Pride Luna Victory Owner's Manual

Luna victory series
Hide thumbs

Advertisement

Table of Contents

LUNA VICTORY
SERIES
Including Models: Luna Victory and Luna Victory E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Luna Victory and is the answer not in the manual?

Questions and answers

Related Manuals for Pride Luna Victory

Summary of Contents for Pride Luna Victory

  • Page 1 LUNA VICTORY SERIES Including Models: Luna Victory and Luna Victory E...
  • Page 2 NTENDED The intended use of the Pride Mobility Products device is to provide mobility to persons limited to a seated position that have the capability of operating a scooter. Please fill out the following information for quick reference:...

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S INTRODUCTION ........................4 SAFETY ............................5 III. YOUR SCOOTER ........................21 IV. BATTERIES AND CHARGING ..................25 OPERATION ..........................30 VI. COMFORT ADJUSTMENTS ....................32 VII. DISASSEMBLY AND ASSEMBLY ...................35 VIII.BASIC TROUBLESHOOTING ...................37 IX. CARE AND MAINTENANCE ....................40 WARRANTY ..........................44 Luna Victory Series www.pridemobility.com...

  • Page 4: Introduction

    Pride to enhance or preserve the safe use of this product.
  • Page 5 Corrosive chemicals contained in battery. EMI/RFI - This product has been tested and passed at an immunity level of 20 V/m. Explosive conditions exist! Indicates electrical shock hazard. Pinch/Crush points created during assembly. Maximum seating weight. Luna Victory Series www.pridemobility.com...
  • Page 6 Contains sealed, non-spillable batteries that meet DOT CRF 173.159 (d), IATA packing instructions 806, IATA provision A67 for safe transportation. Do not remove anti-tip wheels. Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while operating. www.pridemobility.com Luna Victory Series...
  • Page 7 Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and new batteries. Always replace both batteries at the same time. Keep your hands away from the tires when driving. Be aware that loose fitting clothing can become caught in drive tires. Luna Victory Series www.pridemobility.com...
  • Page 8 Battery charger for indoor use only. Disposal and recycling - Contact your authorized Pride Provider for information on proper disposal and recycling of your Pride product and its packaging. Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive conditions.
  • Page 9 125A/50V Connect Red wires to Red Positive (+) Terminal Post. Connect Black wire to Black Negative (-) Terminal Posts. Indicates tie-down points on the scooter. Keep area clean. Manufactured in Keep area dry. Scooter information label. Luna Victory Series www.pridemobility.com...
  • Page 10 PRE-RIDE SAFETY CHECK Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check before each use to make sure your scooter operates smoothly and safely.
  • Page 11 MANDATORY! Stay within the specified weight capacity for your scooter. Exceeding the weight capacity voids your warranty. Pride will not be held responsible for injuries and/ or property damage resulting from failure to observe weight limitations.
  • Page 12 WARNING! Never carry an oxygen tank weighing more than 6,8 kg (15 lbs). Never fill the front or rear basket with contents exceeding 6,8 kg (15 lbs). www.pridemobility.com Luna Victory Series...
  • Page 13 Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/stop position. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when power is removed from the system for any reason. Luna Victory Series www.pridemobility.com...
  • Page 14 Your scooter is designed to provide optimum stability under normal driving conditions—dry, level sur- faces composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encounter other surface types. For this reason, your scooter is designed to perform admirably on packed soil, grass, and gravel.

