted to the roof side-rail sheet metal, behind the headliner, above the first and second row seats. In certain lateral collisions or rollover events, the Safety Canopy system will be activated, regardless of which seats are occupied. The Safety Canopy designed to inflate between the side window area and occupants to further enhance protection provided in side impact collisions and rollover events.
Page 143: Child Restraints
Seating and Safety Restraints • The readiness light (same light as for front airbag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired.
Page 144 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 145 Seating and Safety Restraints • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? • Does the lap belt rest low across the hips? •...
Page 146 Seating and Safety Restraints The shoulder belt should cross the chest, resting snugly on the center of the shoulder. The lap belt should rest low and snug across the hips, never up high across the stomach. If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition.
Page 147 80 lb. (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 148 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 149 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 150 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 151 Seating and Safety Restraints The rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as shown below. The tether strap anchors in your vehicle are in the following positions (shown from top view): •...
Page 152 Seating and Safety Restraints • Behind 2nd row seat • At the rear of the cargo area 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 153 Seating and Safety Restraints 4. Clip the tether strap to the anchor. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Install the child safety seat tightly using the LATCH anchors or safety belts.
Page 154 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol: Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 155 Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln/Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 156: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 157 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter.
Page 158 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 159 Tires, Wheels and Loading government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices, and differences in road characteristics and climate.
Page 160 Tires, Wheels and Loading • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture. • Inflation pressure: A measure of the amount of air in a tire. •...
Page 161 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
Page 162 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label which is located on the B-Pillar or the edge of the driver’s door.
Page 163 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford Motor Company. Use of any tire or wheel not recommended by Ford Motor Company can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 164: Changing Tires
Tires, Wheels and Loading The installation of replacement tires with steel cord body plies in the tire sidewall may cause malfunction of the Tire Pressure Monitoring System (TPMS), and is not recommended (cord material information is molded on the tire sidewall). Additionally, if your vehicle was originally equipped with run-flat tires, replacing them with tires that are not identical to those originally fitted may cause malfunction of the TPMS, and is not recommended.
Page 165 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 166 Tires, Wheels and Loading When driving with the dissimilar spare tire/wheel additional caution should be given to: • Towing a trailer • Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a dissimilar spare tire/wheel and seek service as soon as possible.
Page 167 Tires, Wheels and Loading Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Tool Location Spare tire Under the vehicle, just in front of the rear bumper. The spare tire winch drive nut is located at the rear center of the cargo area under a lid.
Page 168 Tires, Wheels and Loading Rotate the wrench socket out from the handle. Removing the spare tire Do not use an impact wrench on the winch drive nut. This will damage the spare tire winch. 1. Open the cover from the carpeting on cargo floor to expose the winch drive nut.
Page 169 Tires, Wheels and Loading 3. Turn the wrench counterclockwise until the tire is lowered to the ground and the cable has slack. When turning the wrench, make sure that it does not scuff the kick plate. 4. Slide the tire rearward, lift one side and remove the retainer from the spare tire.
Page 170 Tires, Wheels and Loading 3. Assemble the jack handle extension on the lug nut wrench by sliding the square end of the jack handle through the plastic grommet on the lug nut wrench and into the square hole on the other side. 4.
Page 171 Tires, Wheels and Loading To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 172: Lug Nut Torque
Lug nut socket size: ⁄ ” (19 mm) hex Bolt size: ⁄ x 20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 173 Tires, Wheels and Loading When a wheel is installed, always remove any corrosion, dirt and foreign materials present on the mounting surfaces of the wheel and the surface of the front disc brake hub and rotor that contacts the wheel. Installing wheels without correct metal-to-metal contact at the wheel mounting surfaces can cause the wheel nuts to loosen and the wheel to come off while the vehicle is in motion, resulting in loss of control.
Page 174 Tires, Wheels and Loading 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6.
Page 175 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 176 Tires, Wheels and Loading Label which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the vehicle label. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc.
Page 177 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 178 Tires, Wheels and Loading TIRE CARE Improper or inadequate vehicle maintenance can also cause tires to wear abnormally. Here are some of the important maintenance items: Tire wear Measure and inspect the tire tread on all your tires periodically. Advanced and unusual tire wear can reduce the ability of tread to grip the road in adverse (wet, snowy, etc.) conditions.
Page 179 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln Mercury dealer check the wheel alignment periodically.