  • Page 15: Your Scooter

    This prevents the scooter from gaining unwanted momentum should the manual freewheel lever inadvertently be released while driving the scooter. WARNING! Pride recommends that you do not disconnect the batteries when the scooter is in freewheel mode as this may interfere with the function of the controller.
  • Page 16 If you will be transporting your scooter during travel, you may find it necessary to use a vehicle-mounted lift system or elevation product to aid in transportation. Pride recommends that you closely review the warnings, instructions, specifications, and safety information set forth by the manufacturer of the lift/ elevation product before using that product.
  • Page 17 MOTOR VEHICLE TRANSPORT Pride recommends that you do not remain seated in your scooter while traveling in a motor vehicle. The scooter should be stowed in the trunk of a car or in the back of a truck or van with the batteries removed and/or properly secured.
  • Page 18 WARNING! Do not operate your scooter while you are under the influence of alcohol, as this may impair your ability to drive safely. WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in your scooter, although the scooter has passed the necessary testing requirements for cigarette smoking.
  • Page 19 WARNING! The addition of accessories or components to the electrically-powered mobility vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your scooter in any way not authorized by Pride. WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other electrical devices located nearby, such as alarm systems.
  • Page 20 I I I . Y O U R S C O O T E R TILLER CONSOLE The tiller console houses all of the controls needed to drive your scooter. On the Luna Victory model, the controls include the LCD control panel, handbrake lever, tiller adjustment lever, and the throttle control lever.
  • Page 21 Hazard Lights Switch This switch activates the 4-way flashers on your scooter. Toggle the hazard lights switch forward to turn on the flashers. Toggle the hazard lights switch rearward to turn off the flashers. Luna Victory Series www.pridemobility.com...
  • Page 22 OFF-BOARD engage and your scooter will come CHARGER PORT to an abrupt stop! NOTE: The key switch on the Luna Victory model is mounted on the tiller. See figure 6. Tiller Adjustment Lever Figure 6. Off-board Charger Port (Tiller Mounted) See VI.
  • Page 23 PROHIBITED! Do not remove the anti-tip wheels or modify your scooter in any way that is not authorized by Pride. WARNING! The anti-tip wheels may cause interference with the smooth transition of your Travel Scooter when ascending or descending a curb. Contact your authorized Pride Dealer for more information. Motor/Transaxle Assembly The motor/transaxle assembly is an electromechanical unit that converts electrical energy from your scooter’s batteries into the controlled mechanical energy that drives the scooter’s wheels.
  • Page 24 If the breaker trips frequently, you may need to charge the batteries more often or have your authorized Pride Provider perform a load test on the batteries. If the main circuit breaker trips repeatedly, see your authorized Pride Provider for service. SECURING THE SCOOTER Always secure the scooter in a forward-facing position in the vehicle.

  • Page 25: Batteries And Charging

    Do not use an automotive-type battery charger. WARNING! Inspect the battery charger, wiring, and connectors for damage before each use. Contact your authorized Pride Provider if damage is found. WARNING! Do not attempt to open the battery charger case. If the battery charger does not appear to be working correctly, contact your authorized Pride Provider.
  • Page 26 For the safest and most efficient charging of your scooter’s batteries we recommend only use of the charger supplied as original equipment with your Pride product. Any charging method resulting in batteries being charged individually is especially prohibited.
  • Page 27 Do not use wet-cell batteries, which have removable caps. WARNING! Corrosive chemicals are contained in batteries. Use only AGM or Gel- Cell batteries to reduce the risk of leakage or explosive conditions. NOTE: Sealed batteries are not serviceable. Do not remove the caps. Luna Victory Series www.pridemobility.com...
  • Page 28 WARNING! Do not mix old and new batteries. Always replace both batteries at the same time. WARNING! Contact your authorized Pride Provider if you have any questions regarding the batteries in your scooter. WARNING! Do not replace the batteries while the scooter is occupied.
  • Page 29 NOTE: If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag. Contact your local waste disposal agency or your authorized Pride Provider for instructions on disposal and battery recycling, which is our recommended course of action.

  • Page 30: Operation

    Push or pull the appropriate side of the throttle control lever. The electromechanical disc park brake automatically disengages and the scooter accelerates smoothly to the speed you preselected with the speed adjustment dial. Pull on the left handgrip to steer your scooter to the left. www.pridemobility.com Luna Victory Series...
  • Page 31 Although the controller is shut down, power will still be supplied to the scooter’s lighting system. If the power down timer feature takes effect, perform the following steps to resume normal operation: 1. Remove the key from the key switch. 2. Reinsert the key and power up your scooter. Luna Victory Series www.pridemobility.com...