Page 180 Tires, Wheels and Loading The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life.
Page 181 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 182: Tire Information
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS)(IF EQUIPPED) When the Tire Pressure Monitoring System warning light is lit, one or more of your tires is significantly under-inflated. You should stop and check your tires as soon as possible, and inflate them to the proper pressure as indicated on the vehicle’s tire information placard (label).
Page 183 Tires, Wheels and Loading The tire pressure should be checked periodically (at least monthly) using an accurate tire gauge, refer to Inspecting and inflating your tires in this chapter. Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle every minute while you are driving and once an hour when your vehicle is parked.
Page 184 Solid Warning Light 1. Check your tire pressure to ensure they are properly inflated, refer to Inspecting and inflating your tires in this chapter. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge for increased accuracy.
Page 185: Tire Inflation
Tires, Wheels and Loading therefore it may take up to a minute for the light to turn off after you have filled your tires to the recommended tire pressure. • If your vehicle has been parked for over 15 minutes, the sensors go into a low power mode to conserve battery life and therefore only transmit about once an hour.
Page 186: Vehicle Loading
The tires on your vehicle have all-weather treads to provide traction in rain and snow. However, in some climates, using snow tires or traction devices may be necessary. Ford offers tire cables as a Ford approved accessory and recommends use of these or SAE class “S” tire cables. See your dealer or qualified service technician for more information on tire cables for your vehicle.
Page 187 Tires, Wheels and Loading capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Safety Compliance Certification Label: Base Curb Weight –...
Page 188 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 189 Tires, Wheels and Loading GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
Page 190 Tires, Wheels and Loading GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
Page 191 Tires, Wheels and Loading mandatory options, no cargo (internal or external), a tongue load of 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (150 lb. [68 kg]). Consult your dealership (or the RV and Trailer Towing Guide provided by your dealership) for more detailed information.
Page 192 Tires, Wheels and Loading 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. The following gives you a few examples on how to calculate the available amount of cargo and luggage load capacity: •...
Page 193: Trailer Towing
Tires, Wheels and Loading Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in the Driving chapter of this Owner’s Guide. Loaded vehicles may handle differently than unloaded vehicles.
Page 194 Tires, Wheels and Loading • Do not tow a trailer until your vehicle has been driven at least 500 miles (800 km). • Refer to the instructions included with towing accessories for the proper installation and adjustment specifications. Do not exceed the maximum loads listed on the Safety Compliance Certification label.
Page 195 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weight Engine Rear axle Maximum Trailer weight ratio GCWR-lb. range-lb. (kg) (kg) (0-Maximum) Notes: - For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) elevation. For definitions of terms used in this table and instructions on how to calculate your vehicle load, refer to Vehicle loading in this chapter.
Page 196 Tires, Wheels and Loading 4x4/AWD Notes: - For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) elevation. For definitions of terms used in this table and instructions on how to calculate your vehicle load, refer to Vehicle loading in this chapter.
Page 197 Never connect any trailer lighting to the vehicle’s taillamp circuits, because it may damage the electrical system resulting in fire. Contact your local Ford dealership for assistance in proper trailer tow wiring installation. Additional electrical equipment may be required.
Page 198: Recreational Towing
Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 199 • Maximum distance is 50 miles (80 km). If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 200: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, shuts off the engine and all accessories/locks the steering wheel, gearshift lever and allows key removal. 2. ACC, allows the electrical accessories such as the radio to operate while the engine is not running.
Page 201 Driving • Make sure the gearshift is in P (Park). 3. Turn the key to 3 (ON) without turning the key to 4 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. •...
Page 202 Driving Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. This condition may occur when: •...
Page 203: Brakes
Driving If the engine fails to start using the preceding instructions (flexible fuel vehicles only) 1. Press and hold down the accelerator 1/3 to 1/2 way to floor, then crank the engine. 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up.
Page 204 Driving Refer to Brake system warning light in the Instrument Cluster chapter for information on the brake BRAKE system warning light. Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking.
Page 205 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released.
Page 206 Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC WITH ROLL STABILITY CONTROL (RSC) STABILITY ENHANCEMENT SYSTEM (IF EQUIPPED) The AdvanceTrac system provides a stability enhancement feature as well as a traction enhancement feature.