  • Page 32: Comfort Adjustments

    LEVER forward or rearward to adjust the seatback angle. 2. Release the seatback adjustment lever once the seat is in a comfortable riding position. Figure 18. Seatback Adjustment www.pridemobility.com Luna Victory Series...
  • Page 33 LOCATING posts. HOLE 6. Reinstall the nut onto the seat height adjustment bolt and tighten. 7. Reinstall the rear shroud and the seat. SEAT HEIGHT ADJUSTMENT LOWER BOLT SEAT POST Figure 21. Seat Height Adjustment Luna Victory Series www.pridemobility.com...
  • Page 34 MANDATORY! Inspect the positioning belt for loose or damaged parts before each use of the scooter. If you discover a problem, contact your authorized Pride Provider maintenance and repair. www.pridemobility.com Luna Victory Series...

  • Page 35: Disassembly And Assembly

    See figure 27. WARNING! Failure to unplug both battery harnesses and the front- to-rear harness prior to separating the front and rear sections could result in permanent damage to the scooter. Luna Victory Series www.pridemobility.com...
  • Page 36 7. Reinstall the batteries to the battery wells. STRAP 8 Connect both battery harnesses. See figure 24. 9. Secure the battery tie-down strap. 10. Reinstall the battery shroud. 11. Reinstall the seat and rotate it into place. BATTERY SPACERS Figure 27. Battery Spacers www.pridemobility.com Luna Victory Series...
  • Page 37 DIAGNOSTIC FAULT CODES - LUNA VICTORY The diagnostic fault codes for your scooter are designed to help you perform basic troubleshooting quickly and easily.
  • Page 38 V I I I . B A S I C T R O U B L E S H O O T I N G DIAGNOSTIC FAULT CODES - LUNA VICTORY E The diagnostic fault codes for your scooter are designed to help you perform basic troubleshooting quickly and easily.
  • Page 39 If the main circuit breaker trips repeatedly, see your authorized Pride Provider for service. Charge the batteries more frequently. See IV. “Batteries and Charging.” If the problem continues, have both of your scooter’s batteries load tested by your authorized Pride Provider.

  • Page 40: Care And Maintenance

    Your scooter requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you may schedule inspection and maintenance at your authorized Pride Provider. The following areas require periodic inspection and/or care and maintenance. TIRE PRESSURE If equipped with pneumatic tires, always maintain the psi/bar/kPa air pressure rating indicated on each tire.
  • Page 41 If your scooter is equipped with a solid tire insert, either the solid insert or the entire wheel must be replaced depending on the model. Contact your authorized Pride Provider for information regarding replacement wheels for your scooter. WARNING!
  • Page 42 The brake pads on your scooter should be inspected periodicly for wear. Once the pads reach 2 mm or 1/8-th of an inch in thickness, they should be replaced. All brake pads should be replaced at the same time. Contact your authorized Pride Provider for more information on replacing the brake pads. NYLON LOCK NUT REPLACEMENT Any nylon insert lock nut removed during the periodic maintenance, assembly, or disassembly of the scooter must be replaced with a new nut.
  • Page 43 Your scooter must be disposed of according to applicable local and national statutory regulations. Contact your local waste disposal agency or authorized Pride Provider for information on proper disposal of packaging, metal frame components, plastic components, electronics, batteries, neoprene, silicone, and polyurethane materials.

  • Page 44: Warranty

    (tires, belts, bulbs, upholstery, plastic shrouds, motor brushes, fuses, and batteries), or damage to the prod- uct caused by misuse or accident for which Pride or its agent cannot be held responsible. This warranty does not include labor or service calls.
  • Page 45 N O T E S Luna Victory Series www.pridemobility.com...
  • Page 46 N O T E S www.pridemobility.com Luna Victory Series...
  • Page 48 *INFMANU4145*...