Page 207 Driving Driving conditions which may activate AdvanceTrac include: • Taking a turn too fast. • Maneuvering quickly to avoid an accident, pedestrian or obstacle. • Hitting a patch of ice. • Changing lanes on a snow-rutted road. • Entering a snow-free road from a snow-covered side street, or vice versa.
Page 208 Driving warning indicator light in the instrument cluster remains on while the engine is running, have the system serviced immediately. Pressing the control once will disable the AdvanceTrac stability enhancement/Roll Stability Control and the engine power reduction portion of the traction enhancement feature; the brake portion of the traction enhancement feature will still function normally.
Page 209 Driving STEERING To prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than a few seconds when the engine is running. • Do not operate the vehicle with a low power steering pump reservoir fluid level (below the MIN mark on the reservoir).
Page 210: Transmission Operation
Driving Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles. Extra precautions such as slower speeds and increased stopping distance should be taken when driving a heavily loaded vehicle. AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.
Page 211 Driving 3. Remove the access plug with a flat head screwdriver (or similar tool). 4. Insert a tool (or screwdriver) into the access hole to override the brake-shift interlock. Apply the brake and shift into Neutral. 5. Return the cover plug to the access hole. Start the vehicle. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly.
Page 212 Driving Driving with a 5–speed automatic transmission This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
Page 213 Driving D (Drive) with Overdrive The normal driving position for the best fuel economy. Transmission operates in gears one through five. D (Drive) without Overdrive Overdrive can be deactivated by pressing the transmission control switch on the end of the gearshift lever.
Page 214 Driving Forced downshifts • Allowed in D (Overdrive) or Drive. • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. If your vehicle gets stuck in mud or snow If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern.
Page 215 Driving Certain add-on devices such as large trailer hitches, bike or surfboard racks and any device that may block the normal detection zone of the RSS system may create false beeps. The RSS detects obstacles up to six feet (two meters) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for...
Page 216 Driving If your vehicle sustains damage to the rear bumper/fascia, leaving it misaligned or bent, the sensing zone may be altered causing inaccurate measurement of obstacles or false alarms. LIMITED-SLIP AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface.
Page 217 Driving Using the Control Trac 4WD system 4X4 AUTO - Power to all four wheels; used for normal street and highway driving. 4X4 HIGH (4WD High) - Used for extra traction such as in snow or icy roads or in off-road situations. Not intended for use on dry pavement. 4X4 LOW (4WD Low) - Uses extra gearing to provide maximum power to all four wheels.
Page 218 Driving 4. Press the desired 4WD position. • If shifting into 4X4 LOW (4WD Low), wait for the 4X4 LOW light in the instrument cluster to turn on indicating the shift is complete. • If shifting out of 4X4 LOW (4WD Low), wait for the 4X4 LOW light in the instrument cluster to turn off indicating the shift is complete.
Page 219 Driving pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface. • It may be safer to stay on the apron or shoulder of the road and slow down gradually before returning to the pavement. You may lose control if you do not slow down or if you turn the steering wheel too sharply or abruptly.
Page 220 Driving not more. Additionally, smooth variations of the accelerator and/or brake pedal pressure should be utilized if changes in vehicle speed are called for. Avoid abrupt steering, acceleration or braking which could result in an increased risk of loss of vehicle control, vehicle rollover and/or personal injury.
Page 221 Driving 4WD Systems 4WD uses all four wheels to power the vehicle. This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. Power is supplied to all four wheels through a transfer case. On 4WD vehicles, the transfer case allows you to select 4WD when necessary.
Page 222 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 223 Driving possibly rolling over. Whenever driving on a hill, determine beforehand the route you will use. Do not drive over the crest of a hill without seeing what conditions are on the other side. Do not drive in reverse over a hill without the aid of an observer. When climbing a steep slope or hill, start in a lower gear rather than downshifting to a lower gear from a...
Page 224 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 225 Driving Failure to maintain your vehicle properly may void the warranty, increase your repair cost, reduce vehicle performance and operational capabilities and adversely affect driver and passenger safety. Frequent inspection of vehicle chassis components is recommended if the vehicle is subjected to heavy off-road usage.
Page 226: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 227: Fuel Pump Shut-Off Switch
Roadside Emergencies Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.
Page 228: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 229 Roadside Emergencies Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color COLOR Fuse Standard Cartridge...
Page 230: Passenger Compartment Fuse Panel
Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below the instrument panel on the driver’s side. To remove a fuse use the fuse puller tool provided on the fuse panel box. 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 231 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Memory seat module, Driver power seat, Driver power lumbar Moonroof Radio, Amplifier, DVD Front wiper module Flasher relay (Turn, hazards) Key-in-chime Heated mirrors Heated PCV (4.0L engine only) Not used Heated backlight relay coil, A/C...
Page 232 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Not used Cigar lighter, OBD II, Neutral tow Mode-Temperature actuator for auxiliary climate control, Trailer tow battery charge relay coil, TPMS 7.5A Reverse park aid, Brake shift interlock, IVD switch 7.5A Automatic dimming mirror, Digital transmission range sensor, Backup...
Page 233 Roadside Emergencies Passenger compartment fuse panel (top side) These relays are located on the reverse side of the passenger compartment fuse panel. See your dealer or a certified technician for service of this relay box. Fuse/Relay Location Description Relay 1 Flasher Relay 2 Rear defrost...
Page 234: Power Distribution Box
Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 235 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 60A** PJB #1 30A** — Not used 30A** Rear defrost 40A** Anti-lock Brake System (ABS) pump 60A** Delayed accessory, Power windows, Audio 20A** Power point #2 30A**...
Page 236 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating Two-speed 4x4 (relay coils) 20A* PCM with two-speed 4x4 clutch 20A** High beam relay 30A** Trailer electric brake module 30A** Front wiper motor 20A** Low beam, Autolamp 30A** Ignition switch, PCM diode —...
Page 237 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating Brake pressure switch (non-AdvanceTrac vehicles) 20A* High beams — Horn relay — Fuel pump relay — High beam relay — Front foglamps relay — DRL relay (Canada) — A/C clutch relay —...
Page 238 Roadside Emergencies The relays are coded as follows: Fuse/Relay Location Description Relay 14 Not used Relay 15 Trailer tow back-up lamps Relay 16 Not used Relay 17 Not used Relay 18 Not used Relay 19 Trailer tow park lamps Relay 20 Trailer tow battery charge Relay 21 Not used...
Page 239: Jump Starting
Roadside Emergencies Auxiliary relay box (Vehicles equipped with 4x4) The relay box is located on the front right fender well. The relays are coded as follows: Fuse/Relay Location Description Relay 64 Two-speed 4x4 motor clockwise Relay 65 Two-speed 4x4 motor counterclockwise Relay 66 Open JUMP STARTING YOUR VEHICLE...
Page 240 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 241 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 242 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 243 Roadside Emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 244 Roadside Emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 245: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If the vehicle’s battery is discharged, refer to Automatic transmission operation in the Driving chapter for directions on how to move the gearshift lever out of the P (Park) position, for proper towing.
Page 246: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 247 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 248 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
Page 249 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
Page 250 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 251 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 252 4,600 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this 2005 Explorer (exp)
Page 253 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 254: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 255: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 256 Cleaning racks, bumpers, side moldings, mirror housings or the windshield cowl area. The paint sealant will “gray” or stain the parts over time. PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jamb) to your dealer to ensure you get the correct color.
Page 257 Cleaning • Cover the highlighted areas to prevent water damage when cleaning the engine. 4.0L SOHC V6 Engine 4.6L V8 Engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts.
Page 258 Cleaning • For routine cleaning, use Motorcraft Detail Wash (ZC-3–A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42). WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly.
Page 259 Cleaning • Do not use household or glass cleaners as these may damage the finish. INTERIOR For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Motorcraft Professional Strength Carpet &...
Page 260 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 261: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS • Use the scheduled maintenance information to track routine service. • Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. • Your dealership can provide parts and service. PRECAUTIONS WHEN SERVICING YOUR VEHICLE •...
Page 262 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
Page 263: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Engine coolant reservoir 2. Engine oil filler cap 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Power distribution box 6. Battery 7. Engine oil dipstick 8.
Page 264 Maintenance and Specifications 4.6L V8 engine 1. Engine coolant reservoir 2. Engine oil dipstick 3. Brake fluid reservoir 4. Power distribution box 5. Battery 6. Power steering fluid reservoir 7. Engine oil filler cap 8. Air filter assembly 9. Windshield washer fluid reservoir 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 265: Engine Oil
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications later in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 266 Maintenance and Specifications 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). • 4.0L V6 engine 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 267 Maintenance and Specifications • 4.6L V8 engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable, DO NOT ADD OIL. •...
Page 268 Maintenance and Specifications • 4.6L V8 engine • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
Page 269 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 270 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 271: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to scheduled maintenance information for the service interval schedules.
Page 272 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 273: Engine Coolant
Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 274 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 275 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA, OR and NM), VC-7–B (CA, OR and NM), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 276 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 277 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section.
Page 278 Maintenance and Specifications What you should know about fail-safe cooling (4.6L V8 engine only) If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 279 Maintenance and Specifications Never remove the coolant reservoir cap while the engine is running or hot. 5. Restart the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible.
Page 280 Maintenance and Specifications • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 281 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 282 Maintenance and Specifications Octane recommendations Do not be concerned if your engine sometimes knocks lightly. However, if it knocks heavily under most driving conditions while you are (R+M)/2 METHOD using fuel with the recommended octane rating, see your dealer or a qualified service technician to prevent any engine damage.
Page 283 10 to 30 seconds. If the problems persist below this temperature, see your dealer or a qualified service technician. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 284 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 285 Maintenance and Specifications Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill capacities section of this chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 286 Maintenance and Specifications 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading. 4. Subtract your initial odometer reading from the current odometer reading. 5. Follow one of the simple calculations in order to determine fuel economy: Calculation 1: Divide total miles traveled by total gallons used.
Page 287 Maintenance and Specifications • Resting your foot on the brake pedal while driving may reduce fuel economy. • Combine errands and minimize stop-and-go driving. Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy.
Page 288 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 289 Maintenance and Specifications permitted to intentionally remove an emission control device or prevent it from working. Information about your vehicle’s emission system is on the Vehicle Emission Control Information Decal located on or near the engine. This decal identifies engine displacement and gives some tune up specifications.
Page 290 Maintenance and Specifications If the vehicle’s powertrain system or its battery has just been serviced, the on-board diagnostics system is reset to a “not ready for I/M test” condition. To ready the on-board diagnostics system for I/M testing, a minimum of 30 minutes of city and highway driving is necessary as described below: •...
Page 291 Maintenance and Specifications 2. While the engine idles, turn the steering wheel left and right several times. 3. Turn the engine off. 4. Check the fluid level in the reservoir. 5. The fluid level should be between the MIN and MAX lines. Do not add fluid if the level is in this range.
Page 292: Air Filter(S)
Maintenance and Specifications AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft part numbers in this chapter. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 293 Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 294: Part Numbers
Refer to scheduled maintenance information for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 295: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft High Fill to line on Performance reservoir DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft SAE 4.0L 5.0 quarts (including filter 5W-30 Premium (4.7L) change)
Page 296 Maintenance and Specifications Fluid Ford Part Application Capacity Name Engine coolant Motorcraft 4.0L SOHC V6 16.3 quarts Premium Gold engine without (15.4L) Engine Coolant auxiliary climate (yellow-colored) control 4.0L SOHC V6 18.2 quarts engine with (17.2L) auxiliary climate control 4.6L V8 engine 18.6 quarts...
Page 297: Lubricant Specifications
Modifier XL-3 or equivalent to the rear axle whenever the axle has been serviced. Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only have the API Certification mark and meet the requirements of Ford specification WSS-M2C929-A (4.0L) or WSS-M2C930-A (4.6L). LUBRICANT SPECIFICATIONS Ford Part Ford Part...
Page 298 Maintenance and Specifications Ford Part Ford Part Ford Item Name or Number Specification equivalent Engine coolant Motorcraft VC-7-A (U.S., WSS- Premium Gold except CA, OR M97B51-A1 Engine Coolant and NM), (yellow-colored) VC-7-B (CA, OR and NM) Motorcraft SAE 5W-30 Premium...
Page 299 Maintenance and Specifications Ford Part Ford Part Ford Item Name or Number Specification equivalent Motorcraft SAE Front axle 80W-90 XY-80W90-QL WSP-M2C197-A (4X4) Premium Rear Axle Lubricant Motorcraft Transfer case MERCON XT-2-QDX MERCON (4X4) Multi-Purpose Transfer case Premium XG-1-C or Front Output...
Page 300 Maintenance and Specifications Engine 4.0L SOHC V6 4.6L V8 engine engine Spark plug gap 0.051–0.056 inch 0.052–0.056 inch (1.32–1.42mm) (1.32–1.42 mm) Compression ratio 9.7:1 9.4:1 VEHICLE DIMENSIONS Dimensions 4-Door 4x2 or 4x4 XLT Model - Inches (mm) (1) Overall length 191.6 (4866.7) (2) Overall width 73.7 (1870.9)
Page 301 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure by the trailing edge of the driver’s door or...
Page 302 Maintenance and Specifications Vehicle identification number The vehicle identification number (VIN) is a 17 digit combination of letters and numbers. The VIN is XXXXXXXXXXXXXXXXX attached to a metal tag and is located on the driver side instrument panel. The VIN number is also found on the Certification label.
Page 303 Maintenance and Specifications Transmission/Transaxle code designations You can find a transmission/transaxle code on the Safety Compliance Certification Label . The following table tells you which transmission or transaxle each code represents. Code Description Five-speed automatic (5R55S) 2005 Explorer (exp) Owners Guide (post-2002-fmt) USA (fus)
Page 304: Accessories
In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
Page 305 Accessories Interior style Electrochromatic compass/temperature interior mirrors Floor mats Leather wrapped steering wheels Scuff plates Lifestyle Bike racks Cargo organization and management Rear seat entertainment systems Towing mirrors Trailer hitches, wiring harnesses and accessories Peace of mind First aid and highway safety kits Full vehicle covers Locking gas cap Navigation systems...
Page 306 Accessories • To avoid interference with other vehicle functions, such as anti-lock braking systems, amateur radio users who install radios and antennas onto their vehicle should not locate the Amateur Radio Antennas in the area of the driver’s side hood. •...
Page 307: Index
Index jumping a disabled battery ..239 maintenance-free ....271 replacement, specifications ...294 Accessory delay ......70 servicing ........271 AdvanceTrac ......206 BeltMinder .........131 Air cleaner filter ....292, 294 Brakes ........203 Air conditioning ......48 anti-lock ........204 Airbag supplemental restraint anti-lock brake system (ABS) system ........135, 139 warning light ......204 and child safety seats ....137 fluid, checking and adding ..291...
Page 308 ....277, 295 specifications ....297, 299 DVD system .........44 Cruise control (see Speed control) ....72 Customer Assistance ....226 Electronic message center ..83 Ford Extended Service Emergencies, roadside Plan ..........252 jump-starting ......239 Getting assistance outside the U.S. and Canada ....253 Emergency Flashers ....227 Getting roadside assistance ...226...
Page 309 Index service points ....263–264 safety information relating to starting after a collision ..227 automotive fuels .....279 Engine block heater ....203 Fuel - flex fuel vehicle (FFV) .........281–282 Engine oil ........265 checking and adding ....265 Fuses ........228, 230 dipstick ........265 filter, specifications ..269, 294 recommendations ....269 refill capacities ......295 Garage door opener ....67...
Page 310 Index Hood ..........262 Loading instructions ....193 Locks autolock ........106 childproof ........99 Ignition .......200, 299–300 doors ..........98 Infant seats Lubricant specifications ...297, 299 (see Safety seats) .....146 Lug nuts ........172 Inspection/maintenance (I/M) Luggage rack .......97 testing ........289 Lumbar support, Instrument panel cleaning ........258 seats ......113, 115–116 cluster ........10...
Page 311 Index Power distribution box safety belt maintenance ..134 (see Fuses) .......234 warning light and chime .......130–131 Power door locks ......98 Power mirrors ......70 Safety seats for children ..146 Power point ......68–69 Safety Compliance Power steering ......209 Certification Label ....301 fluid, checking and adding ..290 Seat belts fluid, refill capacity ....295 (see Safety restraints) .....122...
Page 312 Index Tire Pressure Monitoring fluid, checking and adding System (TPMS) (automatic) ......291 Driving ........221 fluid, refill capacities ....295 Maintenance and lubricant specifications ..297, 299 Specifications ......182 Trunk .........101 Roadside Emergencies ...164 Turn signal ........57 Warning Displays ....14, 90 Tires ......158–159, 164 alignment ........179 care ..........178 Vehicle dimensions ....300...

Ford Explorer 2005 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Quick Links

Table of Contents

Related Manuals for Ford Explorer 2005

Summary of Contents for Ford Explorer 2005

Table of Contents
